INSTALLATION GUIDE
INSTALLATION GUIDE
MITEL 6940/6940w SIP PHONE
A
Setup
Network Jack
(if inline power provided,
do not install the power adapter)
Other Network Devices
B
Stand Attachment
30°
60°
(Optional) To Other
Network Device
Ethernet Cables
30°
The Mitel word and logo are trademarks of Mitel Networks Corporation, including itself and subsidiaries and authorized entities.
Any reference to third party trademarks are for reference only and Mitel makes no representation of the ownership of these marks.
Mitel's Power over Ethernet (PoE) Powered Device (PD) products are covered by one or more of the U.S. patents (and any foreign patent
counterparts thereto) identified at Mitel's website: www.mitel.com/patents.
For more information on the PD patents that are licensed, please refer to www.cmspatents.com.
© Copyright 2024, Mitel Networks Corporation. All Rights Reserved.
To Network
C
USB Headset Connection (Optional)
60°
48V
0.54A
Power Adapter
Connection
Power Adapter
