Tektronix Phaser 750 Repacking And Shipping Manual
In original packaging
Hide thumbs
Also See for Phaser 750:
- User manual (183 pages) ,
- Setup manual (1 page) ,
- Service manual (148 pages)
Related Manuals for Tektronix Phaser 750
Summary of Contents for Tektronix Phaser 750
- Page 1 Instructions Repacking and Shipping a Phaser® 750 Color Printer in Original Packaging First printing December 1999 Copyright © Tektronix, Inc.
-
Page 2: Before You Start
Proper repacking is necessary to protect the printer from damage during shipping or moving. Complete repacking is required before shipping. However, you can prepare the printer for a short move — such as between buildings or in a car to another site, for example — by just removing the toner cartridges. -
Page 3: What You Need
Printer and accessories Lower Tray Assembly (if applicable) Two people to lift the printer. Without the components, it weighs about 47 kg (104 lbs.) and the Lower Tray Assembly weighs about 14 kg (31 lbs.). Between 30 to 60 minutes, depending on repacking experience. -
Page 4: Repacking The Printer
Remove the power cord and all cables. Prepare the media tray(s) Remove the media tray from the printer, and remove the media from the tray. If you have the Duplex Unit and Lower Tray Assembly installed, remove the Duplex Unit. Repack it according to instructions on page 7. - Page 5 Be careful not to leave the side door open for an extended time. Components can be damaged by light exposure. Open the printer’s right side door. O T E Be careful not to touch the cartridge rollers, as toner may smear on your hands.
- Page 6 Remove and discard the transfer roller/waste bin A U T I O N Remove the transfer roller/waste bin before shipping the printer. Failure to do so may damage the printer and invalidate the printer warranty. Open the printer’s left side door.
- Page 7 Repacking Your Printer Secure doors Close all doors and secure them with adhesive tape. Z740-8-01 Phaser 740 Color Printer...
- Page 8 Lift the printer up and away from the Lower Tray Assembly. A R N I N G Never lift the printer and the Lower Tray Assembly together. You can damage the components and may incur personal injury. Always remove the printer before moving the Lower Tray Assembly.
- Page 9 Repack printer accessories in the original accessory packing boxes. Include the power cord, cables, manuals, parallel cable adapter, and CD-ROMs. O T E If the printer needs repair, refer to "Shipping the printer for repair." Repack the printer and accessories boxes in the original shipping box. 560FS-18...
- Page 10 Using the banding supplies included with your printer, band the shipping box and wooden pallet. Shipping the printer for repair If you are shipping the printer to Tektronix for service, call 1-800-835-6100 for a return authorization number (RMA#). Outside the U.S., contact your local Tektronix office for service information.
