Protocol Based VLAN

(Virtual Local Area Network)
Ethernet Switch
ZyNOS 3.7

Support Notes

Version 3.70
August 2006

Advertisement

loading

Related Manuals for ZyXEL Communications Dimension GS-4024

Summary of Contents for ZyXEL Communications Dimension GS-4024

  • Page 1: Protocol Based Vlan

    Protocol Based VLAN (Virtual Local Area Network) Ethernet Switch ZyNOS 3.7 Support Notes Version 3.70 August 2006...
  • Page 2 IP, IPX, ARP or whatever Ethernet-type that you want in a Hex value. Notes: Protocol Based VLAN is implemented in ZyXEL Switch as a “by port” based feature. For ES-3124, you can apply up to 7 protocol based VLAN rules on a port.
  • Page 3 Scenario of Protocol Based VLAN In the following section, we will provide an example to illustrate how to configure Protocol Based VLAN on a ZyXEL Switch. In this scenario, there is a ZyXEL Management Switch which supports Protocol Based VLAN and port 1 of the Switch is connected to another 5-ports UnManagement switch.
  • Page 4 7. To use Protocol Based VLAN to sort out all the PPPoE traffic on port 1 and set its VID to 500 and 802.1p priority to 1, click “Advanced Application” another tab called “Protocol Based Vlan”. All contents copyright (c) 2006 ZyXEL Communications Corporation. Protocol Based VLAN Support Note http://192.168.1.1 “VLAN”...
  • Page 5 1. The second rule is to sort out Ethernet-type 0x8864 on port 1 and to mark it as VLAN 500 with priority 1 as well. All contents copyright (c) 2006 ZyXEL Communications Corporation. Protocol Based VLAN Support Note...
  • Page 6 Protocol Based VLAN Support Note 10. When this is done, you should see that there are two Protocol Based VLANs on your screen. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 7 Protocol Based VLAN Support Note 11. Finally, do not forget to click the “SAVE” button to save all the changes. Now, when there is PPPoE traffic coming from the port 1 to the switch, it will be assigned VID 500.
  • Page 8 Parity: None Stop bits:1 Flow control: None: Another way is to telnet / SSH the IP of the Switch Management Interface. For In-band interface, the default management IP is 192.168.1.1 (VLAN 1). For Out-band interface, the default management IP is 192.168.0.1 When successfully connected, enter the correct administrator user name and password.
  • Page 9 Protocol Based VLAN Support Note Switch#write mem All contents copyright (c) 2006 ZyXEL Communications Corporation.
