- Page 1 User Guide for NUC7CJYSAMN Intel® NUC 7 Essential, a Mini PC with Windows® 10 – NUC7CJYSAMN User Guide...
-
Page 2: Before You Begin
If such a station isn’t available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Installation Precautions When you install and test the Intel NUC, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: ... -
Page 3: Upgrade System Memory
Unscrew the four corner screws on the bottom of the chassis and lift the cover. Upgrade System Memory The Intel NUC Mini PC NUC7CJYSAMN have two 260-pin DDR4 SO-DIMM sockets, pre-installed with one 4GB DDR4 2400 MHz SO-DIMM. To upgrade memory, be sure to select memory modules that meet these requirements: ... - Page 4 User Guide for NUC7CJYSAMN NOTE If you plan to install only one memory module, install it in the lower memory socket. To upgrade or add memory, follow these steps: 1. Observe the precautions in "Before You Begin" on page 2. 2.
- Page 5 Replace the computer’s cover and reconnect the power cord. Install a 2.5” SSD or Hard Drive Observe the precautions in "Before You Begin" on page 2. Find compatible 2.5” hard drives in the Intel Product Compatibility Tool. NUC7CJYSAMN Follow these instructions to install a 2.5” Solid State Drive (SSD) or Hard Disk Drive (HDD): 1.
-
Page 6: Close The Chassis
User Guide for NUC7CJYSAMN Close the Chassis After all components have been installed, close the Intel NUC chassis. Intel recommends this be done by hand with a screwdriver to avoid over-tightening and possibly damaging the screws. Attach and Use the VESA Bracket (Optional) Follow these instructions to attach and use the VESA mount bracket: 1. - Page 7 User Guide for NUC7CJYSAMN 2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC. 3. Slide the Intel NUC onto the VESA mount bracket.
-
Page 8: Connect Power
User Guide for NUC7CJYSAMN Connect Power Each Intel NUC model includes either a region-specific AC power cord or no AC power cord (only the power adapter). Product codes Power cord type BOXNUC7CJYSAMN No power cord included. An AC power cord needs to be purchased separately. -
Page 9: Set Up Microsoft Windows
User Guide for NUC7CJYSAMN Set Up Microsoft® Windows® 10 Microsoft Windows 10 is already installed on the Intel NUC NUC7CJYSAMN. The first time you start the computer, you’re guided through the Windows 10 setup steps, including: Selecting your region and language. -
Page 10: Operating System Recovery
Intel® Software Guard Extensions Operating System Recovery There’s a Windows recovery partition on the Intel NUC. You can use this partition to Refresh, Reset, or Restore Windows. Here is what each of these actions do: Refresh If your PC isn't performing as well as it once did, and you don't know why, you can refresh your PC. - Page 11 User Guide for NUC7CJYSAMN...
