Expectation Setting Document for
Digital Front End for 5760,5765,5790 and DocuColor 5750, 5799
Customer Support
The Xerox Customer Support Centers are available to provide general information, answer questions and take
service calls. You can reach the Customer Support Center at the following toll-free phone numbers:
Your Xerox Color Analyst will prov ide fee-based training upon request.
General Specifications
Physical and Environmental – M310 & M410 Server
Weight
Dimensions
Operating Temperature
Relative Humidity
Altitude
Electrical Requirements and Compliance – M310 and M410 Server
Server
Line Voltage
Frequency
Power
Server Specifications – M310
Minimum of 300 MHz Pentium II CPU
64 MB RAM
3 GB internal hard drive
Server Specifications – M410
Minimum of 400 MHz Pentium II CPU
128 MB RAM
6 GB internal hard drive
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
Post Launch Version
Page 1 of 7
Splash M310 / M410
United States
Canada
English Units
33 lbs.
24 x 24 x 17 inches
50º - 104º F
5% to 95% (noncondensing)
0 to 10,000 ft.
100 to 125 / 200 to 240 VAC RMS single phase. Minimum 15 amp receptacle (sole use
recommended).
50 to 60 Hz single phase
240 W maximum
1.44 MB floppy drive
10/100 BaseT network interface card - 3Com 3C905B
1.44 MB floppy drive
10/100 BaseT network interface card - 3Com 3C905B
1-800-821-2797
1-800-939-3769
Metric Units
15 kg
61 x 61 x 43.2 cm
10º - 40º C
0 to 3,048 m
14 May 1999
C_P_CED.doc
Advertisement
Related Manuals for Xerox 5750
Summary of Contents for Xerox 5750
-
Page 1: Customer Support
Digital Front End for 5760,5765,5790 and DocuColor 5750, 5799 Customer Support The Xerox Customer Support Centers are available to provide general information, answer questions and take service calls. You can reach the Customer Support Center at the following toll-free phone numbers:... -
Page 2: Network Specifications
Rasterizing (RIP-ing) is only a small fraction of Click to Clunk time. Printing with custom software applications may produce unexpected or unknown results. The Splash M Series server is a continuous printer; therefore, the copier will not cycle down between each job. Printing Resolution Print resolution for all paper sizes is 400 x 400 x 8 dpi. - Page 3 For 5760, 5765, 5790 or DocuColor 5799, the maximum paper size is 11 x 17 with a maximum printer size of 10.69" x 16.47". For DocuColor 5750, the maximum paper size is 12 x 18 with a maximum printer size of 11.69" x 17.53". The application and the 5760, 5765, 5790 or DocuColor 5750/5799 copier/printer setup control image position.
-
Page 4: Supported Paper Sizes
Diamond Merge (variable data). Getting Started Guide: Contains the basic procedures for configuring and connecting the print server to the copier, configuring the copier for the network, and installation of the workstation Viewer software. 2) The following documentation is in hardcopy format. -
Page 5: Optional Kits
25K Record Variable Kit 200K Record Variable Kit Space Guidelines This diagram represents the space relationship between the Digital Front End (DFE) and the copier/printer. It does not define the space requirements for the copier/printer. 24” (310 mm) Work Surface/ 2”... -
Page 6: Responsibility Matrix
Provide spared parts Provide service Xerox responsibility when a Field Service Maintenance Agreement (FSMA) is purchased. If FSMA is not purchased, this action becomes a customer responsibility. Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. - Page 7 Splash M310 / M410 Digital Front End for 5760,5765,5790 and DocuColor 5750, 5799 Primary Customer applications for the 5760, 5765, 5790 and DocuColor 5750/5799 copier / printer: Special considerations or performance limitations identified by Xerox and agreed to by the customer:...
