SMC Networks SMC8612XL3 Technical Specifications

OVERVIEW
The TigerSwitch™ 1000, SMC8612XL3, performs Layer 2 switching and IP-based Layer 3 routing in the
same box. It includes 12 SFP 1000BASE-X ports, including 4 1000BASE-T combo ports. The TigerSwitch is
designed to integrate distant network subnets and VLANs seamlessly, augmenting or completely replac-
ing slow legacy routers, and providing the required throughput for today's web-based intranet traffic flow.
The SMC8612XL3's application is versatile and flexible. It features: GMRP and IGMP to maintain available
bandwidth by limiting multicast packet transmissions to subscribers only; OSPF, DVMRP multicast routing to
significantly conserve bandwidth by minimizing packet replication across the network; QoS and Layer 2/3/4
Class Of Service to ensure a minimum delay for real-time multimedia data across the network, while port-
based and tagged VLANs with support for GVRP are also included to provide traffic security and efficient
use of network bandwidth. With a host of advance features and comprehensive management capabilities,
this device is a strong solution for the network core with the flexibility to be integrated into existing network
infrastructure. VLANs with IEEE802.1Q, 1s, and private, and of course, IGMP for today's multimedia applica-
tions. Also included are features such as RADIUS client enhancement for 802.1x, TACACS+, SSH, SSL, Ac-
cess Control List (ACL) to address today's concerns regarding security.
KEY FEATURES
Flexible IP Routing
Supports both Unicast and Multicast Routing for maximum effi-
ciency on the campus LAN network.
12 SFP ports including 4 combo ports
Offers a wide range of support for different fiber types supported
by SFPs with capacity for trunked copper connections for higher
capacity connections to the backbone.
APPLICATION DIAGRAM
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
SMC8612XL3
TigerSwitch™ 1000 Standalone L3 Managed 12 SFP Port Gigabit Switch
Small Form factor
Standard 19" rack mountable solution with shallow depth for flex-
ible installation options.
Supports up to 4K VLANs*
For applications on campus networks large numbers of VLANs are
often required. The SMC8612XL3 supports up to 4K VLANs for a
variety of installation options.
www.smc.com
POWER TO CONNECT
