CyberPower CPS1500AVR User Manual

Cyberpower systems power supply user manual cps1500avr
Hide thumbs Also See for CPS1500AVR:
Table of Contents

Advertisement

Quick Links

User Manual for:
CPS1500AVR UPS
TM
and PowerPanel Plus Software
ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT:
www.cyberpowersystems.com/1500FAQs.htm

Advertisement

Table of Contents
loading

Related Manuals for CyberPower CPS1500AVR

Summary of Contents for CyberPower CPS1500AVR

  • Page 1 User Manual for: CPS1500AVR UPS and PowerPanel Plus Software ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT: www.cyberpowersystems.com/1500FAQs.htm...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Description Determining Power Requirements Hardware Installation Guide Software Information PowerPanel Plus Installation PowerPanel Plus User Guide Thank you for purchasing a and benefits of this Uninterruptible Power System (UPS), please read and follow all installation and operation instructions completely. This UPS is designed to provide guaranteed power protection for connected electronic equipment.

  • Page 3: Description

    Ports protect standard modem, fax, telephone line or network cable. 12. 10’ Power Cord Heavy-duty long reach power cord allows you to put power where you need it. 13. Resettable Circuit Breakers Resettable circuit breakers provide optimal overload protection. CPS1500AVR...

  • Page 4: Hardware Installation Guide

    INSPECTION The box should contain the following: (1) PowerPanel Plus Software Disk;(1) PowerPanel Software Disk; (2) Serial Interface Cable (DB-9); (1) Telephone Cable; (1) User Manual; (1) Warranty Registration Card; (1) UPS Unit; (2) Rack mount Brackets; (2) Stands. HOW TO DETERMINE THE POWER REQUIREMENTS OF YOUR EQUIPMENT 1.
  • Page 5 Recharge the battery every 3 months to prolong battery life SOFTWARE INSTALLATION INFORMATION The CPS1500AVR comes with two built-in serial ports that allow two computers to be shutdown by the UPS. The serial ports are labeled Serial Port I (PRIMARY) and Serial Port II. Serial Port I is for the primary computer.
  • Page 6 The Primary computer (with PowerPanel Plus installed) is the computer that you will use to control the UPS and make any changes to the operation of the UPS. The Secondary computer (with PowerPanel installed) is unable to exhibit any control over the UPS. When there is a power failure, the Primary computer will start to shutdown after a user controlled delay.
  • Page 7 3. Remove the check mark from the box labeled “UPS is Installed On:”. 4. Click OK. 5. Acknowledge the message that the UPS service is in an unknown state. 6. Exit to the desktop. 7. Shutdown the computer. 8. Turn off the UPS and unplug it. Guaranteed Uninterruptible Power System CPS1500AVR...
  • Page 8 9. Connect the serial interface cable to the UPS and an open serial port on the back of the computer. You must use the serial cable that was provided with the unit. 10. Plug the UPS into and AC outlet, turn the UPS on and start your computer. 11.
  • Page 9 UPS will run until the low battery signal is received (2 minutes of backup time remaining) and then start the shutdown process. 5. Time Between Power Failure and Initial Warning - This setting determines the delay between when the power fails and the first audible alarm. Guaranteed Uninterruptible Power System CPS1500AVR...
  • Page 10 6. Delay between warning messages - User adjustable setting for the delay between the audible alarms that occur during a power failure. 7. UPS Self-test - Allows the user to test the UPS without having to unplug the unit from the wall. When the run button is clicked, the unit will switch to battery power and the unit will beep.
  • Page 11 When your computer restarts, the PowerPanel software will appear on your screen for a few seconds, and then minimize. It will appear as a blue and white battery icon, located in the system tray, near the clock. Guaranteed Uninterruptible Power System CPS1500AVR...
  • Page 12 FOR WINDOWS XP (Home and Professional) 1. Click on Start then click on Control Panel. 2. Double-click on Power Options, then click the UPS tab. 3. Set the manufacturer to None. 4. Exit to the desktop and then shutdown your computer. 5.
  • Page 13 (refer to page 8). Click the red run button. The unit will cycle to battery and emit an audible beep. With the software self-test, the unit will switch back to AC power automatically. Guaranteed Uninterruptible Power System CPS1500AVR...
  • Page 14 REPLACING THE BATTERY CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. Service the battery under the supervision of personnel knowledgeable of batteries and their precautions. CAUTION! Use only the specified type of battery. See your dealer for replacement batteries. CAUTION! The battery may present the risk of electrical shock.

  • Page 15: Led Indicators

    Long Beep Overload - Turn the UPS off and unplug at least one piece of equipment. Wait 5 seconds, reset the circuit breakers and restart the UPS. Surge Protection Malfunction - Power surge has damaged the unit. Please contact CyberPower Systems. Set/Up None Electrical Wiring Fault - Indicates a wiring problem such as a bad ground, missed ground or reversed wiring within the AC outlet.

  • Page 16: Specifications

    Wait 10 seconds, reset the circuit breaker and then turn the UPS on. Allow the unit to recharge for at least 4 hours. Contact CyberPower Systems at tech@cyberpowersystems.com Recharge the battery by leaving the UPS plugged in.

  • Page 17: Warranty

    In purchasing a CPS1500AVR in the United States or Canada, the original end user receives a Limited Warranty and CyberPower's Power Control Guarantee from CyberPower Systems (USA), Inc. (for ease of reading, referred to as "CyberPower"). The Limited Warranty and the Power Control Guarantee are intended to be the initial end-user's exclusive rights and remedies.
  • Page 18 Connected Equipment or damage to such equipment so that CyberPower’s maximum liability shall be reduced to reflect all such other payments or sources of recovery: CyberPower CPS1500AVR - $500,000 4. If CyberPower replaces the connected equipment or pays to the Initial Customer the Agreed Damage Amount, the Initial Customer shall transfer all item(s) to CyberPower without warranty by the Initial Customer, but free of lien or other interest.
  • Page 19 Contact Information: CyberPower's address is 5555 12th Ave East, Suite 110, Shakopee, MN 55379 and its phone number is (952) 403-9500. CyberPower is the warrantor under this Limited Warranty. You may also contact CyberPower on the Internet at www.cyberpowersystems.com. Guaranteed Uninterruptible Power System CONDITIONS COMMON TO THE LIMITED CPS1500AVR...
  • Page 20 CAUTION: Any changes or modific ations not expressly approved by the guarantee of this device could void the user’s authority to operate the equipment. Entire contents copyright All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel and PowerPanel Plus are trademarks of CyberPower Systems (USA), Inc. For more information, contact us at: CyberPower Systems (USA), Inc.
