U-Line Echelon 2015R Installation Manual

U-line echelon 2015r: installation guide
Hide thumbs Also See for Echelon 2015R:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service & Parts Manual
™

Installation Guide

2015R — Refrigerator
www.U-LineService.com
Phone (414) 354-0300 • FAX (414) 354-7905
Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696
OnlineService@U-Line.com
©2005 U-Line Corporation
02/2005

Advertisement

Table of Contents
loading

Related Manuals for U-Line Echelon 2015R

Summary of Contents for U-Line Echelon 2015R

  • Page 1: Installation Guide

    ™ Installation Guide 2015R — Refrigerator www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2005 U-Line Corporation 02/2005...

  • Page 2: Table Of Contents

    Service Information ......16 www.U-LineService.com 2015R — Refrigerator 1 Follow Safety Precautions IMPORTANT PLEASE READ all instructions completely before attempting to install or operate the unit.

  • Page 3: Inspect And Plan

    2015R — Refrigerator 2 Inspect and Plan You have received a carton containing your 2015R Refrigerator with a package inside containing a User Manual and a Product Registration Card. Complete and mail the Product Registration Card or register online at www.U-LineService.com.

  • Page 4: Exterior Cleaning

    2015R — Refrigerator 3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for electrical connection in the rear.

  • Page 5: Product Dimensions

    Figure 3 02/2005 2015R — Refrigerator Reversing the Door (Black and White Units Only) All U-Line units (except Stainless Steel models) may be left- or right-hand opening. The door opening is easily reversed by moving the hinge hardware to the opposite side.

  • Page 6: Other Site Requirements

    Step 2 in old hinge holes (3 each, top and bottom). Figure 10 www.U-LineService.com 2015R — Refrigerator Other Site Requirements Power Supply The unit requires a grounded and polarized 115 VAC, 60 Hz, 15A circuit (normal household current). See Electrical Specifications on Page 13.

  • Page 7: Side-By-Side Installation Instructions

    Side-By-Side Installation Instructions For a complete refreshment center, install your 2015R Refrigerator beside a U-Line Ice Maker, Combo, or Wine Captain Model (see Figure 11 for typical cut-out). Note that each Side-By-Side Installation will be different. • Cut-out width for a side-by-side installation is the total of the widths listed under Cut-Out Dimensions in each unit’s Installation Guide.

  • Page 8: Full Overlay Door Panel

    A full overlay door panel completely covers the doorframe and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit (P/N U-OL2015B — Black or P/N U-OL2015W — White). Appropriate hardware, Modified Handle, Replacement Hinges and a copy of these instructions will be included in the kit.
  • Page 9 5/16" diameter x 1/2" deep, from the routed surface CAUTION Be careful not to drill too deep! Drilling holes too deep may destroy your door panel. 02/2005 2015R — Refrigerator 4. Drill hole for upper door hinge (top of panel) (see Figure 16, Top View). 13/32" 0.177" diameter 3/8"...
  • Page 10 Wood Panel Side of Wood Panel 5/16" Bottom Figure 20 www.U-LineService.com 2015R — Refrigerator #6 X 5/8" 1" ± 1/32" Flat Head Screw Two Required Top Pivot Figure 21 Plate 4. Attach the door panel to the overlay panel using #10 x 5/8"...
  • Page 11 Hinge (using the 7/64" hex key or Phillips screwdriver) and install the hinge onto the unit. 02/2005 2015R — Refrigerator 4. Replace the door closure assembly onto the bottom pivot post (see Figure 25). Be sure that bosses on closers align with holes in hinge and hinge plate.

  • Page 12: Checking Door Alignment

    2. With door upside-down, Figure 27 loosen but do not remove the two screws on the door’s bottom hinge plate. www.U-LineService.com 2015R — Refrigerator Slotted Mounting Holes Raise Outside Door Edge Figure 28 3.

  • Page 13: Electrical Specifications

    Level should be placed along top edge and side edge as shown (see Figure 31). 2. If the refrigerator is not level, adjust the feet on the corners of the unit as necessary (see Figure 32). 23-1/4" Figure 32 3.

  • Page 14: Installation Of The 2015R

    Make any necessary adjustments. The unit’s top surface should be approximately 1/8" below the countertop. Relocating the Shelves Both the glass shelves in the refrigerator and the inner door shelves can be moved to accommodate your bottles, cans and containers. Glass Shelves 1.

  • Page 15: Initial Start-Up

    The unit is shipped with the control preset. No adjustments should be necessary at this time. For information about Adjusting the Temperature Control, see the User Manual. 02/2005 2015R — Refrigerator Start-Up Troubleshooting Problem Unit does not appear to turn on when switch is set to ON.

  • Page 16: Service Information

    For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo ®...
