Omron HHP-BFH01 Instruction Manual

AC Adapter
HHP-BFH01
Instruction Manual
IM-HHP-BFH01-E-03-11/2022
Manufacturer OMRON HEALTHCARE Co., Ltd.
53, Kunotsubo, Terado-cho, Muko, KYOTO,
617-0002 JAPAN
EU-representative OMRON HEALTHCARE EUROPE B.V.
Scorpius 33, 2132 LR Hoofddorp,
THE NETHERLANDS
EU
www.omron-healthcare.com
Importer in EU
EU
Production facility DONGGUAN WAHHING ELECTRICAL
APPLIANCE CO., LTD.
Dongguan Industrial Zone, Sanzhong Village,
Qingxi Town, Dongguan, Guandong, China
Subsidiary Importer in OMRON HEALTHCARE UK LTD.
the United Opal Drive, Fox Milne, Milton Keynes,
Kingdom MK15 0DG, UK
and UK www.omron-healthcare.com/distributors
responsible
person
Made in China
Description of symbols
Ingress protection degree provided by IEC 60529
EN
IP XX
IEC 60529
IEC 60529
Class ll equipment. Protection against electric shock
EN
Refer to the instructon manual
EN
Temperature limitation
EN
Humidity limitation
EN
2022-11-18
Atmospheric pressure limitation
3787255-0E EN
Indication of connector polarity
EN
For indoor use only
EN
Proper disposal of product (used electrical and electronic
EN
equipment)
CE Marking
EN
Direct current
EN
Alternating current
EN
Date of manufacture
EN
Medical device
EN
UKCA Marking
EN
EN
Product production date is integrated in a LOT number, which is placed on the sales
EN
LOT
2
EN
Intended Use
This device is an AC Adapter intended for use with applicable Omron devices.
AR
The Omron devices which are compatible have this model mentioned on the
UR
rating label. In case compatibility is not clear please consult an authorized
Omron service provider.
II AR
Please read this instruction manual and applicable Omron device manual
II UR
thoroughly before using the unit.
Please keep for future reference.
AR
Important safety information
UR
Warning: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
AR
• Do not use the AC adapter if the device or the power cord is damaged. Turn
UR
off the power and unplug the power cord immediately.
• Plug the AC adapter into the appropriate voltage outlet. Do not use in a multi-
AR outlet plug.
• Never plug in or unplug the power cord from the electric outlet with wet hands.
UR
• Do not disassemble or attempt to repair the AC adapter.
Caution: Indicates a potentially hazardous situation which, if
AR
not avoided, may result in minor or moderate injury to
UR
the user or patient or damage to the equipment or other
property.
AR • Fully insert the power plug into the outlet.
• When disconnecting the power plug from the outlet, be sure to safely pull from
UR
the power plug.
• Do not pull from the power cord.
AR •
Do not damage. Do not break it.
UR
Do not tamper with it. Do not forcibly bend or pull.
Do not twist. Do not bundle during use.
Do not pinch. Do not place under heavy objects.
AR
• Wipe any dust off of the power plug.
• Unplug the monitor when not in use.
UR
• Disconnect the power plug before cleaning.
• AC adapter cable may cause accidental strangulation in infants.
AR
Use this AC adapter only for compatible main Omron devices. Use of
CE UR
unsupported adapters may damage and/or may be hazardous to the device.
While using this device, make sure that no mobile phone or any other electrical
AR
degradation of performance of the device.
UR
Using the AC Adapter
AR
and disconnect the AC adapter.
UR
1. Insert the AC adapter plug into the AC adapter jack of the device.
2. Plug the AC adapter into an electrical outlet.
AR
To disconnect the AC adapter, unplug the AC adapter from the
UR
Maintenance and Storage
AR
UR
• Store the device in a clean, safe location.
• Do not use any abrasive or volatile cleaners.
• Do not wash the device or immerse them in water.
UKCA
AR
• Do not use gasoline, thinners or similar solvents to clean the device.
UKCA
UR
• Disconnect the device from the electrical outlet and use a soft dry cloth to
clean.
•
AR
warranty.
UR
Do not disassemble or attempt to repair the device or components.
Product Description AC Adapter
AR
Model HHP-BFH01
Electrical Rating AC100-240 V, 50-60 Hz, 0.12-0.065 A
UR
Output voltage 6V DC / 700 mA
4
Durable period 5 years
(Service life)
Ambient temperature 10 to 40 °C
Relative humidity 15 to 90 % (non-condensing)
Ambient Pressure 700-1060 hPa
Ambient temperature -20 to 60 °C
Relative humidity 10 to 90 % (non-condensing)
Weight Approx. 67.2 g
Dimensions (box) 54 (w) × 72 (h) × 96 (l) mm
IP22
Protection against Class II ME equipment
electric shock
Contents AC Adapter, Instruction Manual
•
•
with IEC 60529. The AC adapter is protected against solid foreign objects of
The AC adapter is protected against oblique falling water drops which may
cause issues during a normal operation.
• This device can be used for continuous operation.
• Please report to the manufacturer and the competent authority of the Member
State in which you are established about any serious incident that has
occurred in relation to this device.
Warranty
Thank you for buying an OMRON product. This product is constructed of high
quality materials and great care has been taken in its manufacturing. It is
designed to give you every satisfaction, provided that it is properly operated
and maintained as described in the instruction manual. This product is
guaranteed by OMRON for a period of 1 year after the date of purchase. The
proper construction, workmanship and materials of this product is guaranteed
by OMRON. During this period of guarantee OMRON will, without charge for
labour or parts, repair or replace the defect product or any defective parts.
Should guarantee service be required, please contact your authorized OMRON
distributor in your country.
www.omron-healthcare.com
Repair or replacement under the guarantee does not give rise to any extension
or renewal of the guarantee period.
The guarantee will be granted only if the complete product is returned together
with the original invoice / cash ticket issued.
Important information regarding Electro Magnetic Compatibility (EMC)
HHP-BFH01 manufactured by OMRON HEALTHCARE Co., Ltd. conforms to
Further documentation in accordance with this EMC standard is available
at OMRON HEALTHCARE EUROPE at the address mentioned in this
instruction manual or at www.omron-healthcare.com. Refer to the EMC
information for HHP-BFH01 on the website.
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
This marking shown on the product or its literature, indicates that it should not
be disposed of, with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this product from other types of wastes and
recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
can return this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed with
other commercial waste for disposal.
