Page 1: Instruction Manual
English Digital Video Camcorder English Instruction Manual Introduction Preparation Basic Functions Advanced Functions Editing Mini Digital Video Printing Cassette Connecting to a PC Please read also the following instruction manual. • Digital Video Software Trouble? Do’s & Don’ts Additional Information...
Page 2: Important Usage Instructions
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING! TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK AND TO REDUCE ANNOYING INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY.
Page 3: Using This Manual
: Additional topics that complement the basic operating procedures. : Reference page number. Capital letters are used to refer to buttons on the camcorder or the wireless controller. [ ] are used to refer to menu items displayed on the screen.
Page 4 • Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the United States and other countries. • HDV is a trademark of Sony Corporation and Victor Company of Japan, Limited (JVC). • Other names and products not mentioned above may be registered trademarks or...
Page 5: Table Of Contents
Step 4: Preparing the Camcorder ..............19 Step 5: Using the Wireless Controller............20 Step 6: Adjusting the LCD Screen ..............21 Step 7: Changing the Display Language ............22 Step 8: Setting the Time Zone, Date and Time..........23 Basic Functions Recording Recording Movies on a Tape .................25 Recording on a Memory Card ...............28...
Page 6 Playing Back/Searching Images..............89 Protecting Images..................90 Erasing Images....................91 Formatting a Memory Card................92 Editing Recording to a VCR or Digital Video Device ..........93 Analog Line-in Recording ..............95 DV Dubbing ...................97 Converting Analog Signals into Digital Signals (Analog-Digital Converter) 100 Audio Dubbing .....................102 Recording from the Tape on a Memory Card ..........105...
Page 7: Checking Supplied Accessories
Lithium Button Battery Power Adapter (incl. Controller CR2025 for the power cord) Wireless Controller MTC-100 Multi Cable PC-A10 SCART IFC-300PCU USB 16 MB miniSD card Adapter* Cable DIGITAL VIDEO SOLUTION DISK For Windows For Macintosh * Not included in China and Oceania.
Page 8: Components Guide
Right side view Lens Cover Switch ( Viewfinder cleaning cover - open, - closed) Serial number – (record review) button ( 27, 36) / BATTERY RELEASE button ( (rewind) button ( Battery attachment unit ( + button ( 27, 36) /...
Page 9: Front View
Front view Back view Flash ( Mode dial ( Mini video light (assist lamp) ( SET dial ( 37, 50, 62) Speaker ( Power switch ( Terminal cover Start/stop button ( 25, 28) Stereo microphone Lock button DC IN terminal (...
Page 10: Top View
Bottom view Zoom lever ( Cassette compartment ( PHOTO button ( OPEN/EJECT switch ( D.EFFECTS button ( Cassette compartment cover ( DRIVE MODE button ( 85) / Strap mount ( 141) AUDIO LEVEL button ( Memory card slot ( (self-timer) button (...
Page 11: Wireless Controller Wl-D85
DATE SEARCH PLAY STOP PAUSE SLOW ZERO SET AUDIO DUB. TV SCREEN MEMORY WIRELESS CONTROLLER WL - D85 START/STOP button ( 25, 28) PHOTO button ( CARD –/+ buttons ( Zoom buttons ( DATE SEARCH buttons ( PLAY button (...
Page 12: Screen Displays
Camcorder shake warning ( Mini video light ( • When “ ” starts flashing in red Flash ( replace the battery pack with a fully AF/AE locked during still image recording charged one. • When you attach an empty battery AF frame ( pack, the power may turn off without displaying “...
Page 13: Screen Displays During Playback
( : Rewind When playing back a still image Image number ( from a memory card ( Number of images Still image size Movie size/playback time Protected image mark When playing back a movie from a memory card (...
Page 14: Step 1: Preparing The Power Supply
Step 1: Preparing the Power Supply Preparation The camcorder can be powered by a battery pack or be connected to a household power source. Charge the battery pack before use. Attaching the Battery Pack 1. Turn the power switch to OFF.
Page 15: Using A Household Power Source
Using a Household Power Source Connect to a household power source to use the camcorder without worrying about the battery power. You can keep the battery pack attached; the battery power will not be consumed. 1. Turn the power switch to OFF.
Page 16 We recommend charging the battery pack in temperatures between 10 °C and 30 °C. Outside the temperature range of 0 °C to 40 °C, the charge indicator flashes rapidly and charging stops. A lithium ion battery pack can be charged at any charge state. Unlike conventional battery packs, you do not need to completely use or discharge it before charging.
Page 17: Step 2: Loading A Cassette
4. Wait for the cassette compartment to retract automatically and close the cassette compartment cover. Do not interfere with the cassette compartment while it is opening or closing automatically, or attempt to close the cover before the cassette compartment has fully retracted.
Page 18: Step 3: Inserting A Memory Card
Remove the memory card. 4. Close the cover. Card access indicator If you use memory cards other than the supplied one, make sure to format them with the camcorder ( 92). Proper operation cannot be guaranteed for all memory cards.
Page 19: Step 4: Preparing The Camcorder
Fastening the Grip Belt Hold the camcorder with your right hand and adjust the belt with your left. Adjust the grip belt so that you can reach the zoom lever with your index finger, and the start/stop button with your thumb.
Page 20: Step 5: Using The Wireless Controller
The wireless controller may not work properly when the remote sensor is subjected to strong light sources or direct sunlight. If the wireless controller does not work, check if the remote sensor is set to [OFF 66).
Page 21: Step 6: Adjusting The Lcd Screen
• You can rotate the panel downward by 90 degrees. • You can rotate the panel by 180 degrees toward the lens (Allowing the subject to monitor the LCD screen while you use the viewfinder. Pull out the viewfinder to use it).
Page 22: Step 7: Changing The Display Language
Step 7: Changing the Display Language The language used in the camcorder displays and menu items can be changed to German, Spanish, French, Italian, Russian, Simplified Chinese, Traditional Chinese, Korean or Japanese. MENU DISPLAY SETUP/ LANGUAGE ENGLISH 1. Turn the power switch to CAMERA or PLAY.
Page 23: Step 8: Setting The Time Zone, Date And Time
The time zone setting appears (see table on the next page). The default setting is Paris. 5. Turn the SET dial to select the setting option that represents your time zone and press the SET dial. To adjust for daylight saving time, select the time zone with the next to the area.
Page 24: Time Zones
Time Zones Once you have set your time zone, date and time, you do not need to reset the clock each time you travel to another time zone. Just set the time zone to the one of your destination, and the camcorder automatically adjusts the clock.
Page 25: Basic Functions Recording
Bright light may make it difficult to use the LCD screen. In such case, use the viewfinder instead. When recording near loud sounds (such as fireworks, drums or concerts), sound may become distorted or may be recorded not in the actual sound level.
Page 26: Screen Displays During Recording
When powered by a battery pack, the camcorder shuts off after 5 minutes when the camcorder is left without any operation to save power ( 66). Approximately 30 seconds before the camcorder shuts off, “ AUTO POWER OFF” appears in the center of the screen. If the camcorder shuts off, turn the power switch to OFF and back on again.
Page 27: Reviewing And Searching When Recording
Reviewing and Searching when Recording You can review the last few seconds of your recording (record review). You can also play back the tape to locate the point where you wish to begin recording (record search). Available only in the mode.
Page 28: Recording On A Memory Card
6. Press the PHOTO button fully. • and focusing frame disappear and you hear a shutter sound. • The card access indicator flashes. Recording Movies on a Memory Card 1. Holding the lock button on the power switch pressed down, set the switch to CAMERA.
Page 29 SET dial up and down. When recording a still image (step 5 above), the image may appear out of focus for a moment while the camcorder is focusing. When the subject is too bright, “OVEREXP.” starts flashing. In such case, use the optional FS-H27U ND filter.
Page 30: Screen Displays During Still Image Recording
Screen Displays during Movie Recording Remaining Card Capacity for Movies Indicates the remaining time in hours and minutes. At less than 1 minute, the remaining time will be displayed in 10 second-steps, at less than 10 seconds in 1 second-steps.
Page 31: Zooming
Zooming The zoom is available in the modes. When recording on the tape, in addition to the 10x optical zoom you can also use the 200x digital zoom 63). Zoom out Zoom in Zoom lever Optical Zoom Move the zoom lever toward W to zoom out (wide- angle).
Page 32: Digital Zoom
4. Turn the SET dial to select a setting option. 5. Press the MENU button to close the menu. A zoom indicator appears for 4 seconds. It extends in light blue when the digital zoom is set to 40x, and extends further in dark blue when set to 200x.
Page 33: Tips For Better Recording
When using a tripod, do not leave the viewfinder exposed to direct sunlight as it may melt (due to concentration of the light by the lens). Do not use tripods with fastening screws longer than Camera 5.5 mm as it may damage the camcorder.
Page 34: Playing Back A Tape
Playing Back a Tape Playback If the playback picture is distorted, clean the video heads using a Canon Head Cleaning Cassette or a commercially available digital video head-cleaning cassette ( 136). 1. Holding the lock button on the power switch pressed down, set the switch to PLAY.
Page 35: Special Playback Modes
To pause playback, press the button during normal playback. (Fast Forward Playback) / (Rewind Playback) Plays back the tape at 9.5 times normal speed (forward or reverse). Press and hold the button during normal playback or fast forward. –/ (Reverse Playback) Press the button on the wireless controller during normal playback.
Page 36: Playing Back A Memory Card
60), edited on a computer and images whose file names have been changed may not be played back correctly. Do not turn off the camcorder, change the position of the TAPE/CARD switch, disconnect the power source, open the memory card cover or remove the memory card while the card access indicator is flashing.
Page 37: Adjusting The Volume
Adjusting the Volume When you use the LCD screen for playback, the camcorder plays back the sound via built-in speaker. The speaker does not sound when you close the LCD panel. Available in the modes. Speaker SET dial Adjusting the Speaker Volume Turn the SET dial up to increase the volume, and down to lower the volume.
Page 38: Playing Back On A Tv Screen
3. Connect the MTC-100 Multi Cable to the camcorder’s AV terminal and the terminals on the SCART Adapter. Connect the white plug to the white AUDIO terminal L (left), the red plug to the red AUDIO terminal R (right) and the yellow plug to the yellow VIDEO terminal.
Page 39 2. Connect the MTC-100 Multi Cable to the camcorder’s AV terminal and the audio terminals on the TV/VCR. Connect the white plug to the white audio terminal L (left), the red plug to the red audio terminal R (right). 3. Connect the MTC-100 Multi Cable to the video terminal on the TV/VCR.
Page 40: Advanced Functions Recording Programs
Sports Beach Fireworks Use this mode to record Use this mode to record Use this mode to record on a sports scenes such as tennis fireworks. sunny beach. It prevents the or golf. subject from being underexposed...
Page 41: Selecting The Recording Program
- Moving subjects may leave a trailing afterimage. - Picture quality may not be as good as in other modes. - White points may appear on the screen. - Autofocus may not work as well as in other modes. In such case, adjust the focus manually.
Page 42 Snow/Beach mode: - The subject may become overexposed on cloudy days or in shaded places. Check the image on the screen. - The picture may not appear smooth when played back. Fireworks mode: To avoid camcorder shake, we recommend using a tripod. Use a tripod when recording in mode as the shutter speed slows down.
Page 43: Using The Program Ae Mode
Using the Program AE Mode The camcorder automatically adjusts shutter speed and exposure according to the brightness of the subject. In Program AE mode, you can point and shoot as in Auto mode, however, you have the option of changing some settings.
Page 44: Using The Shutter-Priority Ae Mode
When using a slow shutter speed in dark places, you can record the subject brightly, but the image quality may be lower, and autofocus may not work well. Do not point the camcorder directly at the sun when the shutter speed is set to 1/1000 or higher.
Page 45: Using The Aperture-Priority Ae Mode
You can select an aperture value, and the camcorder automatically chooses the appropriate shutter speed. Aperture values: 1.8, 2.0, 2.4, 2.8, 3.4, 4.0, 4.8, 5.6, 6.7, 8.0, 9.5, 11, 14, 16 Use low aperture values (large aperture) to blur the background for a portrait, or high aperture values (small aperture) to achieve a broad depth of field for recording landscapes.
Page 46: Adjusting The Exposure Manually
Exposure cannot be adjusted in the Fireworks mode (SCN). 2. Press the EXP button. • “±0” appears on the screen. • When you operate the zoom during exposure lock, the brightness of the image may change. Exposure Adjustment During exposure lock: Turn the SET dial to adjust the brightness of the image.
Page 47: Adjusting The Focus Manually
Readjust the focus when you have turned off the camcorder. Infinity Focus Use this function when you wish to focus on faraway subjects such as mountains or fireworks. Press the FOCUS button more than 2 seconds after step 2 above.
Page 48: Using The Mini Video Light
Using the Mini Video Light You can turn on the mini video light (assist lamp) at any time regardless of the recording program. Mini video light LIGHT button Available only in the modes. Press the LIGHT button. • “ ” appears on the screen.
Page 49: Using The Self-Timer
To cancel the self-timer, press the (self-timer) button. Once the countdown has begun, you can also press the start/stop button (when recording movies) or the PHOTO button (when recording still images) to cancel the self-timer. The self-timer will be canceled when you turn off the camcorder.
Page 50: Changing The Settings
Changing the Settings with the FUNC. Changing the Settings (1) Button Many of the camcorder’s functions are selected from the FUNC. menu that appears when pressing the FUNC. button. For menu items, see List of Menu Items (FUNC.) ( 51).
Page 51: List Of Menu Items (Func.)
SUPER FINE), FINE), NORMAL) Image erase Slide show Protect Print order Transfer order * When recording still images on the card with the drive mode set to [SINGLE], this setting option appears when pressing the FUNC. button right after recording.
Page 52: Setting The White Balance
Setting the White Balance You can use the preset modes to reproduce colors more accurately, or set a custom white balance to obtain the optimal setting. Settings are automatically set by the camcorder. AUTO For recording outdoors on a bright day.
Page 53 [FLUORESCENT] or [FLUORESCENT H]. If the color looks unnatural on the screen, adjust using [AUTO] or [SET]. The camcorder retains the custom white balance setting even if you turn it off. When you want to use a previously made [SET] setting, after selecting [ SET] in step 3, press the FUNC.
Page 54: Selecting An Image Effect
SET dial and select [SET]. 5. Press the FUNC. button. [SOFT SKIN DETAIL]: To obtain the best effect, use this function when recording a person in close-up. Note that areas similar to the skin color may lack in detail.
Page 55: Using Digital Effects
Using Digital Effects The Digital Effects functions include faders, effects, multi-image screen and Card Mix 60). Faders ( Begin or end scenes with a fade to or from black. Fade Trigger (FADE-T) Wipe (WIPE) Corner Wipe (CORNER) Jump (JUMP) Flip (FLIP)
Page 56 Captures moving subjects in 4, 9 or 16 sequences of still images and displays them at one time. Sound will be recorded normally. 4 Sequences 9 Sequences 16 Sequences Card Mix ( You can combine still images from the card with your live video and record on the tape to achieve interesting effects.
Page 57: Selecting A Fader
The symbol of the current setting is displayed. 3. Select the fader type. The selected fader will be demonstrated on the current screen and will be shown in a small animation to the right of the menu item. 4. Press the FUNC. button.
Page 58: Selecting An Effect
Select it and proceed directly to Step 4 below. 3. Select the effect type. The selected effect will be demonstrated on the current screen and will be shown in a small animation to the right of the menu item. 4. Press the FUNC. button.
Page 59: Using The Multi-Image Screen
To cancel the multi-image screen, press the D.EFFECTS button. • MANUAL: Images will be captured each time you press the D.EFFECTS button. The blue frame indicating the next sequence disappears after the last image. Pressing the D.EFFECTS button for more than 1 second cancels the images one after...
Page 60 Combining Images (Card Mix) You can choose one of the sample images from the collection on the supplied disk (such as picture frames, backgrounds and animations) and combine it with the live video recording. Card Chroma Key (CARD CHROMA) Combines frames with your recordings. The live video recording will appear in place of the blue area of the card mix image.
Page 61: Selecting The Card Mix Effect
D.EFFECT OFF 1. Upload a sample image from the supplied disk to the memory card. Refer to Adding Still Images from Your Computer to the Memory Card in the Digital Video Software Instruction Manual. 2. Set the mode dial to a mode other than 3.
Page 62: Changing The Settings With The Menu Button
Changing the Settings with the MENU Changing the Settings (2) Button Many of the camcorder’s functions are selected from a menu that appears when pressing the MENU button. For menu items, see List of Menu Items (MENU) ( 63). MENU button...
Page 63: List Of Menu Items (Menu)
We recommend turning off the image stabilizer when using a tripod or when panning. FOCUS PRI.: The camcorder records the still image once focus is adjusted. Set it to [OFF] when you wish to record a still image as soon as you press the PHOTO button.
Page 64 LP mode may be distorted. We recommend using the SP mode for important recordings. If you record in both SP and LP modes on the same tape, the playback picture may become distorted and the time code may not be written correctly.
Page 65 BRIGHTNESS: Adjusts the brightness of the LCD screen. Turn the SET dial up or down to adjust the brightness. Changing the brightness of the LCD screen does not affect that of the viewfinder or the recordings. LCD MIRROR: The image appears mirror reversed when you rotate the LCD panel so...
Page 66 5 minutes using the power adapter. To cancel the demo mode once it has begun, press any button, turn off the camcorder or load a recording media.
Page 67 When customizing a setting you can check the sound or start-up image before making a selection. To be able to play the sounds, make sure the [BEEP] setting in the [SYSTEM] submenu is not set to OFF.
Page 68: Adjusting The Audio Recording Level
3. Adjust the level with the SET dial. • The maximum level should only slightly exceed –12 dB. • Sound may be distorted if the indicator for 0 dB lights up in red. 4. Press the AUDIO LEVEL button. The green bar disappears.
Page 69 About the audio level indicator: When [MIC LEVEL] is set to [AUTO] and in the mode: the audio level indicator switches on and off with each press of the AUDIO LEVEL button. -dB40 [MIC LEVEL] is set to [MANUAL] Guide (green bar) The audio level can be changed when the green bar is displayed.
Page 70: Using The Wind Screen
Using the Wind Screen The camcorder reduces wind noise automatically. However, you can turn off the wind screen when recording indoors, or when you want the microphone to be as sensitive as possible. Available in the modes. : Only when [AUDIO DUB.] is set to [MIC. IN].
Page 71: Widescreen Tv Recording (16:9)
[WIDESCREEN], set it to [ON] and press the MENU button. • “ ” appears. • The LCD screen switches to the “letterbox” display. The picture on the viewfinder appears horizontally squeezed. When you turn off the image stabilizer, you will get a larger horizontal angle of view.
Page 72: Creating A Start-Up Image
Creating a Start-up Image You can select one of the still images recorded on the memory card and set it as the camcorder’s start-up image. Available only in the mode. MENU MY CAMERA CREATE S-UP IMAGE 1. Select a still image with the +/– buttons.
Page 73: Magnifying The Image
” will display for images that cannot be enlarged. 2. Select the magnified area with the SET dial. Turn the SET dial to move the image to the right and left, or up and down. Pressing the SET dial switches between the directions.
Page 74: Displaying The Data Code
The camcorder maintains a data code containing recording date and time and other camera data such as shutter speed and exposure (f-stop). When you play back a tape, you can display the data code and select the data code combination you wish to display. Available in the modes.
Page 75: End Search
End Search When you have played back a tape, you can use this function to locate the end of the last recorded scene. Available only in the mode. EXP button In stop mode, press the EXP button. • “END SEARCH” appears.
Page 76: Returning To A Pre-Marked Position
Returning to a Pre-marked Position If you wish to return to a particular scene later, mark the point with the zero set memory and the tape will stop at that point when you rewind/fast forward the tape. Available only in the modes.
Page 77: Date Search
Press the button on the wireless controller to begin searching. • Press more than once to search for further date changes (up to 10 times). • Press the STOP button to stop searching. A recording of longer than a minute per date/area is required.
Page 78: Selecting The Image Quality/Size
Users of Windows XP: When you plan to connect the camcorder to a computer using a USB cable, keep the length of one movie shorter than approx. 12 min. in 320 x 240 and 35 min. in 160 x 120.
Page 79: Selecting The Still Image Size And Quality
The symbol of the current setting is displayed. 3. Select the still image size. The number at the lower right corner indicates the number of still images available on the memory card (the same as the number displayed at the upper right corner).
Page 80: Simultaneous Recording On The Tape And Memory Card
Simultaneous Recording on the Tape and Memory Card When you are recording a movie on a tape, you can record the same picture as a still image on the memory card. The size of the still image will be 640 x 480. The image quality can be selected.
Page 81: Using The Flash
Using the Flash You can use the built-in flash for recording still images in dark places. The flash is equipped with the red-eye reduction mode. (auto) The flash fires automatically according to the brightness of the subject. (red-eye reduction, auto) The flash fires automatically according to the brightness of the subject.The assist lamp lights up to reduce the...
Page 82 The red-eye reduction mode cannot be used in stitch assist mode. About the AF-Assist Lamp: While you press the PHOTO button halfway, the assist lamp may light up as the AF-assist lamp responds to the brightness of the subject to enable the camcorder to focus more accurately.
Page 83: Selecting The Metering Method
Selecting the Metering Method You can select the method the camera uses to evaluate the brightness of your subject. Appropriate for standard shooting conditions, including EVALUATIVE backlit scenes. The camcorder divides images into several zones for light metering. It evaluates complex...
Page 84: Changing The Focusing Method
(9-point AiAF) automatically selected from the 9 frames and focused. Center point Of 9 AF frames, the center one is selected to focus. This is convenient for making sure the focus is exactly where you want it. Available only in the mode.
Page 85: Selecting The Drive Mode
2. Press the DRIVE MODE button to switch between the drive modes. The setting changes with each press of the button. The drive mode can also be selected from the FUNC. menu ( 50). When the FUNC. menu is being displayed, the DRIVE MODE button cannot be used.
Page 86 1. Press the PHOTO button halfway. 2. Press and hold the PHOTO button fully. A series of still images will be recorded as long as you hold the PHOTO button. Maximum number of continuous shots at one time: Frames per Second...
Page 87: Recording Panoramic Images (Stitch Assist Mode)
• Minor discrepancies in the overlapped area can be corrected with the software. • You can retake an image by pressing the +/– button to return to the previous image. • A maximum of 26 images can be recorded.
Page 88 8. Press the FUNC. button after the last image. • The Stitch Assist screen will disappear. The DRIVE MODE button can also be used to close the Stitch Assist screen. • For details on how to merge these images, refer to the Digital Video Software Instruction Manual.
Page 89: Playing Back/Searching Images
Playing Back/Searching Images You can display images one after another (slide show) or 6 at one time (index screen). With the Card Jump function, you can quickly locate an image without displaying them one by one. Available only in the mode.
Page 90: Protecting Images
If a memory card is formatted, all still images and movies, even protected ones, will be erased permanently. Movies can only be protected when the first scene is displayed as a still image. Protecting during Single Image Playback Available only in the modes.
Page 91: Erasing Images
You can erase images one at a time or all at once. Be careful when erasing images. Erased images cannot be recovered. Protected images cannot be erased. Movies can only be erased when the first scene is displayed as a still image. Erasing a Single Image Available only in the modes.
Page 92: Formatting A Memory Card
Formatting a Memory Card Format new memory cards, or when you get the message “CARD ERROR”. You can also format a memory card to erase all data recorded on it. Formatting a memory card erases all data, including protected images.
Page 93: Recording To A Vcr Or Digital Video Device
Editing Device You can copy your recordings by connecting the camcorder to a VCR or a digital video device (DVD recorder, another digital camcorder, etc.). If you connect a digital video device, you can copy recordings with virtually no generation loss in image and sound quality.
Page 94 We recommend powering the camcorder from a household power source. When connecting a VCR, the quality of the edited tape will be slightly lower than that of the original. When connecting a DVD Recorder or other Digital Video Device with a DV...
Page 95: Analog Line-In Recording
8. Connected device: Stop playback. Recording the Input Video on a Memory Card The size of the still image recorded on the memory card will be 640 x 480. The still image quality and the movie size can be selected.
Page 96 We recommend powering the camcorder from a household power source. An image recorded from an image in widescreen mode will be vertically compressed. The data code of the image will reflect the date and time it has been recorded on the memory card.
Page 97: Dv Dubbing
7. Connected Device: Stop playback. Recording the Input Video on a Memory Card The size of the still image recorded on the memory card will be 640 x 480. The still image quality and the movie size can be selected.
Page 98 We recommend powering the camcorder from a household power source. An image recorded from an image in widescreen mode will be vertically compressed. The data code of the image will reflect the date and time it has been recorded on the memory card.
Page 99 Copyright Signals During playback: If you try to play back a tape that contains copyright control signals for protection of software, “COPYRIGHT PROTECTED PLAYBACK IS RESTRICTED” appears for a few seconds and the camcorder displays a blank blue screen. You cannot playback the contents of the tape.
Page 100: Converting Analog Signals Into Digital Signals (Analog-Digital Converter)
Turn off all devices before starting the connections. Unload the tape from the camcorder. Check the type and orientation of the DV terminal and make sure you connect the DV cable properly. Refer also to the instruction manual of the connected device.
Page 101 DV OFF 1. Press the MENU button and select [VCR SETUP]. 2. Select [VIDEO INPUT] and choose a setting appropriate to the type of connection to the analog device. Press the SET button to return to the [VCR SETUP] sub-menu.
Page 102: Audio Dubbing
Audio Dubbing You can add sound on a tape with the built-in microphone. With the MVX1Si you can also add sound from external audio devices. This function is operated with the wireless controller. Connecting an Audio Device Refer also to the instruction manual of the connected device.
Page 103 If you use [AUDIO IN] for the dubbing, you can check the audio on the camcorder’s speakers. Set the zero set memory at the end of the scene you wish to dub audio. The camcorder will automatically stop audio dubbing at that point.
Page 104: Playing Back The Added Sound
[AUDIO SETUP]. Select [MIX BALANCE], adjust the balance with the SET dial and press the MENU button. Turn the SET dial down to increase the volume of Stereo 1 and up to increase the volume of Stereo 2.
Page 105: Recording From The Tape On A Memory Card
An image recorded from an image in widescreen mode will be vertically compressed. Recording a Still Image from the Tape The size of the still image recorded on the memory card will be 640 x 480. The still image quality can be selected. FINE/640x480 1.
Page 106 3. Press the PHOTO button fully. • The card access indicator flashes. • You can also record a still image by pressing the PHOTO button fully when the tape is in playback pause mode. An image recorded from an image in widescreen mode will be vertically compressed.
Page 107: Printing Still Images
Printing Still Images Printing You can print still images by connecting the camcorder to a printer with direct print function. You can also use the print order settings for direct printing ( 116). Following printers can be connected to your camcorder:...
Page 108: Printing With The (Print/Share) Button
• If you wish to continue printing, select another still image with the +/– button. Printing after Selecting the Print Settings You can select the number of copies and other settings for printing. The setting options vary depending on your printer model. 1. Press the SET dial.
Page 109 - Canon PIXMA/SELPHY DS printers, CP600: Printing stops even if it is incomplete and the paper is fed through. - Canon CP printers (except for the CP600): A print in progress cannot be stopped. Printing stops when the current print is finished, and the remaining prints are canceled.
Page 110: Selecting The Print Settings
Selecting the Print Settings The procedure for selecting the number of copies is common to all printers. Other print setting procedures vary depending on your printer model. Check which icon appears in the upper left corner of the camcorder screen after connecting, and refer to the relevant pages accordingly.
Page 111: Paper Settings
Paper Settings 1. In the print setting menu, turn the SET dial to select [PAPER] and press the SET dial. 2. Turn the SET dial to select the paper size and press the SET dial. Select the paper size of the paper set in your printer.
Page 112: Setting The Print Effect (Image Optimize)
[BORDERED]: The image area remains relatively unchanged from the recorded image when it is printed. [BORDERLESS]: The center portion of the recorded image is printed at an enlarged size. The image’s top, bottom and sides may be cropped slightly. 1. In the print setting menu, turn the SET dial to select [STYLE] and press the SET dial.
Page 113 [BORDERED]: The image area remains relatively unchanged from the recorded image when it is printed. [BORDERLESS]/[MULTIPLE]: The center portion of the recorded image is printed at an enlarged size. The image’s top, bottom and sides may be cropped slightly. [MULTIPLE] can only be selected when printing on card size paper.
Page 114 2. Turn the SET Dial to select (DATE) and press the SET dial. 3. Turn the SET dial to select a date option and press the SET dial. Pressing the MENU button brings you back to the print settings menu.
Page 115: Trimming Settings
• To cancel the trimming settings, move the zoom lever toward W until the trimming frame disappears. 3. Move the trimming frame. • Turn the SET dial to move the frame. Press the SET dial to switch between the directions (up/down or right/left) and the orientation of the frame (vertical/horizontal).
Page 116: Printing With Print Order Settings
Printing with Print Order Settings You can select still images for printing and set the number of copies. These print order settings are compatible with the Digital Print Order Format (DPOF) standards and can be used for printing on DPOF compatible printers ( 107).
Page 117: Erasing All Print Orders
Restarting Printing Select [ PRINT] from the MENU. Select [RESUME] or [CONTINUE] in the print setting menu and press the SET dial. The remaining images will be printed. Printing cannot be restarted in the following cases: - When you change the print order settings.
Page 118: Transferring Video Recordings To A Computer
[AV DV] to [ON]. 4. Connect the camcorder to the computer with the DV cable as shown below. Check the type and orientation of the DV terminal and make sure you connect the DV cable properly 6-pin 4-pin IEEE1394 (DV)
Page 119 IEEE1394 device is connected to the computer. Depending on the video editing software you use, you may need to set the power switch of the camcorder to a mode other than PLAY. Refer also to the instruction manual of the editing software.
Page 120: Transferring Memory Card Images To A Computer
121). Preparations The first time you connect the camcorder to the computer, you need to install the software and set the auto-launch setting. From the second time on, you will only need to connect the camcorder to the computer to transfer images.
Page 121 Main Window of ZoomBrowser EX. • The camcorder displays the transfer menu when transfer is complete. • To cancel transfer, turn the SET dial to select [CANCEL] and press the SET dial, or press the MENU button. • If choosing [ SELECT &...
Page 122 When the camcorder is connected to the computer and the screen to select images displays, press the MENU button. The transfer menu will display.
Page 123: Selecting Images For Transfer (Transfer Order)
You can select images for transfer to the computer (max. 998). These transfer settings are compatible with the Digital Print Order Format (DPOF) standards. Do not connect a USB or DV cable to the camcorder while setting the transfer orders. Available only in the mode.
Page 124: Using The Dv Messenger Version 2
Using the DV Messenger Version 2 With the Windows XP dedicated DV Network Software (DV Messenger), you can operate your camcorder from the computer, perform videoconferences using the camcorder or remotely access the camcorder at home using the Internet. Download the DV Messenger and the DV Network Software Instruction Manual from the following homepage.
Page 125: Troubleshooting
Troubleshooting Trouble? If you have a problem with your camcorder, refer to this checklist. Consult your dealer or a Canon Service Center if the problem persists. Power Source Problem Solution Camcorder will not turn on. Battery pack is exhausted. Replace or charge the battery pack.
Page 126 TV screen. Check again the camcorder is properly connected to the TV. Tape is running, but image will TV/VIDEO selector on the TV is not set to VIDEO. Set the not appear on the TV screen. selector to VIDEO. Video heads are dirty. Clean the video heads.
Page 127 Memory card is not formatted. Format the memory card. The folder and file numbers have reached their maximum value. Set [FILE NOS.] to [RESET] and insert a new memory card. Memory card cannot be Set the power switch to PLAY and the TAPE/CARD switch to played back.
Page 128 When a cold room is heated rapidly room How to avoid condensation: Unload the cassette, place the camcorder in an airtight plastic bag and let it adjust to temperature changes slowly before removing it from the bag. When condensation is detected: The camcorder stops operating and the warning message “CONDENSATION HAS...
Page 129: List Of Messages
SET THE TIME ZONE, You have not set the time zone, date and time. This message DATE AND TIME appears each time you turn the power on until you set the time zone, date and time. CHANGE THE BATTERY Battery pack is exhausted. Replace or charge the battery pack.
Page 130: Direct Print Related Messages
The following messages may appear on the camcorder screen. On printers equipped with an operation panel or printer that can be connected to a TV, an error number or message displays on the panel or TV monitor. Refer to the printer manual for the remedies corresponding to the error numbers or messages.
Page 131 Paper lever error occurred. Adjust the paper selection lever to the proper position. PRINTER COVER OPEN Close the printer cover securely. NO PRINTHEAD No print head is installed in the printer or print head is defect. Refer to the instruction manual of your printer.
Page 132: Handling Precautions
30 °C. If you do not use the battery pack for long periods, charge and discharge it fully at least once a year. If you have more than 1 battery pack, perform these precautions at the same time for all battery packs.
Page 133 Rewind tapes after use. If the tape becomes slack and damaged, it may cause picture and sound distortion. Return cassettes to the case and store them upright. Rewind tapes from time to time if they are stored for a long time.
Page 134: Memory Card
Duracell2025. Use of other batteries may present a risk of fire or explosion. • The used battery should be returned to the supplier for safe disposal. Do not pick up the battery using tweezers or other metal tools as this will cause a short circuit.
Page 135 Do not remove the cover for any other purpose than removing the battery for recycling when disposing the camcorder. When you have removed the battery, keep it out of reach of children. If it is swallowed, seek medical assistance immediately. The battery case may break and the battery fluids may damage the stomach and intestines.
Page 136: Cleaning The Video Heads
When the message “HEADS DIRTY, USE CLEANING CASSETTE” appears, or when the playback picture becomes distorted, the video heads need to be cleaned. To maintain the best picture quality, we recommend cleaning the video heads frequently with the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette.
Page 137: Maintenance/Others
Maintenance/Others Storage If you do not intend to use the camcorder for a long time, store it in a place free of dust, in low humidity, and at temperatures not higher than 30 °C. After storage, check the functions of your camcorder to make sure that the camcorder is still working properly.
Page 138: Using The Camcorder Abroad
Canon Service Center for information on plug adapters for overseas use. Playback on a TV Screen You can only play back your recordings on TVs with PAL system. The PAL system is used in the following countries/areas: Algeria, Australia, Austria, Bangladesh, Belgium, Brunei, China, Denmark, Finland,...
Page 139: System Diagram (Availability Differs From Area To Area)
PC-A10 SCART MTC-100 Multi Cable Commercially available DVD Recorder or other DV Cable DV equipped Digital Device IFC-300PCU USB Cable Computer SC-2000 Soft Card Adapter Carrying Case Card Reader/Writer miniSD Card Canon printers with direct print function / PictBridge-compliant printers...
Page 140: Optional Accessories
• The image stabilizer is not as effective when the Tele-converter is attached. • The minimum focusing distance with the TL-H27 is 3 m; 3 cm at maximum wide angle. • When the Tele-converter is attached, a shadow may appear in the picture when you record with flash or assist lamp.
Page 141: Shoulder Strap
SC-2000 Soft Carrying Case A handy camcorder bag with padded compartments and plenty of space for accessories. This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark.
Page 142: Specifications
* The camcorder’s operations have been tested with miniSD cards up to 256MB. Performance cannot be guaranteed for all miniSD cards. **This camcorder supports Exif 2.2 (also called “Exif Print”). Exif Print is a standard for enhancing the communication between camcorders and printers. By connecting to an Exif Print-compliant printer, the camcorder’s image data at the time of shooting is used and optimized, yielding extremely high quality prints.
Page 143 Power/Others Power supply (rated) 7.4 V DC Power consumption (AF on) 3.1 W (using viewfinder), 3.2 W (using LCD screen in normal brightness) Operating temperature 0 – 40 °C Dimensions (W x H x D) 54 x 73 x 105 mm excluding protrusions...
