Troubleshooting - US Robotics USR8001 Quick Installation Manual

4. Select Wizard from the menu.
The Setup Wizard will lead you through the basic router configuration process. If you are
unsure about any connection information required by the wizard, contact your ISP.
Note: For configuration details and USB printer installation instructions, refer to the
Guide
on the U.S. Robotics Installation CD-ROM.
5. Make a backup of your new configuration settings:
• Select the Toolbox menu.
• Click Backup Setting.
• Your system will prompt you to save or open the file. Select Save and click OK.
• Browse to the location at which you want the backup file saved and click Save.
Cable or DSL Users
To verify your Internet connection, launch a Web browser and register your product at
www.usr.com/productreg. If the page loads, you are finished with the installation procedure. If
the page does not load, proceed to Troubleshooting, later in this document.
Analogue or ISDN Users
To verify your Internet connection, click Connect in the Status page to initiate a dial-up session
with your ISP. The Status page will indicate whether or not the call was successful. If the settings
are correct, the analogue or ISDN modem can be used to connect to the Internet. If the connection
fails, verify that you entered the correct values.
Congratulations! The installation procedure is now complete.

Troubleshooting

I can't connect to the Router's Web User Interface.
Possible Solution 1:
Make sure all the Ethernet cables are properly and securely connected and the power cord is
plugged in.
Possible Solution 2:
Make sure that you correctly performed all the steps in the "Before You Begin" section of the
Guide . If your computer is configured to use a static IP address, you must now reconfigure it to
Obtain an IP address automatically.
Possible Solution 3:
Make sure that your PC is using an IP address that is within the default range of 192.168.123.xxx.
Make sure the address of the subnet mask is 255.255.255.0. If necessary, the Default Gateway
should be 192.168.123.254. To verify all these settings, perform the following steps:
Windows Me, 98, and 95 Users:
Click Windows Start > Run.
•
• Type winipcfg and click OK.
User
User
5
