Inductive Proximity Sensor
E2KQ-X
Proximity Sensor with Easy Sensing
Distance Adjustment and Teflon* Coating
Effective Oil and Chemical Resistance
• Oil and chemical-resistant Teflon case.
• Sensitivity adjuster ensures easy sensing distance
adjustment according to the sensing object.
• Incorporates a cord connector with an indicator pro-
viding high visibility.
* Teflon is a registered trademark of Dupont Company and Mitsui Du-
pont Chemical Company for their fluoride resin.
Ordering Information
Shape
Sensing distance
Unshielded
M18
* NC models available (E2KQ-X10ME2)
Characteristic data (typical)
Sensing Distance vs. Sensing Object
15
#d
t=3
mm
X
Grounded metal
10
Ungrounded metal
5
0
0
10
20
30
40
50
Side length of sensing object d (mm)
E2KQ-X
Operating
Output
status
DC 3-wire
6 to
NO *
NPN
10 mm
Sensing Object Thickness and Material vs. Sensing Distance
15
10
5
Glass
Phenol resin
0
60
70
80
0
Model
E2KQ-X10ME1
#50
t
X
Grounded metal
Ungrounded metal
Glass
Phenol resin
Wooden plate
Acrylic resin
5
10
15
20
25
Sensing object width t (mm)
30
D-179
