Related Manuals for Smeg CB300U
Summary of Contents for Smeg CB300U
- Page 1 CB300U Instruction Manual Manuale di istruzioni Notice d'Utilisation Manual de instrucciones...
- Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
-
Page 3: Table Of Contents
CONTENTS 1 Your refrigerator 4 Preparation Reversing the doors ......13 2 Important Safety Warnings 5 5 Using your cooler/freezer 15 Intended use ........5 For products with a water dispenser; .7 Freezing fresh food ......16 Child safety ........7 Recommendations for preservation of Compliance with WEEE Directive and frozen food ........17 Disposing of the Waste Product: ..7... -
Page 4: Your Refrigerator
Your refrigerator 1. Butter & Cheese sections 7. Crisper 2. Adjustable door shelves 8. Crisper cover and glass 3. Bottle holder 9. Adjustable shelves 4. Bottle shelf 10. Fan 5. Adjustable front feet 11. Indicator panel 6. Freezer compartment Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. -
Page 5: Important Safety Warnings
Important Safety Warnings Please review the following information. • For products with a freezer Failure to observe this information may compartment; Do not put bottled and cause injuries or material damage. canned liquid beverages in the freezer Otherwise, all warranty and reliability compartment. - Page 6 • In case of any failure or during a • Label of technical specifications is located on the left wall inside the maintenance or repair work, disconnect your refrigerator’s mains supply by either refrigerator. turning off the relevant fuse or unplugging • Never connect your refrigerator to your appliance.
-
Page 7: For Products With A Water Dispenser
For products with a water • Never place containers filled with dispenser; water on top of the refrigerator, otherwise this may cause electric Pressure of water mains should be shock or fire. minimum 1 bar. Pressure of water • Do not overload your refrigerator mains should be maximum 8 bars. -
Page 8: Compliance With Rohs Directive
and other wastes at the end of its catch a fire and ventilate the room in service life. Take it to the collection which the unit is placed. center for the recycling of electrical and DANGER – Risk Of Fire or electronic equipment. -
Page 9: Things To Be Done For Energy Saving
Things to be done for energy saving • Do not leave the doors of your refrigerator open for a long time. • Do not put hot food or drinks in your refrigerator. • Do not overload your refrigerator so that the air circulation inside of it is not prevented. -
Page 10: Installation
Installation “Maintenance and cleaning” section. In case the information which are 3. Connect the plug of the given in the user manual are not refrigerator to the wall socket. When taken into account, manufacturer will the fridge door is opened, fridge not assume any liability for this. -
Page 11: Disposing Of The Packaging
Disposing of the packaging Install your refrigerator to a place that allows ease of use. packing materials 2. Keep your refrigerator away dangerous for children. Keep the from heat sources, humid places and packing materials out of the reach direct sunlight. of children or dispose of them by 3. -
Page 12: Preparation
Preparation • Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. • The ambient temperature of the room where you install your refrigerator should at least be 50ºF. -
Page 13: Reversing The Doors
Reversing the doors Proceed in numerical order... - Page 14 4 mm 1/8 '' Max weight with the door panel for the door.19mm-3/4" (H) Height (cm) unpacked 177.5 cm /69.88" (W) Width (cm) unpacked 55.6 cm /21.89" (D) Depth (cm) unpacked 54.5 cm /21.46" 185.6 cm /73.07 " (H) Height (cm)packed 57.6 cm /22.68 "...
-
Page 15: Using Your Cooler/Freezer
Using your cooler/freezer 1- On/Off function This function can be used for food Press the On/Off button for 3 placed in the fridge compartment and seconds to turn off or turn on the required to be cooled down rapidly. fridge. If you want to cool large amounts of 2- Fridge Set Function fresh food, it is recommended to active... -
Page 16: Freezing Fresh Food
Freezer Fridge Explanations Compartment Compartment Adjustment Adjustment 5°F 40ºF This is the normal recommended setting. 0,-5 or -10°F 40°F These settings are recommended when the ambient temperature exceeds 91°F. Quick Freeze 40°F Use when you wish to freeze your food in a short time. -
Page 17: Recommendations For Preservation Of Frozen Food
3. Take special care not to mix already Vegetables and Crisper frozen food and fresh food. fruits Recommendations for Delicatessen preservation of frozen food Freshzone products (cheese, compartment • Prepacked commercially frozen food butter, salami and should be stored in accordance etc.) with the frozen food manufacturer's Deep-freeze information... -
Page 18: Maintenance And Cleaning
Maintenance and cleaning Never use gasoline, benzene or To remove door racks, remove all the similar substances for cleaning contents and then simply push the purposes. door rack upwards from the base. We recommend that you unplug the Never use cleaning agents or water appliance before cleaning. -
Page 19: Troubleshooting
Troubleshooting Please review this list before calling the service. It will save your time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. - Page 20 The refrigerator is running frequently or for a long time. • New product may be wider than the previous one. Larger refrigerators operate for a longer period of time. • The room temperature may be high. >>>It is normal that the product operates for longer periods in hot ambient.
- Page 21 • Vibrations or noise. • The floor is not level or stable. >>> If the refrigerator rocks when moved slowly, balance it by adjusting its feet. Also make sure that the floor is strong enough to carry the refrigerator, and level. • The items put onto the refrigerator may cause noise.
