FRIGORIFERO CON
CONGELATORE
Istruzioni per l'uso
Nel ringraziarvi per avere acquistato questo
prodotto SMEG, vi raccomandiamo di leggere
attentamente le seguenti istruzioni e di conservare
questo manuale per eventuali consultazioni future.
FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully
before operating and keep it handy for
reference at all times.
KÜHL-/GEFRIERSCHRANK-
KOMBINATION
Benutzerhandbuch
Bitte lesen Sie dieses Benutzerhandbuch vor dem
Betrieb sorgfältig durch und bewahren Sie es zum
späteren Gebrauch auf.
Advertisement
Chapters
Table of Contents
Related Manuals for Smeg CB30PFNF
Summary of Contents for Smeg CB30PFNF
- Page 1 FRIGORIFERO CON CONGELATORE Istruzioni per l'uso Nel ringraziarvi per avere acquistato questo prodotto SMEG, vi raccomandiamo di leggere attentamente le seguenti istruzioni e di conservare questo manuale per eventuali consultazioni future. FRIDGE-FREEZER User's Guide Please read this User's Guide carefully before operating and keep it handy for reference at all times.
-
Page 2: Table Of Contents
Table of Contents Introduction Registration Important Safety Instruction Identification of Parts Temperature Control Operation Extra Freezer Self Test Door Alarm Extra Fresh Ice Making Defrosting Folding Shelf Suggestion On Storing Food Food storage General Information Care and Lamp Replacement Maintenance To Reverse the Doors Cleaning Trouble Shooting... -
Page 3: Introduction
Introduction Registration Introduction The model and serial number are found on the rear of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 4 Important Safety Instruction Warning This fridge-freezer must be properly installed and Precaution • located in accordance with the Installation Instruction before it is used. Before you install this fridge-freezer reference to • installation manual. Never unplug your fridge-freezer by pulling on the •...
- Page 5 Introduction Important Safety Instruction Do not disassemble, repair or alter the appliance. • It may cause fire or abnormal operations, which may lead to injury. Pull the power plug out of the socket before replacing • the interior light in the refrigerator. Otherwise, there is a risk of electric shock.
- Page 6 Important Safety Instruction Warning Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 7 Introduction Important Safety Instruction Caution If the wall socket is loose, do not insert the power • plug. It may cause electric shock or fire. Never unplug your refrigerator by pulling on the • power cord. Always grip plug firmly and pull it straight out from the outlet.
-
Page 8: Identification Of Parts
Introduction Identification of Parts Dairy Corner Lamp Removable Glass Shelf Egg Tray Folding Shelf Door Basket Snack Bin Bottle Guide Multi-Air Flow Duct Vegetable Drawer Bottle Used to keep fruits Door Basket and vegetables crisp Extra Fresh Ice Tray Ice Bank Freezer Compartment Leveling Screw... -
Page 9: Operation
Operation Temperature Control Your fridge-freezer has controls that let you regulate the temperature in the fridge and freezer compartments. Display Panel For Temperature Control Adjusting the temperatures and functions Display Panel Extra Freezer Power Temperature Adjustment Button Temperature Adjustment Button for Freezer Compartment for Extra Fresh Compartment Temperature Adjustment Button... - Page 10 Power If you push button more than 3 seconds • you can switch on or off the Refrigerator. How to adjust the The initial Temperature of the Freezer and Refrigerator • temperature in the Compartment is -20°C and 3°C respectively. You can now adjust the temperature of the refrigerator and compartments as you want.
-
Page 11: Extra Freezer
Operation Extra Freezer Please select this function for prompt freezer. • This function is used when you want to freeze the • foods quickly. Press the Extra FRZ.(Extra Freezer) button once, and then the quick freeze operation starts with the lamp it. The Extra Freeze operation takes about 3 hours. -
Page 12: Extra Fresh
Extra fresh By pressing the button, store vegetables, fruits (at • Temperature relatively low conservation temperature) or other types of food such as meat to be defrosted, raw fish, etc. Transition Corner Method to Use You can select optimum temperature range depending •... -
Page 13: Ice Making
Operation Ice Making Fill water in ice making box of • the ice making corner. If water is fully filled the ice will not be separated well and water can be dropped to make ice lumped. Ice will be dropped into the •... -
Page 14: Folding Shelf
Operation Folding Shelf You can store taller items such as a gallon or bottles by • simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. -
Page 15: Storing Food
Suggestions on food storage Storing Food Caution • • • • • • • • • • • Note Do not store food which goes bad easily at low temperature, such as banana, and melon. Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills. -
Page 16: Care And
General Information Power Failure 1~2 hour power failure does no harm to the foods • stores. Try to avoid opening and closing the door too frequently. If You Move Take out foods from the fridge-freezer and firmly fix the • loose items with tape. -
Page 17: Lamp Replacement
Care and Maintenance Lamp Replacement Caution Note To Reverse the • Doors Caution Unplug the power cord from the outlet or shutdown the main switch in your house. Remove the room lamp lid by taking down while pulling its back projection. Remove the lamp by turning it counterclockwise and replace new one. -
Page 18: Cleaning
Cleaning Before Cleaning Be sure to unplug the power or shutdown the main switch in your house. Clean the outside of the fridge-freezer with a soft cloth Exterior soaked with hot water or liquid detergent. If you use a detergent, be sure to wipe it with a clean wet cloth. Interior As above. -
Page 19: Trouble Shooting
Trouble Shooting Problem Fridge-Freezer does not operate Fridge or Freezer Compartment Temperature too warm Vibration or Rattling or Abnormal Noise Frost or Ice Crystals on frozen Food Moisture forms on Cabinet Surface Before calling for service, check this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. - Page 20 Problem Possible Causes Too frequent or too long door openings. Moisture collects • In humid weather, air carries moisture into fridge when • inside doors are opened. Foods with strong odors should be tightly covered or Fridge has door • wrapped.
