4681FXI Ð Upgrading a Phaser 220e to
a Phaser 220i
This instruction sheet provides the details for replacing a Phaser 220e's image processor board and I/O
board with a 220i image processor board and I/O board. After installing the upgrade you must return
the 220e image processor board and its I/O board to Tektronix.
Static precautions
©
Copyright
1994
by Tektronix, Inc. All rights reserved.
Tools required
#1 POSIDRIV¨ screwdriver
Antimstatic mat 006-7056-00
Leave the printer plugged into its power outlet. This preserves a
ground path for static discharges.
Touch the printer's bare metal frame often to discharge static
electricity from your body.
Handle the circuit board(s) by their edges only.
lay the board(s) on a metal surface.
Do not
Make the least possible movements to avoid generating static
electricity.
Avoid wearing nylon or polyester clothing; they generate static
electricity.
Instruction Sheet
Phaserª 220e
063-1442-AB
Advertisement
Related Manuals for Tektronix Phaser 220e
Summary of Contents for Tektronix Phaser 220e
-
Page 1: Static Precautions
4681FXI Ð Upgrading a Phaser 220e to a Phaser 220i This instruction sheet provides the details for replacing a Phaser 220e's image processor board and I/O board with a 220i image processor board and I/O board. After installing the upgrade you must return the 220e image processor board and its I/O board to Tektronix. - Page 2 4681FXI Ð Upgrading a Phaser 220e to a Phaser 220i Power down the printer. Leave the power cord plugged in to provide a ground path for static discharges. Remove the interface cables. Remove the top-rear and rear plastic cabinet panels.
- Page 3 4681FXI Ð Upgrading a Phaser 220e to a Phaser 220i Remove the card cage top (3 screws). Flip over the hinged card cage top. Lift out the 220e image processor board. Save the board to return to Tektronix. 8699-38...
- Page 4 4681FXI Ð Upgrading a Phaser 220e to a Phaser 220i If installed, remove the RAM SIMM installed in J6 of the 220e image processor board. If you removed a RAM SIMM from the 220e image processor board in Step 8, insert it in the 220i image processor board's connector J6 (or in J7 if J6 is already Þlled) ( a ), and tilt the module upright until it locks in...
- Page 5 Mail the package to Tektronix: Mailing in the USA: Mailing outside the USA: 4681FXI Ð Upgrading a Phaser 220e to a Phaser 220i Write the printer's serial number on the U.S.A shipping return label that was included with the upgrade kit.
