Basic operation (Continued)
5
Projector placement angle adjustments
The placement angle and the height of the projected image can be adjusted by the foot
adjuster.
q Lift up the front of the projector to
the desired angle, then press the
foot adjuster release button.
The foot adjuster extends. Release the
button to lock the position.
w To fine adjust the angle, twist the
foot adjuster.
e To adjust the horizontal angle, use
the right and left tilt adjusters.
• To stow the foot adjuster, hold up the projec-
tor while pressing the foot adjuster release
button, then slowly lower the projector.
6
Adjusting the screen size and focus
q Use the zooming lever to adjust the screen size.
w Use the focusing ring to adjust the focus.
7
Adjusting the volume with the
The speaker volume can be adjusted when an audio signal is being input.
Notes
• Lamp characteristics may rarely cause the brightness to fluctuate slightly.
• A lamp is consumable item. If used for extended periods, images will appear dark, and
the lamp could burn out. This is characteristic of a lamp, and is not malfunction. (The
lifetime of the lamp depends on conditions of use.)
• The LCD panel is made using extremely advanced technology. There may be black spots
(pixels that do not light) or bright spots (pixels that are constantly lit) on the panel. These
are intrinsic characteristics of the technology and are not malfunctions.
• Although this projector supports a wide range of RGB signals
supported by this projector (XGA) will be expanded or shrunk, which will affect image
quality slightly. To view high-quality images, set the computer's external output to XGA.
• With some models of computer having LCD displays or the like, displaying images
simultaneously on the projector and the monitor's display may prevent the images from
displaying properly. If this happens, turn off the computer's LCD display. For information
on how to turn off the LCD display, see the computer's owner's manual.
• If no signal is being input from the connected equipment or signal input is stopped while
projecting, the "No signal" message will appear.
• If a signal not supported by the projector is input, the "Unsupport signal" message will
appear.
• If an unavailable operation button is pressed, the
buttons
, any resolutions not
p.51
icon will appear.
26
Using handy features
■ Using auto setting
(For computer input only)
This function automatically sets up the projector to the optimum
state. It sets up sampling phase, frequency and screen position,
for each type of the input signal by using simple operations.
Press the remote control's AUTO SET button.
For computer input, the
icon will appear during processing.
You can set as well by selecting [Auto setting] in the Image
adjustment menu
.
p.35
Notes
• The image may not be projected or auto adjustment/setting may not be performed
correctly for input signals other than those supported by the projector
• If auto setting fails adjustment, adjust manually with [Position] in the Image
adjustment menu
p.35
.
■ Correcting the keystone distortion
When the projector placement angle against the
screen is changed while projecting the image,
the picture will undergo keystone (trapezoidal)
distortion.
This projector is capable of correcting this keystone
distortion.
Before correction After correction
1
Press the KEYSTONE button.
The Keystone menu appears. By default, [Auto v-keystone] is selected.
Item
Auto v-keystone
Automatically corrects the vertical distortion.
Press
V-keystone
Screen shrinking at
bottom
Remote
Control
p.51
,
Remote
Control panel
Control
Description
.
Screen shrinking at
top
27
p.52
.
