Toolbar commands include Scan Frame, Zoom, Pan, and Pickers.
Windows Macintosh

Scan Frame tool

The Scan Frame lets you create a single scan frame or multiple scan
frames in the preview image, which is the active area on which controls and
commands can be applied.
The Scan Frame can also be used to create batch scans. The current scan
frame is indicated by a marquee (cascading border). The current scan
frame can be more easily distinguished if you turn on the Smoked Glass
Background command (in the Preferences menu).

Zoom tool

The Zoom tool enlarges your view of the preview image, allowing you to
set the scan frame with greater precision if you need to. Only your view of
the preview image is changed; the actual output size of the image remains
unaffected.
Each click of the Zoom tool magnifies or reduces image view by a factor of
2. Thus, the magnification levels increase from 100% to 200%, to 400%,
and to the maximum of 800%.
Note: If the Info window is open, the zoom level will be indicated. This
means you can also zoom in by selecting the appropriate zoom level in the
Info window.
Pan tool
The Pan tool lets you scroll through a preview image, allowing you to move
parts of the image into view.
Scan Frame
Zoom
Pan
Pickers
