Vi
manual.
Specifications
120 volts, AC, 50/60 Hz
12 volt DC, 5A
Power Input:
High or 7522 automatic
BNC type bridging and &-pin
connectors
:
RCA type bridging and 8-pin
connectors
External Sync Input:
BNC type bridging connectors
A3 transistors
66 diodes
1 posistor
9 ICs
23.5kVi1kV
(at zero beam current)
1.0 watt (10% distortion)
1.2 watts maximum
2-1/2 inches Round Type
Voice Coil 162
|
Automatic Impedance Switch
Semiconductors:
Anode Voltage:
Sound Output:
Speaker: -
Automatic Circuits:
AC-46W (Average), DC-46W (Average)
Quality Engineering :
Feature
2.0 ~ 4.0Vp-p, negative composite
Picture Tube:
Dimensions:
Automatic Frequency and Phase
Control
Horizontal Automatic Frequency
Control
Weight:
|
D6
Automatic degaussing
Automatic Voltage Regulator
Automatic Beam Limiter
Automatic Color Contro!
Mode Selector Switch
(VTR/LINE, Underscan, Pulse
Cross, Blue Only, Comb/Trap)
Sync Switch
Vertical Centering Control
Horizontal Centering Control
Vertical Size Control
(Normal/Underscan Modes)
Horizontal Size Control
(Underscan Mode)
Vertical Position Control
(Pulse Cross Mode)
Horizontal Position Contro!
(Pulse Cross Mode)
AC/DC Operation
A26JGZ31X
52 Square inches
10 inches measured diagonally
90° deflection, In-Line
Height:
10-13/16 inches (275 mm)
Width:
41-3/16
inches (284 mm)
Depth:
12-11/16 inches (322 mm)
19-1/4 Ibs. (9.2 kg)
Panasonic industria! Company
Division of Matsushita Electric
Corporation of America
One Panasonic Way Secaucus,
New Jersey 07094
Panasonic Sales Company,
Division of Matsushita Electric
of Puerto Rico, Inc.
Ave. 65 De Infanteria, KM 9.7
Victoria Industrial Park
Carolina, Puerto Rico 00630
Panasonic Hawaii Inc.
91-238 Kauhi St. Ewa Beach
P.O. Box 774
Honolulu, Hawaii 96808-0774
