- Page 1 SYSTEMS CORP. Version:1.0 Total 14 Pages (Cover Page included)
-
Page 2: Revision History
SP-P110 uide Revision History Version Date Changes Official Release 1．0 Version: 1.0 Page 1/13... -
Page 3: Table Of Contents
SP-P110 uide Table of Contents Revision History ……………………………………………………………… ……..1 Table of Contents………………………………………………… ………….2 Getting Started………………………………………………… ……….……………..3 Conventions Used in this Guide………………… ………...……………….3 Safety Precautions……………………………… ………………...………..3 Chapter1. How to Handle Defective Returns………………… ……………………….4 1.1 Overview……………………………………………………………….4 1.2 Problems………………………………………………………………..5 1.2.1 Power LED (indicator) Unlighted………………...……………..6 1.2.2 Does not work or one channel no sound……………………….…..7... -
Page 4: Getting Started
SP-P110 uide Getting Started Conventions Used in this Guide Pay Special Attention: Instructions that are important to remember and may prevent mistakes. Attention Caution: Information that, if not followed, may result in damage to the product. Safety Precautions The following precautions should be observed in handling the speaker described in this guide: Place the speakers on a flat level and stable surface. -
Page 5: Chapter1. How To Handle Defective Returns
SP-P110 uide Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective Speakers from Customers Verifying problems& Proceeding necessary tests Functioning NG Analyzing possible Malfunction causes Deciding & proceeding Functioning OK the rectification methods Functioning NG Replacing necessary... -
Page 6: Problems
SP-P110 uide 1.2 Problems Item Problem descriptions 1.2.1 Power LED (indicator) unlighted 1.2.2 Does not work or one channel no sound 1.2.3 Noise Version: 1.0 Page 5/13... -
Page 7: Power Led (Indicator) Unlighted
SP-P110 uide Please follow the numbered sequence marked within parenthesis given in individual Flow chart, in that this is the best-recommended sequence to rectify the problems. Attention 1.2.1 Power LED (indicator) unlight Problem Power LED (indicator) unlight Secondary wire Diode D1.2.3.4... -
Page 8: Does Not Work Or One Channel No Sound
SP-P110 uide 1.2.2 Does not work or one channel no sound Problem Does not work or One channel no sound Analyze and Defective Broken or Defective IC Identify the Audio cable Short circuit Causes Solutions Replace Check solder Check and replace... -
Page 9: Chapter2. Specifications
SP-P110 uide Chapter 2. Specifications DESCRIPTION UNIT NOMINAL LIMIT INPUT SENSITIVITY AT 10% 480+/-50 DISTORTION（1 KHz）AT 1W <3 OUTPUT POWER AT 10% DISTORTION 0.5+/-0.15 ≥55 S/N RATIO ≥40 CHANNEL SEPARATION FREQUENCY RESPONSE (DOWN 3dB) (LOW) 150+/-30 (HIGH) 20+/-1 ≤2 HUM LEVEL (AT VOL. -
Page 10: Chapter3. Block Diagram
SP-P110 uide Chapter 3. Block Diagram Version: 1.0 Page 9/13... -
Page 11: Chapter4. Exploded View
SP-P110 uide Chapter 4. Exploded View Version: 1.0 Page 10/13... -
Page 12: Chapter5. Part List
RS Part No. Part No. Right speaker: 2300040116001-01 Signal Wire 6.3',Green Pin 2301090150001-02 Speaker Cable,5.9',BLACK Color,Zero to Zero 4102B30016T02-01 Screw,B PT3.0x16mm,Black 0114HIPS00090G01 Rear Cover(R),SP-P110,Black Color,AC Type 2222400800001-01 Transormer,230V,8V/250mA 4102N30010B03-01 Screw,PWB%%C3x10mm,Black 08100104BC112-01 Speaker ,5090,4 , 1W,Magnetically Shielded 0102HIPS02030G01 Front Panel(R),SP-P110,Black Color 9101086078112G01... -
Page 13: Chapter6. Important Notes
SP-P110 uide Chapter 6. Important Notes 6.1 Packing requirement for sending the PCB assembly by post PCB assembly is a kind of sophisticated electronic circuit board. Well packing Will be required when sending them by post. *Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity. -
Page 14: Chapter7. Circuit Schematic
SP-P110 uide Chapter 7. Circuit schematic Version: 1.0 Page 13/13...
