EW122PG2
Wireless |
Systems
Kit Includes:
1 EK100G2 camera-mount receiver
1 ME4 ( cardioid pick-up pattern)
1 camera adapter
4 AA batteries
Operating instructions
1 CL100 XLR cable
1 CL1 jack cable
General Description
The 122-pG2 system is ideal for video recording theatre performances and pre-
sentations. The ME4 clip-on microphone is virtually invisible and has excellent
feedback rejection. The extremely small SK100G2 bodypack transmitter as well as
the EK100G2 camera-mount receiver feature 9 frequency banks with 4 frequency
presets each for direct channel selection and are ready for immediate use.
Features
• 1,440 tunable UHF frequencies for interference-free reception
• Absolutely reliable transmission and extended range due to high RF
output power
• High-quality true diversity reception
• Pilot tone squelch for eliminating RF interference when transmitter is turned off
• Automatic frequency scan feature searches for available frequencies
• Transmitter and receiver with rugged metal housings
• Receiver features user-friendly menu operation via backlit display
• Lock function avoids accidental changing of settings
• HDX compander for crystal-clear sound
• Transmitter and receiver feature "Low Battery" indicators
• Mute function for the transmitter
• Wide range of accessories adapts the system to any requirement
EK100G2
Fixed
Antenna
Backlit Display
Belt clip
EK100G2—Portable non-diversity receiver. 1/8" locking connector, and auto
scan feature.
* Illustrations do not show camera adapter
59.553"
(1512.65 mm)
1/8" TRS Connector
ø 0.13"
(3.4 mm)
59.553"
(1512.65 mm)
ø 0.08"
(2.2 mm)
1/8" TRS Connector
Clip
e
2.50"
(63.7 mm)
1/8" audio output
unbalanced"
1.250"
(31.75 mm)
Battery
Door
Foam Windscreen
Clip
ÿ.900"
(22.86 mm)
EK100G2, ME4
SK100G2
1.250"
(31.75 mm)
Foam Windscreen
ÿ.900"
(22.86 mm)
ME4—Electret condenser lavaliere microphone. Cardioid polar
pattern.
EW122PG2
Power ON
Low Battery Status
RF Status
Channel select
& program setting
Backlit Display
Fi
Anten
Belt clip
