WORLD TIME
World Time shows the current time in 50 cities (27 time zones) around the world.
• All of the operations in this section are performed in the World Time Mode, which
you enter by pressing C.
To view the time in another city code
In the World Time Mode, press D to scroll forward through the city codes.
NOC Code
City code
Mode
indicator
NOC code
• Selecting a city code causes the NOC code screen to appear first, followed a short
time later by the time screen.
• NOC codes are the abbreviations designating the National Olympic Committee for
each geographic area (as of December 2000).
• For full information about city codes, see the "CITY CODE TABLE".
• If the current time shown for a city is wrong, check your Timekeeping Mode time and
Home City code settings and make the necessary changes.
To toggle World Time Mode times between standard time and Daylight Saving Time
In the World Time Mode, hold down A for about two
seconds to toggle between Daylight Saving Time (DST
displayed) and standard time (DST not displayed).
• The above operation toggles all World Time city codes
between Daylight Saving Time and standard time. Note
that you cannot make settings for individual city codes.
DATA BANK MODE
The Data Bank Mode lets you store up to 30 records,
Name
each containing name and telephone number data.
Records are automatically sorted based on the characters
of the name. You can recall records by scrolling through
them on the display.
• See "CHARACTER LIST" for details on how the watch
sorts records.
• All of the operations in this section are performed in the
Mode indicator
Data Bank Mode, which you enter by pressing C.
Telephone number
Remaining memory
To create a new Data Bank record
1. In the Data Bank Mode, press B and D at the same
Name area
time to display the remaining memory screen.
• If the message "FULL" appears on the display, it
means that memory is full. To store another record,
you will first have to delete some of the records stored
in memory.
2. Hold down A until the flashing cursor (
the name area of the display, which indicates the
setting screen.
3. Use D and B to change the character at the cursor
position in the name area. The character changes in the
Number area
following sequence.
Press
.
(space)
4. When the character you want is at the cursor position, press C to move the cursor
to the right.
5. Repeat steps 3 and 4 until the name is complete.
• You can input up to eight characters for the name.
6. After you input the name, press C as many times as necessary to move the cursor
to the number area.
• When the cursor is located at the eighth space of the name area, moving the
cursor to the right causes it to jump to the first digit of the number. When the
cursor is at the 16th digit of the number, moving it to the right (by pressing C)
causes it to jump to the first character in the name.
7. Use D and B to change the character (hyphen, number, space, or plus) at the
cursor position in the number area. The character changes in the following
sequence.
Press
.
0 to 9
Press
.
8. When the character you want is at the cursor position, press C to move the cursor
to the right.
9. Repeat steps 7 and 8 until you complete number input.
• You can input up to 16 digits for the number.
10. Press A to store your data and return to the Data Bank record screen (without
the cursor).
• When you press A to store data, the message "SORT" appears on the display for
a while, indicating that data is being sorted. After the sort operation is complete, the
Data Bank record screen appears.
Time
Current time in the zone of the selected city code
) appears in
Press
.
A to Z
0 to 9
(space)
To recall Data Bank records
In the Data Bank Mode, press D to scroll forward through Data Bank records on the
display.
• The name and/or telephone number of the selected Data Bank record scrolls on the
Data Bank record screen. The symbol
telephone number follows next.
• Each press of A in the Data Bank Mode changes the scroll operation as shown
below.
Name scrolls
Name stops
Number scrolls
Number scrolls
To edit a Data Bank record
1. In the Data Bank Mode, scroll through the records and display the one you want to
edit.
2. Hold down A until the flashing cursor appears on the display.
3. Use C to move the flashing to the character you want to change.
4. Use D and B to change the character.
• For details on inputting characters, see "To create a new Data Bank record" (step
3 for name input and 7 for number input).
5. After making the changes that you want, press A to store them and return to the
Data Bank record screen.
To delete a Data Bank record
1. In the Data Bank Mode, scroll through the records and display the one you want to
delete.
2. Hold down A until the flashing cursor appears on the display.
3. Press B and D at the same time to delete the record.
• The message "CLR" appears to indicate that the record is being deleted. After
the record is deleted, the cursor appears on the display, ready for input.
4. Input data or press A to return to the Data Bank record screen.
ALARMS
This watch has two alarms (Alarm 1 and Alarm 2), for
which you can make separate hour, minute, and day of
the week settings.
When an alarm is turned on, the alarm tone sounds when
the alarm time is reached by the Timekeeping Mode
digital time.
• Use the Alarm 1 and Alarm 2 Modes to set alarms. You
can enter an Alarm Mode using C. The setting
procedure is the same for both of the alarm screens.
Mode indicator
Alarm Types
The alarm type is determined by the settings you make, as described below.
• Daily alarm
Set the hour and minutes for the alarm time. This type of setting causes the alarm to
sound everyday at the time you set.
• Weekly Alarm
Set the hour, minutes, and the day of the week for the alarm time. This type of setting
causes the alarm to sound every week at the time you set, on the day of the week you
set.
To set an alarm time
1. After enter the Alarm 1 or Alarm 2 Mode, hold down A
Day of week
until the day of the week setting starts to flash, which
indicates the setting screen.
• This operation automatically turns on the
corresponding alarm.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Day of week
Alarm time
3. While a setting is flashing, use D (+) and B (–) to
(Hour : Minutes)
change it.
• To set an alarm that does not include a day of the week (daily alarm), set "– – –"
for the day of the week. Press D or B until the "– – –" mark appears (between
SUN and MON) while the day of the week setting is flashing.
• When setting the alarm time using the 12-hour format, take care to set the time
correctly as a.m. (no indicator) or p.m. (P indicator).
4. Press A to exit the setting screen.
Alarm Operation
The alarm sounds at the preset time for about 10 seconds, or until you stop it by
pressing any button.
To test the alarm
While in the Alarm 1 or Alarm 2 Mode, hold down D to sound the alarm.
To turn an alarm on and off
1. Enter the Alarm Mode (Alarm 1 or Alarm 2) you want to
Alarm 1 on
Alarm 2 on
turn on or off.
indicator
indicator
2. Press D to toggle the alarm on (alarm time displayed)
and off (OFF displayed).
• The Alarm 1 on indicator indicates that Alarm 1 is on,
while the Alarm 2 on indicator indicates Alarm 2 is on.
• Alarm on indicators are displayed in all modes.
2700-2
indicates the first character of the name or
Name scrolls
Number stops
Hour
Minutes
