Page 1: User Manual
DG-M22-12D1P-XA(GB) 2005.12.22 8:9 AM ˘ mac001 1200DPI 100LPI HELP LINE Number ; 0870 100 2525 With queries, please quote the page number, reference number and model number. HDD/DVD Recorder HDD/DVD Recorder DH-6100P/DHR-8100P User Manual... -
Page 2: Safety Instructions
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Safety Instructions Safety Instructions Please keep the product’s guarantee sheet and receipt in a safe place. Precautions • Read this booklet carefully. • Make sure the rating of your household electricity supply matches that • Read this page and chapter ‘Setting up your product’ to help you set up •... -
Page 3: Important Safeguards
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Important Safeguards Important Safeguards CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated... - Page 4 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing.
- Page 5 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM product. 17 DISC Do not use a cracked, deformed or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction. 18 SERVICING Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
-
Page 6: Table Of Contents
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Table of Contents Table of Contents Introduction Safety Instructions ____________________________1 Important Safeguards _________________________2 Table of Contents ______________________________5 Overview ______________________________________6 Identification of Controls ______________________10 Connections Connecting Antenna/Cable ____________________15 Connecting a TV _______________________________15 Connecting an Amplifier/Receiver _____________16 Connecting Optional Equipment ______________17 Connecting a Digital Camcorder ______________17 Setup Initial Installation ______________________________18... -
Page 7: Overview
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Overview Overview Overview Time Shifting : Simultaneous video recording and playback • Pause and resume the live TV broadcast. Issue trick mode commands like fast forward, fast rewind, jump and instant replay • Play a previously recorded program while another program is being simultaneously recorded Program Recording... - Page 8 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Dual Media Supporting Disc ±RW / ±R Recording Format ±Disc + VR format Finalize -RW, -R, +R After finalising other DVD playback All discs can playback Consumer Does not need selection (recording format) Remark : A DVD Recorder that supports ‘dual media’ recording allows DVD+RW format recording (+VR) on either DVD-R, DVD-RW, DVD+R or DVD+RW media.
- Page 9 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM About DVD Recording Notes on Recording • The recording times shown are not exact because the HDD/DVD Recorder uses variable bit-rate video compression. This means that the exact recording time will depend on the material being recorded. •...
- Page 10 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Precautions Handling the Unit When shipping the unit The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packaged at the factory. When setting up the unit The picture and sound of a nearby TV, VCR, or radio may be distorted during playback.
-
Page 11: Identification Of Controls
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Identification of Controls Identification of Controls Front Panel Disc Tray (DVD deck) Insert a disc here. Front Panel Display Shows the current status of the HDD/DVD Recorder. OPEN/CLOSE (DVD) Opens or closes the disc tray. PLAY/PAUSE (ENTER) Starts playback of a disc or HDD. -
Page 12: Front Panel Display
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Front Panel Display DVD MODE Disc is loaded DVD Timer Recording is set Channel PR23 TV Channel Input mode AV1 input Au-1 Au-2 AV2 input Recording on disc Indicates a DVD Timer recording is 1 1 : 1 5 set. -
Page 13: Remote Control
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM ˘ ` 12 mac001 1200DPI 100LPI Identification of Controls Remote Control - Turns the HDD/DVD Recorder on and off. - Locks the front panel by pressing and holding it over 5 seconds. Opens and closes the disc tray. Selects DVD mode. - Page 14 QUESTIONS REGARDING OUR TV SET COMPATIBILITY 'WITH THIS MODEL 525p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTRE. ˘ ` 13 mac001 1200DPI 100LPI Identification of Controls DH-6100P HQ (16Hrs), SP (33hrs), EP (64hrs), SLP (97hrs) DHR-8100P HQ (32Hrs), SP (66hrs), EP (128hrs), SLP (195hrs)
-
Page 15: Rear Panel
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Rear panel & S-VIDEO OUT Connect to a TV with an S-Video Input. AUDIO OUT (L, R) Connect to a TV or other equipment with audio inputs. COMPONENT VIDEO OUT (Y Pb Pr) Connect to a TV with Component Video (Y Pb Pr) inputs. -
Page 16: Connections
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Connections Connections • There are a variety of ways to connect the HDD/DVD Recorder to your TV and other equipment. Use only one of the connections described below. Whichever TV connection you use will work with all input sources. •... -
Page 17: Connecting An Amplifier/Receiver
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM S-Video Connection Connect the S-VIDEO OUT jack on the HDD/DVD Recorder to the S-Video in jack on your TV using an S-Video cable (S). Connect the Left and Right AUDIO OUT jacks from the HDD/DVD Recorder to the left/right audio in jacks on your TV using the audio cables. -
Page 18: Connecting Optional Equipment
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM ˘ ` 17 mac001 1200DPI 100LPI Connections Connecting Optional Equipment To receive audio/video signals from other equipment, connect the AVF (Audio/Video Front) jacks on the HDD/DVD Recorder to the audio/video out jacks on your external component, using optional audio/video cables. -
Page 19: Initial Installation
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Initial Installation Initial Installation After successfully connecting your HDD/DVD Recorder to your TV and other devices, this chapter will show you how to complete the initial installation. You must follow the initial installation process to set the time, date, channels, and language preferences for the HDD/DVD Recorder. -
Page 20: Setup Menu
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Setup menu Setup menu Setup Menu Overview The HDD/DVD Recorder Setup menu includes six categories, including: Installation, Recording Options, Languages, Preferences, System Info, and Restore Defaults. Press [SETUP] and [œ/√] on the remote control to view the first and second levels of the Setup menu. - Page 21 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Use […/†] to select ‘Auto Search‘. Search the real channel number by pressing [œ/√]. Manual Setup Standard PAL-BG Reception Aerial Auto Search CH-02 Fine Tune Decoder Store Channel PR-01 Program Name P-01 Instructions: Enter-Confirm Setup-Exit Move …† Select ‘Fine Tune’.
- Page 22 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Auto Set The HDD/DVD Recorder has a frequency synthesized tuner capable of receiving channels that include VHF Low E2~S6, VHF High S7~S36, and UHF S37~E69. Preparation: Connect the HDD/DVD Recorder to the desired type of antenna or cable TV system, as shown in ‘Connecting Antenna/Cable‘...
-
Page 23: Recording Options Settings
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Adjust Channels Follow steps 1-2 as shown under ‘Manual Set’. Use […/†] to select ‘Adjust Channels‘. Installation Manual Set Auto Set Set Clock Adjust Channels Instructions: Enter-Confirm Setup-Exit Move …† Press [ENTER]. The Adjust Channels menu appears. -
Page 24: Language Settings
2005.12.22 8:4 AM HDD Record Quality You can set the default HDD recording quality to (Approx. time) : [DHR-8100P] HQ (High Quality - 32hrs), SP (Standard Play - 66hrs), EP (Extended Play - 128hrs), or SLP (Super Long Play - 195hrs). -
Page 25: Preferences / Video Settings
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM PREFERENCES / Video Settings Press [SETUP]. Use [œ/√] to select ‘Preferences‘. While ‘Preferences‘ is selected, press [†] to select ‘Video‘. Press [ENTER]. The ‘Video‘ submenu is displayed. Preferences Video Audio Parental Controls Auto Settings Hard Disk Instructions: Enter-Confirm Setup-Exit Move …†... -
Page 26: Preferences / Audio Settings
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM PREFERENCES / Audio Settings Follow the same procedure as ‘Video’ Settings to select ‘Audio’ Settings. Preferences Video Audio Parental Controls Auto Settings Hard Disk Instructions: Enter-Confirm Setup-Exit Move …† Digital Output Use […/†] to select ‘Digital Output‘ while the ‘Audio’... -
Page 27: Preferences / Parental Controls
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM PREFERENCES / Parental Controls Set Parental Level The Parental Controls feature allows you to prevent DVDs from being played based on their ratings or to have certain discs played with alternative scenes. You can set the parental level from ‘Adult’ to ‘Kid safe’. - Page 28 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Change Password While ‘Preferences‘ is selected, press [†] to select ‘Parental Controls‘. Press [ENTER]. The ‘Parental Controls‘ submenu appears. Use […/†] to select ‘Change Password‘ then press [ENTER]. Parental Control Set Parental Level Adult Change Password Parental Country Code Set Hdd Parental Lock Instructions:...
-
Page 29: Preferences / Auto Settings
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Set Hdd Parental Lock It allows you to prevent from being played the title parental locked in HDD video menu. You can set the HDD parental lock as follow. While ‘Preferences‘ is selected, press [†] to select ‘Parental Controls‘. -
Page 30: Preferences / Hard Disk
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM VPS/PDC VPS/PDC is a service provided by some stations to enable you to perform timer recordings precisely even if the broadcaster delays the start time of the program slightly. The time you enter is the VPS/PDC time so this must be correct. - Page 31 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Use […/†] to select the desired option. Press [ENTER] to confirm your selection. Press [SETUP] to exit the menu. Preserve “Preserve” maintains the content of the buffer upon changing the TV channel. Refresh Refreshes the buffer upon changing the TV channel. Jump To Internal This feature enables you to skip to internal which is set in timeshift mode.
-
Page 32: System Information
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM System Information System Information helps service personnel identify key firmware information about your HDD/DVD Recorder in case service is required. System Info System Version System Version Version FD30902DXVL Main Build 3.3.0 Instructions: Micom Software 1.9.5 Enter-Confirm Setup-Exit Loader Version BDR-B2DX Move …†... -
Page 33: On-Screen Display Overview
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM On-Screen Display Overview On-Screen Display Overview The On-Screen Display provides feedback on the status of the HDD/DVD Recorder and/or the currently loaded disc or HDD. To access the On- Screen Display (or OSD), press [DISPLAY]. Displaying Disc Information To display information about the currently loaded disc or HDD: On-screen display operation... -
Page 34: Changing Tv Channels
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Elapsed Shows the elapsed playing time, and skips to the desired time. Press [DISPLAY] during playback. The on-screen display appears on the TV screen. Use […†] to select the ‘Elapsed’ icon on the on- screen display. Press [ENTER] to search by time. The submenu appears. -
Page 35: Dvd Playback
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM DVD Playback DVD Playback Playing a DVD Press [DVD] to set the remote control to operate the DVD. DVD Selected Turn the TV on and select the Actions are now for video input source connected to the HDD/DVD Recorder. Audio system: Turn the audio system on and select the input source connected to the HDD/DVD Recorder. - Page 36 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM • The Zoom function may not work on some DVDs (ex. Jpg..) • The Zoom function does not work in PAUSE mode. Repeat To repeat the currently playing chapter, press [REPEAT]. ‘REPEAT CHAPTER’ appears on the TV screen.
-
Page 37: Playing A Picture Or Music Files
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Playing a Picture or Music files Playing a Picture or Music files Audio CD Playback The HDD/DVD Recorder can play audio CDs on CD- R/RW, DVD+R/RW, DVD-R/RW. Insert the disc and close the tray. The CD Music folder tree appears. Use […†] to select a track or a file, then press [ENTER] or [PLAY]. - Page 38 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM JPEG Playback (HDD Media, DVD) The HDD/DVD Recorder can play JPEG Picture files on a disc such as CD-R/RW, DVD+R/RW, DVD- R/RW, or on HDD Media. Prior to playing Jpeg picture files on disc, insert disc and close the tray. Press [MENU] to bring up the Media Browser and select the media (HDD Media, DVD) you want to play.
- Page 39 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Playing MP3 Files During a Slide Show You can enjoy a slide show while listening to MP3 music files. Prepare the Disc which includes both MP3 and JPEG files. Or copy the files to HDD Media category.
-
Page 40: Time Shifting & Saving
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Time shifting & Saving Time shifting & Saving Time shifting in HDD mode When the HDD/DVD Recorder is turned on or you press the [HDD] button on the remote control or the [DVD/HDD] button on the front panel to move to HDD mode from other menus, the last viewed TV channel will be tuned in and Time shifting starts automatically. -
Page 41: Saving To Hdd
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Saving to HDD Save While viewing a program, press [REC]. This will start saving the segment you are watching. You can navigate forward. During the saving operation, by pressing [REC], you will increase the length of the program you are saving by 15 minutes up to a maximum of 10 hours. -
Page 42: Recording
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Basic Recording Basic Recording Recording to DVD or HDD If you press [DVD] or [HDD], you will be in DVD or HDD mode. You can start recording to DVD or HDD by pressing the [REC] button. (In the case of a DVD, it must be a recordable media in the tray.) Turn on the HDD/DVD Recorder and load a recordable disc . -
Page 43: To Pause The Recording
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM To Pause the Recording Press [PLAY/PAUSE] to pause the disc during recording. To continue recording in DVD mode, press [PLAY/PAUSE] or [REC ( )]. • To quit One Touch Recording, press and hold [STOP] for 5 seconds. •... -
Page 44: Timer Recording Using Videoplus System
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Enter the necessary information for your Timer Recording(s). • œ √ – Moves the cursor left/right. • …† – Changes the setting of the current cursor position. • Press [SETUP] to exit the Timer Record menu. •... -
Page 45: Canceling A Timer Recording
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM The decoded information appears after confirmation. You can go back at any time to change the information by pressing [ENTER]. Select the appropriate input field using […†]. If required, change the information using […†]. If all the information is correct, press the [ENTER] button. -
Page 46: Recording From An External Input
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Recording from an External Input Recording from an External Input Recording from External Components You can record from an external component, such as a camcorder, VCR or Digital Camera, connected to any of the HDD/DVD Recorder’s external inputs. Make sure the component you want to record from is connected properly to the HDD/DVD Recorder;... -
Page 47: Dubbing
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Dubbing Dubbing Dubbing will copy the selected titles (+VR format) with the same properties (title name, duration, index picture, chapter mark) in HDD Videos to DVD or vice versa. The Media BROWSER can not be activated in the middle of dubbing, that means play, stop, any edits does not work. -
Page 48: Media Files Copying
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Dubbing from DVD to HDD Prior to selecting titles for dubbing, you need to insert a disc to be dubbed into the tray. Press [DUB], then 'Media Dubbing' appears. Select 'DVD to HDD'' using [ …† ] and press [ENTER]. - Page 49 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM - Copy Folder : Copy folders including all files in the folder. - Rename Folder HDD Music Create Folder DVIX/ Delete Folder Copy Folder Rename Folder 02_LIVIN ON PRAYER.MP3 Select the title you want to copy using [ …† ]. Then select 'Edit‘...
-
Page 50: Hdd Playback And Editing
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM HDD Playback and Editing HDD Playback and Editing At first, go to ‘HDD Videos’ mode. Press [HDD] to select HDD mode. HDD Selected Actions are now for √ Live Press [MENU] to enter the media browser. While ‘HDD Videos‘... -
Page 51: Editing A Hdd Title
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Editing a HDD title Renaming (Labeling) a Title Follow these instructions to rename a title list name,i.e., to edit the title of a recorded program. Select the title to be labeled using [ENTER]. Select ‘Edit’ using [… †] . Press [ENTER] to go to submenu. - Page 52 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM HDD Videos Name 1. Title PR-01 ---- Parental Lock 2. Title PR-02 ---- Protect 3. Title PR-03 ---- Video Edit 4. Title PR-04 ---- HDD Videos 5. Title PR-05 ---- 6. Title PR-06 ---- Date : 22/06/05 1. Title PR-01 ---- 7.
-
Page 53: Sorting A Hdd Title
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Sorting a HDD title Follow these instructions to sort a title from the Title List by varying the order. Select the title to be sorted using [ENTER]. Then select ‘Sort‘ using [… †]. Press [ENTER] to go to submenu. Select ‘Record Date’... -
Page 54: Disc Manager
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Disc Manager Disc Manager This section explains edit functions for the entire disc and for the titles in the disc. At first, go to ‘Disc Menu’ mode. Press [MENU] to go to ‘Disc Menu’ menu. If you want to display ‘Title Edit’ menu, press [√] in ‘Disc Menu’... -
Page 55: Make Compatible
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Erase the disc Press [Enter] if you want to erase the disc. All Erase the disc existing recordings will Erase the disc? be cleared. All recordings will be lost. Instructions: Enter-Confirm Instructions: Enter-Confirm Move …† DVD±R discs cannot be locked (unlocked) or erased. -
Page 56: Disc Editing In Dvd±R, Dvd-Rw Disc
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Change Disc Name You can rename your disc to any name you choose. The default disc name is ‘MY DVD‘. Use [œ/√] to select ‘Change Disc Name‘. Press [ENTER] as shown on the screen. The Keyboard Menu appears. Use [œ... -
Page 57: Title Editing
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Title Editing You can manage the titles on your DVD±R/±RW discs using the Title menu. At first, go to ‘Title Edit’ mode. Press [MENU] to go to ‘Disc Menu’ menu. Select the desired title you want to manage using […†]. -
Page 58: Advanced Disc Editing
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Record Option To set DVD±R and DVD±RW recording options: Select ‘Record Options’ using [œ √] and press [ENTER]. Select your preferred record options for each disc type: For DVD±R The last recorded title : Allows you to append your new recording to the end of your last recording, or record it as a new title. - Page 59 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM desired chapter number and then press [ENTER]. Edit Chapters You can add a chapter marker anywhere in a title during playback. Once the chapter is marked, you can use the chapter search feature as described above. You can add/delete chapter markers or delete all chapter markers in a title.
-
Page 60: Troubleshooting
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Troubleshooting Troubleshooting Check the following guide for the possible cause of a problem before contacting customer support. Symptom Cause No power. The power cord is disconnected. No picture. The TV is not set to receive HDD/DVD Recorder signal output. -
Page 61: Moisture Condensation
DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM Symptom Cause Cannot record or did not The remaining blank space on the record successfully. disc is insufficient. The source you are trying to record is copy-protected. When setting the recording channel, the channel is tuned on your TV’s tuner. -
Page 62: Technical Specifications
[DVD] (Approx.) 1 hour (HQ mode), 2 hours (SP mode), 4 hours (EP mode), 6 hours (SLP mode) [HDD] (Approx.) [DHR-8100P] 32 hours (HQ mode), 66 hours (SP mode), 128 hours (EP mode), 195 hours (SLP mode) [DH-6100P]16 hours (HQ), 33... - Page 63 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM ˘ ` 62 mac001 1200DPI 100LPI...
- Page 64 DG-M22-12D1P-XA(GB) 2005.12.22 8:4 AM ˘ ` 63 mac001 1200DPI 100LPI...
