Vulcan-Hart ECO2C Catalog Of Replacement Parts
Half size electric convection ovens
Hide thumbs
Also See for ECO2C:
- Installation & operation manual (21 pages) ,
- Service manual (40 pages)
Table of Contents
Advertisement
Quick Links
HALF SIZE ELECTRIC
CONVECTION OVENS
MODEL
ML-114570
ML-114572
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
ECO2D
ECO2C
REPLACEMENT PARTS
P.O. BOX 696, LOUISVILLE, KY 40201-0696
CATALOG OF
MODEL ECO2C
TEL. (800) 814-2028
FORM 31000 Rev. C (Dec. 2008)
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart ECO2C
Summary of Contents for Vulcan-Hart ECO2C
-
Page 1: Replacement Parts
CONVECTION OVENS MODEL ML-114570 ECO2D ML-114572 ECO2C For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF... - Page 2 ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS Style 35-36 Style 1 11 13 THRU 15 33-34 33-34 NOTE: Item 33 removed for clarity CABINET – 2 – 21-22 26 THRU 30 31-32 42 New PL-52611A-3...
- Page 3 REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS ILLUS. PART PL-52611A-3 NO. 00-427855-00001 Striker-Door Switch (Old Style) (Prior to December 2008) ... 1 00-499340-00001 Bracket, Shaft, Micro Switch (New Style) (Beginning December 2008) ... 1 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ... 1 SD-034-47 Self-Tapping Screw 6-32 x 1 Hex Washer Hd., Type T ...
- Page 4 ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS 5 THRU 8 Old Style Mounted to Door PL-52612A-1 Mounted to Upper “C” Channel See Page 2 9-10 DOOR – 4 –...
- Page 5 Door Assy (Old Style) ... 1 00-499305-000G1 Door Assy. (New Style) ... 1 NOTE: When ordering item 9 for an old style oven, 1 of part 423014-G1 is also needed. DOOR NAME OF PART Hex Washer Hd., Type AB ... 4 -20 x Truss Hd.
- Page 6 ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS 14-15 5-6-7 9-10-11 CONTROL PANEL COMPONENTS VIEWED FROM BACK OF PANEL. Old Style PL-52386 CONTROL PANEL (ECO2D) – 6 – New Style...
- Page 7 REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS ILLUS. PART PL-52386 00-422560-000G1 Panel-Control (Prior to February 2003) ... 1 00-340324-00006 Switch (D.P.S.T.) (Prior to February 2003) ... 1 00-354575-00001 Light Indicator (On/Heat) (200-240V) ... 1 00-340324-00009 Switch (D.P.D.T.) ... 2 00-353613-00002 Controller - Temperature ...
- Page 8 ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS PL-52421 Fig. 2 Old Style New Style CONTROL PANEL (ECO2C) COMPUTERIZED CONTROLS – 8 –...
- Page 9 REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS ILLUS. PART PL-52421 00-355903-00004 Controller W/Cook, Hold & Pulse (Prior to November 1999) ... 1 00-358628-00002 Switch - Rocker (2 Position) (Prior to November 1999) ... 1 00-422585-000G1 Panel-Control (Prior to November 1999 ... 1 00-422584-00001 Overlay ...
-
Page 10: Component Panel
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS 13-14 10-11 ILLUS. PART PL-52389 00-422712-00001 Panel-Component ... 1 00-358629-00001 Transformer-Controls (ECO2C) (Prior to November 1999) ... 1 SD-034-49 Self-Tapping Screw 8-32 x 00-411497-000C5 Contactor 3 pole ... 1 SD-034-49... -
Page 11: Electric Heaters
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS ILLUS. PART PL-52388 00-351393-00002 Heater Unit Assy. (Outer)(208V) ... 1 00-351393-00004 Heater Unit Assy. (Outer)(240V) ... 1 00-351393-00001 Heater Unit Assy. (Inner)(208V) ... 1 00-351393-00003 Heater Unit Assy. (Inner)(240V) ... 1 00-342131-00001 Clamp-Large ... -
Page 12: Options And Accessories
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS PART 00-347498-00003 Guide-Rack (LH) ... 1 00-347498-00004 Guide-Rack (RH) ... 1 00-347497-00002 Rack ... AR 00-340445-00002 Leg - Adjustable (6") ... 4 00-348164-00001 Leg - Adjustable (4") ... 4 00-341655-00006 Caster - 6"...
