Extremely small size.
Plugs into RCA type inputs on any TV or monitor.
Can be turned on and off from X10 controllers.
Remote controlled power supply (included).
Monitor a child's bedroom, etc.
Use it outdoors to monitor your front door, back yard, etc. (60 ft. cable included).
The SC18A includes a very small and compact color video camera (WC10A) that plugs into the RCA audio/video jacks
on any TV or monitor. You can place it anywhere you want to monitor (indoors or outdoors). It also includes a microphone
so you can hear as well as see what's going on. It is powered from a remote controlled power supply (XM10A) so you can
turn it on and off by remote control using X10 controllers and remotes (sold separately).
1. Attach the camera to a wall in the location you want to
monitor. Mount it with the cable coming out of the bottom. If
you are installing the camera outdoors, pass the 60 ft. cable
from the camera through a small hole in your exterior wall.
2. Plug the camera's plug into the adapter cable.
3. Plug the video plug on the adapter cable into the yellow Video
In socket on your TV/monitor.
4. Plug the audio jack into either audio socket (red or white)
on your TV/monitor.
5. Plug the power supply's jack into the power socket on the
adapter cable.
6. Plug the power supply into any 120V AC outlet.
X10 Wireless Technology, Inc.
LIMITED 1-YEAR WARRANTY
X10.com, a division of X10 Wireless Technology, Inc. (X10)
warrants X10 products to be free from defective material and
workmanship for a period of one (1) year from the original date
of purchase at retail. X10 agrees to repair or replace, at it's sole
discretion, a defective X10 product if returned to X10 within the
warranty period and with proof of purchase.
If service is required under this warranty:
Call 1-800-675-3044 or visit www.x10.com, or e-mail
sales@x10.com to obtain a Return Merchandise
Authorization (RMA) number.
Please visit www.x10.com/warranty to complete your on-
line warranty registration. Thank you.
X10.com, a division of X10 Wireless Technology, Inc.
Visit www.x10.com/support for more help.
Indoor/Outdoor Color Video Camera
(with microphone)
Video/Audio
monitor of
your choice
Video
Audio
In
In
Plug video
3
adapter in
here.
WC10A
2
Plug camera in here.
60 ft.
Set the Housecode dial to
match the setting on the X10
Controller or Remote Control
that you want to control the
camera connected to the
XM10A from.
Set the Unit Code dial to any
unused number between 1
and 16.
Model SC18A
4
Plug audio in here.
Adapter Cable.
Plug power
5
supply in here.
Plug into any
6
AC outlet
SC18A-8/02
