Xerox Document WorkCentre 470cx

To go to a chapter in this book, click on one of the following links.

After displaying a chapter, you can click on an entry in the

chapter's Table of Contents, or click on the Search button to look

for a key word or phrase. To go to a printable copy of this User

Guide, click on the Print Preview button on the left.

Safety Notes

Getting Started

Making a Copy

Sending a Fax

Receiving a Fax

Printing

Scanning

Troubleshooting

Maintenance

Specifications and Regulatory Information

Telephone Connectivity Guide

Glossary

Online User Guide

Table of Contents

Summary of Contents for Xerox Document Centre 470cx

Page 1 Search Print Preview Xerox Document WorkCentre 470cx To go to a chapter in this book, click on one of the following links. After displaying a chapter, you can click on an entry in the chapter’s Table of Contents, or click on the Search button to look for a key word or phrase.
Page 2: Safety Notes
Book Chapter Search Safety Notes Your WorkCentre 470cx and supplies are designed and tested to meet strict safety requirements. Included are safety agency examination and approval and compliance to established environmental standards. Please read the following instructions carefully before operating the WorkCentre 470cx, and refer to them as needed to ensure the continued safe operation of your WorkCentre.
Page 3 Book Chapter Search Do not use the WorkCentre 470cx near water, in wet locations, or outdoors. Do not place the WorkCentre 470cx on an unstable cart, stand, or table. The WorkCentre 470cx may fall, causing personal injury or serious damage to the machine. This product is equipped with a grounding type plug.
Page 4 Book Chapter Search Slots and openings in the cabinet and in the back and sides of the WorkCentre are provided for ventilation. To ensure reliable operation of the WorkCentre and to protect it from overheating, these openings must not be blocked or covered. The WorkCentre 470cx should never be located near or over a radiator or heat register.
Page 5 Always keep the document cover closed during operation and storage. If you need additional safety information concerning the WorkCentre or Xerox supplied materials, you may call the following toll-free number. In the United States or Canada: 1 - 800 - 828 - 6571...
Page 6 Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted. Xerox and all Xerox products mentioned in this publication are trademarks of Xerox Corporation. Xerox and all Xerox products mentioned in this publication are registered trademarks of the Xerox Corporation and used by Xerox Canada Ltd.
Page 7: Getting Started
Book Chapter Search Click on one of the following topics, or use the Search button on the left. Set Up Your Machine Paper Guidelines Guidelines for Special Paper and other Media Installing Software Using the Control Panel System Setup Previous Page Chapter 1 Getting Started Next Page...
Page 8 Book Chapter Search Set Up Your Machine Unpacking WorkCentre Cartridges Document exit Document tray Input tray Telephone line Power cord cord *1 CD ROM containing Installer, Software and Online User Guide. *2 Appearance may vary according to country. Previous Page WC470cx Quick WC470cx Quick Installation Guide...
Page 9: Control Locations And Functions
Book Chapter Search Control Locations and Functions Take a moment to familiarize yourself with the main components and their locations. Document Automatic Input Tray Document Feeder Paper Guide Document Guide Control Panel Document Exit Tray Paper Exit Tray Note: Your machine may look slightly different than the illustration. Previous Page Paper Feeder Extension Tray...
Page 10 Book Chapter Search Rear Power Cord Connector PC Cable Connector Inside Color Ink Cartridge Control Panel Cover Previous Page EXT Jack LINE Jack Ink Cartridges Next Page...
Page 11: Choosing A Location
Book Chapter Search Choosing a Location To help guarantee trouble-free operation of your machine, place it on a flat, stable surface near your workstation. Leave enough space to allow for easy paper loading, paper unloading, and opening of the front cover. Do not place your machine: •...
Page 12 Book Chapter Search Paper Exit Tray Slide the Paper Exit Tray out from the base of the machine. If desired, fold out the extension tray. Document Exit Tray Insert the two tabs on the document exit tray into the slots on the front of your machine.
Page 13 Book Chapter Search Telephone Line Note: There are many possible ways to connect telephone accessories to the WorkCentre 470cx. Refer to Connectivity Guidelines on page 9-25 for more detailed connection scenarios. Plug one end of the telephone line cord into the TEL LINE jack and the other end into a standard phone wall jack.
Page 14 WorkCentre 470cx, connect it to the jack labeled EXT on the side of the machine. PC Cable Your Xerox WorkCentre 470cx is equipped with a parallel interface port for use with IBM PCs and compatible computers. Using the supplied Centronics parallel cable, connect your WorkCentre 470cx to a computer that supports bi-directional communications (IEEE standard 1284).
Page 15 Book Chapter Search To connect the WorkCentre 470cx to a computer, follow the steps below: CAUTION: Make sure the computer is turned off, and the WorkCentre 470cx is unplugged from the power outlet. Plug the parallel cable into the connector on the back of the WorkCentre 470cx.
Page 16 Book Chapter Search AC Power Cord WARNING: THERE IS NO ON/OFF SWITCH FOR THE WORKCENTRE 470CX. WHEN THE AC POWER CORD IS PLUGGED IN, THE MACHINE IS FULLY ENERGIZED. Plug one end of the AC power cord into the back of the machine and the other end into a grounded AC power outlet.
Page 17 Book Chapter Search The machine turns on and performs a self diagnostic test. POWERING UP PLEASE WAIT appears on the LCD display. If you are setting up the machine for the first time, or if the machine has not been operated for an extended period of time, it will emit an alarm sound and the Alarm LED will light.
Page 18: Installing Ink Cartridges
The procedures in this section cover Ink Cartridge Installation without using the WorkCentre 470cx Control Program. To install Ink Cartridges using the WorkCentre 470cx Control Program, refer to The Xerox WorkCentre Control Program Previous Page on page 5-26. 1-12 Next Page...
Page 19 Book Chapter Search Installing Ink Cartridges Press the button. The Cartridge Carrier Assembly Cartridge moves to the center of the machine. Lift open the Control Panel cover by pulling up on the Control Panel. Control Panel The Cartridge Compartment Cover is now accessible. Open the Cartridge Compartment Cover by lifting up on the recessed handle.
Page 20 Book Chapter Search Unwrap and remove the Black Ink Cartridge from its packaging. Hold the cartridge by the top only. Note: Avoid touching the electrical contacts on the cartridge. Carefully remove the sealing tape by pulling straight out on the tab located at the end of the Ink Cartridge.
Page 21 Book Chapter Search Locate the Black Ink Cartridge holder inside the printer. The Black Ink Cartridge holder is located on the right side of the Cartridge Carrier Assembly and can be identified by a black key tab. Slide the Black Ink Cartridge down into the holder and push it in the direction of the arrow until it clicks into place.
Page 22 Book Chapter Search Unwrap and remove the Color Ink Cartridge from its packaging. Hold the cartridge by the black areas or colored top only. Note: Avoid touching the electrical contacts on the back of the cartridge. Carefully remove the sealing tape by pulling straight out on the tab located on the end of the Ink Cartridge.
Page 23 Book Chapter Search Locate the Color Ink Cartridge holder inside the printer. The Color Ink Cartridge holder is located on the left side of the Cartridge Carrier Assembly and can be identified by a light blue key tab. Slide the Color Ink Cartridge down into the holder and push it in the direction of the arrow until it clicks into place.
Page 24: Loading Paper
Book Chapter Search Press the button to confirm your choice. RIGHT CARTRIDGE? appears in the top line of the LCD display. Press the buttons until NEW BLACK CARTRIDGE appears in the lower line of the display. Press the button to confirm your choice. The Cartridge Carrier Assembly moves back to the docking position.
Page 25 Book Chapter Search Using the Automatic Paper Feeder You can stack paper, envelopes, card stocks, labels, or transparencies in the Automatic Paper Feeder to feed automatically. The Automatic Paper Feeder can hold a maximum of 100 sheets of 20 lb plain paper, or 10 envelopes or other print media.
Page 26 Book Chapter Search Straighten the edges on a level surface. Note: If envelopes jam while printing, try reducing the number of envelopes in the Automatic Paper Feeder. For transparencies, be sure to use transparency stock approved for use with inkjet printers. Refer to the packaging for the transparency stock to determine the print side.
Page 27 Book Chapter Search Load the print material in the Automatic Paper Feeder. Ensure that the right edge of the media is in contact with the right side of the Automatic Paper Feeder. Do not exceed the rated capacity. Do not mix different types of print media. Refer to the following instructions for loading each type of print material.
Page 28 Book Chapter Search While squeezing the tab on the paper guide, move the guide to the right. Slide the paper guide until it lightly touches the side of the stack of print media. Do not press the paper guide too tightly to the edge of the print media, the guide may bend the media or provide too much resistance when feeding.
Page 29 Book Chapter Search Loading Envelopes When printing envelopes, remember to use the envelope guide in the Automatic Paper Feeder. To load envelopes: Turn the envelope guide upright. Previous Page 1-23 Next Page...
Page 30 Book Chapter Search Load envelopes with the address side facing you. The end of the envelope with the stamp area must enter the Automatic Paper Feeder first. The right edge of the envelope must align with the raised edge of the envelope guide. Squeeze the Left Paper Guide and move it to the right until it lightly touches the envelope.
Page 31 Book Chapter Search CAUTION:Never use envelopes with clasps, snaps, windows, coated linings, or self-adhesive seals. These envelopes may severely damage the printer. Using the Manual Paper Feeder Use the Manual Paper Feeder to feed paper one sheet at a time into your machine.
Page 32 Book Chapter Search Place the paper in the Manual Paper Feeder and adjust the paper guide to the width of the print material. Slide the paper guide to the right until it lightly touches the stack of print media. Do not tightly press the paper guide to the edge of the print media, the guide may bend the media or prevent the media from feeding.
Page 33: Paper Guidelines
• Attempting to print on damp, curled, wrinkled, or torn paper can cause paper jams and poor print quality. • Use only high quality, copier grade paper. Avoid paper with embossed lettering, perforations, or texture that is too smooth or too rough.
Page 34: Paper Selection
Paper Types Plain Paper The machine supports paper sizes of letter, legal, and A4 in portrait orientation. You can use regular copier paper, cotton bond papers, and typical letterhead. Always use paper without curls, folds, staples, or damaged edges. Inkjet Paper This paper has been developed specifically for printing with inkjet printers.
Page 35 Book Chapter Search Coated Paper The coated paper has been developed for high quality printing with minimal or no smearing or running when in contact with water or damp surfaces, making it a good choice for damp or rainy environments. Glossy Photo Paper Glossy photo paper is a high gloss, thicker paper that produces the look and feel of a photograph.
Page 36 Book Chapter Search Greeting Card Stock Get the most out of card making software with Greeting Cards. These cards give your unique, personalized cards the look and feel of professional cards. You can create cards, invitations, announcements, and more. Guidelines for Special Paper and other Media Be sure to read any instructions that come with your special paper.
Page 37 Book Chapter Search To avoid smudging caused by fingerprints, handle transparency film and coated paper carefully. To avoid fading, do not expose the printed film to prolonged sunlight. Store unused media flat. Do not remove papers from their protective packaging until you are ready to use them. Store unused media at temperatures between 59 and 86 degrees Fahrenheit (15 to 30 degrees Centigrade).
Page 38: Installing Software
Book Chapter Search Installing Software System Requirements Proper operation of the WorkCentre 470cx requires that your personal computer meets or exceeds the following system requirements: • IBM compatible personal computer, with a 486SX 33MHz or faster processor • Windows operating environment (3.1x, Windows 95, Windows 98, Windows NT 4.0) •...
Page 39: Software Installation Procedure
CD ROM. Software Installation Procedure In Windows 3.x, Windows 95/98, or Windows NT 4.0 Make sure the Xerox WorkCentre 470cx is connected to your computer. Power off the WorkCentre 470cx by unplugging it from the wall outlet.
Page 40 Power on the Workcentre 470cx by plugging it into a grounded wall outlet. Insert the supplied CD into your computer’s CD ROM drive. The Xerox WorkCentre 470cx installation program will begin. If the program does not start: From the Start menu, select Run (Windows 95/98 and NT 4.0).
Page 41: Uninstalling Software
Book Chapter Search Note: You must shut down and restart your computer to complete the installation process. If your computer does not shut down and restart automatically, you must shut it down manually and restart it before the changes you have made take effect. Note: The WorkCentre 470cx will be selected as the Default printer in Windows after installing the printer driver.
Page 42 Book Chapter Search The Program Group will open. Double Click on the Uninstall icon. The selected component is uninstalled. In Windows 95/98, or Windows NT Start Windows. From the Start menu, select Programs. Locate the Start Menu Program Item for the component you wish to uninstall.
Page 43: Using The Control Panel
Book Chapter Search Using the Control Panel Stop Use to stop an operation at any time. Copy Use to copy a document. Start/Enter Use to start a job. Also use to activate the selection shown in the display. One-touch Dial and Special Function Buttons Use to call most...
Page 44 Book Chapter Search Use to move the ink cartridge assembly to the center position when installing or changing ink Use to eject paper from the printer if the paper is not automatically fed out from the printer after printing. Also, use to load paper if the machine runs out of paper during a PC print job.
Page 45 Book Chapter Search Search/Delete Use to search for numbers in memory. Also use to delete digits in the edit mode. Receive ( Receive Mode ) Use to choose the receive mode you want to use. The selected mode is displayed. Resolution Use to choose the resolution of copied or transmitted documents.
Page 46: System Setup
Book Chapter Search System Setup Ringer Volume You can adjust the volume of the ringer to the desired loudness. Press the button, then press the System Setup button Menu on the one-touch keypad. The display indicates RINGER VOLUME ?. Press the Start/Enter button, then press the button to choose the desired loudness of the ringer.
Page 47: Default Settings
Book Chapter Search DEFAULT SETTING ?. For details on the Default Settings menu, see Default Settings To return to Standby mode, press the Default Settings The default print resolution and contrast can be set to their most frequently used modes. Whenever a document is sent or copied, the home contrast and resolution mode will be activated unless otherwise changed by using the Resolution or Contrast button on the control panel.
Page 48 Book Chapter Search Press 1. or press the Start/Enter Resolution set up menu. You may also use the buttons to select 1. RESOLUTION. DEF. RESOLUTION FINE The current Default Resolution is displayed. Press the Left or Right the desired mode: •...
Page 49 Book Chapter Search Press the and Down keypad to enter the Default Contrast set up menu. DEF. CONTRAST NORMAL The current Default Resolution is displayed. Press the Left or Right the desired mode: • NORMAL–use with documents of average or normal contrast.
Page 50 Book Chapter Search Arrange Alignment The Arrange Alignment menu settings provides an easy way to check and adjust Ink Cartridge print head alignment. To run the Arrange Alignment: Press the button, then press the Maintenance button Menu on the one-touch keypad. The display indicates SELF TEST ?. Press the Down button.
Page 51 Book Chapter Search The letter A, located on the right end of the lower line in the display, corresponds to alignment test pattern A. The range of numbers bracketed in the center of the display line indicates the range of valid pattern selection choices. The flashing number on the left side of the display indicates the line from print pattern A that is currently selected as optimal.
Page 52: Clean Head
Book Chapter Search Using the Number Keypad, enter the number of the line which appears the straightest from Alignment pattern D. Press the Start/Enter button to confirm your selection and return to normal operation. Clean Head The Clean Head procedure cleans the print nozzles and removes any deposits that may impair printing functions.
Page 53: Select Language
Book Chapter Search Select Language Select Language allows you to configure the default language for the LCD panel display. You may choose between two different languages: English and French. To select a default language: Press the button, then press the System Setup button Menu on the one-touch keypad.
Page 54: Adjusting Speaker Volume
Book Chapter Search Adjusting Speaker Volume Press the button on the front panel to adjust the speaker volume. If you cannot hear a dial tone, check the phone line connection. The display indicates the current volume level. Press the or Down button repeatedly until the desired loudness setting is displayed.
Page 55: Setting The Date And Time
Book Chapter Search Press 1 to select a 12 hour Clock Mode or, Press 2 to select a 24 hour Clock Mode. Setting the Date and Time The current date and time are shown in the display when the machine is on and ready for use (Standby mode). The date and time are printed on all faxes you send.
Page 56: Setting The System Id (Your Number And Name)
Book Chapter Search Press the Start/Enter button when the date and time settings displayed are correct. The display indicates the date and time you have set, then returns to Standby mode. Note: If an invalid number is entered, the machine beeps and does not proceed to the next step.
Page 57 Book Chapter Search Note: If there is a number previously registered, it appears in the display. Enter the telephone number (up to 20 digits) to which your machine is connected. You can enter a space by pressing the Right times. If an incorrect number is entered, press the Right button to move the cursor under the incorrect digit, then enter the correct number or press the Search/Delete button to delete...
Page 58 Book Chapter Search If you want to enter the same letter or number in succession (for example, SS, AA, 777), enter one digit, then move the cursor by pressing the Right button, and enter the next digit. Use the Right button to insert a space in the name.
Page 59 Book Chapter Search Reports/Lists Your fax machine can print reports or lists containing useful information like Scheduled Jobs and System Data. The following reports are available: • Journal (One-Touch button 14) The journal consists of two reports, a Transmission Report and a Reception Report.
Page 60 Book Chapter Search You can set up your machine to print a TX Confirm report: • Automatically after each transmission (ON). • Automatically only if an error occurs during transmission (ERR). The machine can be set to print no report at all (OFF). You can print this report manually whenever you want.
Page 61 Book Chapter Search To Print Reports/Lists Press the button. Menu Press the One-Touch button corresponding to the desired report or list on the one-touch keypad. Refer to the table below: One-Touch Button Label Button # Journal Help List TX Confirm Schedule Job Phone Book System List...
Page 62 Book Chapter Search Note: Any report or list which is configured to print automatically will not print if your machine runs out of ink or paper, has a paper jam, or is printing a file sent from a PC. User Options (System Data) Your machine has various user-selectable features.
Page 63 Book Chapter Search You can use Right or Left setting. Press the Start/Enter button to store your choice in memory. You can exit from setup mode at any time by pressing the button. When you press the stores the options you changed and returns to the Standby mode.
Page 64 Book Chapter Search Press 1 to print a confirmation report automatically each time you send a fax (ON). Press 2 to turn this feature off (OFF). Press 3 to print only when an error occurs and the transmission was not successful (ERR). •...
Page 65 Book Chapter Search Press 1 if the fax machine is connected to a tone (Touch Tone) dial line. Press 2 if the fax machine is connected to a pulse (Rotary) dial line. • ECM MODE (Error Correction Mode) - This mode compensates for poor line quality and ensures accurate, error- free communication with any other ECM-equipped facsimile machine.
Page 66 Book Chapter Search This will reduce incoming pages equally along both axes in order to maintain the proportionality of the original image, as shown below. Received Data Original Press 2 to turn off RX Reduction. Press 3 to enable vertical only RX Reduction. The machine will reduce an incoming page containing overflow data along the vertical axis only.
Page 67 Book Chapter Search If the data is within the margin, and the Auto Reduction feature is turned ON, it will be reduced to fit into the appropriate size paper (Discard does not take place). If the Auto Reduction feature is turned OFF or fails, the data within the margin will be discarded.
Page 68 Book Chapter Search Enter the ring count by selecting a number from 1 through 7 on the number keypad. • SEND FROM MEMORY - With this feature enabled, all transmission documents are automatically scanned into memory, and it will not be necessary to wait until documents in the Automatic Document Feeder (ADF) are sent out before you can send or store other fax jobs.
Page 69 Book Chapter Search Press 2 to turn this feature off. FAXPRINT QUALITY - This feature determines the print quality for incoming faxes. The two choice available are Letter Quality (LQ) and Draft. Letter Quality Faxprint will print out faxes at a higher resolution than Draft Faxprint Quality. However, Letter Quality Faxprint will print slower and consume more ink.
Page 70 Book Chapter Search Using the Distinctive Ring Pattern Detection feature, your fax machine can "learn" the ring pattern you designate to be answered as a fax. Unless you change it, this ringing pattern will continue to be recognized and answered as a fax call. All other ringing patterns will be forwarded to the extension telephone or answering machine plugged into the EXT jack.
Page 71 Book Chapter Search fax machine. When your machine begins to ring, do not answer the call. The machine requires several rings to learn the pattern. When the machine completes "learning," the LCD displays END DRPD SETUP. With the DRPD feature active, DRPD appears in the display and the previously set reception mode is ignored.
Page 72: Making A Copy
Book Chapter Search Making a Copy Your machine is a high quality copier which offers the following features: • Adjustable Contrast - The contrast setting can be changed to obtain the best copy quality for documents containing faint markings, dark images, photographs or other halftone images.
Page 73 Book Chapter Search To make one quick copy: Adjust the document guides to match the width of the document. Slide the document face down into the Automatic Document Feeder until it is grasped and pulled into the machine. If necessary, press the Contrast button or the Resolution button.
Page 74 Book Chapter Search Press the Copy button to display the COPY menu. For two or more copies (2 to 99), enter the desired number using the Number keypad, then press the Down Start/Enter button. COPY [01-99] <01> The display shows the next option: the COPY RATE menu where you can manually adjust the copy image scale size settings.
Page 75 Book Chapter Search • Selecting 1:ON will make 1 copy of page 1, 2, and 3 in order, then makes a second copy of 1, 2, and 3 until a total of n copies has been made. SORT • Selecting 2:OFF will make n copies of page one, n copies of page two, and so on.
Page 76 Book Chapter Search Note: When setting the copy options, pressing the button will begin the copy operation immediately without displaying any remaining options. Previous Page Copy Next Page...
Page 77: Sending A Fax
Book Chapter Search Click on one of the following topics, or use the Search button on the left. Sending a Fax Using the WorkCentre 470cx Manual Faxing Configuring Automatic Dialing Features Setting Document Resolution and Contrast Other Functions Polling Sending a Fax Using the WorkCentre 470cx You can send faxes with the WorkCentre 470cx: •...
Page 78: Manual Faxing
Book Chapter Search Manual Faxing This section provides information and instructions for faxing a document from the WorkCentre 470cx using the features of the Control Panel. Preparing Documents for Faxing or Scanning You can fax documents that are printed on standard letter, legal or A4 size paper.
Page 79: Sending A Fax Manually
Book Chapter Search • Remove all staples and paper clips before feeding the document. • Make sure any glue, ink or correction fluid on the paper is completely dry before loading the document. • Do not load documents containing different sizes or weights of paper.
Page 80 Book Chapter Search To insert more than one sheet, ensure that the bottom sheet enters first. Stagger the leading edge of the sheets slightly and insert them with light pressure to ensure smooth feeding. To add pages while the fax is sending, insert them face down into the Automatic Document Feeder on top of the already loaded sheets.
Page 81: Sending A Fax Using A One-Touch Number
Book Chapter Search Sending a Fax Using a One-Touch Number Adjust the document guides to match the width of the document. Slide the document face down into the Automatic Document Feeder until it is grasped and pulled into the machine. Press the One-Touch button (01 through 20) to which you assigned the telephone number you wish to call.
Page 82: Sending A Fax Using Group Dialing (Multi-Address Transmission)
Book Chapter Search The machine will scan the document and dial the number automatically. When the remote fax machine answers, the document will be transmitted automatically. Note: You can store One-Touch or Speed Dial numbers so you can dial your most frequently used numbers with one touch of a button or a two digit speed dial number.
Page 83: Sending A Fax After Talking
Book Chapter Search Follow the procedure for the desired operation (see Transmission (Broadcasting) Transmission on page 3-13). When you come to the step where the display prompts you to enter the remote fax number, enter the Group Number. Note: You can use only one Group Number in a single operation. Continue the procedure to complete the (Memory Transmission or Delayed Transmission) operation.
Page 84 Book Chapter Search Call the remote location. DIAL FAX NUMBER THEN PRESS START appears in the LCD display. Note: For a successful fax transmission, it is imperative that steps 5 to 7 occur in the proper order. When finished talking, instruct the person at the remote location to press the Start/Enter machine.
Page 85: Canceling A Transmission
Book Chapter Search Canceling a Transmission To cancel a fax: Press the at any time during the transmission. Stop button The machine continues to send the fax, and the display shows a message warning you that the machine is in use. Press the again to cancel the transmission.
Page 86 Book Chapter Search Press the Menu button Press the System Data button (01) on the One-Touch keypad. Press the Down CONF. appears in the display. Press 1 to print a confirmation report automatically each time you send a fax (ON). Press 2 to turn this feature off (OFF).
Page 87: Memory Transmission (Broadcasting)
Book Chapter Search Memory Transmission (Broadcasting) With Memory Transmission (Memory TX), documents are stored in memory and automatically sent to one or more remote stations. Use this feature to send your documents to multiple locations. You can store a maximum of ten fax numbers for a memory transmission.
Page 88 Book Chapter Search • One-Touch keypad dialing of stored telephone numbers (see One-Touch Dialing on page 3-18). • Speed Number dialing using the numeric keypad (see Dialing on page 3-22). Press the Start/Enter button. The display prompts you to enter another fax number. ANOTHER FAX NUMBER? If you have entered the last fax number, press the...
Page 89: Delayed Transmission
Book Chapter Search machine dials the first telephone number and begins sending the document. Note: Only a single Group Dial number may be used per Memory Transmission operation. Delayed Transmission You can configure your machine to send a fax at a specified time. Up to 10 delayed transmission operations can be reserved in your machine.
Page 90 Book Chapter Search • Group and Speed number dialing using the numeric keypad (see Configuring Automatic Dialing Features Press the Start/Enter button. The display prompts you to enter another fax number. ANOTHER FAX NUMBER? If you have entered the last fax number setting, press the button If you want to send the document to more than one location, press the Start/Enter...
Page 91 Book Chapter Search The display prompts you to enter an ID for the transmission. If you want to assign a name to the transmission, enter it using the Number keypad. If not, proceed to Step 7. For details on how to enter letters using the Number keypad, Entering Alphanumeric Characters Press the Start/Enter button.
Page 92: Adding Documents To A Standby Operation
Book Chapter Search Note: If you want to cancel the Delayed Transmission, see Canceling a Standby Operation Adding Documents To a Standby Operation You can add documents to a Delayed Transmission previously entered into memory. Place the document face down in the Automatic Document Feeder.
Page 93: Canceling A Standby Operation
Book Chapter Search Press the Down the operation you want to add documents to, then press the Start/Enter button. The machine automatically adds the new documents to the pages already in memory, displays the number of total pages and added pages, then returns to Standby mode. Canceling a Standby Operation Press the , then press the Add/Cancel button...
Page 94 Book Chapter Search Configuring Automatic Dialing Features One-Touch Dialing One-Touch dialing lets you use any one of the 20 One-Touch buttons located on the left of the machine’s control panel to automatically dial a number. Storing a Number for One-Touch Dialing When assigning a One-Touch number, press and hold the One- Touch button (01 through 20) for 2 seconds.
Page 95 Book Chapter Search If you make a mistake while entering a number, use the Right or Left buttons to move the cursor under the wrong digit, then enter the correct digit, or press the Search/Delete button. The display asks you to enter a name. Using the Number keypad, enter the desired name (up to 20 alphanumeric characters).
Page 96 Book Chapter Search Dialing a One-Touch Number Press the One-Touch button (0-20) to which you assigned the number you wish to dial. The number is automatically dialed. If a document is loaded into the Automatic Document Feeder, the WorkCentre 470cx will begin transmission of the document after the remote machine answers.
Page 97 Book Chapter Search Remove the clear cover and label using a pointed instrument, as shown below. Label Note: You may want to write on the label using a pencil in case you wish to change these numbers later. Write information on the label and re-install the label and cover. Previous Page 3-21 Next Page...
Page 98: Speed Dialing
Book Chapter Search Speed Dialing You can store up to 30 numbers in two digit Speed Dial locations (01-30). Storing a Number for Speed Dialing You can assign up to 30 fax or telephone speed dial numbers using the two digit numbers 01-30 on the Number keypad. Press and hold the Speed/Dual button for 2 seconds.
Page 99: Group Dialing (For Multi-Address Transmission)
Book Chapter Search Press the Start/Enter button when the name appears correctly or without entering a name. To store more telephone numbers, repeat steps 2 through 5. To return to Standby mode, press the Dialing a Speed-Dial Number Press the Speed/Dual button, then enter the two digit number assigned to the number you wish to call.
Page 100 Book Chapter Search automatically redial any number previously busy. Before you can use this feature, you must coordinate and store Group numbers. Note: Group Dial numbers are assigned to One-Touch buttons; up to 20 can be supported. A Group number can’t include other Group numbers as a component but can include two digit Speed Dial numbers.
Page 101 Book Chapter Search The display prompts you to press a One-Touch button or enter a Speed Dial number which you wish to include in the group. ENTER ONE-TOUCH / SPEED DIAL> Press the One-Touch button assigned to the fax number you wish to include in the group.
Page 102: Setting Document Resolution And Contrast
Book Chapter Search Press the Start/Enter button. The display prompts you to assign another group dial number. If you want to store another group dial number, repeat steps 2 through 8. To return to Standby mode, press the Using Group Dialing Group Dial numbers can be used for Memory Transmission, Delayed Transmission, or Continuous Polling operations.
Page 103 Book Chapter Search Resolution Press the Resolution button to increase sharpness and clarity. By pressing the Resolution button repeatedly after loading a document, you can choose between STANDARD, FINE, or SUPER FINE modes. The document types recommended for these settings are described in the table on the next page.
Page 104 Book Chapter Search Note: Super Fine Resolution mode is not available if the Send From Memory feature is set to ON. If Send From Memory is set to ON, all documents will be stored to memory in Fine Resolution mode. If the WorkCentre 470cx is set to Super Fine Resolution mode and the remote fax machine does not support Super Fine Resolution, the WorkCentre 470cx will transmit using the highest resolution mode...
Page 105: Using The Number Keypad
Book Chapter Search Note: You can set the default resolution and contrast. The default mode will be in effect when a document is sent or copied unless you change the setting for an individual operation. The machine will automatically revert to default settings after the operation is completed.
Page 106 Book Chapter Search Entering Alphanumeric Characters Locate the button labeled with the character you want. Press the button repeatedly until the correct letter appears in the display. For example, to enter the letter O, press the 6 key (labeled MNO). Each time you press the 6 key, the display shows a different letter, first M, the N, and O, and finally 6.
Page 107 Book Chapter Search To enter another letter, locate the Number keypad button labeled with the letter you want. Press the button repeatedly until the letter appears in the display. If the next letter is printed on the same Number keypad button, move the cursor by pressing the Right Number keypad button labeled with the letter you want.
Page 108 Book Chapter Search Keypad Character Assignments Assigned numbers, letters or characters Space Entering Numbers You can enter the telephone number of a remote fax machine manually by using the Number keypad. The number you press appears in the LCD display. TEL>5551212_ You can also use One-Touch buttons (including a Group Dial number) or a two digit Speed Dial number for entering telephone...
Page 109 Book Chapter Search Your machine will send the same document to more than one location. After you enter a fax number, the display prompts you to enter ANOTHER FAX NUMBER?. To enter another fax number, you can enter the number manually, use a One-Touch button, or a two digit Speed Dial number.
Page 110: Redial Memory
Book Chapter Search When you dial a number, the dialing process pauses for about 3 seconds at the point where you inserted the pause. If you require a longer pause time, press the Redial/Pause button twice. Other Functions Redial To redial the last number called: Press the Redial/Pause button.
Page 111: Searching For A Number In Memory
Book Chapter Search When the number you want appears in the display, press the Start/Enter button to commence dialing. If a document is loaded in the Automatic Document Feeder, transmission begins when the remote machine answers. Searching for a Number in Memory There are two ways to search for a number in memory.
Page 112 Book Chapter Search Touch dial, ‘S’ for speed, or ‘G’ for group dial number. These letters indicate how the number is stored. When the desired number appears in the display, press the Start/Enter button to commence dialing. If a document is loaded, transmission will begin when the remote fax machine answers.
Page 113 Book Chapter Search Tone If your telephone service is configured for pulse dialing, you may still need to use Touch Tone signals to perform special operations by phone. Bank-by-phone and voice mail are two examples of systems that require Touch Tone signals. You can send Touch Tone signals by following these steps: Dial the number using pulse dialing.
Page 114: Automatic Redial
Book Chapter Search Press the Flash button again to return to the first caller. CAUTION:If your telephone service does not use the switch-hook signal, do not press the Flash button during a call. Doing so could disconnect the call. Automatic Redial If the number you dial to send a fax is busy or there is no answer, the machine beeps, hangs up, and waits for the specified retry period.
Page 115: Priority Transmission
Book Chapter Search Priority Transmission When priority transmission is enabled, a high priority document can be transmitted ahead of previously scheduled operations. A priority transmission interrupts a broadcast operation between stations, for example, when transmission to station A ends but before transmission to station B begins.
Page 116 Book Chapter Search • Speed Number dialing using the numeric keypad (see Touch Dialing on page 3-18). Note: Group Number Dialing functions are not available in a Priority Transmission. The display prompts you to enter a name for the transmission. To assign a name to the transmission, enter it using the Number keypad and press the Start/Enter If you do not want to assign the transmission a name, press the...
Page 117: Being Polled By A Remote Machine (Tx Poll)
Book Chapter Search Polling What is Polling? Polling is used when one fax machine requests another to send a document. This is useful for sending unattended faxes. The person who wants to receive the document calls the machine holding the original and requests that the document be sent.
Page 118 Book Chapter Search Press the Menu button Press the Polling button on the One-Touch keypad. The display prompts you to choose one of the two polling options: TX (Transmission Polling) and CONT. (Continuous Polling). Press the Start/Enter button to confirm TX POLL. The display prompts you to enter a 4-digit poll code.
Page 119: Adding Documents To The Job To Be Polled
Book Chapter Search The machine returns to Standby mode and displays a reminder that a Polling Transmission is set. The machine automatically switches to FAX mode (automatic receiving) when configured to be polled. Adding Documents To the Job to be Polled If you want to add documents to the original documents waiting in memory to be polled, follow the procedure below.
Page 120 Book Chapter Search Cancelling a Job Already in Memory Which is Waiting to be Polled If you want to cancel a job already in memory waiting to be polled, follow the procedure below. Press the Menu button Press the Add/Cancel button on the One-Touch keypad. The LCD display prompts you to select 1.ADD or 2.CANCEL.
Page 121: Receiving A Fax
Book Chapter Search Click on one of the following topics, or use the Search button on the left. Reception Modes Determining the Reception Mode Receiving Automatically in FAX Mode Receiving Automatically in TEL/FAX Mode Receiving Manually in TEL Mode Receiving Automatically in ANS/FAX Mode Receiving a Fax When the Machine is Out of Paper Distinctive Ring Pattern Detection (DRPD) Polling...
Page 122: Reception Modes
Book Chapter Search Reception Modes Your multi-function machine has four reception modes as described below: • FAX The machine answers an incoming call and immediately goes into fax receive mode. • TEL/FAX The machine answers the incoming call. If a fax signal is not detected, the WorkCentre 470cx sounds a ringing tone to indicate a voice phone call.
Page 123 Book Chapter Search Determining the Reception Mode The current reception mode is displayed in the bottom line of the LCD display window. JAN-15-1999 100% 08:30AM Reception mode If you seldom use the fax line for phone conversations, set the WorkCentre 470cx to either FAX mode or TEL/FAX mode. In these modes, the WorkCentre 470cx answers incoming calls and receives faxes automatically.
Page 124: Receiving Automatically In Tel/Fax Mode
Book Chapter Search Receiving Automatically in FAX Mode Press the Receive button until the display indicates FAX. When a fax call comes in, the machine answers on the second ring and receives the fax automatically. Note: To change the number of rings before the machine answers Selectable Options an incoming call, see To adjust ringer volume, press the Menu...
Page 125: Receiving Manually In Tel Mode
Book Chapter Search Note: To change the number of rings before the machine answers an incoming call, see Selectable Options To adjust ringer volume, press the Menu Setup (04) button on the One-Touch keypad. Ringer volume is the first item displayed. Press the Down button to set the desired loudness.
Page 126: Receiving Automatically In Ans/Fax Mode
Book Chapter Search If you hear a fax tone, or if the person calling asks you to receive a fax, press the Start/Enter If the machine is equipped with an external phone, you may also press the characters * 9 * (star-nine-star) on the external phone to initiate reception.
Page 127: Receiving A Fax When The Machine Is Out Of Paper
Book Chapter Search If a fax tone is detected on the line, the fax receive mode is automatically activated. Note: If you set your machine to ANS/FAX mode and your answering machine is switched off, or no answering machine is connected to the WorkCentre 470cx, the machine will automatically go into fax receive mode after six rings.
Page 128: Distinctive Ring Pattern Detection (Drpd)
Book Chapter Search After receiving documents, the machine displays MEMORY RECEIVED and the cause. When the condition is cleared, for example by loading new paper or clearing a jam, the machine will automatically print the fax stored in memory. If you clear the problem while the machine is receiving documents into memory, it will print the stored document immediately upon clearing the problem.
Page 129 Book Chapter Search forwarded to the telephone or answering machine plugged into the EXT jack. You can easily suspend or change Distinctive Ring Pattern Detection at any time. See With the DRPD feature active, DRPD appears in the display and the previously set reception mode is ignored.
Page 130 Book Chapter Search Note: The remote machine must also support polling to use this feature. Press the Menu button Press the Polling button on the One-Touch keypad. The display shows the polling options: SELECT POLLING 1. TX 2.CONT. Press 2. CONT. (Continuous Polling). The display asks you to enter the number of the remote fax machine.
Page 131 Book Chapter Search ANOTHER FAX NO? 1.YES 2.NO The display asks if you want to enter another fax number to receive documents from another location. If you do want to receive documents from more than one location: Press the 1 button and enter another fax number using the numeric keypad, a One-Touch button, or two digit Speed Dial number.
Page 132 Book Chapter Search If the remote machine is secured with a poll code, you must enter the correct code, and press the Start/Enter If the remote machine is not secured with a poll code, press the Start/Enter button to accept [0000] which represents no code.
Page 133 Book Chapter Search INTERVAL TIME HH:MM Type the interval time for polling. Press the Start/Enter button. The machine display returns to the standby mode. The machine display will alternate every four seconds between time/ reception display and continuous poll/scheduled time display. JAN-15-1999 100% 08:30AM JAN-15-1999 100%...
Page 134: Printing A Document
Printer Settings Windows 95/98 and 3.x Printer Settings Windows NT 4.0 Printer Settings The Xerox WorkCentre Control Program Printing a Document This procedure describes the general steps required for printing from various Windows applications. The exact steps for printing a document may vary depending on the application program you are using.
Page 135: Printer Settings
Book Chapter Search Verify that you have installed the print driver software for your machine. See Installing Software Start the program you are using to create the document, and create or open the document you want to print. Choose Print or Print Setup from the File menu. Make sure the WorkCentre 470cx is selected as your default printer.
Page 136 Windows application. Selecting Properties will provide access to the Page, Main, and Advanced tabs. • Select the Xerox WorkCentre 470cx printer from the Settings/ Printers folder, then select Properties from the File menu. This method will provide access to the General, Details, and Sharing tabs, as well as the Page, Main, and Advanced tabs.
Page 137 Note: In Windows 3.x: Go into Main/Print Manager and select the Xerox WorkCentre 470cx printer; pull down the Options menu and select Printer Setup. Click the Setup button to view the Paper/ Ouput, Image Quality, and About tabs. When you see the Printer properties displayed, you can then review and change whatever settings are needed for your print job.
Page 138 Book Chapter Search • Sharing tab - for configuring printer accessibility over a network. • Page tab - for paper sources and sizes, number of copies, and orientation. • Main tab - for document and paper types and for print quality. •...
Page 139 Book Chapter Search Previous Page Next Page...
Page 140 Book Chapter Search Media Source Click on one of the two radio buttons to select either Automatic Feeder or Manual Feeder for your paper source. You can also select a paper source by placing the cursor over the required paper bin on the printer image.
Page 141 Book Chapter Search the two radio buttons to select either Portrait or Landscape as the orientation for your document. Media Size Move the horizontal bar or click on the right or left arrow to locate the desired Media Size option, then select. The media size options are: Letter 8.5 x 11 in.
Page 142 Book Chapter Search Main Tab Note: If this tab is accessed through the Printers folder, any changes made to settings will become the default settings for the printer. Settings made when the printer properties are accessed through an application File menu and Print or Print Setup will remain active until the application you are printing from is closed.
Page 143 Book Chapter Search 5-10 Previous Page Next Page...
Page 144 Book Chapter Search Print Document As When you select a document type, other settings in the printer driver automatically change to accommodate that document type. Use the horizontal bar or the right or left arrow to locate the appropriate document type, then select: •...
Page 145 Book Chapter Search Click on the appropriate radio button to select the paper type for your document: Media Plain Paper Coated Paper Glossy/Photo Paper Transparency Iron-on Transfer Greeting Card Stock Dry Time Delay Check this box to activate a delay between the printing of pages to allow inks to dry.
Page 146 Click this button to restore default settings on all available tabs. About Click the About button for the printer software version number and copyright information. If you need help with the printer driver, please note the version number before calling Xerox Technical Support. Previous Page Direction Unidirectional printing Unidirectional printing...
Page 147 Book Chapter Search Advanced Tab Note: If this tab is accessed through the Printers folder, any changes made to settings will become the default settings for the printer. Settings made when the printer properties are accessed through an application File menu and Print or Print Setup will remain active until the application you are printing from is closed.
Page 148 Book Chapter Search 5-15 Previous Page Next Page...
Page 149 Book Chapter Search Halftone Halftone is an array in which dots are placed to simulate colors and shades of gray. Use the Halftone settings to improve the appearance of pictures and graphics. A Halftone is chosen automatically when you choose a document type from the Main tab.
Page 150 Book Chapter Search The image to the right of these controls gives an impression of the final result of your changes to the settings. The image may not appear exactly as you would expect if your color monitor does not support enough colors.
Page 151 Then press the Properties button. This provides access to the Page Setup, Advanced, and Cartridges tabs. • Select the Xerox WorkCentre 470cx printer from the Settings/ Printers folder, click the right mouse button, then select Document Defaults from the drop-down list. This provides access to the Page Setup, Advanced, and Cartridges tabs.
Page 152 Book Chapter Search 5-19 Previous Page Next Page...
Page 153 Book Chapter Search Advanced Tab The Advanced tab is a main control center for choosing most of the settings which govern the appearance and printing of your document. Previous Page 5-20 Next Page...
Page 154 Book Chapter Search The main window shows a tree of options with an icon to the left of each main category. The categories include: • Paper/Output • Graphic • Document Options Each category item, when clicked on, expands to reveal more options.
Page 155 Book Chapter Search 5-22 Previous Page Next Page...
Page 156 The default settings appear in blue text, enclosed in brackets. When you change a setting, the text turns to red. Click on the title Xerox WorkCentre 470cx Document Settings to access the Undo Changed Option, and About Xerox WorkCentre 470cx, which provides copyright and version information.
Page 157 Book Chapter Search 5-24 Previous Page Next Page...
Page 158 Book Chapter Search Change Left Cartridge This feature enables you to install a Color print cartridge in the left position of the print cartridge carrier. Change Right Cartridge This feature enables you to install a Black or Photo cartridge in the right position of the print cartridge carrier.
Page 159 Search The Xerox WorkCentre Control Program In addition to the printer driver, the printer software also includes the Xerox WorkCentre Control Program. The WorkCentre Control Program contains setup options that define the operation of your machine. Note: The WorkCentre Control Program is not included with Windows NT 4.0.
Page 160 Search Select the Xerox WC470cx Control Program. The Xerox WorkCentre 470cx Control Program window opens. In Windows 3.x From the Program Manager at system startup, open the Xerox WorkCentre 470cx group. Double-click on the Xerox WorkCentre 470cx Control Program icon.
Page 161 Book Chapter Search The Status tab includes these buttons: • Cancel Print • Pause • Print Test Page Previous Page 5-28 Next Page...
Page 162 Book Chapter Search The information area displays which job is printing, which page and copy, the time, and any alert messages. Using the Options Tab This tab allows you to specify the Control Program setup options. Previous Page 5-29 Next Page...
Page 163 When you select this option, it takes longer for the first page of a job to begin printing. • Disable Xerox WC470cx DOS Printing (Enable DOS printing to other printers) - Select this feature when you are using a DOS application to print to a printer other than your...
Page 164 3.x for the change to take effect. Note: If a Xerox printer and another printer are connected to the same port on your computer through a switch box or other device, check Disable Xerox WC470cx DOS Printing and restart Windows before switching from one printer to the other.
Page 165 Book Chapter Search Using the Cartridges Tab This tab allows you to view the level of ink in the cartridges and to choose cartridge options. Previous Page 5-32 Next Page...
Page 166 Book Chapter Search The cartridge options: • Install Black Cartridge - Click Install Black Cartridge to install a Black (P/N 8R7881) print cartridge in the printer. Choosing this option moves the print cartridge carrier to the load position and displays the Change Black Cartridge dialog box.
Page 167 Book Chapter Search Align the cartridges after you install a new print cartridge, or when the black portions of text or graphics do not align with the color portions. Note: The bidirectional alignment patterns cannot be adjusted when the Photo cartridge is installed. Previous Page 5-34 Next Page...
Page 168 Book Chapter Search Using the DOS Printing tab Use the DOS Printing tab to change print settings for DOS applications that run from the DOS prompt in Microsoft Windows. Previous Page 5-35 Next Page...
Page 169 Book Chapter Search Select the desired options in the Print Quality, Paper, and Font Settings. Choose if desired: Print Fonts or Defaults. Other settings: • Graphics - Click Graphics to set the addressability in dots per inch (dpi). The default is 75 dpi. •...
Page 170 Book Chapter Search Using the About Tab The About tab gives the Software version number and Copyright information for the Control Program. Previous Page 5-37 Next Page...
Page 171 Book Chapter Search Click on one of the following topics, or use the Search button on the left. Overview The WorkCentre 470cx TWAIN Scanner Program Scanner Control Tabs Preview Window Overview The WorkCentre 470cx TWAIN Scanner Program is an image- scanning program that operates under various image-editing and OCR applications.
Page 172 Book Chapter Search The TWAIN standard also allows many software packages access to the same image input device. Examples of some TWAIN- compliant software packages are: ScanSoft Pagis Pro, ScanSoft TextBridge Pro and Adobe Photoshop. ScanSoft Pagis Pro and Textbridge Pro are provided with your WorkCentre 470cx. For questions concerning Pagis or TextBridge applications consult your on-line help or visit the Pagis website at http://www.pagis.com.
Page 173 Book Chapter Search To access these features, the WorkCentre 470cx TWAIN Scanner window below opens when Acquire (or a similar selection) is selected from the File menu of a TWAIN compliant image editing application. Previous Page Next Page...
Page 174 Book Chapter Search With this array of image previewing and scanning functions, you can see the results of the changes you made to an image, before you save the images you create. Note: Your WorkCentre 470cx can scan in black/white, grayscale, and color.
Page 175 Book Chapter Search documents or photographs from the TWAIN compliant image editing application. To start the WorkCentre 470cx TWAIN Scanner application: Note: To start the WorkCentre 470cx TWAIN Scanner application from TextBridge Pro, refer to Starting the WorkCentre 470cx TWAIN Scanner Application from TextBridge Pro below.
Page 176 From the File menu, click on Select Scanner. A list of supported scanners will be displayed. From the list, select Xerox WorkCentre 470cx (TWAIN). Click From the TextBridge Pro Process menu, select Get Page. A Page Type dialog will be displayed.
Page 177 Book Chapter Search Select the desired page type and select Scanner as the Page Source. Click OK. The WorkCentre 470cx TWAIN Scanner application is displayed. Select the appropriate scan options for the document or photograph to be scanned. After adjusting the settings in the Scan window, you can perform a preliminary preview scan of the image before performing a final scan.
Page 178 Book Chapter Search The WorkCentre 470cx TWAIN Scanner Window The 470cx TWAIN Scanner Window is used to view and modify the scanned image. Using the features of this window, various image processing options can be applied to the scanned image. Scanner Control Tabs For more information, page 6-9...
Page 179 Book Chapter Search WorkCentre 470cx TWAIN Scanner Help You can refer to the WorkCentre 470cx TWAIN Scanner application on-line help for assistance. To access on-line help, move the cursor over the feature of the window that help is desired for. A yellow popup dialog box will appear. Click on the dialog box to access on-line help.
Page 180 Book Chapter Search • The About Tab indicates the version of the WorkCentre 470cx TWAIN Scanning application. Scanner Control Tabs Previous Page 6-10 Next Page...
Page 181 Book Chapter Search The Basic Tab The features of the Basic Tab are described in this section. All of the features of this tab are available when the Image type selection is True Color, 256 Colors, or Gray 256 Scales. Refer to the table below which indicates the tab features that are available for the Lineart B/W and Halftone B/W Image Type selections.
Page 182 Book Chapter Search The following examples of the scan modes illustrate possible output for the scanned image. True Color, RGB In this scan mode, your scanner captures 24 bits of color image information for every dot (pixel) in your resulting scanned image. Therefore over 16 million colors are possible.
Page 183 Book Chapter Search Additionally, a high color or true color graphics card is required to adequately display the color information. 256 Colors Images scanned in 256 Colors mode are scanned in a maximum of 256 colors. The quality is not as high as True Color, RGB, but it is acceptable for most applications.
Page 184 Book Chapter Search each individual pixel. It actually provides 256 shades, representing white by the value 255 and black by the value zero, with progressively lighter intermediate shades of gray by values from 1 through 254. Halftone B/W This scan mode uses various combinations of black and white pixels to simulate gray scales.
Page 185 Book Chapter Search For this reason, files created in this mode will require approximately the same amount of disk space as a Halftone B/W file. Note: In both Halftone and Lineart modes, the resolution can only be set at 150, 200, or 300 dpi. Resolution The resolution setting determines the amount of information the scanner will capture in a scanned image.
Page 186 Book Chapter Search Resolution is measured in dpi (dots per inch). The higher the resolution is, the finer the image detail and the bigger the image file size is. Increasing the resolution will result in corresponding increases in image detail and image file size. See the examples of images at 75 and 300 dpi.
Page 187 Book Chapter Search Note: The Resolution settings can be restored by clicking Default All at the bottom of the Basic tab. Reduce/Enlarge This feature allows an image to be automatically enlarged or reduced as it is scanned. The default scaling factor is 100%. The selected scaling factor affects size of the printed scan output.
Page 188 Book Chapter Search Scaling 100% Fixed scaling options are displayed as percentages of reduction or enlargement. Image width and height are scaled proportionally when fixed scaling factors are used. To scale to a size other than the fixed sizes, select the Custom option in the Scaling menu. The Custom Scaling dialog box will appear.
Page 189 Book Chapter Search Note: You can also change Height and Width values by directly adjusting the selection frame. Note: Output image file size is proportional to both Height and Width. If both Height and Width values are doubled, then the image area and image file size will increase four-fold.
Page 190 Book Chapter Search Descreen This selection is used to eliminate moire patterns from the output image. Moire patterns are objectionable patterns resulting from the superimposition of different patterns of curves. Moire occurs as a result of differences in the screen pattern used to print the document and the scanner electronics.
Page 191 Book Chapter Search Art print (175 lpi) The Art print selection is used to smooth the fine dot pattern found in high quality art prints and magazines made in a resolution higher than 200dpi. Magazine (133 lpi) The Magazine selection is used to smooth the fine dot pattern found in glossy magazines made in the resolution higher than 200dpi.
Page 192 Book Chapter Search Saved Settings Saved Settings allow the user to save a custom scan configuration. Saved settings are used when the user wants to scan with a specific set of parameters on a regular basis. The saved settings give the user the ability to create a named set that can be selected at any time, avoiding the work of manually re-entering the parameters.
Page 193 Book Chapter Search The Image Quality Tab The features of the Image Quality tab are described below. All of the features of this tab are available when the True Color RGB, 256 Colors, and Gray 256 Scales selections are made for Image Type.
Page 194 Book Chapter Search Color Channel The Color Channel radio buttons are used to specify the color channel in which to change the Highlight, Shadow and Midtone values. Gray Channel The Channel Selector allows you to select an active channel. The Gray Channel is the only channel available when the scanned image is scanned as Gray 256 Scales, Halftone, B/W, and Lineart, B/W.
Page 195 Book Chapter Search With color scanning selected, you may select a color channel from the above set of buttons. This will allow you to adjust the highlight, shadow, and midtone for each color in the Red, Green, and Blue spectrum. Highlight This control changes the highlighting of the entire image.
Page 196 Book Chapter Search Shadow The Shadow value represents the darkest value in an image. All pixels below this point will be rendered as pure black. If you subsequently broaden the shadow points on the Level Adjustment graph, the pixels will be re-mapped within the new range thus allowing you to see more detail in the image.
Page 197 Book Chapter Search provides Midtone adjustment for you to compensate for these differences in your scanner, and it produces better scanned images. To change the Midtone value, move the Slider to the left or right to change the values in the adjacent text box. The value in the adjacent box will change in the range 0.10 to 10.00 as the slider moves.
Page 198 Book Chapter Search To activate the Level Adjustment or Tonal Map functions, click on the Advanced... button at the bottom of the Image Quality tab. When this button is selected, the Level Adjustment window is displayed by default. Level Adjustment The Level Adjustment dialog box shows the distribution of brightness levels in your image.
Page 199 Book Chapter Search Level Adjustment tab Shadow control Midtone (Gamma) control By varying the Shadow points and Highlight points you can change the relative shades and highlights of the image. The Shadow point represents the darkest value and the Highlight point is the brightest value.
Page 200 Book Chapter Search Therefore, all pixels in the original that are darker than the current shadow point are now completely black in the enhanced image. Conversely, all pixels in the original that are brighter than the current highlight point are now completely white in the processed image.
Page 201 Book Chapter Search Master, Red, Green, Blue Channel With color scanning selected, you may select a color channel via the color buttons. This will allow you to adjust the highlight, shadow, and midtone for each color in the Red ,Green , and Blue spectrum.
Page 202 Book Chapter Search The effect of the Histogram plot changes in the Histogram dialog box may be restricted to a single color channel by selecting the Red, Green, or Blue channel buttons. Changes may be applied to all three color channels by selecting the Master button. Color saturation information at indicated levels will appear above the Histogram plot.
Page 203 Book Chapter Search Operation Summary: Select the Advanced... button on the Image Quality tab. This will display the Level Adjustment window. On the histogram, use the mouse key to click on the Black, Gray, or White triangles to make changes to the Shadow, Midtone, and Highlight respectively.
Page 204 Book Chapter Search Tonal Map If you select the Tonal Map tab, the following will be displayed. Previous Page Tonal Map tab 6-34 Next Page...
Page 205 Book Chapter Search The Tonal Map is yet another way to adjust Highlight, Midtone, or Shadow levels in your images. When you open the Tonal Map dialog box, a tonal map consisting of a diagonally straight line appears. Notice that at every point on the default tonal map, the output shadow, midtone, and highlight brightness levels are equal to the input shadow, midtone, and highlight brightness levels.
Page 206 Book Chapter Search Normal Image Lightened Image If the curve is changed into a concave shape below the original diagonal, the enhanced image will be darker than the original. Previous Page 6-36 Next Page...
Page 207 Book Chapter Search Normal Darkened Image Image Previous Page 6-37 Next Page...
Page 208 Book Chapter Search Operation: Click on the Tonal Map icon in the Preview window or the Tonal Map tab in the Enhancement dialog box. Tonal Map dialog box will appear. Click on the Tonal Map curve, an indicator appears which can then be dragged to change the shape of the curve.
Page 209 Book Chapter Search each color in the Red ,Green , and Blue spectrum. The same procedure applies for color as is described above for Gray 256 Scales. Color Channel Buttons In the above example, the Green curve has been dragged to a convex shape.
Page 210 Book Chapter Search The Filters Tab The features of the Filters Tab are described below, and are used to apply various visual modifications to the scanned image. All of the features of this tab are available when the Color or Gray 256 Scales selections are made for Image Type.
Page 211 Book Chapter Search Filter Filter is typically useful for high-contrast images which soften or sharpen edges and boundaries of an image. No Filter This is the default filter option. No filtering will take place when using this option. Sharpen This selection emphasizes the edges of an image. It sharpens the image boundaries by increasing the relative contrast between adjacent pixels.
Page 212 Book Chapter Search Blur This selection softens the image by smoothing out any sharp transitions in intensity between two adjacent pixels. Blur More This option further softens the image by performing the same function as the Blur option, but to a greater extent. Note: If you blur the image too much, you will risk losing texture and depth in the image.
Page 213 Book Chapter Search Flip Image This selection provides the ability to flip an image. The flipping mechanism flips an image about the horizontal or vertical axis. Previous Page 6-43 Next Page...
Page 214: Preview Window
Book Chapter Search Invert Image This function inverts all the tone values, providing a photographic negative of the original. This effect is similar to using the Tonal Map to tonally invert the image. Preview Window After adjusting the settings in the Scanner Control window, choose any one of the tools in the Preview Window to further enhance the image.
Page 215 Book Chapter Search Frame Tool After a preview image has been created, you can define the boundaries of the area to be included in your final scan by using the Frame tool. Previous Page Image Control Tools. For information, see page 6-44.
Page 216 Book Chapter Search Use the Frame tool to select a rectangular portion (selection frame) of the preview screen, or select the entire preview screen, for the final scan boundaries. When you select the Scan button, only the area within the selection frame will be included in the final scan.
Page 217 Book Chapter Search Note: If you hold down the Shift key and drag the mouse diagonally, the sides of the selection frame will resize proportionally. Zoom In and Out Tools The Zoom In and Out tools allow you to zoom in or out on an image within the Preview window;...
Page 218 Book Chapter Search As an alternative to the method stated above, select the Zoom tool and then, while holding the mouse key down, drag the cursor over the area you want to enlarge. A solid frame, defining the area of enlargement, will appear while the mouse key is being held down.
Page 219 Book Chapter Search Width and Height Indicators The Width and Height indicators will display the width and height of the frame defined with the frame tool. File Size Indicator The file size indicator will display the file size that will result for the scanned image defined with the Frame tool.
Page 220 Book Chapter Search Scan Button The Scan button is used to obtain the final scan of the document after all of the enhancement features have been applied to the prescanned document. When Scan is selected, the scanned image does not appear in the Preview Window.
Page 221: Troubleshooting
Book Chapter Search Click on one of the following topics, or use the Search button on the left. Clearing Jams Document Jams While Sending a Fax Paper Jams While the Machine is Printing Tips for Avoiding Paper Jams LCD Display Error Messages Fax Problems Printer Problems Print Quality Problems...
Page 222: Clearing Jams
Book Chapter Search Clearing Jams Document Jams While Sending a Fax If a document jams while you are sending it, DOCUMENT JAM appears in the display. CAUTION:Do not pull the document out of the slot or you may damage your machine. Open the control panel by pulling lightly on the Control Panel cover.
Page 223: Paper Jams While The Machine Is Printing
Book Chapter Search Carefully remove the jammed document. Close the control panel firmly until it clicks into place. Paper Jams While the Machine is Printing By carefully selecting paper type and loading them properly, you should be able to avoid most paper jams. If paper jams occur, an error message appears in the display.
Page 224 Book Chapter Search Remove the jammed paper by gently pulling it straight up as shown in the diagram below. After you remove the jammed paper, reload the stack of paper back into the Automatic Paper Feeder with the print side facing you.
Page 225 Book Chapter Search Adjust the paper guide to match the width of the paper. If Paper is Jammed in the Printer Output Area If the paper jams as it exits to the printer exit tray, PAPER JAM will appear on the display. Remove the jammed paper by pulling gently on the paper as shown in the diagram below.
Page 226 Book Chapter Search If Paper is Jammed Inside the Machine Open the Control Panel cover (1) and the Cartridge Compartment cover (2). Previous Page Next Page...
Page 227: Tips For Avoiding Paper Jams
Book Chapter Search Carefully remove the jammed paper as shown in the diagram below. Close the Control Panel cover and the Cartridge Compartment cover. Tips for Avoiding Paper Jams By carefully selecting print materials and loading them properly, you should be able to avoid most paper jams. If jams do occur, follow the steps outlined in Clearing Jams occur frequently, make sure that you are following these tips to...
Page 228 Book Chapter Search • Do not overload the paper. Never exceed the maximum capacity of 100 sheets of paper in the Automatic Paper Feeder. • Flex, fan, and straighten paper before loading it. • Do not load wrinkled, creased, damp, highly curled, or previously stapled paper.
Page 229: Lcd Display Error Messages
Book Chapter Search LCD Display Error Messages LCD Display Meaning CARTRIDGE The print cartridge is MISMATCH not correctly installed in the machine INK OUT The print cartridge is out of ink. DUPLICATED The number entered is already stored in another one-touch or speed dial location RETRY REDIAL? The machine is...
Page 230 Book Chapter Search LCD Display Meaning INCOMPATIBLE • Remote machine did not have the requested feature, such as Polling. • The remote machine has insufficient memory to complete the operation you are attempting. DOCUMENT JAM The document jammed in the paper feeder. DOOR OPEN The cover is not securely latched.
Page 231 Book Chapter Search LCD Display Meaning LINE ERROR Your machine cannot connect with the remote site, or it has lost contact because of a problem on the phone line. Previous Page Solution • Try again. If the failure persists, wait an hour or so for the line to clear, then try again.
Page 232 Book Chapter Search LCD Display Meaning LOAD DOCUMENT You have attempted to set up a sending operation without loading a document. MEMORY FULL! The machine’s memory is full. NO ANSWER! The remote machine has not answered and all redial attempts have been made.
Page 233 Book Chapter Search LCD Display Meaning NO PAPER The paper feed tray is ADD PAPER empty. THEN PRESS The message is also displayed if paper narrower than A4, Letter, or Legal is loaded to print a PC file. The file can be printed regardless of the message.
Page 234 Book Chapter Search LCD Display Meaning POLLING ERROR • The remote fax machine you want to poll is not ready to respond to your poll. • When setting up to poll another fax machine, you have used an incorrect poll code. POWER FAILURE A power failure occurred.
Page 235: Fax Problems
Book Chapter Search Fax Problems Symptom Solution The machine is not • Unplug the power cord and plug it in. working, there is no • Check for power at the outlet. display, and the buttons are not working. There is no dial tone. •...
Page 236 Ensure that you are hanging up the handset receive faxes manually. before you press the Start/Enter NOTE: This applies only to Xerox WorkCentre 470cx models equipped with a telephone connected to the EXT jack on the bottom of the machine.
Page 237 Book Chapter Search Symptom Solution Stretched words appear The machine sending the fax had a on incoming faxes. temporary document jam. Lines appear on copies or Check your machine’s scan glass for marks outgoing faxes. and clean it, if necessary. See Document Scanner on page Previous Page Cleaning the...
Page 238 Book Chapter Search Symptom Solution Spots or lines appear on • Check to see if the phone line is noisy. received faxes. • Check the print head in your machine by making a copy. • Check the transmitting machine for a dirty scan glass.
Page 239: Printer Problems
Book Chapter Search Printer Problems Symptom Cause and Solution The printer does not print. • The PC cable is not connected properly. • The PC cable is defective. Swap the cable with one known to work. If necessary, replace the cable. •...
Page 240 Book Chapter Search Symptom Cause and Solution The paper does not feed • Paper has not been loaded properly. into the printer. Remove and re-insert the paper correctly. Refer to • There is too much paper in the Automatic Paper Feeder. Decrease the number of sheets of paper in the Automatic Paper Feeder.
Page 241 Book Chapter Search Symptom Cause and Solution The printer prints the • The printer cable may be connected wrong data, or it prints improperly. Check the cable connection. incorrect characters. • There may be a problem with the printer driver software. Exit Windows and reboot the computer.
Page 242 Book Chapter Search Symptom Cause and Solution Printing is too slow. • If using Windows 3.x, Print Manager may be disabled. From the Control Panel Printers menu, check the Use Print Manager box. • If using Windows 3.x, the Background Printing item in the Option menu of Print Manager may be set incorrectly.
Page 243: Print Quality Problems
Book Chapter Search Print Quality Problems Symptom Cause and Solution Light or blurred • You may be using Draft quality or Normal characters. quality mode. Try using High 1200 dpi print quality mode. • The print cartridge may be running out of ink.
Page 244 Book Chapter Search Symptom Cause and Solution Smudged or dark • Make sure you are using the correct type characters. of paper. Try another type of paper. • Make sure the paper is straight and unwrinkled. • Let ink dry before handling the paper. You can use ‘Dry Time Delay’...
Page 245 Book Chapter Search Symptom Cause and Solution Incorrect format or • The media is incorrectly loaded or is an characters do not align unsupported size or type. See correctly at left margin. Guidelines on page media, it is recommended to feed one sheet at a time.
Page 246 Book Chapter Search Symptom Cause and Solution Printed color does not • The color print cartridge has run out of one match screen colors. or more inks. Install a new cartridge. See Replacing the Ink Cartridge on page • The print head may need cleaning. See Print Cartridge Nozzle Test on page Black and white is •...
Page 247 Book Chapter Search Symptom Cause and Solution Printer power is on, but • The printer is improperly connected to the nothing prints. computer. Make sure the printer cable is firmly connected to the printer and the computer. • Make sure the printer cable is IEEE 1284- compliant bi-directional parallel interface cable.
Page 248 Book Chapter Search Symptom Cause and Solution Unexpected characters are • Make sure your application has the printed or characters are WorkCentre 470cx selected as the default missing. printer. • The printer cable may not be securely connected to the printer and the computer, or the printer cable may not he correct type.
Page 249 Book Chapter Search Symptom Cause and Solution Page does not print. Some extremely complicated page formats may not be printable on the printer. If you are using too many fonts, or if you are printing complex graphics, you can experience this problem. Simplify the page format or use fewer fonts.
Page 250: Paper Feeding Problems
Book Chapter Search Paper Feeding Problems Symptom Cause and Solution Paper is jammed during Clear the paper jam. See printing. the Machine is Printing Paper sticks together. • Ensure there is not too much paper in the Automatic Paper Feeder (APF). Depending on the thickness of your paper, the APF can hold up to 100 sheets of paper.
Page 251 Book Chapter Search Symptom Cause and Solution Paper skews or buckles • Ensure there is not too much paper in the APF. Depending on the thickness of your paper, the APF can hold up to 100 sheets of paper. • Make sure the paper guide does not cause the paper to bow in the APF.
Page 252: Scanning Problems
Book Chapter Search Scanning Problems Symptom Cause and Solution You cannot scan a • Make sure you load the document to be document into memory. scanned in the document tray. • There may not be enough available memory to hold the document you want to scan.
Page 253 Book Chapter Search Symptom Cause and Solution The following message There may be a copying or faxing job in appears on the computer progress. When the current job is completed, screen: try the job again. Scanner is busy receiving or printing data. When the current job is completed, try again.
Page 254 Book Chapter Search Symptom Cause and Solution The following message The printer cable may be improperly appears on the computer connected or the power may be off. Ensure screen: that the Port is disabled. Check if WorkCentre 470cx is plugged in. If the the port is properly problem persists, turn the computer and connected, power is on,...
Page 255: Maintenance
Book Chapter Search Click on one of the following topics, or use the Search button on the left. Clearing Memory Cleaning the Document Scanner Managing the Ink Cartridges Tips for your ink cartridges Print Cartridge Nozzle Test Cleaning the Print Heads Replacing the Ink Cartridge Cartridge Alignment ADF Rubber Retard Pad Replacement...
Page 256: Clearing Memory
Book Chapter Search Clearing Memory You can selectively clear information stored in your machine’s memory. Press the , then press Memory Clear on the Menu button One-Touch keypad. MEMORY CLEAR ITEM (1-4) appears briefly on the display followed by the list shown below. Use the Up and Down buttons to scroll through the list of options.
Page 257 Book Chapter Search Press the Start/Enter button. ARE YOU SURE? appears in the LCD display. Press 1 to confirm, or use the Right choose YES, then press the Start/Enter cleared. Previous Page or Left button to button. The selected memory is Next Page...
Page 258: Cleaning The Document Scanner
Book Chapter Search Cleaning the Document Scanner To keep your machine working properly, occasionally clean the white roller, Automatic Document Feeder (ADF) rubber, and the scanning glass. If they are dirty, documents sent to another fax machine may not be clear. Power off the WorkCentre 470cx by unplugging it from the wall outlet.
Page 259 Book Chapter Search Pull the roller upward and out of the machine. Wipe the roller surface with a soft cloth dampened with water. Previous Page Next Page...
Page 260 Book Chapter Search Using a cotton swab or a soft dry cloth, clean the ADF rubber pad. Carefully wipe the scanning glass with a SOFT, DRY CLOTH. If the glass is very dirty, first wipe it with a slightly dampened cloth, then with a dry cloth.
Page 261 Book Chapter Search CAUTION:Never spray liquid directly onto the scanning glass. Replace the roller by performing steps one and two in reverse order. Previous Page Next Page...
Page 262 Book Chapter Search Close the control panel firmly until it clicks into place. Managing the Ink Cartridges Tips for your ink cartridges To get the maximum benefit from your ink cartridges: • Do not remove a ink cartridge from its packaging until you are ready to install it.
Page 263 Book Chapter Search • Do not swap the color cartridge with the black or photo cartridges. The color cartridge should be installed in the Left carrier and the black or photo cartridge should be installed in the Right carrier. • If you have an opened ink cartridge you are not currently using and do not have an available print cartridge storage unit, store it in an airtight plastic bag.
Page 264 Book Chapter Search To run the Clean Head Procedure: Press the , then press the Maintenance button Menu button on the one-touch keypad. The display indicates SELF TEST ?. Press the button. CLEAN HEAD ? appears in the LCD display. Press the Start/Enter button.
Page 265 Search To clean the nozzles from your PC: In Windows 95/98: Go to Start, Programs, Xerox WorkCentre 470cx. Select Xerox WorkCentre 470cx Control Program on LPT1. The Control Program window opens. Note: For Windows 3.x: At system startup, open the Xerox WorkCentre 470cx group from Program Manager.
Page 266 Book Chapter Search Click the Cartridges tab, then click the Clean Print Nozzles button. The printer feeds a sheet of paper and prints the nozzle test pattern. Previous Page 8-12 Next Page...
Page 267 Book Chapter Search Note: There are minor differences in the appearance of the Cartridges Tab between Windows 95/98 and Windows NT 4.0 Examine the test pattern. The example below shows a test pattern of all nozzles functioning correctly on the color and black ink cartridges.
Page 268 Book Chapter Search If the bottom line shows improvement, rerun this test. If improvement continues, rerun the test. If all nozzles are not printing after running the test three times, continue with step 5. If print quality does not improve, remove and reinstall the ink cartridge.
Page 269 Book Chapter Search If you are cleaning a color ink cartridge, be especially careful to wipe the nozzles in only one direction so the colors do not mix. Allow the copper-colored area to dry, then reinstall the ink cartridge and repeat the nozzle test. If the line is still broken, clean the print cartridge carrier contacts in your machine Cleaning the Cartridge Carrier...
Page 270 Book Chapter Search Cleaning the Cartridge Carrier Contacts Press the Cartridge Button. The Cartridge Carrier Assembly moves to the center of the machine. Open the Control Panel and the Cartridge Compartment Cover. Unplug the power cord from the electrical outlet or the rear of the machine.
Page 271 Book Chapter Search Remove the Ink Cartridges. Use a CLEAN, LINT FREE, DRY CLOTH to clean the ink cartridge carrier contacts inside the printer. Reinstall the ink cartridge. Close the Control Panel and the Cartridge Compartment Cover. Previous Page 8-17 Next Page...
Page 272 Book Chapter Search Plug the power cord in. Replacing the Ink Cartridge The ink cartridge includes the ink supply and the print head. Each time you replace the ink cartridge, you are replacing the print head as well. When you notice the print becomes light or INK LOW appears in the display, replace your cartridge.
Page 273 Book Chapter Search To replace the ink cartridge, perform the following steps: Open the control panel (1) and the cartridge compartment cover (2). Pull the handle of the ink cartridge(s) you want to replace toward you until there is a click. Remove the ink cartridge(s). Remove a new ink cartridge from its packaging and carefully remove the tape covering the print head.
Page 274 Book Chapter Search If you changed a black or photo cartridge changed a color and a black or photo cartridge Press the Start/Enter button. Select the replaced cartridge type using the butons. If the replaced cartridge is a used cartridge, select: OLD COLOR, OLD BLACK, or OLD PHOTO.
Page 275 The cartridge alignment test will straighten the vertical lines. To align the cartridge from your PC: Open the Xerox WorkCentre 470cx Control Program on LPT1. Refer to Starting the WorkCentre 470cx Control Program page 5-26 and to Using the Cartridges Tab Click the Align Cartridges button.
Page 276 Book Chapter Search Examine the test print. If the vertical lines are straight, no adjustment is needed. If the lines are not straight, select the number in which the lines appear the straightest and click OK. 8-22 Previous Page Next Page...
Page 277 Book Chapter Search To align the cartridge using the control panel of your WorkCentre: The Arrange Alignment menu settings provides an easy way to check and adjust Ink Cartridge print head alignment. To run the Arrange Alignment: Press the , then press the Maintenance button Menu button on the one-touch keypad.
Page 278 Book Chapter Search numbers bracketed in the center of the display indicates the range of valid pattern selection choices. The flashing number on the left side of the display indicates the line from print pattern A that is currently selected as optimal. Using the Number Keypad, enter the number of the line which appears the straightest from pattern A.
Page 279 Book Chapter Search Press the Start/Enter button to confirm your selection. The LCD panel updates and returns to normal operation. ADF Rubber Retard Pad Replacement After about one year of operation, or if you have multiple pages scanning at one time, your retard pad will become worn and may impair the performance of the document feeder.
Page 280 Book Chapter Search Remove the retard pad and plastic support from the machine. Insert a new retard pad and support onto the holder, and snap in into place. Previous Page 8-26 Next Page...
Page 281 Book Chapter Search Click on one of the following topics, or use the Search button on the left. Specifications FCC Regulations Send Header Requirements Data Coupler Information Radio Frequency Emissions Canadian Certification Safety and Legal Requirements for the UK The Electricity at Work Regulation (in England and Wales) UK ONLY European Product Marking Requirements CTR 21 Annex II...
Page 282: Specifications
Book Chapter Search Specifications Applicable line Compatibility Fax Data coding Modem speed Transmission speed Effective scanning width Effective printing width Scanning method Memory Halftone Printing speed Black Ink Cartridge Yield Previous Page Public Switched Telephone Network (PSTN) or behind PABX (FCC Part 68 2-wire compliant) ITU Group 3 MH/MR/MMR (ITU-T-T4)
Page 283 Book Chapter Search Color Ink Cartridge Yield About 240 Sheets (15% Pattern, A4) Source document output tray 30 sheets (20 lb or 75 g/m 16 characters x 2 lines Dimension (W x D x H) 438 x 360 x 192 mm Weight 14.5 lb with tray (6.6 Kg) Power requirements...
Page 284 Book Chapter Search Recording paper size - for automatic paper feeder Letter: 8.5 x 11 inches (216 x 279 mm) A4 : 8.27 x 11.69 inches (210 x 297 mm) Legal : 8.5 x 14 inches (216 x 356 mm) - for manual paper feeder Length: 5 to 14 inches (127 to 356 mm) Width: 5.6 to 8.5 inches (143 to 219 mm)
Page 285: Data Coupler Information
Book Chapter Search FCC Regulations Send Header ÿequirements Federal communications commission (FCC) regulations require all persons within the United States who send any message via a facsimile machine to include an identifying message in the transmission. The message must clearly contain an identifier and telephone number for the entity (business or individual) sending the message.
Page 286 Ask your local telephone company for the modular jack type installed on your line. Connecting this machine to an unauthorized jack can severely damage telephone company equipment. You, not Xerox, assume all responsibility and/or liability for any damage caused by the connection of this machine to an unauthorized jack.
Page 287 Do not connect this machine to a party or coin operated phone line. Repairs to the machine should be made only by a Xerox representative or an authorized Xerox service agency. This applies at any time during or after the service warranty period. If unauthorized repair is performed, the remainder of the warranty period is null and void.
Page 288: Radio Frequency Emissions
Book Chapter Search be reasonable, required in the operation of their business, and consistent with FCC rules. They must give you prior written notification if the changes can: • Make your machine incompatible with their equipment. • Require modification or alteration of the machine. •...
Page 289: Canadian Certification
• Consult the dealer or an experienced radio/TV technician for help. Change or modifications to this equipment not specifically approved by the Xerox Corporation may void the authority granted by the FCC to operate this equipment. Shielded cables must be used with this equipment to maintain compliance with FCC regulations.
Page 290 Book Chapter Search Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord).
Page 291 Book Chapter Search Notice: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to e connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.
Page 292 Search Safety and Legal Requirements for the UK Approvals and Certification The CE marking applied to this product symbolises Xerox Europe Declaration of Conformity with the following applicable Directives of the European Union as of the dates indicated: January 1, 1995: Council Directive 73/23/EEC amended by Council Directive 93/68/EEC, approximation of the laws of the member states related to low voltage equipment.
Page 293 Book Chapter Search A full declaration, defining the relevant directives and referenced standards can be obtained from your Xerox Europe representative or by contacting: Xerox Europe Product Safety, Xerox Europe Technical Centre, PO Box 17, Bessemer Road, Welwyn Garden City,...
Page 294 Book Chapter Search WARNING: IN ORDER TO ALLOW THIS EQUIPMENT TO OPERATE IN PROXIMITY TO INDUSTRIAL, SCIENTIFIC AND MEDICAL (ISM) EQUIPMENT, THE EXTERNAL RADIATION FROM THE ISM EQUIPMENT MAY HAVE TO BE LIMITED OR SPECIAL MITIGATION MEASURES. Your product and supplies have been designed and tested to meet strict safety requirements.
Page 295 Book Chapter Search Do not use this product near water, wet locations, or outdoors. Do not place this product on an unstable cart, stand, or table. The product may fall, causing personal injury or serious damage to the product. WARNING: THIS PRODUCT MUST BE EARTHED.
Page 296 Never spill liquid of any kind on the product. Never remove any covers or guards that require a tool for removal, unless directed to do so in a Xerox approved maintenance kit. Never defeat interlock switches. Machines are designed to restrict operator access to unsafe areas.
Page 297 Chapter Search If you need additional safety information concerning the copier or Xerox supplied materials you should contact your Xerox representative or you may contact Xerox Environment Health and Safety on: 44 (0)1707 353434 *(UK) *Safety Quality Standards: The product is certified to EN 60950.
Page 298 Book Chapter Search All Xerox equipment have been designed to exacting safety standards. They have all undergone a variety of stringent safety tests including earth bond, insulation resistance and electrical strength tests. Xerox Europe manufacturing plants have been awarded ISO 9000 quality certification and are subject to regular audits by the British Standards Institution or equivalent national standards body.
Page 299 The regulation does not impose on, amongst others, manufacturers or suppliers of such electrical systems. However, rest assured that all Xerox equipment which Xerox Europe and its authorised distributors supplies to customers, conform with all the relevant safety legislation and standards.
Page 300 Book Chapter Search standards. If you would like your Xerox equipment to be serviced and maintained to such high standards, please contact your local Xerox Europe Customer Service Organisation. They will be pleased to assist you. QUESTION: Does the Xerox equipment in my premises...
Page 301 Service Engineer will provide you with a certificate which details the results of all tests completed. In the event of any defect being noted, the Xerox equipment will be switched off and disconnected from the supply until the defect has been corrected. You will be advised of such action to enable such defects to be corrected.
Page 302 Book Chapter Search Please contact us if you have any queries regarding the information provided in this document. Xerox Europe Product Safety, Xerox Europe Technical Centre, PO Box 17, Bessemer Road, Welwyn Garden City, Herts AL7 1HE, England European Product Marking Requirements...
Page 303 Chapter Search CTR 21 Annex III The Xerox fax option for the WorkCentre 470cx has been approved in accordance with Council Decision 98/482/EC for pan-European single terminal connection to the public switched telephone network (PSTN). However, due to differences between...
Page 304 The fax kits may also be configured by a Xerox representative to be compatible with other country networks. Other countries, not listed above, will be approved against their own National requirements.
Page 305 Book Chapter Search Telephone Connectivity Guidelines This section will help you connect and set up your WorkCentre 470cx with several different telephone accessories. The Quick Install Guide and User Guide cover the most common ways to set up the WorkCentre. This guide covers those again, as well as more complicated setups.
Page 306 Book Chapter Search • Connecting the WorkCentre to a PC with a fax/data modem, and extension telephone. • Connecting the WorkCentre to a PC with a fax/data modem, answering machine, and extension telephone. • Connecting the WorkCentre to a PC with a fax/data modem with voice mail capabilities, and extension telephone.
Page 307 Book Chapter Search The WorkCentre Telephone Connectors There are two telephone connectors on the side of the WorkCentre. They are: • Line • EXT The Line connector is always used as a direct connection from your WorkCentre to your telephone wall outlet. EXT is used for other accessories, such as an answering machine, extension telephone, and PC fax/data modem.
Page 308 Book Chapter Search You’re using your WorkCentre as a stand-alone fax machine without a PC This is the simplest of all configurations. Plug one end of a telephone cable into the WorkCentre’s Line connector, and the other end into the wall outlet. Wall Outlet From the Line connector The WorkCentre is set up at the factory to automatically answer an...
Page 309 Book Chapter Search Next, enter the number of times the telephone will ring before the WorkCentre answers the call ( You can connect an extension telephone to EXT on the WorkCentre. You’re connecting the WorkCentre with the following: • PC (without a fax/data modem) •...
Page 310 Plug the extension telephone into the EXT connector. The PC printer port is connected to the WorkCentre’s printer port with the Xerox supplied printer cable. The WorkCentre is set up at the factory to automatically answer an incoming call.
Page 311 Book Chapter Search You’re connecting the WorkCentre with the following: • PC (without a fax/data modem) • extension telephone • answering machine From the Printer From the EXT connector connector From the LINE connector In this configuration, you probably want the answering machine to answer incoming calls, but have the WorkCentre take over if the incoming call is a fax.
Page 312 Line into the EXT connector, and plug the extension telephone into the answering machine. The PC printer port is connected to the WorkCentre’s printer port with the Xerox supplied printer cable Set the WorkCentre’s Receive mode to ANS/FAX. At the control panel, press the Receive button (until ANS/FAX displays).
Page 313 Book Chapter Search You’re connecting the WorkCentre with the following: • PC with a fax/data modem • extension telephone From the Printer From the EXT connector connector From the LINE connector In this configuration, you may have two fax machines; the WorkCentre and your PC fax/data modem.
Page 314 Book Chapter Search connected to the WorkCentre’s printer port with the Xerox supplied printer cable. If both units are set to automatically answer an incoming call, the machine set to answer the call in the fewest number of rings will receive the incoming fax.
Page 315 Book Chapter Search You’re connecting the WorkCentre with the following: • PC with a fax/data modem • extension telephone • answering machine From the Printer From the EXT connector connector From the LINE connector In this configuration, you have two fax machines; the WorkCentre and your PC fax/data modem.
Page 316 Line out connector of the answering machine. The PC printer port is connected to the WorkCentre’s printer port with the Xerox supplied printer cable. The answering machine will answer incoming calls, but the WorkCentre will take over if the incoming call is a fax. Set the WorkCentre’s Receive mode to ANS/FAX.
Page 317 Book Chapter Search You’re connecting the WorkCentre with the following: • PC with a fax/data modem that has voice mail capabilities • extension telephone From the Printer From the EXT connector connector From the LINE connector In this configuration, you have two fax machines; the WorkCentre and your PC fax/data modem.
Page 318 Chapter Search telephone into the EXT connector. The PC printer port is connected to the WorkCentre’s printer port with the Xerox supplied printer cable. You should use the PC fax/data/voice mail to answer incoming calls and receive faxes. Use the WorkCentre to send hard copy faxes and print.
Page 319 Book Chapter Search Term Definition ANS/FAX Mode To use this mode, you must have an answering machine attached to the EXT jack on the back of the machine. In ANS/ FAX mode, the machine automatically answers the phone call. If the machine detects a fax signal, it will receive that fax.
Page 320 Book Chapter Search (IEEE standard 1284) between your machine and your PC. Contrast This refers to the difference or contrast between light and dark areas of an image. There is a Contrast button on the control panel, to increase or decrease image contrast on printed sheets.
Page 321 Book Chapter Search Document Tray The Document Tray fits into the slots in the top of your machine. It holds those documents that will be scanned for fax or copy purposes. Dots per inch abbreviation. A unit of measure indicating the resolution of the image.
Page 322 Government that establishes laws and standards for any machines involving communications. There is an FCC Registration number on your machine’s Xerox label, located on the back of the machine. Flash Pressing this button on the control panel performs the equivalent of a switch-hook.
Page 323 Book Chapter Search into memory before transmission. This eliminates the waiting time between faxes. Home Contrast This term is the same as default contrast mode, and is used whenever a document is sent or copied. You can override this default mode.
Page 324 Book Chapter Search LPT1 Line Printer 1. Most PCs have a single parallel port that is connected to the printer with a Centronics cable. Some PCs have a second parallel port called LPT2. Megabyte. A measure of memory storage capacity. Millimeter.
Page 325 Book Chapter Search Portrait A printing term specifying that the long axis of the printed page is vertically oriented. Power Saving This feature lets you reduce machine power when the printer is idle. You can change the length of time the printer waits after a job is printed before power is reduced.
Page 326 Book Chapter Search Redial Try This refers to the number of redials the machine will attempt before giving up. Ringer Equivalence Number. This number can be found on the label located on the back of your machine. Resolution see DPI. Ringer volume You can adjust the machine’s ringer to the desired volume.
Page 327 Book Chapter Search Sound control At your option, an alarm sounds when an error occurs in the machine. System ID The System ID consists of your telephone number (up to 20 digits and pauses) and name (up to 40 characters). System reports Your machine can print many different system reports including: Help List,...
Page 328 For this function, the LCD display on the control panel shows TEL/FAX. Xerox label This is the machine label found on the back of your machine. It contains such items as the Federal Communications Commission Registration number, the Ringer Equivalence Number and the machine’s...

This manual is also suitable for:
