1.2 Specifications

Platform:
CPU:
Chipsets:
VGA:
Memory:
IDE:
Floppy Port:
Audio:
LAN:
Hardware Monitor:
PCI slots:
AGP slot:
AMR slot:
USB 2.0:
ASRock I/O :
BIOS:
OS:
Micro ATX form factor (9.6" x 7.5", 24.4 x 19.1 cm)
Socket 478 for Intel
North Bridge (GE Pro-HT):
SiS 651 chipset, FSB @ 533/400MHz,
supports Hyper-Threading Technology (see CAUTION 1);
North Bridge (GE Pro-M2):
SiS 533/333 chipset, FSB @ 533/400MHz;
South Bridge: SiS 962L chipset, supports USB 2.0, ATA 133
SiS Real 256E, 4MB-64MB VRAM (share memory)
2 DDR DIMM slots: DDR DIMM1 and DDR DIMM2
support PC1600 (DDR200) / PC2100 (DDR266) /
PC2700 (DDR333), Max. 2GB;
IDE1: ATA 133 / Ultra DMA Mode 6;
IDE2: ATA 133 / Ultra DMA Mode 6;
Can connect up to 4 IDE devices
Supports 2 floppy disk drives
5.1 channels AC'97 Audio
Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
CPU temperature sensing (ASRock U-COP);
Chassis temperature sensing;
CPU overheat shutdown to protect CPU life (ASRock U-COP)
(see CAUTION 2);
Voltage monitoring: +12V, +5V, +3V, Vcore;
CPU fan tachometer; Chassis fan tachometer
2 slots with PCI Specification 2.2
1 universal AGP slot, AGP 2.0 compliant,
supports 3.3V / 1.5V, 4X / 2X / 1X AGP card
1 slot, supports ASRock MR card (Optional)
4 default USB 2.0 ports and 1 extra set of header for 2 additional
USB 2.0 ports upgrade (see CAUTION 3)
PS/2: 1 keyboard port / 1 mouse port;
1 RJ 45 port; 4 rear default USB 2.0 ports;
1 VGA port; 1 parallel port: ECP/EPP support;
Audio Jack: Line Out/ Line In/ Microphone + Game port
AMI legal BIOS; Supports "Plug and Play";
ACPI 1.1 compliance wake up events;
Supports jumperfree; SMBIOS 2.3.1 support;
CPU frequency stepless control
(only for advanced users' reference, see CAUTION 4)
®
Microsoft Windows
® ®
Pentium 4 / Celeron
®
98SE / ME / 2000 / XP compliant
®
processor
