YOUR YOUR CAMERA CAMERA Camera Front Camera Sides Multi-meter finder AF Area Mode button Drive mode/Self-timer Exposure Mode button selector Exposure Compensation Sync terminal button IEEE 1394 port IEEE 1394 port IEEE 1394 port Self-timer LED AC Adapter AC Adapter...
Image LCD OK button Cancel button Microphone Menu button CANCEL Tag/Record button Navigate switch MENU Flash Sync Mode button TAG/ RECORD Custom Setting Menu button Back Status LCD panel ISO button Remote Release Accessory port Auto Exposure/Flash Exposure bracketing button...
Camera Top Camera Bottom AF Area Mode button Power/LCD Panel Illumination switch Shutter Release button Power Switch Lock release Exposure Compensation button Exposure Mode (MODE) button Tripod mount Top Status LCD panel Data plate label Diopter Adjustment knob Battery/PC Card door...
ISO/Bracketing information/ Flash sync mode Custom Setting Personal computer connection ISO Setting mode SLOW REAR Bracketing bar graphs Auto Exposure/Flash Custom setting CUSTOM Exposure Bracketing Card present AUTO White Balance Microphone Frame number Battery level Frames remaining on PC Card...
Page 8
Image LCD/Menu Bar Folder icon Menu icon White Balance icon Video icon (appears if Video is enabled using Main Menu) Contrast icon...
Page 9
Displaying and Navigating the Menu Bar Turn the Image LCD on. There are two ways to turn the Image LCD on: Press the OK button to turn the Image LCD on Press the Menu button to turn the Menu bar on.
Page 10
Making a Menu Selection Navigate the Menu bar until the Folder or Menu icon is highlighted. A dropdown menu lists the available options. Press the top or bottom of the Four-way switch to highlight an option. Press the OK button to activate the option.
Page 11
Disable Region of Interest box (Zoom mode): Press the Cancel button. Navigate through images in all Display modes except Press the left or right side of the Four-way switch. Zoom mode when Region of Interest box is on: Navigate the Menu bar and display menus: Press the left or right side of the Four-way switch.
Plug the power cord into a wall outlet. You will need to charge a battery before using it Insert one or two batteries into the slots on the top for the first time, then whenever it is low. of the battery charger. (For one battery, you can use either slot).
Page 13
INITIAL SETUP Battery, PC Card and Lens Turn the camera off by pressing the Power Switch Lock release and rotating the Power switch counter-clockwise. Lift the latch assembly on the Battery/PC Card door and turn it counterclockwise to open the door.
Page 14
S E R IA L V ID Turn the latch assembly clockwise and return it to its flat position to close the door. Position the lens in the Turn the camera on by camera’s bayonet mount so that pressing the Power Switch...
Page 15
AC Adapter When working indoors, you can Select the power cord conserve your battery and Plug the AC adapter into power your camera using the with the universal plug the round connector on the AC adapter provided with your that is appropriate for side of the camera.
Time and Date Highlight the Menu icon and choose Main Press the left or right side of the Four-way Menu from the dropdown menu. switch to sequence through the numeric fields. Choose Time/Date from the Main menu. Press the top or bottom of the Four-way The Date/Time screen appears.
GENERAL SETUP White Balance There are two types of white balance: preset (which provides preset settings) and custom (which is based on a specific image). Refer to the User’s Guide for information on Custom White Balance. Auto - Flouresc Highlight the White Balance icon.
Page 18
Select a card if two are inserted. Folders Select a folder. Images are stored in folders on a PC Card. You can specify a folder to hold subsequently captured images. Highlight the Folder icon. The Folder menu appears. It varies, depending on whether one or two cards are inserted.
View total number of camera actuations Default folder for image capture Video format Make your selection and change settings, as Video signal needed. Use the same technique described for setting the time and date to change the Battery Save Onset and Display Off Time.
Basic Settings Set the lens to its Set the Focus Mode minimum aperture selector to S for (f/16). Single Servo AF. Slide the lock lever towards the aperture ring so that the white dot on the tab aligns Press and hold the AF with the orange dot.
Page 21
CAPTURING IMAGES While pressing the Lightly press the lock release, set the Shutter Release Metering System button. selector for 3D Color Matrix Metering. Press and hold the Confirm that a green Exposure Mode • appears inside the button and rotate the...
Reviewing Images Selecting a Display Mode You can review images on the active PC Card in one of five Display modes: Press the OK button to turn the Image LCD on Single Image mode - displays 1 image. or, if a menu is displayed, press the Cancel or Zoom mode - zooms to 1:3 or 1:1.
Enabling/Disabling the Region of Interest Box in Zoom Mode In Zoom mode you can pan or zoom when the Region of Interest box is enabled or navigate to a different image when it is disabled. Press the OK button to enable, or the Cancel...
Display Contrast Tagging Images or Recording Sounds You can tag images that you do want to You can adjust the contrast on the Image LCD delete or record sounds to be associated with (not on the actual images): an image.
Deleting Multiple Images You can delete all images in a folder, all untagged images in a folder, all images on a PC Card, or all untagged images on the card. Tag any images that you want to delete DO NOT (if you plan to use a tagged option).
