Sennheiser MD 46 Technical Data

MD 46
MD 46 Handheld Dynamic ENG/EFP Microphone
Designed for audio journalists and field reporters, the Sennheiser MD 46 offers a host of
advantages. Its extended frequency response provides clarity that exceeds any comparable
mic in its class, and it's dimensions and weight ratio lend a completely comfortable feel. Add
the fact that it's rugged enough to stand the strain of ENG/EFP, and you have a dynamic winner
Features—Bene ts
• Rugged all metal body
• Extremely low sensitivity to handling noise
• Very insensitive to pop and wind noise
• Uniform frequency response
• Excellent sound quality
• Integral microphone clamp thread
Technical Data
Acoustic principle
Frequency response
Pick-up pattern
Rejection at 1 kHz at 180 degrees
Sensitivity at 1kHz
Nominal impedance at 1kHz
Min. terminating impedance
Magnetic field at 50 Hz
Dimensions in inches
Weight
Optional Accessories
Table stand
Microphone clamp
Foam windsheild
Architect's Speci cations
Cardioid reporter's microphone, frequency response 40–18,000 Hz, sensitivity
(free field, no load) 1.8 mV/Pa ± 2.5 dB at 1 kHz, nominal impedance 200 Ω, min. terminating
impedance 200 Ω, dimensions 11.92 x 9.84 inches, weight approx. 12.7oz.
pressure gradient transducer
40–18.000 Hz
cardioid
>20dB
2.0mV/Pa+-2.5dB (= - 54dB mit 0dB=1V/Pa)
(= - 74dB mit 0dB=1V/ubar) (USA)
350 Ω
1000 Ω
<=1uV/uT
1.92 x 9.84
12.7oz
MZT 100
MZQ 800
MZW 65Pro (velour foam),
MZW 4032 (w/ ID color bands)
MZW 5000 (w/ ID color bands)
MZW 1
MD 46
