Summary of Contents for Clevo P670SA

  • Page 1 P670SA / P671SA...
  • Page 3 Preface Notebook Computer P670SA / P671SA Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P670SA / P671SA series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 MB ....................A-5 HDD ....................A-6 Overview ..................1-1 LCD ....................A-7 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &...
  • Page 12 Preface GPU Decoupling ................B-28 NVVDD Phase 1 & 2 ..............B-60 DACA Interface XTAL ..............B-29 FBVDDQ ..................B-61 IFP I/O Interface ................B-30 Audio Board ..................B-62 Misc - GPIO, I2C and ROM ............B-31 Power Board .................B-63 GPU NVVDD, FBVDDQ, and GND ........... B-32 HDD Board ...................B-64 Lynx 1/9 ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P670SA / P671SA series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Memory Intel® Core™ i7 Processor Four 204 Pin SO-DIMM Sockets Supporting DDR3L 1600MHz Memory i7-4870HQ (2.50GHz), i7-4720HQ (2.60GHz) 6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 47W (The real memory operating frequency depends on the FSB  of the processor.) Core Logic Latest Specification Information Memory Expandable from 4GB (minimum) up to 32GB...
  • Page 15 Introduction Audio Communication High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN S/PDIF Digital Output 2.0M FHD PC Camera Module Two Speakers WLAN/ Bluetooth M.2 Modules: Sound Blaster X-Fi MB3 (Factory Option) Intel® Wireless-AC 7265 Wireless LAN ANSP ™ 3D sound technology on headphone output (802.11ac) + Bluetooth 4.0 Built-In Array Microphone (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Array Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View RIGHT SIDE VIEW 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. USB 3.0 Ports 5. Multi-in-1 Card Reader 6.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent 2. HDMI-Out Port 3. Powered USB 3.0 LEFT SIDE VIEW Port 4. Mini DisplayPorts Figure 5 REAR VIEW Rear View 1. Vent 2. DC-In Jack 3.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Sub Woofer  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Memory Slots DDR3L SO-DIMM 2. KBC-ITE IT8587 3. CMOS Battery 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (WLAN Module) 2. Mini-Card Connector (M.2 3G/SATA Module) 3. Mini-Card Connector (M.2 PCIE/SATA SSD Module) 4. GPU-GTX965M 5. Memory Slots DDR3L SO-DIMM 6. CPU Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB Port 3.0 Connector 3. Mini Display Port 4. eSATA + USB 3.0 5. DC-In Jack 6. Keyboard Cable Connector 7. TP Connector 8. Speaker Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Multi-in-1 Card Reader 2. Battery Connector 3. Fan Connector 4. LCD Cable Connector 5. CCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P670SA / P671SA series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: 1. Remove the keyboard page 2 - 5 To remove the Battery: 1.

  • Page 29: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove screws from the 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- bottom of the computer cial eject stick...

  • Page 30: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove the SD card cover and screws (Figure 2a). a. Remove the SD cover 3. Carefully lift the bottom case up in the direction of the arrow and remove it (Figure 2b and screws.
  • Page 31 Disassembly 5. Carefully disconnect the cable , then remove screws (Figure 3d Figure 3 6. Lift the battery off the computer (Figure 3e Battery Removal 7. Reinsert the bottom case starting from point as shown (Figure 3f) to avoid damaging the rear eSATA/USB 3.0 (cont’d.) port.

  • Page 32: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 33 Disassembly 4. Carefully pull the hard disk assembly in the direction of arrow (Figure 5c Figure 5 5. Lift the hard disk assembly out of the bay (Figure 5d HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 5e Removal (cont’d.) 7.

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM-1 Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L up to 1600 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer.
  • Page 35 Disassembly 4. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 8c). The RAM module will pop-up Figure 8d , and you can then remove it RAM-1 Module 5.
  • Page 36 Disassembly Memory-2 Upgrade Process Figure 8 RAM-2 Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The RAM-2 modules will be visible at point on the mainboard (Figure 8a 3. Gently pull the two release latches ( &...

  • Page 37: Removing And Installing The The M.2 Ssd Module

    Disassembly Removing and Installing the the M.2 SSD Module Figure 9 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The SSD module will be visible at point on the mainboard (Figure 9a).
  • Page 38 Disassembly M.2 SSD-2 Removal Procedure Figure 10 M.2 SSD-2 Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the module, it is visible at point Figure 10a 3. Remove the screw from the module Figure 10b a.
  • Page 39 Disassembly M.2 SSD-2 Installation Procedure Figure 11 1. Place the thermal pad on the module as shown (Figure 11a). M.2 SSD-2 Module 2. Insert the module in the computer Figure 11b Installation 3. Tighten the screw to secure it in place (Figure 11c).
  • Page 40 Disassembly 4. Press down the mylar and thermal pad into place at point as shown (Figure 12d). Figure 12 5. Make sure that the mylar is secure in place and the thermal pad is in place along the contour (no glue is M.2 SSD-2 Module required).

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 13a).

  • Page 42: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 43: Removing The 3G / M.2 Sata Module

    Disassembly Removing the 3G / M.2 SATA Module Figure 14 3G Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 14a b.
  • Page 44 Disassembly M.2 SATA Removal Procedure Figure 15 M.2 SATA Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the module, it is visible at point Figure 15a 3. Remove the screw from the module Figure 15b a.

  • Page 45: Part Lists

    Appendix A:Part Lists This appendix breaks down the P670SA / P671SA series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 A - 2...

  • Page 47: Top

    Figure A - 1 Top A - 3...

  • Page 48: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...
  • Page 49 Figure A - 3 MB A - 5...

  • Page 50: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 51: Lcd

    Figure A - 5 LCD A - 7...
  • Page 52 A - 8...

  • Page 53: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P670SA / P671SA notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 54: System Block Diagram

    Schematic Diagrams System Block Diagram VDD3,VDD5 P650SE Shark Bay System Block Diagram P650 AUDIO BOARD SHEET 53 6-71-P6508-D03 SHEET 61 5V,3.3V,5VS,3VS, P650 POWER SW BOARD 6-7P-P650C-001 3.3VM SHEET 54 6-71-P650C-D01B SHEET 62 6-71-P6500-D03 <=4.5" PCIE*16 Vcore P650 HDD BOARD 1067/1333/1600 MHz SHEET 57 6-71-P650N-D02 SHEET 63...

  • Page 55: Processor 1/7-Dmi, Fdi, Peg

    Schematic Diagrams Processor 1/7-DMI, FDI, PEG Haswell Processor 1/7 ( DMI,FDI,PEG ) HASWELL_BGA_E U104A 12 mil R206 24.9_1%_04 PEG_RCOMP VCCIOA_OUT PEG_RX#0 PEG_RXN0 PEG_RX#1 DMI_TXN0 DMI_RXN0 PEG_RXN1 DMI_TXN1 DMI_RXN1 PEG_RXN2 PEG_RX#2 PEG_RX#3 DMI_TXN2 DMI_RXN2 PEG_RXN3 PEG_RX#4 DMI_TXN3 DMI_RXN3 PEG_RXN4 PEG_RXN5 PEG_RX#5 PEG_RX#6 DMI_TXP0 DMI_RXP0...

  • Page 56: Processor 2/7- Clk, Misc

    Schematic Diagrams Processor 2/7- CLK, MISC PU/PD for JTAG signals Haswell Processor 2/7 ( MISC,JTAG,CLK ) 1.05VS XDP_TMS R328 51_04 XDP_TDI_R R329 51_04 XDP_PREQ# R330 *51_04 XDP_TDO_R R327 51_04 XDP_TCLK U104B HASWELL_BGA_E R744 51_04 XDP_TRST# R745 51_04 MISC PROC_DETECT# BB51 SM_RCOMP_0 XDP_TDO_R R326...

  • Page 57: Processor 3/7- (Ddr3L

    Schematic Diagrams Processor 3/7- (DDR3L) Haswell Processor 3/7 ( DDR3L ) HASWELL_BGA_E U104D 11,12 M_B_DQ[63:0] M_B_DQ0 AC54 AY36 RSVD_AY36 SB_DQ0 RSVD M_B_DQ1 AC52 AW27 M_B_CLK_DDR#0 SB_DQ1 SB_CKN0 M_B_DQ2 AE51 AV27 M_B_CLK_DDR0 SB_DQ2 SB_CK0 M_B_DQ3 AE54 AU36 SB_DQ3 SB_CKE0 M_B_CKE0 M_B_DQ4 AC53 AW26 SB_DQ4...

  • Page 58: Processor 4/7- Display

    Schematic Diagrams Processor 4/7- Display Haswell Processor 4/7 ( DISPLAY ) VCCIOA_OUT HASWELL_BGA_E U104J R204 10K_04 DP_B#0 DDIB_TXN0 EDP_AUXN EDP_AUXN DP_B0 EDP_AUXP DDIB_TXP0 EDP_AUXP DP_B#1 DDIB_TXN1 EDP_HPD DP_B1 DDIB_TXP1 mini DP DP_B#2 EDP_TXN_0 DDIB_TXN2 EDP_TXN0 DP_B2 DDIB_TXP2 EDP_TXN1 EDP_TXN_1 DP_B#3 EDP_TXP_0 14 EDP_HPD 13,14...

  • Page 59: Processor 5/7- Power

    Schematic Diagrams Processor 5/7- Power V_VCCDDQ VDDQ Haswell Processor 5/7 ( POWER ) 47W->85A VCORE VCORE U104E HASWELL_BGA_E RSVD C427 C449 C428 C450 C429 C451 C445 C446 C447 C448 4.2A V_VCCDDQ RSVD RSVD V_VCCDDQ RSVD AR29 VDDQ AR31 VDDQ C424 C443 C396 C499...

  • Page 60: Processor 6/7- Pognd

    Schematic Diagrams Processor 6/7- POGND VCORE VCORE HASWELL_BGA_E HASWELL_BGA_E U104F U104I Haswell Processor 6/7 ( POWER,GND ) AB45 BC10 AB46 BC12 BC15 AC46 BC18 AC47 BC22 HASWELL_BGA_E HASWELL_BGA_E BC26 U104H U104G AD46 BC30 AT40 AY50 AJ48 BC33 AT42 AJ51 AE46 BC36 AT43 AJ54...

  • Page 61: Processor 7/7-Rsvd

    Schematic Diagrams Processor 7/7- RSVD Haswell Processor 7/7 ( RESERVED ) CFG STRAPS FOR PROCESSOR HASWELL_BGA_E HASWELL_BGA_E U104K U104L RSVD_TP RSVD_TP RSVD_TP RSVD_TP PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS RSVD_TP RSVD_TP DAISY_CHAIN_NCTF_A3 DAISY_CHAIN_NCTF_A4 CFG_RCOMP RSVD_TP CFG_RCOMP 1: (DEFAULT)NORMAL OPERATION; BF51 RSVD_TP CFG16...

  • Page 62: Ddr3 Cha So-Dimm_0

    Schematic Diagrams DDR3 CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] STD TYPE H=4mm J_DIMMA_1A 4,10 M_A_A[15:0] M_A_DQ[63:0] 4,10 M_A_A0 M_A_DQ0 J_DIMMA_1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ3 M_A_A3 M_A_DQ7 VDDQ M_A_A4 M_A_DQ5 M_A_A5 M_A_DQ4 VDD1 VSS16 M_A_A6 M_A_DQ2 VDD2 VSS17 M_A_A7 M_A_DQ6 VDD3 VSS18 M_A_A8 M_A_DQ9...

  • Page 63: Ddr3 Cha So-Dimm_1

    Schematic Diagrams DDR3 CHA SO-DIMM_1 Channel A SO-DIMM 1[RAM3] REV TYPE H=5.2mm J_DIMMA_2A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ0 J_DIMMA_2B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ3 M_A_A3 M_A_DQ7 VDDQ M_A_A4 M_A_DQ5 M_A_A5 M_A_DQ4 VDD1 VSS16 M_A_A6 M_A_DQ2 VDD2 VSS17 M_A_A7 M_A_DQ6 VDD3 VSS18 M_A_A8 M_A_DQ9 VDD4 VSS19...

  • Page 64: Ddr3 Chb So-Dimm_0

    Schematic Diagrams DDR3 CHB SO-DIMM_0 RSV TYPE Channel B SO-DIMM 0[RAM2] H=4mm J_DIMMB_1A 4,12 M_B_B[15:0] M_B_DQ[63:0] 4,12 M_B_B0 M_B_DQ1 J_DIMMB_1B M_B_B1 M_B_DQ5 M_B_B2 M_B_DQ3 M_B_B3 M_B_DQ2 VDDQ M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ0 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18 M_B_B8 M_B_DQ8...

  • Page 65: Ddr3 Chb So-Dimm_1

    Schematic Diagrams DDR3 CHB SO-DIMM_1 Channel B SO-DIMM 1[RAM4] STD TYPE H=5.2mm J_DIMMB_2A 4,11 M_B_B[15:0] M_B_DQ[63:0] 4,11 M_B_B0 M_B_DQ1 J_DIMMB_2B M_B_B1 M_B_DQ5 M_B_B2 M_B_DQ3 VDDQ M_B_B3 M_B_DQ2 M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ0 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18 M_B_B8 M_B_DQ8...

  • Page 66: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL POWER PANEL CONNECTOR (For coaxial cable) PLVDD C144 *MTS3572G6 VLED J_LCD1 1u_6.3V_X5R_04 C197 C206 3.3VS C222 *0.22u_50V_Y5V_06 *4.7K_06 LVDS-U0N LVDS-U0P *1M_04 LVDS-U1N GND5 *100K_04 LVDS-U1P GND5 GND4 GND4 GND3 LVDS-U2N GND3 GND2 LVDS-U2P GND2 3.3V GND1 GND1 LVDS...

  • Page 67: Rtd2136N-Cg

    Schematic Diagrams RTD2136N-CG Power 3.3VS 3.3VS 0_06 0_06 AVCC33 DVCC33 DVCC33 ENBLT ENBLT VC17 VC19 6-19-31001-245 VC16 2.2u_6.3V_X5R_06 2.2u_6.3V_X5R_06 VR15 0.1u_10V_X7R_04 0.1u_10V_X7R_04 10K_04 Note: VR23 0_04 1. Entire trace of Panel VCC should be wider than 80-mil 5,13 EDP_HPD LVDS-L0N LVDS-L0N LVDS LVDS-L0P...

  • Page 68: Mini Dp Port D

    Schematic Diagrams Mini DP Port D mini-Display Port D R758 0_04 R760 0_04 Close to Display PORT MDP_D#3 D_MDP_D#3 C857 0.1u_10V_X7R_04 D_MDP_D3 C856 0.1u_10V_X7R_04 3.3VS 3.3VS_MDP MDP_D3 *DVI2012F2SF-900T05_08 VOUT R771 0_04 R774 0_04 C488 C511 SY6288DAAC MDP_D#2 C866 0.1u_10V_X7R_04 D_MDP_D#2 *10u_6.3V_X5R_06 10u_6.3V_X5R_06 C864...

  • Page 69: Mini Dp Port B

    Schematic Diagrams Mini DP Port B mini-Display Port B PLEASE CLOSE TO CONNECTOR 3.3VS_MDP Close to Display PORT R780 0_04 C566 DP_B#3 C874 0.1u_10V_X7R_04 D_DP_B#3 D_DP_B3 C872 0.1u_10V_X7R_04 10u_6.3V_X5R_06 DP_B3 *DVI2012F2SF-900T05_08 R779 0_04 R784 0_04 DP_B#2 C877 0.1u_10V_X7R_04 D_DP_B#2 D_DP_B2 C875 0.1u_10V_X7R_04 DP_B2...

  • Page 70: Hdmi Connector

    Schematic Diagrams HDMI Connector HDMI_5VS HDMI CONNECTOR For ESD HDMI_5VS J_HDMI1 C128L1-K1909-L R634 R666 VOUT P/N = 6-21-14A90-019 C394 C393 2.2K_04 2.2K_04 SY6288DAAC 22u_6.3V_X5R_08 22u_6.3V_X5R_08 *LBAV99LT1G *LBAV99LT1G *LBAV99LT1G PCB Footprint = C12881-100C 3,15,52,54,55 SUSB HDMI_HPD-C HDMI_SCL-C HOT PLUG DETECT uP7549UMA5-20 PCB Footprint = M-SOT23-5A HDMI_SDA-C DDC/CEC GND...

  • Page 71: Vga Pci Express

    Schematic Diagrams VGA PCI Express 3V3_AON 37,48,60 DGPU_PWRGD NV PCI EXPRESS R546 10K_04 2SK3018S3 PEX_CLKREQ# PEG_CLKREQ# R547 *100K_04 BGA1745 PLACE AT PLACE OUTSIDE COMMON PEX_VDD 1/21 PCI_EXPRESS BALLS OF BGA SNN_PEXWAKE BJ21 PEX_WAKE AW33 PEX_IOVDD BE20 AY32 R545 0_04 C109 C125 C101 GPU_PEX_RST#...

  • Page 72: Vga Frame Buffer Partition

    C106 C191 R522 R530 0.1u_10V_X7R_04 0.1u_10V_X7R_04 10K_1%_04 10K_1%_04 10K_1%_04 10K_1%_04 P650SA, P670SA, P65SA Frame A,B ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ 20,21,22,23,24,25,26,27,31,60 FBVDDQ Title Title Title [19] VGA Frame Buffer Partition [19] VGA Frame Buffer Partition...

  • Page 73: Frame Buffer Partition A

    FBA_CLK0* FBA_CLK0* FBA_CLK1* FBA_CLK1* ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ P650SA, P670SA, P65SA Frame A,B Title Title Title [20] Frame Buffer Partition A [20] Frame Buffer Partition A [20] Frame Buffer Partition A 19,21,22,23,24,25,26,27,31,60...

  • Page 74: Frame Buffer Partition B

    20,24,25,30 GPIO10_ALT_MEM_VREF FBB_CLK0* FBB_CLK0* ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ P650SA, P670SA, P65SA Frame A,B Title Title Title [21] Frame Buffer Partition B [21] Frame Buffer Partition B [21] Frame Buffer Partition B Size...

  • Page 75: Frame Buffer Partition A_B

    Schematic Diagrams Frame Buffer Partition A_B FRAME BUFFER PARTITION A/B DECOUPLING FBVDDQ DECOUPLING AROUND FBA MEMORIES (DQ0-DQ31) PLACE Under MEM FBVDDQ PLACE Under MEM DECOUPLING AROUND FBA MEMORIES (DQ32-DQ63) SPARE SPARE C619 C621 C634 FBVDDQ Sheet 22 of 70 FBVDDQ Frame Buffer 1K_1%_04 INS53650384...

  • Page 76: Gpu Frame Buffer Partition

    Schematic Diagrams GPU Frame Buffer Partition FBD_DBI[7..0] FBD_CMD[31..0] GPU FRAME BUFFER PARTITION C/D FBD_DBI[7..0] FBD_CMD[31..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_EDC[7..0] FBC_EDC[7..0] P650SE, P670SE, P65SE Frame D FBC_CMD[31..0] BGA1745 BGA1745 FBC_CMD[31..0] COMMON COMMON FBVDDQ FBC_D[63..0] 4/21 FBC 5/21 FBD FBC_D[63..0] FBC_D0 FBC_CMD0...

  • Page 77: Frame Buffer Partition C

    Schematic Diagrams Frame Buffer Partition C FRAME BUFFER PARTITION C FBC_CMD[31..0] FBC_CMD[31..0] FBC_WCK01 FBC_W CK01 FBC_WCK01* FBC_D[63..0] FBC_D[63..0] FBC_W CK01* FBC_WCK23 FBC_W CK23 FBC_DBI[7..0] FBC_WCK23* FBC_DBI[7..0] FBC_W CK23* FBC_WCK45 FBC_W CK45 FBC_EDC[7..0] FBC_WCK45* FBC_EDC[7..0] FBC_W CK45* FBC_WCK67 FBC_W CK67 FBC_WCK67* INS53657275 FBC_W CK67* BGA170...

  • Page 78: Frame Buffer Partition D

    Schematic Diagrams Frame Buffer Partition D FRAME BUFFER PARTITION D FBD_CMD[31..0] FBD_CMD[31..0] FBD_WCK01 FBD_W CK01 FBD_D[63..0] FBD_WCK01* FBD_D[63..0] FBD_W CK01* FBD_WCK23 FBD_W CK23 FBD_DBI[7..0] FBD_WCK23* FBD_DBI[7..0] FBD_W CK23* FBD_WCK45 FBD_W CK45 FBD_WCK45* INS100801293 FBDEDC[7..0] BGA170 FBD_EDC[7..0] FBD_W CK45* FBD_WCK67 COMMON FBD_W CK67 FBD_WCK67* FBD_W CK67*...

  • Page 79: Frame Buffer Partition C_D

    Schematic Diagrams Frame Buffer Partition C_D FRAME BUFFER PARTITION C/D DECOUPLING FBVDDQ FBVDDQ PLACE Under MEM DECOUPLING AROUND FBC MEMORIES (DQ0-DQ31) DECOUPLING AROUND FBC MEMORIES (DQ32-DQ63) PLACE Under MEM SPARE SPARE C678 C679 C266 C272 C261 C140 C230 C217 C246 C102 C224 C207...

  • Page 80: Gpu Decoupling

    Schematic Diagrams GPU Decoupling GPU DECOUPLING FBVDDQ NVVDD MID-FREQ CERAMICS x11 22uF X5R 0805 FBVDDQ PLACE Near GPU x4 10uF X5R 0805 PLACE Under GPU C171 C172 C124 C174 C173 C648 C651 C650 x8 100nF 0402 X7R C160 C202 C220 C108 C219 C196...

  • Page 81: Daca Interface Xtal

    Schematic Diagrams DACA Interface XTAL DACA INTERFACE and XTAL N15E-GT GC6 1.0 IO PORT PCH BGA1745 COMMON 6/21 DACA AW18 DACA_VDD I2CA_SCL 3V3_RUN I2CA_SCL I2CA_SDA I2CA_SDA AW20 DACA_VREF AY20 BA20 DACA_RSET DACA_HSYNC AY18 DACA_VSYNC AY21 DACA_RED BA21 DACA_GREEN AW21 DACA_BLUE N16E-GT Sheet 28 of 70 DACA Interface and...

  • Page 82: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface N15E-GT optimus IFP I/O INTERFACE IO PORT PCH BGA1745 BGA1745 COMMON COMMON BGA1745 COMMON 7/21 IFPAB 10/21 IFPEF 8/21 IFPC DVI/HDMI GK104 GM204 BB14 IFPCD_RSET IFPA_AUX_SDA DVI/HDMI IFPE_AUX_SDA IFPA_AUX_SCL IFPE_AUX_SCL BB12 IFPCD_PLLVDD IFPC_AUX_SDA BF15 IFPB_AUX_SDA IFPC_AUX_SCL IFPE_L3 BE15...

  • Page 83: Misc - Gpio, I2C And Rom

    Schematic Diagrams Misc - GPIO, I2C and ROM 3.3V MULTI-LEVEL STRAPS MISC: GPIO, I2C, and ROM 3V3_RUN 3V3_RUN 3V3_AON BIOS ROM 3.3V Setting RAM type 3V3_RUN INS53767385 R124 R125 R126 R101 BGA1745 R130 R136 R137 R135 4.99K_1%_04 *34.8K_1%_04 *4.99K_1%_04 *45.3K_1%_04 *45.3K_1%_04 COMMON *4.99K_1%_04...

  • Page 84: Gpu Nvvdd, Fbvddq, And Gnd

    Schematic Diagrams GPU NVVDD, FBVDDQ, and GND BGA1745 BGA1745 GPU NVVDD, FBVDDQ, AND GND COMMON COMMON 16/21 GND_1/2 17/21 GND_2/2 AJ25 BB32 AJ27 BB34 AJ29 BB35 AJ31 BB36 AA15 AK14 NVVDD AA17 AK16 BGA1745 BGA1745 NVVDD NVVDD NVVDD COMMON COMMON AA19 AK18 AA21...

  • Page 85: Lynx 1/9

    Schematic Diagrams Lynx 1/9 Lynx Point (RTC,AZALIA,SATA,JTAG) INTVRMEN- Integrated SUS C797 1.05V VRM Enable 10p_50V_NPO_04 High - Enable Internal VRs RTCVCC Low - Enable External VRs P/N:6-S03-0LYNX-0S0 VDD3 R690 LPT_PCH_M_EDS U108A C770 1u_6.3V_X5R_06 10M_04 SATA_RXN0 SATA_RXN_0 C798 QTFM28-32768K125P20R RTC_X1 SATA_RXP0 main HDD RTCX1 SATA_RXP_0...

  • Page 86: Lynx 3/9

    Schematic Diagrams Lynx 2/9 Lynx Point (LPC,SMBUS SPI,C-LINK) 3.3VA RTC-WakeUp U108D LPT_PCH_M_EDS PCH_BT_EN# R278 10K_04 SMB_CLK R305 2.2K_04 PCH_BT_EN# SMB_DATA R304 2.2K_04 SMBALERT#/GPIO11 48,49 LPC_AD0 LAD_0 SMB_CLK DRAMRST_CNTRL R277 1K_04 SMBus SMBCLK SMB_CLK 9,10,11,12,43,45,50 48,49 LPC_AD1 LAD_1 SMB_DATA SML0_DATA R282 499_1%_04 SMB_DATA 9,10,11,12,43,45,50...

  • Page 87: Lynx 6/9

    Schematic Diagrams Lynx 3/9 Lynx Point (DMI,FDI,GPIO) DSWODVREN - On Die DSW VR Enable R1 STUFFED, Enabled (DEFAULT) R2 UNSTUFFED LPT_PCH_M_EDS U108B AW22 R1 STUFFED, Disabled DMI_RXN0 DMI_RXN_0 AR20 DMI_RXN_1 R2 UNSTUFFED DMI_RXN1 AJ35 FDI_RXN_0 AP17 DMI_RXN2 DMI_RXN_2 AV20 AL35 DMI_RXN3 DMI_RXN_3 FDI_RXN_1...

  • Page 88: Lynx 8/9

    Schematic Diagrams Lynx 4/9 Lynx Point (CRT,DISPLAY,PCI) DDPB mini Display port 3.3VS DDPC HDMI DDPD mini Display port HDMI_CTRLCLK R150 2.2K_04 HDMI_CTRLDATA R149 2.2K_04 INT_PIRQE# R256 *10K_04 SATA_ODD_DA# R220 10K_04 INT_PIRQG# R226 *10K_04 U108E LPT_PCH_M_EDS INT_PIRQH# R192 *10K_04 Flash Descriptor security override strap VGA_BLUE DDPB_CTRLCLK DP_B_CLK...
  • Page 89 Schematic Diagrams Lynx 5/9 Lynx Point (PCIe,USB) P6x0SA P655SE 0 U108I LPT_PCH_M_EDS C750 0.1u_10V_X7R_04 AW31 PCIE_RXN1_SSD USB_PN0 PERN1/USB3RN3 USB2N0 C748 0.1u_10V_X7R_04 AY31 USB3 PORT1, , Charger PCIE_RXP1_SSD PERP1/USB3RP3 USB2P0 USB_PP0 USB_PN1 USB2N1 C744 0.1u_10V_X7R_04 BE32 USB3 PORT2, USB_PP1 PCIE_TXN1_SSD PETN1/USB3TN3 USB2P1 C746 0.1u_10V_X7R_04...
  • Page 90 Schematic Diagrams Lynx 6/9 Lynx Point (GPIO,VSS_NCTF,RSVD) 3.3VA R733 10K_04 SB_BLON C760 *0.1u_10V_X5R_04 H_THRMTRIP# R732 10K_04 GPIO27 PLL_ODVR_EN R311 *10K_04 LPT_PCH_M_EDS R295 *1K_04 U108F PLL_ODVR_EN: EDP_CARD_DET# C754 0.01u_16V_X7R_04 H_CPUPW RGD HIGH- ENABLED (DEFAULT) BMBUSY#/GPIO0 LOW - DISABLED D02A SMI#_R R623 10K_04 SMI# TACH1/GPIO1...
  • Page 91 Schematic Diagrams Lynx 7/9 Lynx Point (POWER) U108G LPT_PCH_M_EDS 1.05VS 1.312A 0.07A R576 *15mil_short_06 VCCADAC1_5 1.312A AA24 CRT DAC AA26 0.0133A V3.3S_ADACBG AD20 R177 *15mil_short_06 VCCADACBG3_3 AD22 C356 C328 C347 C358 C350 AD24 0.183A VCCAPLL_FDI 10u_6.3V_X5R_06 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 AD26 BB44 R152...
  • Page 92 Schematic Diagrams Lynx 8/9 Lynx Point (POWER) 1.05VS VCCIO2PCH RTCVCC R219 0_06 C373 C372 C370 C778 C779 C777 0.1u_10V_X7R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04 0.261A HCB1608KF-121T25 3.3VA 1.05VS C346 C330 R180 0_04 3.3VA LPT_PCH_M_EDS 0.1u_10V_X7R_04 U108H 0.1u_10V_X7R_04 C355 C345 0.1u_10V_X7R_04 0.1u_10V_X7R_04 3.3VS VCCSUS3_3...
  • Page 93 Schematic Diagrams Lynx 9/9 U108J LPT_PCH_M_EDS Lynx Point (GND) AL34 AL38 AM14 AM24 3G_CLKREQ# AM26 R704 10K_04 3.3VS AM28 PCIECLKRQ2# R701 10K_04 AM30 PEG_CLKREQ# R309 10K_04 3.3VA AM32 R294 *10K_04 AM16 AN36 AN40 AN42 LPT_PCH_M_EDS 3.3VA U108C AP13 AP24 PCIECLKRQ3# R306 10K_04 AP31...

  • Page 94: Usb3.0 + Esata Combo

    Schematic Diagrams USB3.0 + eSATA Combo USB3.0 re-driver USB3.0 PORT5 3.3V (MB ) 3.3V USBVCC3.0_5 *4.7K_04 *0_04 *4.7K_04 *0_04 R513 R519 VOUT *4.7K_04 *0_04 *4.7K_04 *4.7K_04 C639 C638 *4.7K_04 2K_1%_04 I2C_SCK_P5 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 I2C_SDA_P5 R517 *4.7K_04 R516 0_04 R512 R518 *10mil_short_04 SY6288DAAC...

  • Page 95: Usb Charger

    Schematic Diagrams USB Charger USB3.0 re-driver 3.3V 3.3V R686 *4.7K_04 R687 *0_04 R680 *4.7K_04 R681 *0_04 R659 R694 R676 *4.7K_04 R677 *0_04 *4.7K_04 *4.7K_04 R671 *4.7K_04 R672 2K_1%_04 I2C_SCK_P1 I2C_SDA_P1 R667 *4.7K_04 R668 0_04 R660 R695 *4.7K_04 *4.7K_04 I2C_SDA_P1 I2C_SCK_P1 USB3_TXN1 TXN1 0.1u_10V_X7R_04...

  • Page 96: M.2 Sata

    Schematic Diagrams M.2 3G + M.2 SATA 3.3VS M.2 SATA re-driver 3G CARD / M.2 SATA R761 SATA5_GPIO49 CURRENT2A ,DON'T DROP BELOW 3.135V SATA5_GPIO49 *10K_04 3G_3.3V 80 mils H: SATA 3.3VS 3G_CONFIG1 J_3G1 C850 220u_6.3V_6.3*6.3*4.2 L: PCIe R391 *0_04 R403 0_04 *2SK3018S3 C516...

  • Page 97: Wlan+Bt, Pcie4X Ssd

    Schematic Diagrams M.2 WLAN+BT, PCIE4X SSD J_W LAN1 40 mil WLAN+BT W LAN_3.3V GND10 3.3V3 Reserved/REFCLKN1 3.3V2 C281 Reserved/REFCLKP1 UIM_Power_In/Gpio1/PEWake1# GND9 UIM_Power_Out/CLKREQ1# 0.1u_16V_Y5V_04 Reserved/PERn1 UIM_SWP/PERST1# Reserved/PERp1 Reserved1 GND8 ALERT#(I) R163 10K_04 *2mm Reserved/PETn1 I2C CLK(O) W LAN_3.3V 3.3V R162 10K_04 Reserved/PETp1 I2C DATA(IO) VDD3...

  • Page 98: Realtek Alc892

    Schematic Diagrams Realtek ALC892 3.3V 3.3V 2,3,13,30,32,41,42,43,44,49,50,51,52,54,55,58,59,60 Layout Note: 3.3VS 3,9,10,11,12,13,14,15,16,17,32,33,34,35,37,38,39,40,41,43,44,46,48,49,50,51,54,57 41,49,51,52,54,55,58,59,60 U43 pin 1 ~ pin 11 and pin 47 and pin 48 C522 0.1u_16V_Y5V_04 13,15,16,17,32,35,46,47,49,50,51,54,57 are Digital signals. R457 C521 0.1u_16V_Y5V_04 The others are Analog signals. *100K_04 HCB1005KF-121T20 C525 0.1u_16V_Y5V_04 3.3VS...

  • Page 99: Tpa2008D2

    Schematic Diagrams TPA2008D2 AMP_5VS TPA2008D2 HCB1608KF-121T25 The volume control.the gain range is from -80db(Vvolume=5V) to +20db(Vvolume=0V) with P2P BA20550 64 steps precise control. C535 C536 C526 (TSSOP24) 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 22u_6.3V_X5R_08 Front Speaker R / L AUDG AUDG AUDG 4 Ohm 2W Speaker AMP_EN ROUTP FCM1005KF-121T03...

  • Page 100: Subwoofer

    Schematic Diagrams Subwoofer P670SE ONLY 2.2_04 2200p_50V_X7R_04 SAMP_PW R SAMP_PW R SC40 SC41 SC12 SC10 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 BCIHP0420TB-2R2M SAMPPW R_SW 10K_04 AUDG_2 AUDG_2 AUDG_2 AUDG_2 AUDG_2 FMS3004-AS-H SOSCIN *10K_04 45,46 AMP_EN OSCIN 10u_6.3V_X5R_06 SR13 0_04 MUTE OSOC SAMPPW R_FREQ SR19...

  • Page 101: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 P670SE IT8587 MODEL_ID RB (PL) RA (PH) Voltage J_KB2 KBC_AVDD (85208-24051) VDD3 P650SE HCB1005KF-121T20 KB-SI0 MODEL_ID R783 10K_04 P650SG VDD3 VDD3 KB-SI1 C534 C562 C610 C611 C604 C609 KB-SI2 R781 *10K_04 P670SE 15.4K KB-SI3 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04...

  • Page 102: Tpm, Ccd, Tp

    Schematic Diagrams TPM, CCD, TP FOR TP SLB9665TT 3.3VS TP_VCC R488 *0_04 R427 *0_04 R456 R425 C865 3.3V 3.3VS D02A C617 C616 R426 0_04 10K_04 10K_04 *10u_6.3V_X5R_06 R489 0_04 3.3VS 0.1u_16V_Y5V_04 *10u_6.3V_X5R_06 J_TP1 C923 0.1u_16V_Y5V_04 TP_CLK PIN5 TP_DATA 33,48 LPC_AD0 LAD0 VDD1 PIN5...

  • Page 103: Fan, Lid, Kb, Led, G Sensor

    Schematic Diagrams Fan, LID, KB, LED, G Sensor CPU FAN CONTROL VGA FAN CONTROL-Selector LID SWITCH IC FON1# VDD3 VOUT C321 C316 100K_04 VSET 1u_6.3V_X5R_04 *4.7u_6.3V_X5R_06 NCT3940S-A C705 0.1u_16V_Y5V_04 CPU_FAN CPU_FAN LID_SW # 13,48 5VS_CPU_FAN J_FAN1 VGA_FAN2SEN *1u_10V_Y5V_06 0.1u_16V_Y5V_04 MH-248 *100p_50V_NPO_04 VGA_FAN1SEN MH248-ALFA-ESO...

  • Page 104: Connector

    Schematic Diagrams Connector D02A 3.3VS LED BOARD LAN BOARD C381 ( USB3.0x2, PHONE JACK) *0.01u_16V_X7R_04 J_LED1 J_LAN1 LED_ACIN LED_PW R USB_PN9 LED_BAT_CHG USB_PP9 C453 C437 LED_BAT_FULL LED_NUM# USB3_TXN6 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 D02A LED_CAP# USB3_TXP6 R1300 0_04 LED_SCROLL# DGPU_PW R_EN 58,59 USB3_RXN6 AIRPLAN_LED# USB3_RXP6 R1299...

  • Page 105: Ddr 1.35V / 0.75Vs, Pch 1.5V

    Schematic Diagrams DDR 1.35V / 0.75VS, PCH 1.5V PQ36 1.35V/0.75VS (MDU1516) PC212 PC220 PC219 ULTRASO-8 RB0540S2 G5616 VTT_MEM VDDQ_R PC74 1.35V PC79 0.1u_10V_X7R_04 VLDOIN VBST Short 10u_6.3V_X5R_06 EMR1 VDDQ_R VTT_MEM DRVH 0_06 1.0UH_10*10*4.5 PJ14 PC77 VDDQ VTTGND PC73 PC75 PR79 EMR2 22u_6.3V_X5R_08 *10u_6.3V_X5R_06...

  • Page 106: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR186 *0_04 PR189 0_04 PC190 1u_10V_Y5V_06 PR188 PR202 EN_3V EN_5V PC192 130K_1%_04 130K_1%_04 PC210 1000p_50V_X7R_04 1000p_50V_X7R_04 D01A PU17 VREG3 PC217 PC216 PC215 PC207 Sheet 53 of 70 PC188 R737 *10K_04 15u_25V_6.3*4.4 0.1u_50V_Y5V_06 SYS5V VDD3 LDO3 VDD5 1u_6.3V_X5R_06 PC208...

  • Page 107: 5Vs, 3.3V, 3.3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA VIN1 VIN1 DD_ON R167 100K_04 VIN1 R168 *100K_04 USB_CHARGE_EN 42,48,53 DD_ON_LATCH C893 C894 C895 C568 C513 R216 10K_04 R169 10K_04 C486 M_BTN# M_BTN# PWR_SW# VDD3 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 R217 *100K_04 R170 1K_1%_04 PW R_SW # INSTANT-ON USB_CHARGE_EN R218...

  • Page 108: Series

    Schematic Diagrams 1.05 Series For CV test 1.05V_LAN_M R615 100K_04 PR180 820K_1%_06 PJ18 *CV-40mil PC182 PC183 PC186 1.05V_LAN_M_EN PM_SLP_LAN# PJ19 PU16 PQ27 (MDU1516) VTT_SELECT VTT VR Output Voltages PR179 PC179 ULTRASO-8 34,42,45,46,48,54,55 SUSB# 1.1 V PJ20 *1mm 0_06 0.1u_10V_X7R_04 high (V1.1S_VTT) 1.05 V EN_PSV C752...

  • Page 109: Ac_In, Charger

    Schematic Diagrams AC_In, Charger EMB20P03V PR222 0_04 PQ15 V_BAT EMB20P03V PR221 *470K_04 EMR11 C559 C541 C518 EML2 2.2_06 HCB2012KF-800T80 0.01u_50V_X7R_04 0.01u_50V_X7R_04 0.01u_50V_X7R_04 EMB20P03V PQ17 EMB20P03V EML1 *HCB2012KF-800T80 0.01u_50V_X7R_04 EMC7 PR223 C567 PR213 2200p_50V_X7R_04 *49.9K_1%_04 JBATTA1 20K_1%_04 J_DC_JACK1 EML5 0.01u_50V_X7R_04 PQ43A HCB2012KF-800T80 EMB20P03V PQ16...

  • Page 110: Power V-Core1

    Schematic Diagrams POWER V-Core1 3.3VS PR225 *20mil_04 PR224 *20mil_04 PR113 PR101 *20mil_04 TSENSE EWTF02-104F4F-N PR70 SWN3 CSREF 100K_04 162K_1%_06 PC81 PR75 APGND *20K_04 PJ13 PR72 PR69 SWN1 PR74 165K_1%_04 162K_1%_06 CSP3 PR73 6.98K_1%_04 *CV-40mil SWN3 0.047u_10V_X7R_04 APGND PJ12 75K_1%_04 PR131 VR_EN PC80 1200p_50V_X7R_04...

  • Page 111: Pex_Vdd, 3V3_Aon, 3V3_Run

    PGOOD FBVDD/Q For P650SE Title Title Title GC6_FB_EN [58] PEX_VDD, 3V3_AON, 3V3_RUN [58] PEX_VDD, 3V3_AON, 3V3_RUN [58] PEX_VDD, 3V3_AON, 3V3_RUN P650SG, P670SE, P670SG, P650SA, P670SA, P655SE, P655SA Size Size Size Document Number Document Number Document Number 6-71-P6500-D03 6-71-P6500-D03 6-71-P6500-D03 Custom...

  • Page 112: Nvvdd Phase 1 & 2

    Schematic Diagrams NVVDD Phase 1 & 2 PR173 2.2_1%_06 PWR_SRC_NV PAGE 21: NVVDD PHASE 1 and 2 Optional Place Close to DrMOS PS1_NVVDD_VCC PR50 100K_04 PS1_NVVDD_PVCC PC34 PC132 PC133 PC65 PC54 PC171 PC58 PC67 PC66 PC50 PC63 PC62 0.1u_10V_X7R_04 0.1u_10V_X7R_04 22u_6.3V_X5R_08 FREQ SELECTION PR28...

  • Page 113: Fbvddq

    Schematic Diagrams FBVDDQ PAGE22: NVVDD PHASE 3, FBVDDQ, and MXM Mounting Holes ~6A at 15A/1.5V Output with 7V Input PWR_SRC_NV_FB Optional Place Close to DrMOS FBVDDQ PC130 PC131 PC26 PC21 PC16 PC10 PC126 PC12 PC25 INS102340263 TPS51211 DFN10 COMMON LFPAK 3.3V PQ25 PC129...

  • Page 114: Audio Board

    Schematic Diagrams Audio Board AJ_SPDIF1 A_5VS AJ_MB1 ASIDE_L FCM1005KF-121T03 ASIDE_R FCM1005KF-121T03 ASIDE_SENSE AGND ASPDIFO AC10 A_AUDG AJD_SENSEA A_5VS 680p_50V_X7R_04 680p_50V_X7R_04 AJD_SENSEB A_AUDG DRIVE AMIC1-R AMIC1-L ASPDIFO FCM1005KF-121T03 ASIDE_R 1.56 ASIDE_L P/N = 6-20-B2820-005 AR10 0.1u_16V_Y5V_04 PCB Footprint = TOJ-001ST-2-H4 AHEADPHONE-RC *220_04 180p_50V_NPO_04 VENDOR P/N = TOJ-0015STR2-2-H4-PA9T-J...

  • Page 115: Power Board

    Schematic Diagrams Power Board B3.3VS BJ_BTN1 BM_BTN# FP226H-004S10M PCB Footprint = fp226h-004xxxm_r BGND *0_04 *0_04 *0_04 *0_04 Sheet 62 of 70 B3.3VS POWER BUTTON *0_04 *0_04 POWER Power Board B_SW1 SWITCH TJE-532-Q-T/R BM_BTN# 20mil 220_1%_04 PCB Footprint = NTC017-BB1J-X160T 20mil BGND 0.1u_50V_Y5V_06 20mil...

  • Page 116: Hdd Board

    Schematic Diagrams HDD Board SATA PORT1 HJ_SATA1 H_SATA_TXP1 H_SATA_TXN1 H_SATA_RXN1 H_SATA_RXP1 H_3.3VS HJ_MB1 HGND HSATA_TXP1 HC13 HC11 HSATA_TXN1 *0.01u_16V_X7R_04 *10u_6.3V_X5R_06 HSATA_RXN1 H_5VS HGND HGND HSATA_RXP1 H_5VS HGND HC10 HC12 H_3.3VS HGND EEFCX0J221YR 0.1u_16V_Y5V_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 220u,6.3V,ESR=15m ,H=1.9mm 50009-03041-001 51824-0227A-001 P/N = 6-21-C2430-215 Sheet 63 of 70 P/N = 6-20-437J0-022 PCB Footprint = 50009-0304x...

  • Page 117: Finger Sensor Board

    Schematic Diagrams Finger Sensor Board NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND MODE FUSB_PP F3.3V AVDD FUSB_PN F2.5V F2.5V DVDD FMOSI F3.3V F3.3V VDDIO UVDD FMCLK FLED1 FLED1 FMCS FMCS FLED2 LED1 SPI_CS FMISO FDISCON FMOSI FMISO SPI_MOSI...

  • Page 118: Click Board

    Schematic Diagrams Click Board T3.3V W/O FP TJ_CLICK T_TP_VCC T_TP_BTN_L TJ_TP FCM1005KF-121T03 T_TP_BTN_R T_TP_CLK H7_0D3_7 H7_0D3_7 T_TP_DATA FP226H-004S10M TJ_FP1 PCB Footprint = JXT_FP226H-004XXAM T_TP_BTN_L T_TP_VCC T_TP_BTN_R TGND 27.4_1%_04 TUSB_PN10 TJ_MB 50501-0060N-001 27.4_1%_04 TUSB_PP10 T_TP_CLK TGND TGND TGND *V15AVLC0402 T_TP_DATA FP226H-004S10M TGND *V15AVLC0402 PCB Footprint = fp226h-004xxxm_r...

  • Page 119: Usb Board 1/4

    Schematic Diagrams USB Board 1/4 LAN (RTL8411B) Switching Regulator close to PIN48 2 IN 1 SOCKET Crystal 5032 SIZE ZR44 0_06 ZVDD10 ZRSET ZR33 2.49K_1%_04 (>20mil) Standard PUSH PUSH CARD READER ZGND meet realtek Freq tolerance 50ppm ZR37 *1K_04 ZREGOUT ZVDD10 ZJ_CARD1 ZXTAL2...

  • Page 120: Usb Board 3/4

    Schematic Diagrams USB Board 2/4 USB3.0 re-driver Z3.3V USB3.0 PORT6 Z3.3V P67 USB D02 ZR59 *4.7K_04 ZR60 *0_04 ZR70 *4.7K_04 ZR71 *0_04 ZR99 ZR42 ZUSBVCC3.0_6 ZR79 *4.7K_04 ZR80 *0_04 *4.7K_04 *4.7K_04 100 MIL ZR87 *4.7K_04 ZR88 2K_1%_04 VOUT Z_SCK_P6 ZR93 *4.7K_04 ZR94 0_04...
  • Page 121 Schematic Diagrams USB Board 3/4 USB3.0 PORT2 USB3.0 re-driver Z3.3V Z3.3V ZUSBVCC3.0_2 ZR61 *4.7K_04 ZR62 *0_04 100 mil ZR73 *4.7K_04 ZR74 *0_04 ZR100 ZR45 VOUT ZR81 *4.7K_04 ZR82 *0_04 ZC18 *4.7K_04 *4.7K_04 10u_6.3V_X5R_06 ZC17 ZC16 Z_SCK_P2 ZR89 *4.7K_04 ZR90 2K_1%_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 Z_SDA_P2...
  • Page 122 Schematic Diagrams USB Board 4/4 RSVD. RTS5227 Colay RTS5250 Z3.3VS Z3V3AUX ZR34 ZCR1_LEDN ZR32 *10K_04 *10K_04 Z3.3VS Sheet 69 of 70 40 mil IDD-3V3AUX: 375mA(typ) ZR26 *0_04 *RB751S-40C2 71,72 ZPCIE_W AKE# ZC33 ZC30 USB Board 4/4 100ohm +/- 15% *4.7u_6.3V_X5R_06 *0.1u_16V_Y5V_04 ZGND ZGND...

  • Page 123: Led Board

    Schematic Diagrams LED Board P67 LED D03 YR30 *330_04 YJ_MB YLED_ACIN YLED_ACIN YD1_1 YR17 330_04 YLED_PWR Oragne YLED_BAT_CHG YR31 *330_04 YLED_BAT_FULL YLED_NUM# YLED_PWR YR16 330_04 YD1_3 YLED_CAP# Green YLED_SCROLL# RY-SP195UHYUYG4 Y_WLAN_AIRPLANE# AC IN/POWER ON LED Y_dGPU_LED MBD03 BCN YSATA_LED# Y_GND LOT3 Y_GND Y_3.3VS...
  • Page 124 Schematic Diagrams B - 72...

  • Page 125: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 126: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.

This manual is also suitable for:

P671sa

Table of Contents
