Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified
Communications Manager
First Published: 2017-11-22
Last Modified: 2024-02-23
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883

Advertisement

Table of Contents
loading

Related Manuals for Cisco ATA 191

Summary of Contents for Cisco ATA 191

  • Page 1 Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager First Published: 2017-11-22 Last Modified: 2024-02-23 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883...
  • Page 2 Cisco has more than 200 offices worldwide. Addresses and phone numbers are listed on the Cisco website at www.cisco.com/go/offices. Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: https://www.cisco.com/c/en/us/about/legal/trademarks.html.

  • Page 3: Table Of Contents

    Answer call waiting on your ATA phone Put a call on hold on your analog phone Forward your analog phone calls to another number Transfer a call from your Analog phone Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 4 FCC Part 15.21 Statement FCC RF Radiation Exposure Statement FCC Receivers and Class B Digital Statement Compliance Information for Brazil Cisco Product Security Overview Important Online Information Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 5: Get Started With Your New Ata

    Each port supports either voice calls or fax sessions, and both ports can be used simultaneously. • One WAN network port—An RJ-45 10/100BASE-T data port to connect an Ethernet-capable device to the network. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 6: Ata 191 Top Panel

    • A factory reset is performed successfully. Off: Power is off. Network LED Flashing green: Data transmission or reception is in progress through the WAN port. Off: No link. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 7: Ata 191 Back Panel

    Figure 2: ATA 191 Back Panel The following table describes the ports that are located on the back panel of your ATA. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 8: Devices Associated With Your Ata

    • To reduce fax failures, use overseas mode, if available; if not, set the fax machine transmission speed to low. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 9: Install Your New Ata

    Connect the network cable to your network and to the NETWORK port on the ATA. Step 2 Connect the phone cable to the PHONE 1 port on the ATA and to your analog device (phone or fax machine). Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 10: Mount Your Ata

    To prevent the ATA from overheating, do not operate it in an area that exceeds an ambient temperature of 104°F (40°C). Desktop Placement Place the ATA on a flat surface near an electrical outlet. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 11: Wall Mounting

    Recommended hardware (not included): Two #6 pan head, 5/8 in., self-tapping screws with anchors for sheet rock installation. Note Insecure mounting might damage the ATA or cause injury. Cisco is not responsible for damages incurred byinsecure wall-mounting. Procedure Step 1 Determine where you want to mount the unit.

  • Page 12: Supported Ata Call Features

    Some analog phones with a large LCD screen may display a voicemail icon. • Call Forward. • Redial. Related Topics Calls, on page 15 Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 13 Get Started with Your New ATA Supported ATA call features Voice Mail on Your Analog Phone, on page 21 Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 14 Get Started with Your New ATA Supported ATA call features Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 15: Manage The Ata Using The Ivr

    To access the IVR, go off-hook on the phone connected to PHONE1 or PHONE2. Step 2 Press **** from the phone keypad. The IVR prompts for a password. The ATA 191 allows you to enter only numerical values for the password. Step 3 Follow the voice prompts on the IVR.

  • Page 16: Ivr Configuration Menu Options

    Answers with 0, the default option Method (DHCP). (IPv4) Set the Internet Addressing Method 0: DHCP; 1: Static IP Check Stack Mode. 0: IPv4; 1:IPv6; 2: Dual Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 17 Available in IPv6 static IP mode only. prefix length (IPv6) Check the TFTPv6 server address (IPv6) Set the TFTPv6 server address (IPv6) Check the gateway IP address Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 18 73738 Factory Reset Configure the 802.1x authentication 0: Disabled; 1: Enabled Check the 802.1x authentication Respond with a number: 0 or 1. configuration 0: Disabled; 1: Enabled Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 19: Calls

    (Optional) Dial the digits for an outside line and wait for a dial tone. Step 3 Dial the phone number. Redial a number from your analog phone You can call the most recently dialed phone number. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 20: Answer A Call On Your Ata Phone

    While on an active call, perform a hook flash. Step 2 To return to the call, either: • Perform another hook flash. • Hang up the handset. Pick up the handset when your phone rings. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 21: Forward Your Analog Phone Calls To Another Number

    Step 5 Hang up your phone to complete the transfer. Make a conference call from your analog phone You can talk with several people in a single call. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 22: Host A Meet Me Conference On Your Analog Phone

    • Shared lines can barge into an active call: • If autobarge is enabled, the shared line going off-hook triggers cBarge. • If autobarge is disabled, the shared line dials **6 to trigger cBarge. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 23: Call Features And Star Codes For Analog Phones

    Send and Receive Fax Calls You can send and receive fax calls when a fax machine is connected to a phone port on the ATA 191. Follow the instructions for your fax machine to send and receive fax transmissions.

  • Page 24: Procedure

    Procedure Step 1 Pick up the handset and check for a dial tone. Step 2 Dial the emergency number. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 25: Voice Mail On Your Analog Phone

    Procedure Step 1 Press * then 0. Step 2 Follow the prompts from your voice-messaging system to listen to and manage your voice messages. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
  • Page 26 Voice Mail on Your Analog Phone Check your voicemail from your analog phone Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 27: Product Safety And Security

    • Shorten the length of the external device cable. • Apply ferrites or other such devices on the cables for the external device. Cisco cannot guarantee the performance of external devices, cables, and connectors. Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 28: Phone Behavior During Times Of Network Congestion

    • Increase the separation between the equipment or devices • Connect the equipment to an outlet other than the receiver's • Consult a dealer or an experienced radio/TV technician for assistance Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...

  • Page 29: Compliance Information For Brazil

    This product contains cryptographic features and is subject to U.S. and local country laws that govern import, export, transfer, and use. Delivery of Cisco cryptographic products does not imply third-party authority to import, export, distribute, or use encryption. Importers, exporters, distributors, and users are responsible for compliance with U.S.
  • Page 30 Product Safety and Security Important Online Information Cisco ATA 191 Analog Telephone Adapter User Guide for Cisco Unified Communications Manager...
