- Page 1 SunCell-Plus Modules Solahart475DH1 Solahart480DH1 Installation Manual Solahart PV Systems must be installed and serviced by a suitably qualified person.
-
Page 2: Table Of Contents
Catalogue Introduction ............................... 3 1.1 Purpose ................................3 1.2 Scope of liability ............................... 3 Regulations ................................. 3 Safety Precautions ............................. 3 3.1 General safety ..............................4 3.2 Operation safety measures ..........................5 Handling and unpacking ..........................6 4.1 Transport ................................6 4.2 Unpack ................................ -
Page 3: Introduction
Introduction manual is complied with is beyond the control of Solahart. Solahart shall not be liable for any form of We appreciate for your trust and confidence towards the loss, including but not limited to loss, damage, casualty photovoltaic (PV) module products from Solahart. -
Page 4: General Safety
unauthorized personnel, including but not limited to ！WARNING replacing any part of PV modules (such as diodes, junction boxes, connectors, etc.). Read and understand all safety instructions before installing, wiring, handling, and/or maintaining PV It is forbidden to plug in connectors of different modules. -
Page 5: Operation Safety Measures
wear any metal accessories to avoid the risk of Avoid partial shading of PV modules for a long electric shock; if it is installed far above the ground, period of time, otherwise the temperature of the please wear a seat belt. shaded module may rise due to hot spot effect, burning the module and causing fire hazard in severe ... -
Page 6: Handling And Unpacking
It is strictly forbidden to touch wet PV box provided by Solahart, and they should be stored modules, unless you are wearing electric shock in the original packaging box before installation. -
Page 7: Unpack
metal corrugated, etc. when the PV modules are removed from the container, the distance between the upper surface of the forklift When the PV modules are stacked, they must be neatly tines and the ground should be less than 80mm, and stably stacked on a horizontal surface, and stacked otherwise collisions may easily occur, which may with the glass side facing down and the back side facing... -
Page 8: Tilt Angle Selection
Solahart recommends an installation tilt angle of no less corrosive substances (e.g. salt, salt spray, brine, than 10°, so that when it rains, the dust on surface is... -
Page 9: Bolted Mounting
The PV module must be securely fastened to the mounting system. If the PV module is mounted in a snowy area, the height of the mounting system should be designed in a way that the lowest end of the PV module is not covered by snow. In addition, it should be ensured that the lowest end of the PV module is not shaded by surrounding trees or other Fig 3. -
Page 10: Clamped Mounting
Then screw on the module, otherwise it should be confirmed by top of a stainless-steel spring washer or toothed lock Solahart in advance. washer. Finally, lock with a stainless-steel nut. The above two diagrams show the mounting method ④... - Page 11 (as shown in Fig. 13), and the overlap between the C Class 8.8 screw and bolts. side of the module and the rail should be ≥ 15mm. Solahart limited warranty will be void if improper clamps or improper installation is used. Fig. 10 Schematic diagram of the mid clamp...
- Page 12 Fig 2 & Fig Fig 5 L*W*H (mm) Fig 8 Fig 9 Fig 6 3 & Fig 4 1908 *1134*30 +5400Pa +5400/-2400Pa +1800/-1800Pa Solahart 475DH1 -2400Pa Installation scope Installation scope Solahart 1908 *1134*30 480DH1 D = 320~520mm D = 150~250mm...
-
Page 13: Electrical Installation
manual) Electrical Installation : minimum ambient temperature. Electrical characteristics ！ATTENTION The electrical characteristics are detailed in the PV Under normal operating conditions, the output current module product datasheet. and/or voltage of the PV module may be higher than The rated values of electrical characteristics, including the value under standard testing conditions. - Page 14 The number of modules connected in series and connecting the positive terminal of one module to the positive terminal of the next module. If a module is not parallel should be reasonably designed according to the connected correctly, the bypass diode may be damaged. system configuration.
-
Page 15: Grounding
M5 and made of stainless steel When a diode failure is suspected or found, please (Fig. 15). Grounding hole location on the panel frame contact Solahart team and do not attempt to open is shown in Fig. 16 below. the junction box cover. -
Page 16: Maintenance
Insert the bolt through the cup washer and wrap the breakage, junction box damage, cell cracks, and copper wire around the bolt. (Note that the copper backsheet breakage and other factors that cause wire cannot be attached directly to the aluminum.) functional and safety failures of PV modules. -
Page 17: Modified Version And Date
Modified version and date · Rev 1.4A, released in February 2023 Solahart Industries Pty Ltd (A.B.N. 45064945848) For SERVICE Telephone - 1800 638 011 Registered Office Email us: solahart@solahart.com.au 1 Alan Street (PO Box 7508, Silverwater, 2128) Rydalmere or your nearest Solahart Dealer...
