Installation and Operation Instructions
Compact Countertop Water Filter
Model CT-2
Congratulations!
You have purchased a quality Culligan
you cleaner, more healthful, better-tasting water. For over 60 years, Culligan has
been supplying better quality water to the world. Trust Culligan for the best water
you can get, anytime you want it. Our goal is to provide you with the highest
quality water, and the best possible service. For your home. For your health. For
your family.
Operating Specifications
Pressure Range: 30–125 psi (2.1–8.6 bar)
Temperature Range: 40–100°F (4.4–38°C)
Rated Service Flow: 0.5 gpm @ 60 psi (1.9 Lpm @ 4.1 bar)
Filter Capacity: CT-2: 400 gal. (1514 L)*
*Filter cartridge life varies depending on usage and water conditions.
Estimated filter life: CT-2 = 4 months
Parts Included (see diagram on p. 4)
• Filter Housing • Diverter Valve with Tubing
• Base • Adapter Kit
• Filter Cartridge
Precautions
WARNING: Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the system. Systems
certified for cyst reduction may be used on disinfected waters that may contain
filterable cysts.
CAUTION: Filter must be protected against freezing, which can cause cracking of
the filter and water leakage.
NOTE:
• Filter cartridge life varies depending on filter type, usage, and water conditions.
• For cold water use only.
• Make certain that installation complies with all state and local laws and
regulations.
• The replacement filter cartridge used with this system has a limited service life.
Changes in taste, odor, or flow of the water being filtered indicate that the
cartridge should be replaced.
• The contaminants or other substances removed or reduced by these systems
are not necessarily in your water. Ask your local water municipality for a copy
of their water analysis, or have your private well tested by a reputable water
testing lab.
• After prolonged periods of non-use (such as during a vacation) it is
recommended that the system be flushed thoroughly. Let water run for 5–6
minutes before using.
® water filtration product designed to give
Technical Support: 1-800-645-5426 Mon–Fri., 7:30 AM–5 PM CST
The CT-2 is Tested and Certified by NSF International against NSF/ANSI Standards
42 for the aesthetic reduction of Taste and Odor, Chlorine Particulate Class I.
Standard 53 - Asbestos, Cyst, Lead, Mercury and Turbidity Reduction.
Installation
• Please read all instructions and precautions before installing and using your
Culligan Countertop Water Filter.
• Numbered diagrams correspond with numbered steps.
1. Remove aerator from faucet on which filter will be installed (Fig. 1).
2. Determine the type of threads on your faucet:
External threads: No adapters should be needed. Proceed to Step 3.
Internal threads: Through trial and error, select the proper adapter and
washer (Fig. 2) and screw into faucet. Tighten manually.
NOTE: Adapters are included which will fit most faucets. To create a tight seal, you
may need to use the gasket from your faucet's aerator in addition to the washers
included with the adapters. If the adapters do not fit, consult your local plumbing
or hardware supplier for assistance in obtaining the correct thread adapter.
3. Screw the diverter valve onto the faucet, turning swivel collar to tighten (Fig.
3). Make certain that gasket (already installed in diverter valve) is positioned
securely between the diverter valve and the faucet (or adapter). Rotate diverter
valve stem to desired position. Swivel collar may need to be retightened. Place
assembly conveniently next to sink.
1
Diverter
Valve
3
Swivel Collar
Valve Stem
CT-2
2
Gasket
Adapter
Gasket
Adapter
