Look 313 Media Features
SnapShot Button
1
You can press the snapshot button to take the images.
Lens
2
-Adjust the focus by twisting the lens.
-Move upward or downward to adjust the view angle
Speaker
3
Play the music through this delicate speaker
USB to PC/NB
4
Connect the mini-B USB cable to the computer in order to
activate the Look 313 Media
USB2.0 Hub
5
Connect to the USB device
2-Channel Audio
6
Connect to the Microphone and headset
-1-
English
Advertisement
Related Manuals for Genius LOOK 313 MEDIA
Summary of Contents for Genius LOOK 313 MEDIA
- Page 1 -Move upward or downward to adjust the view angle Speaker Play the music through this delicate speaker USB to PC/NB Connect the mini-B USB cable to the computer in order to activate the Look 313 Media USB2.0 Hub Connect to the USB device...
- Page 2 Insert the Look 313 Media Installation CD into the CD-ROM drive. Double click on the CD-ROM drive. Click on the file folder of “Look 313 Media Driver OSX 1.0”. Click on “Look 313 Media Driver Install” then simply follow the on-screen instructions.
- Page 3 USB connector to your computer’s USB port. Meanwhile, this USB connector has the hub feature. So, you can connect the USB device to it as long as it is connected to the computer.
- Page 4 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Look 313 Media”...
- Page 5 English Snapshot mode Video Clip Mode Security monitoring system Exit the Genius UI Camera Control NOTE In the “camera control section”, you can personalize your camera settings for different circumstances.
- Page 6 - You can flip the image horizontally or vertically by choosing “Image Mirror” or “Image Flip”. - When the light is not sufficient, you may click on “Low Light” to get a clear image. You can adjust different values for different circumstances and environment When you want a still image capture, you can drag the bar to select a resolution size you want.
- Page 7 English Select the correct frequency according to the country where you are using the web camera. (Before doing this, you will need to select “Indoor”.) -If your web camera is located in backlight position, you may click “Backlight compensation” to get a sharper image.
- Page 8 There will be 27 different kinds of video effects/frames for you to select. The effects can also be applied to the video chat software, like MSN Messenger. You can directly connect to this effect page from the web camera settings in the video chat software.
- Page 9 English Auto Change: Once you choose this, the 27 kinds of video effects will take turns from the first one to the last one. No effects & frame: Once you choose this, the video effects will be determinate. In this section, you can enable the “Zoom” function. Please select “Enable Zoom”...
-
Page 10: Preview Mode
English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward Move the image to the left... -
Page 11: Snapshot Mode
There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mode... - Page 12 English Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes. 4. Video Clip Mode You can record real-time image in this section.
- Page 13 5.Security Monitoring System This function records any movements that appear in front of your monitor automatically. It can also record anytime until the HD is full. If there’s no movement, it will shut down automatically after four seconds or otherwise it will be active when detecting new movement.
-
Page 14: Volume Adjustment
6. Volume adjustment After installing the Genius application, you will find the icon on the right-hand side on the task bar. You can click on it to pop out the window as below to adjust the volume of the audio devices. - Page 15 Mute: Select it to disable the voice. Volume: Scroll the bar to control the volume Balance: Scroll the bar to control the volume of the right and left speaker. Speaker Volume You can adjust the speaker’s volume or the microphone in this section.
- Page 16 English MSN Messenger, Yahoo Messenger, AOL MSN Messenger a. For live video function, you’ll need MSN Messenger version 6 or later. If you don’t have it, please refer to the website: http://messenger.msn.com to download. b. Now, get to sign onto MSN Messenger service.
- Page 17 Sign onto AOL Instant Messenger. c. Click on “Show Messenger Lists” and choose the friend you want to start with video chat. d. Your friend will then receive an invitation message. When your friend confirms to talk, the video chat will start.
- Page 18 Internet. 1. Installing the DDPlayCam Software a. Insert the Look 313 Media Installation CD into the CD-ROM drive. b.The Autorun screen will bring up the installation screen. Click on “DDPlayCam” then simply follow the on-screen instructions. Once finished, DD ThemeParty , DD PlayCam @live and DD PrintCenter are ready to go.
- Page 19 Open DD PrintCenter to print snapshots. Close Window Close DD ThemeParty 2.0. Help Open DD ThemeParty 2.0 user guide. Minimize DD PlayCam to a button on the Minimize Window taskbar. Mute Turn off audio. Send a message to DD PlayCam technical Technical Support support.
- Page 20 Load the instant messenger software For using the DD PlayCam @live with your instant messenger software, you need to go to the section of the camera setting in your instant messenger software. Whatever the web camera uses for the instant messenger, you have to change the device to “DDPlayCam”.
- Page 21 2.0 virtual camera driver, stream data can be transmitted synchronously by the same procedures to connect to other peers, so that the alternative peer can see the process as you use the software. If you want to stop the data transmission, just press the button again on the interface of DD ThemeParty 2.0.
- Page 22 English Step 1: Select Paper Size and Layout or Load Document DD PrintCenter provides you three standard paper sizes. They are A4, 4*6 and 3*5 inch styles. Each paper size contains three types of layout templates. First, you select a paper...
- Page 23 Step 2: Choose and Load Photo You can see an empty layout template and thumbnail pictures that you captured and saved in the DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template.
- Page 24 DD PrintCenter document. For the next time, you can use the Load button to open the PCF file for further editing. You can also use Save as a function to save a file as the format you indicated. -24-...
- Page 25 NOTE For further information about the DDPlayCam software, please go to the task bar and follow “Start” Click “Program” Choose “DDPlayCam” You can click Click “DD ThemeParty 2.0 Technical Support”; “DD ThemeParty 2.0User Guide”...
