- Page 1 EM-422 2-Slot XFP 10Gigabit Module User’s Guide Version 1.00 7/2007 Edition 1 Copyright © 2007. All rights reserved...
-
Page 2: Table Of Contents
EM-422 User’s Guide Overview The EM-422 is an uplink module with two slots for XFP (10- Gigabit Small Form Factor Pluggable) transceivers. It is designed for use with high-speed switches, such as the XGS- 4528F. After installing the EM-422 in a switch, the switch can have 10 Gigabit connections to a backbone switch or other network devices. -
Page 3: Hardware
EM-422 User’s Guide 1 Hardware Installation Follow these steps to install the EM-422 in a switch. Modules are NOT hot swappable! 1 Turn off your switch and unplug all power supply cords (including any backup power supply cords) from the switch. - Page 4 5 Secure it to the switch with the retaining screws. 6 Turn on the switch. The switch automatically detects the installed EM-422. Connect any necessary network cables to the EM-422 and check the LEDs to verify that it is functioning properly.
-
Page 5: Transceiver
1 Insert the transceiver into the slot with the exposed section of PCB board facing down. 2 Press the transceiver firmly until it clicks into place. 3 The EM-422 automatically detects the installed transceiver. Check the LEDs to verify that it is functioning properly. -
Page 6: Transceiver
EM-422 User’s Guide The following table describes the LEDs on the EM-422 panel. Color Status Description LNK/ Blue The port is connected to an Ethernet device. Blinking The port is transmitting or receiving data. The port is not connected to an Ethernet device. -
Page 7: Troubleshooting
None of the lights turn on after I install the EM- 422 and connect it to a network device. • Make sure the EM-422 is properly installed in a switch. • Make sure that you are using the XFP transceivers to con- nect the EM-422 to other device(s). -
Page 8: Safety Warnings
EM-422 User’s Guide Feature Specification Switching • Maximum frame size: 1522 bytes including tag/ • Store and forward Approvals FCC Part 15 of Class A & CE 7 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. -
Page 9: Legal Information
EM-422 User’s Guide • This product is recyclable. Dispose of it properly. 8 Legal Information Certifications Federal Communications Commission (FCC) Interference Statement This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. - Page 10 PRODUIT CONFORME SELON 21 CFR 1040.10 ET 1040.11. Viewing Certifications 1 Go to http://www.zyxel.com. 2 Select your product on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. ZyXEL Limited Warranty...
- Page 11 This warranty is in lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular use or purpose. ZyXEL shall in no event be held liable for indirect or consequential damages of any kind to the purchaser.
- Page 12 Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others. ZyXEL further reserves the right to make changes in any products described herein without notice.
