2-16
Setup and Operation
To display a submenu, use the arrow keys to move the cursor to the submenu you want.
Then press
Enter
.
Main Menu
The following subheadings describe the parameters available from the Main Menu. Other
Main Menu parameters are available by selecting submenus.
Use the arrow keys to move the cursor to parameter and press
Items with lighter text are not available.
System Date/Time
Use this menu to set the current time and date. The settings remain in memory even after
you turn off the system power.
To set the date, enter the current day, month, and year in dd/mm/yyyy format.
To set the time, enter the current hour, minute, and seconds in hh:mm:ss, 24-hour format.
To example, type 13:30:00 for 1:30 P.M.
Diskette Drive
This menu selects the type of diskette drive in your system. Unless you are changing your
hardware, you do not need to change the diskette drive (floppy) A or B settings.
If you add an optional 5 1/4-inch diskette drive to your system, select "Floppy B" and
change the parameter to "1.2 MB, 5.25".
Hard Disk
The "Hard Disk C:" through "Hard Disk F:" field reports the presence of, and identification
string reported by, up to four physical IDE drives (two on each PCI/IDE connector). When
the cursor is placed on one of these fields and it is selected by pressing the Enter key. The
Hard Disk Submenu appears (see the following table) allowing parameters the drive
parameters to be set.
NOTE: See How to Start Setup for a look at a
typical Main menu screen.
Enter
to select a submenu.
