Food Storage

Drawers
The drawers should only be removed for servicing by a
trained and certified repair person.
Top Storage Bin
Figure 8
Grasp the bin handle and slide backward to access the
contents below (Figure 8). The bin may be completely
removed for cleaning once it is slid forward, making sure
it clears the guides on each side of the drawer. Then lift
straight up. If heavy items are stored in bin, push front of
bin down slightly while sliding. Slide bin forward,
especially with heavy items, to ensure that drawer closes
completely.
Drawer Organizer
Adjust the drawer organizer to compensate for different
size bottles or items. The organizer can be used in the top
drawer only.
1
Figure 9
The organizer may be adjusted left-to-right or front-to-
back as required.
10
ULIN_0084_A
C2275DWR
When adjusting the organizer, open the drawer fully,
remove the bin and all other items, and brace the drawer
to prevent movement. To adjust, turn the drawer
organizer knob (Figure 9, 1) counterclockwise to loosen
and use two hands to position as desired. Tighten knob
after adjustment is made. Do not over-tighten.
Clean the drawer organizer with warm water and a mild
detergent only. Do not use solvent based or abrasive
cleaners and do not place the drawer organizer in a
dishwasher.
Figure 10
Be sure that items stored in the rear of the top drawer do
not interfere with the sliding operation of the storage
bin. Tall items such as milk jugs can be stored toward the
front of the drawer as long as they do not interfere with
the closing of the drawer. Taller items can be stored on
their side (Figure 10, 1) in the storage bin.
The storage bin is designed to accommodate the storage
of two wine bottles, even when opened.
Place the bottle in the bin so that the neck of the bottle
rests on the front lip of the bin.
1
ULIN_0089_A
