Summary of Contents for Smeg FA55PCIL1

  • Page 2: Table Of Contents

    Table of contents Entry Introduction Important safety instruction Identi cation of parts Where to install Installation Door removal Door replacement Feed water pipe installation Height adjustment Starting Operation Adjusting the temperatures and functions Refreshment center (Applicable to some models only) Shelf (Applicable to some models only) Wine holder (Applicable to some models only) Egg box...

  • Page 3: Introduction

    Introduction Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.
  • Page 4 DANGER: Risk of child entrapment. Child entrapment Before you throw away your old refrigerator or freezer: warning inside. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 5 Introduction *Dispenser model - Type 2 2 Freezer Compartment Automatic Icemaker Shelf or Drawer Lamp Shelf or Drawer Drawer Door rack Drawer (2 or 3) Door rack Lower cover NOTE Parts, features, and options vary by model. Your model may not include every option. •...

  • Page 6: Where To Install

    Optional Where to Install 1. Place your appliance where it is easy to Select a good use. location 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain su cient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall.

  • Page 7: Door Removal

    Door removal Electric Shock Hazard Warning Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally. Remove the lower cover by loosening all the Remove lower screws.

  • Page 8: Door Replacement

    Pass the Pass the refrigerator laterally through the access refrigerator door as shown in the right figure. Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation (*Dispenser model only) Before Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5 installation...

  • Page 9: Height Adjustment

    Installation Height adjustment If the freezer Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it clockwise ( ). compartment door is lower than the refrigerator compartment door If the freezer Level the door by inserting flat ( - type) driver into the groove of the right height compartment door...

  • Page 10: Operation

    Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions *Non dispenser model Optional Type-1...
  • Page 11 Operation *Dispenser model - Type 2 2 hidden) ptional Type-1 Display Power Saving Mode Type-2 NOTE Your model may not include every option. • Refreshment Center Button Refreshment Center Function display board...
  • Page 12 Display power This function save the display power saving Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for 5 (on some model) seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.
  • Page 13 Operation *Dispenser model - Type 2 2 (hidden) Your model may not include every option. • The control display is operated by touch. Excessive moisture on the display may • cause a malfunction. Please keep display clean and dry. Refreshment Center Button Refreshment Center...
  • Page 14 Display Power Saving Mode This function places the display into power saving mode until the next time the door is opened. Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for 5 seconds until the Ding sounds. All LEDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.
  • Page 15 Operation Dispenser use Select among crushed ice, water, and cubed ice and press the push switch with a glass or other container. (on some model) Crushed Ice Light the crushed ice lamp by pressing the selection button. Reference : Hold your cup in place for a couple of seconds after dispensing ice or water so •...
  • Page 16 To get cold water Cautions in The dispensed water is not icy cold, but just cool or cold. If you want colder water, using the dispenser dispense ice before dispensing water. (on some model) and then push it back. When the ice dispenser will not operate properly It is normal when a small amount of ice is left.
  • Page 17 Operation When ice maker Ice is lumped together does not operate When ice is lumped together, take the ice lumps out of the ice storage bin, break smoothly them into small pieces, and then place them into the ice storage bin again. When the ice maker produces too small or lumped together ice, the amount of water supplied to the ice maker need to adjusted.
  • Page 18 The other Door open warning functions 3 times of warning sounds at the interval of 30 seconds if a minute passes with the door of refrigerator and the hombar door opened or completely closed. Please contact with the local service center if warning continue to sound even after closing the door.

  • Page 19: Refreshment Center (Applicable To Some Models Only)

    Operation Refreshment center (Applicable to some models only) How to use Open the refreshment center door. You can access the refreshment center without opening refrigerator door and thus saving electricity. Inner lamp is lit in refrigerator compartment when the refreshment center door opens. Thus it is easy to identify the contents.

  • Page 20: Shelf (Applicable To Some Models Only)

    Shelf (Applicable to some models only) Folding Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder (Applicable to some models only) Wine holder Bottles can be stored laterally with...

  • Page 21: Humidity Control In The Vegetable Compartment

    Operation Humidity control in the vegetable compartment (Applicable to some models only) The humidity can be controlled by adjusting the humidity control switch to the left/right when storing vegetables or fruits. High humidity HIGH Low humidity HIGH Convert into a vegetable or meat compartment (Applicable to some models only) The bottom drawer in the refrigerator can be converted into a vegetable or meat compartment...

  • Page 22: Extra Fresh Temperature Transition Corner (Applicable To Some Models Only)

    Extra Fresh Temperature Transition Corner (Applicable to some models only) By pressing the button, store vegetables, fruits or other types of food such as meat to be defrosted, raw sh, etc. Temperature Change at Extra Fresh (Applicable to some models only) You can select optimum Method to Use temperature range depending on...

  • Page 23: Suggestion On Food Storage

    Suggestion on food storage Location of foods (Refer to identification of parts) Wine holder Store wine. Snack drawer Store small foods such as bread, snacks, etc.. Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food.

  • Page 24: Storing Foods

    Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons.

  • Page 25: Care And Maintenance

    Care and maintenance How to dismantle parts NOTE Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out Freezer pressing...
  • Page 26 To remove the lamp cover, press the protrusion Lamp in then pull the lamp cover out. refrigerator Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be compartment purchased at a service center. Separate the bin ( Refreshment Separate the upper rack of the refreshment center...

  • Page 27: General Information

    Care and maintenance Care and maintenance 0 Suggestion on food storage General information Vacation time During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.

  • Page 28: Trouble Shooting

    Care and maintenance Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Runing of refrigerator Refrigerator control is off.
  • Page 29 Care and maintenance Occurrence Refrigerator Thermostat is keeping the refrigerator compressor at a constant temperature. does not run. Temperatures are too cold Temperature in the Freezer control is set too cold freezer is too cold but the refrigerator temperature is satisfactory.
  • Page 30 Possible cause Occurrence Sound and noise Louder sound Today’s refrigerators have increased levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures levels when during the start of the ON cycle. compressor comes on.
  • Page 31 Care and maintenance Occurrence Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in the refrigerator. Some containers and wrapping materials produce odors. Opening/Closing of doors/Drawers Door(s) will not Food package is keeping door open. close. Door(s) will not Door was closed too hard, causing other close.
  • Page 32 Occurrence Possible cause Ice has melted and frozen around auger Dispenser will due to infrequent use, temperature not dispense fluctuations and/or power outrages. ice. Ice cubes are jammed between the ice Ice dispenser maker arm and back of the bin. is jammed.
  • Page 33 SMEG IN THE WORLD Headquarters Subsidiaries Belgium France Germany Great Britain Holland Portugal Russia Spain Showroom Madrid Sweden Representative Offices Hong Kong Saudi Arabia...
  • Page 34 MFL62880422...
