Programming Example

7-3-28 Displaying the Cycle Time

1,2,3...
7-4

Programming Example

7-4-1

Preparatory Operations

1,2,3...
to move the cursor to the next digit. The following table shows the setting
ranges for each value.
Year Month Day
00 to 99 01 to 12 01 to 31
4. Press the WRITE Key to write the new value.
Press the CLR Key to return to the initial display.
This operation is used to display the current average cycle time (scan time). It
is possible only in RUN or MONITOR mode while the program is being exe-
cuted.
RUN
OK OK
1. Press the CLR Key to bring up the initial display.
2. Press the MONTR Key to display the cycle time.
There might be differences in displayed values when the MONTR Key is
pressed repeatedly. These differences are caused by changing execution
conditions.
Note "MS" indicates milliseconds.
This section demonstrates all of the steps needed to write a program with the
Programming Console.
Use the following procedure when writing a program to the CQM1H for the
first time.
1. Set the Programming Console's mode switch to PROGRAM mode and
turn ON the CQM1H's power supply. The password input display will ap-
pear on the Programming Console.
MONITOR
RUN PROGRAM
2. Enter the password by pressing the CLR and then the MONTR Key.
CLR
Hour Minute
00 to 23 00 to 59
TIM
11:04:32 FRI(5)
WRITE
MONITOR PROGRAM
No
SCAN TIME
MONTR
<PROGRAM>
PASSWORD!
<PROGRAM>
MONTR
Section 7-4
Second Day-of-week
00 to 59 0 to 6
(SUN to SAT)
99 03 19
– –
012.1MS
179
