Xerox 5750 Reference Manual

Xerox 5750: reference guide
Hide thumbs Also See for 5750:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual, Service Manual
Expectation Setting Document for
Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799

Customer Support

The Xerox Customer Support Centers are available to provide general information, answer questions and take
service calls. You can reach the Customer Support Center at the following toll-free phone numbers:
Your Xerox Color Analyst will provide fee-based training upon request.

General Specifications

Physical and Environmental
Server
Weight
Dimensions
Operating Temperature
Relative Humidity
Altitude
Electrical Requirements and Compliance
Server
Line Voltage
Frequency
Power
Server Specifications
266 MHz Apple G3 Desktop System
128 MB frame buffer memory
4 GB internal hard drive
MAC OS 8.1
128 MB pipeline buffer memory (PCI 1280 only)
Operating System Software
The customer must retain the MAC OS CD-ROM that comes bundled with the server in the event the Service
Representative needs to reload the operating system.
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
Launch Version
Page 1 of 8
Splash PCI Series v6.0
United States
Canada
English Units
32 lbs.
20.8 x 18.6 x 13 inches
50º - 104º F
5% to 95% (noncondensing)
0 to 10,000 ft.
100 to 125 / 200 to 240 VAC RMS single phase, automatically configured. Minimum 15
amp receptacle.
50 to 60 Hz single phase
230 W maximum not including monitor
1-800-821-2797
1-800-939-3769
Metric Units
14.5 kg
51.9 x 46.6 x 32.5 cm
10º - 40º C
0 to 3,048 m
24 x internal CD-ROM
Token Ring Network capability (optional)
Banyan Vines Network capability (optional)
100 BaseT Network capability (optional)
10 BaseT Network capability (standard)
21 July 1999
60_CED.doc

Advertisement

Table of Contents
loading

Related Manuals for Xerox 5750

Summary of Contents for Xerox 5750

  • Page 1: Customer Support

    Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Customer Support The Xerox Customer Support Centers are available to provide general information, answer questions and take service calls. You can reach the Customer Support Center at the following toll-free phone numbers:...

  • Page 2: Network Specifications

    Expectation Setting Document for Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Network Specifications Protocol Stack Novell IPX / SPX PServer Novell 3.2 Novell 4.x (Bindery Emulation) Novell 4.x (NDS) PServer TCP / IP AppleTalk Banyan Vines (VIP)

  • Page 3: Printing Resolution

    For MajestiK, Regal, and DocuColor 5799, the maximum paper size is 11 x 17 with a maximum printer size of 10.69" x 16.47". For DocuColor 5750, the maximum paper size is 12 x 18 with a maximum printer size of 11.69" x 17.53". The application and the MajestiK, Regal, DocuColor 5750, or DocuColor 5799 setup, control image position.
  • Page 4 Expectation Setting Document for Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Features The Splash PCI Series v6.0 server contains the same features as the version 5.x server such as Color Correction, Print Job Pre-flighting, and Rip-While-Print. However, the Splash PCI Series v6.0 has added additional features,...

  • Page 5: Supported Paper Sizes

    Expectation Setting Document for Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Print Quality and Color Management The appearance of the document displayed on the monitor screen may not match the output print unless Splash ColorCal and color correction tools are used.

  • Page 6: Reference Material

    Expectation Setting Document for Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Reference Material The Splash PCI Series v6.0 is shipped with a complete set of documentation for the installation and use of the server. This documentation is in one of two formats (listed below) and is provided in the Customer Media Pack bundled with each server.

  • Page 7: Responsibility Matrix

    Provide Helpline Support Provide spared parts Provide service Xerox responsibility when a Field Service Maintenance Agreement (FSMA) is purchased. If FSMA is not purchased, this action becomes a customer responsibility. Purchasable option. Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
  • Page 8 Splash PCI Series v6.0 Digital Front End for MajestiK, Regal, DocuColor 5750, and DocuColor 5799 Primary Customer MajestiK, Regal, DocuColor 5750, or DocuColor 5799 printer / Splash Applications: Special Considerations or performance limitations identified by Xerox and agreed to by the customer:...
