Sennheiser Audiology SET 810 Infra-red Specifications

Set 810 Infra-red
Audiology |
Description
The Set 810 system consists of a TI 810 infra-red stereo transmitter and
an RI 810 infra-red stereo stethoset receiver. The TI 810 transmitter is
simply connected to the headphone socket of a television set or hi-fi sys-
tem. The stethoset receiver has a large, easy-to-use volume control.
Features
Stereo/mono selector switch
j
Easy, intuitive operation due to special ergonomic design
j
Switchable compression ensures excellent speech intelligibility
j
Individually adjustable to the listener's hearing
j
Very comfortable to wear due to individually adjustable earbow pressure
j
Automatic on/off function
j
Transmitter with integrated charging compartment for spare accupack
j
Receiver quick charging on the transmitter
j
Delivery includes: 1 RI 810 stethoset receiver, 1 TI 810 transmitter,
j
1 BA 151 accupack, 1 plug-in mains unit, 1 spare set of
ear-cushions, 1 audio connection cable with 3.5 mm/
1/4" jack plug, 1 SCART adaptor
Recommended Accessories
BA 151 Spare accupack
j
RI 810 Additional stethoset receiver
j
Transmitter (optional)
j
TI 810 (European version)
TI 810-UK (UK version)
TI 810-120 (US version)
MKE 800 TV, TV microphone
j
L 151-2 Charger
j
Replacement Parts
Replacement ear-cushions
j
(black, firmer version)
Replacement ear-cushions
j
(transp., softer version)
Product Variants
Set 810-UK as Set 810, but with UK plug-in
j
mains unit and MKE 800 TV microphone
Set 810-120 as Set 810, but with US plug-in
j
mains unit, audio connection cable with RCA phono
connector and MKE 800 TV microphone
Cordless Infra-Red Stethoset System
for TV Sound Transmission
Technical Data – System
Colour ........................................................................... red/anthracite
Modulation.......................................................................... FM, stereo
Receiving frequencies................................................... 2.3/2.8 MHz
AF frequency response............................................ 40 Hz – 15 kHz
THD ............................................................................< 2 % at 120 dB
Signal-to-noise ratio ..........................................................60 dB A
Range .............................................................................................12 m
Covered area............................................................................... 60 m
Technical Data – Transmitter
Audio input ............................................ 3.5 mm jack, stereo/mono
Microphone socket ............................................ 2.5 mm jack, mono
Charging time (receiver accupack) .............................. approx. 4 h
Charging time (spare accupack)................................. approx. 14 h
Power supply ................................................ 24 V DC via mains unit
Weight (w/o accupack)................................................ approx. 94 g
Dimensions ............................................ Ø 150 mm, height: 47 mm
Technical Data – Receiver
Max. SPL ................................................................................ > 125 dB
Operating time .............................................................................> 4 h
Power supply ................................... 2.4 V DC via BA 151 accupack
Weight (w/o accupack)................................................ approx. 51 g
Dimensions ........................................................ 230 x 125 x 25 mm
Cat. No. 004146
Cat. No. 004985
Cat. No. 004983
Cat. No. 004991
Cat. No. 004993
Cat. No. 004995
Cat. No. 004457
Cat. No. 037080
Cat. No. 040949
Cat. No. 004989
Cat. No. 004993
Cat. No. 004981
rms
2
