GEPS12-25U-NA
Power Supply Features
• Supports all 12 VDC Tetra Products
• Dry and Damp Locations Rated
• Class 2 Power Supply
• 120-277 VAC Input
BEFORE YOU BEGIN
Read these instructions completely and carefully.
RISK OF ELECTRIC SHOCK
• Disconnect power at fuse box or circuit breaker before servicing
or installing product.
• Properly ground Tetra
power supply.
®
• Must be enclosed in an end product.
RISK OF FIRE
• In the end product, power supply spacing to other heat
producing components shall be minimum 2 inches spacing to
sidewalls and minimum 2 inches spacing to top of enclosure.
• Adjacent power supplies shall be spaced at least 1 in. end to
end and 4 in. in any other direction.
• Use only approved wire for input/output connection. Minimum
size 18 AWG (0.82 mm
).
2
• Follow all local codes.
• Application considerations potentially requiring additional
spacing include high ambient temperature seen by the
power supply, poor contact with a heat dissipating material,
inadequate ventilation, or direct exposure to sun.
RISK OF INJURY
• While performing installations described, gloves, safety
glasses or goggles should be worn.
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
(
120-277
VAC input /
WARNING/AVERTISSEMENT
12
VDC output /
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l'alimentation électrique à la boîte de fusibles ou au disjoncteur avant
l'entretien ou l'installation du produit.
• Assurez-vous de correctement mettre à terre le bloc d'alimentation Tetra
• Doit être inclus à l'intérieur d'un produit final.
RISQUES D'INCENDIE
• Dans le produit fini, l'espacement entre le bloc d'alimentation et les autres
composants dégageant de la chaleur doit être d'au moins 2 pouces des
parois latérales et d'au moins 2 pouces du haut de l'enceinte.
• Les blocs d'alimentation adjacents doivent être espacés d'au moins 1 po
de bout en bout et 4 po dans toute autre direction.
• N'utilisez que des fils approuvés pour les entrées/sorties de connexion.
Taille minimum 18 AWG (0.82 mm
• Respectez tous les codes locaux..
• Certaines applications pourraient requérir un espacement additionnel, p.
ex. une température ambiante élevée autour du bloc d'alimentation, un
mauvais contact avec une matière dissipatrice de chaleur, une ventilation
inadéquate ou une exposition directe au soleil.
CAUTION/ATTENTION
RISQUES DE BLESSURE
• Lors de l'exécution des installations décrites, des gants, des lunettes de
sécurité ou des lunettes de protection doivent être portées.
Prepare Electrical Wiring
Electrical Requirements
• Limited to use in dry and damp locations.
• The suitability of rain enclosure shall be determined if
intended for wet location.
• The grounding and bonding of the LED Driver shall be
done in accordance with National Electric Code (NEC)
Article 600.
• Follow all National Electric Codes (NEC) and local codes.
1
Installation Guide
25
W)
).
2
12
Volt
.
®
