SIMM Removal

If the SIMM configuration requires the removal of a SIMM, remove the SIMM as follows.
Press the metal clips at the outer edges of the socket away from the SIMM.
1.
Push the SIMM away from the locking tabs and remove it from the socket.
2.

SIMM Installation

Remove the system unit side panel (see "Removing the Side Panel").
1.
Locate the correct SIMM sockets for the desired configuration (see Figure 3-2).
2.
If you need to remove a currently installed SIMM, see "SIMM Removal."
Align the notched end of the SIMM with the socket end closest to the bottom of
3.
the system.
Insert the SIMM at an angle into the socket.
4.
CAUTION: Reduce static discharge by touching
the system's metal chassis.
Figure 3-6 Removing a SIMM
CAUTION: Before you install a SIMM, reduce
static discharge by touching the system's metal
chassis.
Option Installation
Clips
3-11
