- Page 1 TRENDnet TU-ET10 Universal Serial Bus Ethernet Adapter...
-
Page 2: Fcc Certification
USER's Guide FCC Certification Part 15, Class B FCC ID: MQ4USB10TA The United States Federal Communication Commission (FCC) and the Canadian Department of Communications have established certain rules governing the use of modems and other electronic equipment. FCC Part 15 Registration This modem complies with Part 15 of FCC rules. - Page 3 conditions: 1) This device may not cause harmful interface, 2) this device must accept any interface received, including interface that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 4: Hardware Installation
ow you can experience a true plug-and-play Network device easier than ever. The USB (Universal Serial Bus) Network Adapter allows you to connect a 10Mbps network from an USB-enabled PC, notebook, or USB HUB. With instant hardware recognition from Windows 98 and “Hot Swap” feature from USB specification, you don’t need to be a MIS specialist to operate it. -
Page 5: Usb Cable
To properly install the USB LAN adapter, it is very important to recognize the USB hardware. 1. USB Cable USB cable has two ends – One has rectangular plug, or called A-Type connector; another one has a square plug, or called B-type connector. 2. -
Page 6: Windows 98 Setup
Windows 98. If you don’t have Windows 98 STOP installed, please now. Windows 98 Setup Note: Before you begin the driver installation, please make sure disable any network card currently installed into your system. And, have your Windows 98 CD-ROM copy handy. Step 1: Install the USB LAN Adapter into your PC or Notebook Step 2: Start up your computer and Windows 98... - Page 7 diskette into Driver A and select “Search for the best driver for your device (Recommended).” Click “Next.” Step 5: Windows 98 will ask you to indicate the best driver. Make sure the floppy disk driver is selected and drive is specified. Click “Next” to continue.
- Page 8 driver and start the download the driver. Click “Next” to continue. Step 7: When Windows 98 finish the driver installation, click “Finish” button. Step 8: Then Windows will ask you to restart...
- Page 9 your computer. Click “ ” to continue. Step 9: Once you are back at the desktop, click on the “Start” button. Then click on ”Settings,” then “Control Panel.” Step 10: Double-click the Network icon. Then select “Configuration” tab. Make sure the network components are installed.
-
Page 10: Led Indicator
Step 11: Now you can select the network protocol. After that the system restart your computer to let the setting be permanent. LED Indicator Link: Indicates a good linkage between the ALN adapter and supporting HUB or Switch Activity (Tx/Rx): Flash when data is transmitting between network. -
Page 11: Specifications
Specifications Network Specification IEEE 802.3 10BaseT Ethernet Cat 3/Cat 5 UTP, 100ohm STP cable up to 328ft/100M Host Interface Bus-powered from USB host or HUB, no external power needed High speed upstream B type USB port Suspend power saving mode supported Data Speed 10Mbps for Ethernet data transfer Environment Operating Ranges...
