PB Series Split Type Wall Mounted Air Conditioner
Installation Manual
MODELS
System
Indoor
HSNRP26B
HINRP26MB
HSNRP35B
HINRP35MB
HSNRP50B
HINRP50MB
HSNRP60B
HINRP60MB
HSNRP70B
HINRP70MB
HSNRP80B
HINRP80B
Ref Only
HINRP20MB
Outdoor
HONRP26B
HONRP35B
HONRP50B
HONRP60B
HONRP70B
HONRP80B
Matching Multi System Only
REFRIGERANT
R32

Advertisement

Table of Contents
loading

Related Manuals for Rinnai HINRP26MB

Summary of Contents for Rinnai HINRP26MB

  • Page 1 MODELS REFRIGERANT System Indoor Outdoor HSNRP26B HINRP26MB HONRP26B HSNRP35B HINRP35MB HONRP35B HSNRP50B HINRP50MB HONRP50B HSNRP60B HINRP60MB HONRP60B HSNRP70B HINRP70MB HONRP70B HSNRP80B HINRP80B HONRP80B Ref Only HINRP20MB Matching Multi System Only PB Series Split Type Wall Mounted Air Conditioner Installation Manual...
  • Page 2 This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. REFRIGERANT Rinnai PB Series Split AC IM – Issue 1...

  • Page 3: Table Of Contents

    Note on Adding Refrigerant ������������������������������������������������������������������������������������������������������������������������������ 27 Electrical and Gas Leak Checks Before Test Run ������������������������������������������������������������������������������������������������������������������������������������������������ 28 Electrical Safety Checks ����������������������������������������������������������������������������������������������������������������������������������� 28 Test Run Test Run Checks ���������������������������������������������������������������������������������������������������������������������������������������������� 29 Checklist Specifications Contacts Rinnai PB Series Split AC IM – Issue 1...

  • Page 4: Warnings And Important Information

    For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances.
  • Page 5 This appliance uses R32 (difluoromethane) refrigerant, which is a flammable gas class 2.2 according to AS/NZS 1677 and must be handled by a refrigeration mechanic with appropriate Australian refrigerant handling licence. Rinnai PB Series Split AC IM – Issue 1...
  • Page 6 If the air conditioner is used together with burners or other heating devices, thoroughly ventilate theroomtoavoidoxygendeficiency. In certain functional environments, such as kitchens, server rooms, etc., the use of specially designedair-conditioningunitsishighlyrecommended. Rinnai PB Series Split AC IM – Issue 1...
  • Page 7 The table below indicates the temperature ranges the air conditioner can be operated within. MODE Cool Mode Heat Mode Dry Mode Room Temperature > 16°C < 30°C > 16°C Outdoor Temperature 0°C ~ 50°C -15°C ~ 24°C 0°C ~ 50°C Rinnai PB Series Split AC IM – Issue 1...
  • Page 8 If connecting power to fixed wiring, an all-pole disconnection device which has at least 3mm clearances in all poles, and have a leakage current that may exceed 10mA, the residual current device (RCD) having a rated residual operating current not exceeding 30mA, and disconnection mustbeincorporatedinthefixedwiringinaccordancewiththewiringrules. Rinnai PB Series Split AC IM – Issue 1...
  • Page 9 50 tonnes of CO equivalent, If the system has a leak detection system installed, it must be checked for leaks at least every 24 months. Whentheunitischeckedforleaks,properrecord-keepingofallchecksisstronglyrecommended. Rinnai PB Series Split AC IM – Issue 1...

  • Page 10: Accessories

    Varies by model Pass the belt through it on the connective cable. ) the hole of the Magnetic ring to fix it on the cable Page 16   Rinnai PB Series Split AC IM – Issue 1...

  • Page 11: Installation Summary

    Attach Mounting Plate Select Installation Location Determine Wall Hole Position Drill Wall Hole Connect Piping Connect Wiring Wrap Piping and Cable Prepare Drain Hose STEP Mount Indoor Unit Rinnai PB Series Split AC IM – Issue 1  Page 17 ...

  • Page 12: Description

    (Some Units) Refrigerant Piping NOTE ON ILLUSTRATIONS Illustrations in this manual are for explanatory purposes. The shape of the indoor unit may vary from model to model.  Page 18  Rinnai PB Series Split AC IM – Issue 1...

  • Page 13: Indoor Installation

    Then secure the mounting plate to the wall by tightening the screws directly into the clip anchors. Page 19   Rinnai PB Series Split AC IM – Issue 1  Page 19 ...
  • Page 14 16mm or more, the wall hole should be 90mm. 90mm different. But the installation dimensions are the Different models have different mounting plates. 199mm 603mm same for the same size of indoor unit. HINRP26MB 403mm 402mm Page 20   129mm...
  • Page 15 To prevent unwanted leaks the unit. Any dents in the piping will affect you must plug the unused the unit’s performance. drain hole with the rubber plug provided. Rinnai PB Series Split AC IM – Issue 1 Page 21  ...
  • Page 16 10 minutes or more before WIRING DIAGRAM LOCATED ON THE you touch the electrical components. ’ BACK OF THE INDOOR UNIT S FRONT PANEL . Rinnai PB Series Split AC IM – Issue 1 Page 22  ...
  • Page 17 (refer to Electrical Checks and Leak Checks section of this manual). Rinnai PB Series Split AC IM – Issue 1 Page 23 ...
  • Page 18 Use a bracket or wedge to prop up the unit, giving you enough room to connect the refrigerant piping, signal cable, and drain hose. Rinnai PB Series Split AC IM – Issue 1 Page 24  ...

  • Page 19: Outdoor Installation

    Mount the unit high enough to be above the average accumulated area snowfall. The minimum height must be 46 cm. Rinnai PB Series Split AC IM – Issue 1 Page 25  ...
  • Page 20 In cold climates, make sure that the drain hose is as vertical as possible to ensure swift water drainage. If water drains too slowly, it can freeze in the hose and flood the unit. Rinnai PB Series Split AC IM – Issue 1  Page 26...
  • Page 21 PROTECTION IS RECOMMENDED AT ALL on brackets. TIMES. 7. Bolt the unit firmly to the brackets. 8. If allowed, install the unit with rubber gaskets to reduce vibrations and noise. Page 27   Rinnai PB Series Split AC IM – Issue 1...
  • Page 22 Please select the appropriate through-hole according 6. Using the cable clamp, fasten the cable to the to the diameter of the wire. unit. Screw the cable clamp down tightly. Page 28 Rinnai   PB Series Split AC IM – Issue 1...

  • Page 23: Refrigerant Piping Connection

    3. Make sure that the pipe is cut at a perfect 90° deform the pipe while cutting. This will angle. drastically reduce the heating efficiency of the unit. Page 29   Page 29   Rinnai PB Series Split AC IM – Issue 1...
  • Page 24 Instructions for Connecting Piping to Indoor Unit Align the center of the two pipes that you will connect. Indoor unit tubing Flare nut Pipe Rinnai PB Series Split AC IM – Issue 1 Page 30  ...

  • Page 25: Instructions For Connecting Pipe To Outdoor Unit

    Valve cover While firmly gripping the body of the valve, use a torque wrench to tighten the flare nut according to the correct torque values. Rinnai PB Series Split AC IM – Issue 1 Page 31  ...

  • Page 26: Air Evacuation

    Wait for 5 minutes, then check that there has been no change in system pressure. Page 32   Rinnai PB Series Split AC IM – Issue 1 Page 32  ...

  • Page 27: Note On Adding Refrigerant

    R32: > Standard pipe Vacuum Pump (Pipe length – standard length) x 12g/m (Pipe length – standard length) x 24g/m length CAUTION mix refrigerant types. DO NOT Rinnai PB Series Split AC IM – Issue 1 Page 33  ...

  • Page 28: Electrical And Gas Leak Checks

    C& D: Indoor unit flare nuts A: Low pressure stop valve B: High pressure stop valve C& D: Indoor unit flare nuts  Page 34   Page 34  Rinnai PB Series Split AC IM – Issue 1...

  • Page 29: Test Run

    Perform Test Run as normal. Unit performs COOL function properly Unit performs HEAT function properly Indoor unit louvers rotate properly Manual control button Indoor unit responds to remote controller Page 35   Rinnai PB Series Split AC IM – Issue 1...

  • Page 30: Checklist

    Has air purging been carried out? No cooling or heating Has the appliance been tested for correct operation? No cooling or heating Is the end user fully aware of the operating procedure? Incorrect operation Ifyouhaveanswerednotoanyoftheabove,youmustcheckandcorrectbeforeappliancehand-overtocustomer. Rinnai PB Series Split AC IM – Issue 1...

  • Page 31: Specifications

    Maximum Input Current (Cooling / Heating) 10.5 10.5 Suitable Area Coverage (up to 2.6m insulated ceiling) m² 11-17 16-23 Indoor Unit Model No. HINRP26MB HINRP35MB Air Flow (Turbo / Hi / Med / Lo / Min) 175/139/100/83/56 183/147/106/86/58 Moisture Removal 1.00 1.20...
  • Page 32 SPECIFICATIONS RINNAI - PB Series Hi-Wall Split System HSNRP50B HSNRP60B Nominal Capacity Power Supply to Outdoor Unit V - Ph - Hz Recommended Circuit Breaker Wi-Fi Enabled Connectivity DRED Enabled Demand Response Enabling Device Cooling Rated Capacity Capacity Range 2.10-7.20 2.10-7.20...
  • Page 33 SPECIFICATIONS RINNAI - PB Series Hi-Wall Split System HSNRP70B HSNRP80B Nominal Capacity Power Supply to Outdoor Unit V - Ph - Hz Recommended Circuit Breaker Wi-Fi Enabled Connectivity DRED Enabled Demand Response Enabling Device Cooling Rated Capacity 7.15 Capacity Range 3.20-8.0...
  • Page 34 NOTES Rinnai PB Series Split AC IM – Issue 1...
  • Page 35 NOTES Rinnai PB Series Split AC IM – Issue 1...

  • Page 36: Contacts

    If your appliance requires service, please call our National Help Line. Rinnai recommends that this appliance be serviced once a year. With our policy of continuous improvement, we reserve the right to change, or discontinue at any time, specifications or designs without notice.
