Quick Installation Guide
TEW-650AP
1.01

Advertisement

loading

Related Manuals for TRENDnet TEW-650AP

Summary of Contents for TRENDnet TEW-650AP

  • Page 1 Quick Installation Guide TEW-650AP 1.01...
  • Page 2 Table of Contents English 1. Before You Start 2. Hardware Installation Troubleshooting Version 08.04.2010...
  • Page 3 1. Before You Start Package Contents Ÿ TEW-650AP Ÿ Multi-Language Quick Installation Guide Ÿ CD-ROM (Utility and User's Guide) Ÿ Power Adapter (12V DC, 0.5A) Ÿ Cat. 5 Ethernet Cable (0.6m / 2ft.) System Requirements Ÿ Web Browser: Internet Explorer (6 or higher) Ÿ...
  • Page 4 2. Hardware Installation Note: 1. Locate an optimum location for the Access Point. The best place for the Access Point is usually at the center of your wireless network. 2. Disable any anti-virus and firewall programs before starting hardware installation. For Windows Users 1.
  • Page 5 5. Connect the provided RJ-45 cable from a LAN port on your Router to the LAN port on the TEW-650AP. Then click Next. 6. Connect a RJ-45 cable from a LAN port on your Router to the Ethernet port on your computer. 7.
  • Page 6 10. Select Access Point and then click Next. Note: For AP Client setup, please refer to the User's Guide for step by step instructions. The User's Guide can be found on this product's CD-ROM. 11. Select Dynamic IP Address Configuration and then click Configure.
  • Page 7 14. Select the desired Wireless Mode and then click Next. 15. Select a Security Mode and then click Next (example shows WPA-PSK). Note: To protect your network from any unauthorized access it is recommended to enable security. 16. Select the desired WPA mode, enter characters for your Pre-Shared key and then click Next.
  • Page 8 18. Give the file a name, then click Save (optional). 19. Click Configure to apply the settings. 20. Click Exit. 21. Click Yes to exit.
  • Page 9 Troubleshooting section, User's Guide on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at: Thank you for choosing TRENDnet...
  • Page 10 Troubleshooting 1. All the settings are correct, but I can not make a wireless connection to the Access Point. Double check that the wireless LED on the Access Point is lit. 2. Power cycle the Access Point. Unplug the power to the Access Point. Wait 15 seconds, then plug the power back in.
  • Page 11 6. How do I configure AP Client mode on the TEW-650AP? Please refer to the User Guide. The User Guide is on the provided CD-ROM. If you still encounter problems or have any questions regarding the TEW-650AP, please contact TRENDnet's Technical Support Department.
  • Page 12 Wireless Tips The following are some general wireless tips to help minimize the impact of interference within an environment. Assign your network a unique SSID Do not use anything that would be identifying like “Smith Family Network”. Choose something that you would easily identify when searching for available wireless networks. Do not turn off the SSID broadcast The SSID broadcast is intended to be on and turning it off can cause connectivity issues.
  • Page 13 2. Keep the number of obstructions to a minimum. Each obstruction can reduce the range of a wireless device. Position the wireless devices in a manner that will minimize the amount of obstructions between them. 3. Building materials can have a large impact on your wireless signal. In an indoor environment, try to position the wireless devices so that the signal passes through less dense material such as dry wall.
  • Page 15 The source codes are available for download from TRENDnet's web site (http://trendnet.com/downloads/list_gpl.asp) for at least three years from the product shipping date. You could also request the source codes by contacting TRENDnet. 20675 Manhattan Place, Torrance, CA 90501, USA. Tel: +1-310-961-5500 Fax: +1-310-961-5511.
  • Page 16 GPL/LGPL informações Gerais Este produto TRENDnet inclui software gratuito desenvolvido por terceiros. Estes códigos estão sujeitos ao GPL (GNU General Public License) ou ao LGPL (GNU Lesser General Public License). Estes códigos são distribuídos SEM GARANTIA e estão sujeitos aos direitos autorais dos desenvolvedores. TRENDnet não presta suporte técnico a estes códigos.
  • Page 18 Copyright © 2010. All Rights Reserved. TRENDnet.
