O W N E R ' S M A N U A L
2024 VOYAGER

Advertisement

Table of Contents
loading

Related Manuals for Chrysler VOYAGER 2024

Summary of Contents for Chrysler VOYAGER 2024

  • Page 1 O W N E R ’ S M A N U A L 2024 VOYAGER...
  • Page 2 24 HOURS, 7 DAYS A WEEK AT YOUR SERVICE. manual may also include a description of features and equipment that are CALL 1-800-521-2779 OR VISIT CHRYSLER.RSAHELP .COM (USA) no longer available or were not ordered on this vehicle. Please disregard CALL 1-800-363-4869 OR VISIT FCA.ROADSIDEAID.COM (CANADA)

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ................6 GETTING TO KNOW YOUR VEHICLE .
  • Page 4 INTRODUCTION Child Protection Door Lock System — Rear Doors . 22 Lane Change Assist — If Equipped ..39 Battery Protection ....39 STEERING WHEEL .
  • Page 5 GETTING TO KNOW YOUR If Engine Fails To Start ....74 Enabling And Disabling ParkSense ..87 Cold Weather Operation Service The ParkSense Rear Park Assist INSTRUMENT PANEL (Below –22°F Or −30°C) .
  • Page 6 RADIO OPERATION AND MOBILE PHONES ..116 VEHICLE MAINTENANCE ....188 IN CASE OF EMERGENCY Regulatory And Safety Information ..116 Engine Oil .
  • Page 7 INTERIORS ..... . . 222 CUSTOMER ASSISTANCE Seats And Fabric Parts ....222 SUGGESTIONS FOR OBTAINING SERVICE FOR Plastic And Coated Parts .

  • Page 8: Introduction

    FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Chrysler vehicle best, have factory-trained technicians and genuine Mopar® parts, and care about your satisfaction.

  • Page 9: Symbols Key

    INTRODUCTION SYMBOLS KEY VEHICLE MODIFICATIONS/ALTERATIONS WARNING! WARNING! These statements apply to operating pro- cedures that could result in a collision, Any modifications or alterations to this vehicle could seriously affect its roadworthi- bodily injury and/or death. ness and safety and may lead to a collision resulting in serious injury or death. CAUTION! These statements apply to procedures that could result in damage to your...
  • Page 10 INTRODUCTION Red Warning Lights Red Warning Lights Brake Warning Light Liftgate Open Warning Light page 65 page 66 Oil Temperature Warning Light Door Open Warning Light page 65 page 66 Electric Power Steering (EPS) Fault Warning Light Oil Pressure Warning Light page 66 page 66 Electronic Throttle Control (ETC) Warning Light...
  • Page 11 INTRODUCTION Yellow Warning Lights Yellow Warning Lights Anti-Lock Brake System (ABS) Warning Light Low Fuel Warning Light page 67 page 68 Electric Park Brake Warning Light Low Washer Fluid Warning Light page 67 page 68 Service Automatic Emergency Braking (AEB) or Pedestrian Emer- Electronic Stability Control (ESC) Active Warning Light gency Braking (PEB) Warning Light page 67...
  • Page 12 INTRODUCTION White Indicator Lights Yellow Indicator Lights Cruise Control Ready Indicator Light Automatic Emergency Braking (AEB) or Pedestrian Emergency Brak- page 70 ing (PEB) OFF Indicator Light page 69 Set Speed Display Indicator Light Green Indicator Lights page 70 Cruise Control Set Indicator Light page 69 Blue Indicator Lights High Beam Indicator Light...

  • Page 13: Getting To Know Your Vehicle

    GETTING TO KNOW YOUR VEHICLE To Lock/Unlock The Doors And Liftgate • KEYS The key fob LED light brightness is designed for indoor light viewing, so the LED light may not be Push and release the unlock button on the key fob once visible in direct sunlight page 231.
  • Page 14 GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! • The doors have to be open and then closed in order • The integrated key fob contains a coin cell battery. for the vehicle to detect a key fob. The Key Left Do not ingest the battery;...

  • Page 15: Sentry Key

    GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH After placing the ignition in the ON/RUN position, the WARNING! Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the bulb • Always remove the key fobs from the vehicle and KEYLESS ENTER ‘N GO™...

  • Page 16: Remote Start - If Equipped

    GETTING TO KNOW YOUR VEHICLE The push button ignition can be placed in the following CAUTION! modes: An unlocked car is an invitation for theives. Always • remove the key fobs from the vehicle and lock all The engine is stopped doors when leaving the vehicle unattended.

  • Page 17: How To Use Remote Start

    GETTING TO KNOW YOUR VEHICLE • The ignition must be placed in the ON/RUN position TO EXIT REMOTE START MODE WARNING! before the Remote Start sequence can be repeated To drive the vehicle after starting the Remote Start sys- for a third cycle. •...

  • Page 18: Remote Start Front Defrost Activation

    GETTING TO KNOW YOUR VEHICLE Manual Temperature Control (MTC) — If Equipped REMOTE START FRONT DEFROST REMOTE START ABORT MESSAGE • In ambient temperatures of 40°F (4.5°C) or below, ACTIVATION — IF EQUIPPED One of the following messages will display in the instru- the climate settings will default to maximum heat, ment cluster display if the vehicle fails to remote start When Remote Start is active, and the outside ambient...

  • Page 19: To Arm The System

    GETTING TO KNOW YOUR VEHICLE NOTE: TO ARM THE SYSTEM SECURITY SYSTEM MANUAL OVERRIDE • Follow these steps to arm the Vehicle Security system: The driver's door key cylinder and the liftgate button on the key fob cannot arm or disarm the Vehicle 1.

  • Page 20: Power Door Locks - If Equipped

    GETTING TO KNOW YOUR VEHICLE POWER DOOR LOCKS — WARNING! IF EQUIPPED • For personal security and safety in the event of a A power door lock switch is on each front door trim collision, lock the vehicle doors before you drive as panel.

  • Page 21: Keyless Enter 'N Go™ - Passive Entry

    GETTING TO KNOW YOUR VEHICLE Frequency Operated Button Integrated Key • KEYLESS ENTER ‘N GO™ — The sliding side doors can be unlocked from the (FOBIK-Safe) outside using the Passive Entry system. PASSIVE ENTRY To Unlock From The Driver Or Passenger Side: To minimize the possibility of unintentionally locking a The Passive Entry system is an enhancement to the key fob inside your vehicle, the Passive Entry system is...

  • Page 22: Automatic Unlock Doors On Exit - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: To Lock The Vehicle’s Doors And Liftgate AUTOMATIC UNLOCK DOORS ON With one of the vehicle’s key fobs within 5 ft (1.5 m) of EXIT — IF EQUIPPED • After pushing the door handle lock button, you must the driver or passenger front door handle, push the wait two seconds before you can lock or unlock the door handle lock button to lock all four doors and the...

  • Page 23: Power Sliding Side Door - If Equipped

    GETTING TO KNOW YOUR VEHICLE POWER SLIDING SIDE DOOR — IF EQUIPPED The power sliding door may be power opened or closed in several ways: • Key fob • Inside or outside handles • Buttons located: ○ In the overhead console ○...

  • Page 24: Child Protection Door Lock System - Rear Doors

    GETTING TO KNOW YOUR VEHICLE NOTE: • CHILD PROTECTION DOOR LOCK The inside door handle will not open the sliding door when the Child Protection Door Lock is engaged. SYSTEM — REAR DOORS • If anything obstructs the power sliding side door •...

  • Page 25: Steering Wheel

    GETTING TO KNOW YOUR VEHICLE STEERING WHEEL WARNING! WARNING! • Do not adjust the steering column while driving. Persons who are unable to feel pain to the skin TILT/TELESCOPING STEERING Adjusting the steering column while driving or driving because of advanced age, chronic illness, diabe- COLUMN with the steering column unlocked, could cause the tes, spinal cord injury, medication, alcohol use,...

  • Page 26: Manual Adjustment (Front Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE Manual Seat Height Adjustment — MANUAL ADJUSTMENT (FRONT If Equipped SEATS) — IF EQUIPPED The seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pump WARNING! the lever upward to raise the seat height or pump the lever downward to lower the seat height.

  • Page 27: Manual Adjustment (Rear Seats)

    GETTING TO KNOW YOUR VEHICLE MANUAL ADJUSTMENT (REAR SEATS) While sitting in the seat, pull up on the handle and slide To recline, lean forward slightly, lift the lever, and push the seat forward or rearward. Release the bar once you back to the desired position and release the lever.
  • Page 28 GETTING TO KNOW YOUR VEHICLE Easy Entry Easy Tilt Seat — With Or Without Child Seat Installed The second row seats can be tilted forward for easy entry into the third row with or without a child seat installed. 1. Located in the seatback of the second row seat is a lever (or handle for Stow ‘n Go seats) that provides easier access to the third row by tilting the seat forward.
  • Page 29 GETTING TO KNOW YOUR VEHICLE Easy Entry — With The Seat Folded Flat The seats can be folded and tilted for more accessibility for passengers to enter and exit the third row. 1. Without a child seat installed, you can fold the seat by pulling the recliner handle on the bottom part of the seat.
  • Page 30 GETTING TO KNOW YOUR VEHICLE 1. Lower the center head restraint down to the seat- 2. Pulling strap “2” releases the seatback to return to back by pushing the button on the guide and push- its full upright position. ing the head restraint down. 2.
  • Page 31 GETTING TO KNOW YOUR VEHICLE Stow 'n Go Seating 2. Pull the latch located near the second row seat to 4. Remove the plastic storage bin from the storage open the floor panel. area, and store in a safe location. On vehicles equipped with Stow 'n Go seating, the sec- 5.
  • Page 32 GETTING TO KNOW YOUR VEHICLE TO UNSTOW SECOND ROW SEATS 7. Close the floor by pulling the floor panel backwards WARNING! by the bottom corner edge of the panel. To unstow the seat from the floor, move the front seat In a collision, serious injury could result if the seat all the way forward using the manual seat adjustment storage bin covers are not properly latched:...
  • Page 33 GETTING TO KNOW YOUR VEHICLE 2. Pull the latch located near the second row seat to 4. Pull the strap located on the seat and pull the seat open the floor panel. out of the storage area. Push the seat rearward making sure that it locks into the floor.

  • Page 34: Power Adjustment (Front Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE Adjusting The Seat Up Or Down WARNING! WARNING! The height of the seats can be adjusted up or down. • • In a collision, you or others in your vehicle could be Adjusting a seat while driving may be dangerous. Pull upward or push downward on the rear of seat injured if seats are not properly latched to their Moving a seat while driving could result in loss of...

  • Page 35: Heated Seats

    GETTING TO KNOW YOUR VEHICLE HEATED SEATS CAUTION! WARNING! Front Heated Seats — If Equipped • Do not place any article under a power seat or Persons who are unable to feel pain to the skin impede its ability to move as it may cause damage to because of advanced age, chronic illness, diabe- The front heated seats control buttons are the seat controls.
  • Page 36 GETTING TO KNOW YOUR VEHICLE WARNING! • Head restraints should never be adjusted while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

  • Page 37: Uconnect Voice Recognition - If Equipped

    GETTING TO KNOW YOUR VEHICLE Head Restraints — Third Row BASIC VOICE COMMANDS The outboard head restraints can be manually folded The following basic Voice Commands can be given at forward for improved rearward visibility. Pull the release any point while using your Uconnect system. strap to fold them forward.

  • Page 38: Additional Information

    GETTING TO KNOW YOUR VEHICLE • A passenger can press the VR button shortcut on For Uconnect system support, call 1-877-855-8400 ILLUMINATED VANITY MIRRORS — the radio status bar to also issue a command. (24 hours a day 7 days a week) or visit IF EQUIPPED DriveUconnect.com (US) or DriveUconnect.ca (Canada).

  • Page 39: Conversation Mirror

    GETTING TO KNOW YOUR VEHICLE CONVERSATION MIRROR OUTSIDE MIRRORS FOLDING FEATURE Located in the overhead console there is a conversation mirror to view all the passengers in the vehicle. Push All outside mirrors are hinged and may be moved either the panel to release the drop down mirror.

  • Page 40: Headlight Switch

    GETTING TO KNOW YOUR VEHICLE NOTE: HEADLIGHT SWITCH For vehicles sold in Canada, rotate the headlight switch The headlight switch is located on the left side of the clockwise from the parking light and instrument panel instrument panel. The switch controls the operation of light position to the first detent to turn on the head- the headlights, parking lights, instrument panel lights, lights also.

  • Page 41: High/Low Beam Switch

    GETTING TO KNOW YOUR VEHICLE Turn Signal Warning HIGH/LOW BEAM SWITCH To activate the delay feature, place the ignition in the OFF position while the headlights are still on. The If the vehicle electronics sense that the vehicle has Push the multifunction lever toward the instrument 90 second delay interval begins when headlight switch traveled for about 1 mile (1.6 km) with a turn signal on, panel to switch the headlights to high beams.

  • Page 42: Interior Lights

    GETTING TO KNOW YOUR VEHICLE Rear Courtesy/Reading Lights — INTERIOR LIGHTS If Equipped INTERIOR COURTESY LIGHTS Located above the rear passengers are courtesy/ reading lights. The lights turn on when a front door, a The courtesy light switches are used to turn the cour- sliding door or the liftgate is opened.

  • Page 43: Windshield Wiper & Washers

    GETTING TO KNOW YOUR VEHICLE Intermittent Wipers At the top detent of the instrument panel dimmer, all the interior lights will illuminate. At the bottom most Use the intermittent wiper when weather conditions setting (extreme bottom) interior lights are turned off make a single wiping cycle with a variable pause (dome off), and the cluster, radio and instrument light- between cycles desirable.

  • Page 44: Rain Sensing Wipers - If Equipped

    GETTING TO KNOW YOUR VEHICLE • Neutral Wipe Inhibit — The Rain Sensing feature will RAIN SENSING WIPERS — CLIMATE CONTROLS not operate when the ignition is ON, when the trans- IF EQUIPPED mission gear selector is in the NEUTRAL position MANUAL CLIMATE CONTROL and the vehicle speed is less than 3 mph (5 km/h), This feature senses rain or snowfall on the windshield...
  • Page 45 GETTING TO KNOW YOUR VEHICLE MAX A/C Button Recirculation Button cause the Automatic Temperature Control (ATC) to switch into manual mode. If the Front Defrost mode is Press and release the MAX A/C button to Press and release this button to change the turned off the climate system will return the previous change the current setting.
  • Page 46 GETTING TO KNOW YOUR VEHICLE Front Temperature Control Blower Control Bi-Level Mode These buttons provide the driver and passenger with Blower Control is used to regulate the Air comes from the instrument panel outlets independent temperature control. amount of air forced through the Climate and floor outlets.
  • Page 47 GETTING TO KNOW YOUR VEHICLE Controlling The Rear Climate Controls REAR TEMPERATURE CONTROL PANEL MODE From The Front MTC Display/ These buttons provide the rear passengers with inde- Press this button on the touchscreen to Touchscreen pendent temperature control. change the air distribution mode to Panel Push the up arrow button on the touch- Mode.

  • Page 48: Climate Voice Commands

    GETTING TO KNOW YOUR VEHICLE Rear Manual Temperature Control (MTC) REAR TEMPERATURE CONTROL BI-LEVEL MODE The rear Manual Temperature Control (MTC) system has Push the up arrow button to raise the tem- Air comes from both the headliner outlets floor air outlets at the rear right side of the third row perature.

  • Page 49: Operating Tips

    GETTING TO KNOW YOUR VEHICLE Cabin Air Filter OPERATING TIPS WEATHER CONTROL SETTINGS Refer to the chart at the end of this section for sug- The Climate Control system filters out dust and pollen Cold Weather Set the mode control to gested control settings for various weather conditions.
  • Page 50 GETTING TO KNOW YOUR VEHICLE Front Door Storage Instrument Panel Drawer Both interior front door panels have multiple pockets for There is a storage drawer located in the lower center of storage. the instrument panel. It can be released by pushing the access button above it.
  • Page 51 GETTING TO KNOW YOUR VEHICLE 1. To access the storage bins with front seats in the WARNING! WARNING! rearward position, place the lock rod in the unlocked position so the load floor can fold upwards towards • In a collision, serious injury could result if the seat In a collision, serious injury could result if the seat the seatback.

  • Page 52: Usb/Aux Control

    GETTING TO KNOW YOUR VEHICLE SEAT STORAGE BIN COVER EMERGENCY NOTE: There are multiple USB “Charge Only” ports in this vehicle. RELEASE LEVER Two devices can be plugged in at the same time, and • both ports will provide charging capabilities. Only one On the back of the front row seats (if equipped).

  • Page 53: Power Outlets

    GETTING TO KNOW YOUR VEHICLE POWER OUTLETS Your vehicle is equipped with 12 Volt (15 Amp) power outlets that can be used to power cellular phones, small electronics and other low powered electrical accessories. The power outlets can be labeled with either a “key”...

  • Page 54: Windows

    GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! The front power outlet can be changed to battery pow- ered at all times by switching the power outlet fuse in • Many accessories that can be plugged in draw the Power Distribution Center panel from fuse location power from the vehicle's battery, even when not in F95A to F95B.

  • Page 55: Automatic Window Features

    GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: WARNING! Power Window controls will also remain active for up to The sliding door windows do not fully open, stopping 10 minutes after the ignition has been placed in the several inches above the window sill. There is no anti-pinch protection when the window is OFF position, depending upon the accessory delay set- almost closed.

  • Page 56: Hood

    GETTING TO KNOW YOUR VEHICLE HOOD WARNING! Be sure the hood is fully latched before driving your OPENING vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. The hood release lever (to open the primary latch) and Failure to follow this warning could result in serious safety latch (to open the secondary latch) must be injury or death.

  • Page 57: To Lock/Close The Liftgate

    GETTING TO KNOW YOUR VEHICLE POWER LIFTGATE — IF EQUIPPED The key fob and the overhead console button will oper- ate the liftgate when the liftgate is locked. The outside The power liftgate may be opened or closed in several handle requires the liftgate to be unlocked.

  • Page 58: Cargo Area Features

    GETTING TO KNOW YOUR VEHICLE NOTE: CARGO AREA FEATURES If the power liftgate will not fully open or latch close, Cargo Area Storage check the latch for damage or obstacles that may be preventing the closing operation. If the problem per- When the third row seats are not in the stowed position, sists, proceed as follows: there is a large area for cargo storage.

  • Page 59: Getting To Know Your Instrument Panel

    GETTING TO KNOW YOUR INSTRUMENT PANEL BASE INSTRUMENT CLUSTER...

  • Page 60: Base Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL Use this QR code to access your digital WARNING! experience. A hot engine cooling system is dangerous. You or oth- ers could be badly burned by steam or boiling cool- ant. You may want to call an authorized dealer for Scan me service if your vehicle overheats page 186.

  • Page 61: Premium Instrument Cluster

    GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...

  • Page 62: Premium Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER trols allow you to scroll through and enter the main CAUTION! menus and submenus. You can access the specific DESCRIPTIONS information you want and make selections and Driving with a hot engine cooling system could dam- adjustments.

  • Page 63: Oil Life Reset

    GETTING TO KNOW YOUR INSTRUMENT PANEL OK Button Oil Life Reset • Push the OK button to access/select the informa- 1. Without pressing the brake pedal, push the ENGINE tion screens or submenu screens of a Main Menu START/STOP button and place the ignition in the item.

  • Page 64: Instrument Cluster Display Menu Items

    GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Economy INSTRUMENT CLUSTER DISPLAY Tire PSI is an information only function and cannot be reset page 127. Push and release the up or down MENU ITEMS arrow button Coolant Temp until the Fuel Economy Menu item is highlighted in the The instrument cluster display can be used to view the Displays the actual coolant temperature.
  • Page 65 GETTING TO KNOW YOUR INSTRUMENT PANEL Audio PREMIUM INSTRUMENT CLUSTER DISPLAY Upper Left or Upper Right SCREEN SETUP OPTIONS Push and release the up or down arrow button None Compass Outside Temp until the Audio Menu displays in the instrument cluster (If Equipped) display.

  • Page 66: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL • BATTERY SAVER ON/BATTERY The following are electrical loads that may be switched The battery was used for an extended period with off (if equipped), and vehicle functions which can be the engine not running to supply radio, lights, char- SAVER MODE MESSAGE —...

  • Page 67: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL Brake Warning Light WARNING LIGHTS AND MESSAGES WARNING! This warning light monitors various brake The warning/indicator lights will illuminate in the instru- Driving a vehicle with the red brake light on is danger- functions, including brake fluid level and ment panel together with a dedicated message and/or ous.
  • Page 68 GETTING TO KNOW YOUR INSTRUMENT PANEL Electric Power Steering (EPS) Fault Liftgate Open Warning Light If the light continues to flash when the vehicle is run- Warning Light ning, immediate service is required and you may experi- This warning light will illuminate when the ence reduced performance, an elevated/rough idle, or liftgate is open.

  • Page 69: Yellow Warning Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Seat Belt Reminder Warning Light Vehicle Security Warning Light — Electronic Stability Control (ESC) Active If Equipped Warning Light — If Equipped This warning light indicates when the driver or passenger seat belt is unbuckled. When This warning light will flash at a fast rate for This warning light will indicate when the ESC the ignition is first placed in the ON/RUN or...
  • Page 70 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Check/Malfunction Indicator Service Automatic Emergency Braking CAUTION! Warning Light (MIL) (AEB) or Pedestrian Emergency Braking (PEB) Warning Light — If Equipped Prolonged driving with the Malfunction Indicator Light The Engine Check/Malfunction Indicator (MIL) on could cause damage to the vehicle control Light (MIL) is a part of an Onboard Diagnos- This warning light will illuminate to indicate a system.

  • Page 71: Yellow Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS mal- YELLOW INDICATOR LIGHTS CAUTION! function indicator to indicate when the system is not Automatic Emergency Braking (AEB) or operating properly. The TPMS malfunction indicator is Do not continue driving with one or more flat tires as combined with the low tire pressure light.

  • Page 72: White Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Stop/Start Active Indicator Light — WHITE INDICATOR LIGHTS ONBOARD DIAGNOSTIC SYSTEM — OBD II If Equipped Cruise Control Ready Indicator Light Your vehicle is equipped with a sophisticated Onboard This indicator light will illuminate when the Diagnostic system called OBD II.

  • Page 73: Onboard Diagnostic System (Obd Ii) Cybersecurity

    GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND ONBOARD DIAGNOSTIC SYSTEM 3. Approximately 15 seconds later, one of two things will happen: (OBD II) CYBERSECURITY MAINTENANCE PROGRAMS ○ The MIL will flash for about 10 seconds and Your vehicle is required to have OBD II and a connection then return to being fully illuminated until you port to allow access to information related to the perfor- turn OFF the ignition or start the engine.

  • Page 74: Starting And Operating

    STARTING AND OPERATING NOTE: STARTING THE ENGINE NORMAL STARTING Only press one pedal at a time while driving the vehicle. To Turn On The Engine Using ENGINE START/STOP Torque performance of the vehicle could be reduced if Before starting your vehicle, adjust your seat, adjust Button both pedals are pressed at the same time.
  • Page 75 STARTING AND OPERATING ALWAYS DO A VISUAL CHECK that your vehicle is in • Driver’s door is ajar WARNING! • Driver’s seat belt is unbuckled PARK by looking for the “P” in the instrument cluster • It is dangerous to shift out of PARK or NEUTRAL if •...

  • Page 76: Extended Park Starting

    STARTING AND OPERATING IF ENGINE FAILS TO START CAUTION! WARNING! If the engine fails to start after you have followed the Damage to the transmission may occur if the follow- If vehicle speed is not below 1.2 mph (1.9 km/h) “Normal Starting”...

  • Page 77: Cold Weather Operation (Below -22°F Or −30°C)

    STARTING AND OPERATING NOTE: NOTE: COLD WEATHER OPERATION If the ignition switch is left in the ACC or RUN (engine (BELOW –22°F OR −30°C) • The engine block heater cord is a factory installed not running) position and the transmission is in PARK, option.

  • Page 78: Parking Brake

    STARTING AND OPERATING cluster and the LED indicator on the switch will illumi- CAUTION! nate. If your foot is on the brake pedal, you may notice a small amount of brake pedal movement while the Never use Non-Detergent Oil or Straight Mineral Oil in parking brake is engaging.
  • Page 79 STARTING AND OPERATING SafeHold WARNING! CAUTION! SafeHold is a safety feature of the Electric Park Brake • Never use the PARK position as a substitute for the If the Brake System Warning Light remains on with (EPB) system that will engage the parking brake auto- parking brake.

  • Page 80: Automatic Transmission

    STARTING AND OPERATING While in Brake Service Mode, the EPB Warning Light WARNING! WARNING! will flash continuously while the ignition switch is ON. • • The transmission may not engage PARK if the vehicle Do not leave the key fob in or near the vehicle (or When brake service work is complete, the following is moving.

  • Page 81: Brake/Transmission Shift Interlock (Btsi) System

    STARTING AND OPERATING NOTE: BRAKE/TRANSMISSION SHIFT In the event of a mismatch between the gear selector INTERLOCK (BTSI) SYSTEM position and the actual transmission gear (for example, This vehicle is equipped with a BTSI that holds the driver selects PARK while driving), the position indicator will blink continuously until the selector is returned to transmission gear selector in PARK unless the brakes the proper position, or the requested shift can be...
  • Page 82 STARTING AND OPERATING When exiting the vehicle, always: During cold temperatures, transmission operation may WARNING! be modified depending on engine and transmission • Apply the parking brake. temperature as well as vehicle speed. This feature • Do not coast in NEUTRAL and never turn off the igni- Shift the transmission into PARK.

  • Page 83: Active Noise Cancellation

    STARTING AND OPERATING ACTIVE NOISE CANCELLATION 3. Push and hold the ignition switch until the engine cates that the vehicle needs to be taken to an autho- turns off. rized dealer for service. It is likely the vehicle has lost power steering assistance page 66.

  • Page 84: Possible Reasons The Engine Does Not Autostop

    STARTING AND OPERATING • • The vehicle must be completely stopped. The transmission is not in a forward gear. TO MANUALLY TURN OFF THE • • The gear selector must be in a forward gear and the Hood is open. STOP/START SYSTEM brake pedal pressed.

  • Page 85: To Manually Turn On The Stop/Start System

    STARTING AND OPERATING TO MANUALLY TURN ON THE WARNING! STOP/START SYSTEM Leaving the Cruise Control system on when not in use After turning off the Stop/Start system, push the Stop/ is dangerous. You could accidentally set the system Start OFF switch again (located on the switch bank). or cause it to go faster than you want.

  • Page 86: Parksense Rear Park Assist - If Equipped

    STARTING AND OPERATING To Resume Speed Metric Speed (km/h) • Automatic brakes will not be available if there is a Pushing the SET (+), or SET (-) button once will faulted condition detected with the ParkSense Park • To resume a previously set speed, push the RES button Assist system or the Braking System Module.

  • Page 87: Parksense Sensors

    STARTING AND OPERATING ParkSense can be active only when the gear selector is PARKSENSE DISPLAY in REVERSE. If ParkSense is enabled at this gear selec- When the vehicle is in REVERSE and an obstacle has tor position, the system will remain active until the been detected, the warning display will turn on indicat- vehicle speed is increased to approximately 7 mph ing the system status, and remain on until the vehicle is...
  • Page 88 STARTING AND OPERATING Rear ParkSense Arcs 1 — Continuous Tone/Flashing Arc 4 — Slow Tone/Solid Arc 2 — Fast Tone/Flashing Arc 5 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 6 — Single 1/2 Second Tone/Solid Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle:...

  • Page 89: Enabling And Disabling Parksense

    STARTING AND OPERATING WARNING ALERTS Greater than Rear Distance 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches Less than 79 inches (inches/cm) (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) (65-30 cm) 12 inches (30 cm) (200 cm) Arcs —...

  • Page 90: Cleaning The Parksense System

    STARTING AND OPERATING • CLEANING THE PARKSENSE Clean the ParkSense sensors regularly, taking care WARNING! not to scratch or damage them. The sensors must SYSTEM not be covered with ice, snow, slush, mud, dirt, or • Before using ParkSense, it is strongly recom- debris.

  • Page 91: Parkview Rear Back Up Camera

    STARTING AND OPERATING PARKVIEW REAR BACK UP CAMERA REFUELING THE VEHICLE The following table shows the approximate distances for each zone: The ParkView Rear Back Up Camera allows you to see Zone Distance To The Rear Of The Vehicle There is no fuel filler cap. Two flapper doors inside the an on-screen image of the rear surroundings of your pipe seal the system.

  • Page 92: Vehicle Loading

    STARTING AND OPERATING VEHICLE LOADING Each axle GAWR is determined by the components in the system with the lowest load carrying capacity (axle, springs, tires or wheels). Heavier axles, or suspension CERTIFICATION LABEL components sometimes specified by purchasers for increased durability, do not necessarily increase the As required by National Highway Traffic Safety Adminis- vehicle's GVWR.

  • Page 93: Trailer Towing

    STARTING AND OPERATING Loading Gross Combination Weight Rating TRAILER TOWING (GCWR) The actual total weight and the weight of the front and In this section you will find safety tips and information rear of your vehicle at the ground can best be deter- The GCWR is the total permissible weight of your on limits to the type of towing you can reasonably do mined by weighing it when it is loaded and ready for...

  • Page 94: Trailer Hitch Classification

    STARTING AND OPERATING Trailer Sway Control (TSC) Weight-Distributing Hitch WARNING! The TSC can be a mechanical telescoping link that can A Weight-Distributing Hitch works by applying leverage • An improperly adjusted Weight-Distributing Hitch be installed between the hitch receiver and the trailer through spring (load) bars.

  • Page 95: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    STARTING AND OPERATING TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Trailer Tow Package GCWR Frontal Area Maximum GTW Maximum Trailer TW 8,600 lb (3,900 kg) 40 sq ft (3.72 sq m) 3,600 lb (1,632 kg) 360 lb (163 kg)
  • Page 96 STARTING AND OPERATING Max Cargo With Max Max Trailer TW, Max Number Of Persons / Weight Of Occupants Max Cargo No Trailer Trailer TW 360 lb Trailer (163 kg) 1,205 lb (546 kg) – 360 lb (163 kg) = 845 lb (383 kg) 2 People / 300 lb (136 kg) 1,205 lb (546 kg)

  • Page 97: Trailer And Tongue Weight

    STARTING AND OPERATING TRAILER AND TONGUE WEIGHT TOWING REQUIREMENTS WARNING! Never exceed the maximum tongue weight stamped on To promote proper break-in of your new vehicle drive- • When hauling cargo or towing a trailer, do not over- your fascia/bumper or trailer hitch. train components, the following guidelines are load your vehicle or trailer.
  • Page 98 STARTING AND OPERATING Towing Requirements — Tires The electrical connections are all complete to the WARNING! vehicle but you must mate the harness to a trailer con- • Do not attempt to tow a trailer while using a com- nector. Refer to the following illustrations. •...

  • Page 99: Towing Tips

    STARTING AND OPERATING TOWING TIPS Before towing, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission Select the DRIVE range when towing. The transmission controls include a drive strategy to avoid frequent shift- ing when towing.

  • Page 100: Driving Tips

    STARTING AND OPERATING Acceleration NOTE: Recreational Towing Front-Wheel Drive (FWD) Models • Rapid acceleration on snow covered, wet, or other slip- To avoid inadvertent Electric Park Brake (EPB) Recreational towing is allowed ONLY if the front wheels pery surfaces may cause the driving wheels to pull engagement, you must ensure that the Auto Park are OFF the ground.

  • Page 101: Driving Through Water

    STARTING AND OPERATING DRIVING THROUGH WATER WARNING! Driving through water more than a few inches/ • Failure to follow these warnings may result in inju- centimeters deep will require extra caution to ensure ries that are serious or fatal to you, your passen- safety and prevent damage to your vehicle.

  • Page 102: Multimedia

    MULTIMEDIA UCONNECT SYSTEMS UCONNECT SETTINGS The risk of unauthorized and unlawful access to your vehicle systems may still exist, even if the most recent version of vehicle software (such as Uconnect software) For detailed information about your Uconnect 5 With The Uconnect system uses a combination of buttons on is installed.

  • Page 103: Customer Programmable Features

    MULTIMEDIA NOTE: CUSTOMER PROGRAMMABLE FEATURES • Only one touchscreen area may be selected at a time. • Depending on the vehicle’s options, feature settings may vary. When making a selection, press the button on the touchscreen to enter the desired menu. Once in the desired menu, press and release the preferred setting option until a check mark appears next to the setting, showing that setting has been selected.
  • Page 104 MULTIMEDIA My Profile When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Language This setting will change the language of the Uconnect system and Instrument Cluster Display. The available languages are English, Français, Español, and Italiano.
  • Page 105 MULTIMEDIA Setting Name Description Wake Up Word This setting will allow you to turn the voice recognition “Wake Up” word on or off. Voice Barge-in This setting will allow you to turn the voice recognition barge-in feature on or off. Show Command List This setting will allow the Command List to be shown on or off.
  • Page 106 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Language This setting will change the language of the Uconnect system and Instrument Cluster Display. The available languages are English, Français, Español, and Italiano.
  • Page 107 MULTIMEDIA Safety & Driving Assistance After pressing the Safety & Driving Assistance button on the touchscreen, the following settings will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Forward Collision Warning Sensitivity — Located In This setting will change the distance at which the Forward Collision Warning (FCW) alert sounds.
  • Page 108 MULTIMEDIA Clock & Date After pressing the Clock & Date button on the touchscreen, the following settings will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Sync Time With GPS This setting will sync the time to the GPS receiver in the system. The system will control the time via the GPS location. Set Time This setting will allow you to manually set the time of your clock.
  • Page 109 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smart- phone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
  • Page 110 MULTIMEDIA Navigation — If Equipped When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can change which icons display on the map, how “time to arrival” is calculated, and route types. For more information on Navigation and settings, refer to your Uconnect Radio Instruction Manual.
  • Page 111 MULTIMEDIA Mirrors & Wipers When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Rain Sensing Auto Wipers This setting will turn the Rain Sensing Auto Wipers on or off.
  • Page 112 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following settings will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Auto Park Brake This setting will turn the Auto Park Brake on or off. Brake Service This setting will allow you to retract the brakes for servicing.
  • Page 113 MULTIMEDIA Setting Name Description This setting will chime an audible alert when the power liftgate is raising or lowering. Selectable options are “On” and Power Liftgate Alert “Off”. This setting will chime an audible alert when the sliding door reverses or sense an obstacle. Selectable options are “On” Sliding Door Alert and “Off”.
  • Page 114 MULTIMEDIA Key Off Options When the Key Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Key Off Power Delay...
  • Page 115 MULTIMEDIA Setting Name Description Surround Sound This setting will turn the Surround Sound system on or off. AUX Volume Offset This setting will tune the audio levels from a device connected through the AUX port. The available settings are “+” and “-”. Auto Play This setting will automatically begin playing audio from a connected device.
  • Page 116 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® satellite radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: •...
  • Page 117 MULTIMEDIA System Information When the System Information button is pressed on the touchscreen, the system displays the radio system information. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Version Information When this feature is selected, a Version Information screen will appear, displaying information about the version of your radio. License Information When this feature is selected, a License Information screen will appear, displaying the licensing information of your radio.

  • Page 118: Steering Wheel Audio Controls

    MULTIMEDIA STEERING WHEEL AUDIO CONTROLS RADIO OPERATION REGULATORY AND SAFETY INFORMATION Pushing the top of the switch will seek up for the next The remote sound system controls are located on the available station, and pushing the bottom of the switch US/CANADA rear surface of the steering wheel at the three and nine will seek down for the next available station.

  • Page 119: Safety

    SAFETY Anti-Lock Brake System (ABS) Warning SAFETY FEATURES WARNING! Light • The ABS contains sophisticated electronic equip- ANTI-LOCK BRAKE SYSTEM (ABS) The yellow ABS Warning Light will turn on when the igni- ment that may be susceptible to interference tion is placed in the ON/RUN mode and may stay on for caused by improperly installed or high output radio The ABS provides increased vehicle stability and brake as long as four seconds.

  • Page 120: Electronic Brake Control (Ebc) System

    SAFETY Brake Assist System (BAS) required. If the Brake System Warning Light does not WARNING! come on when the ignition is placed in the ON/RUN The BAS is designed to optimize the vehicle’s braking mode, have the light repaired as soon as possible. •...
  • Page 121 SAFETY Electronic Roll Mitigation (ERM) • Oversteer — when the vehicle is turning more than WARNING! appropriate for the steering wheel position. ERM anticipates the potential for wheel lift by monitor- • • Vehicle modifications, or failure to properly main- Understeer —...
  • Page 122 SAFETY NOTE: The ESC Activation/Malfunction Indicator Light starts to The following conditions must be met in order for HSA flash as soon as the tires lose traction and the ESC sys- to activate: When driving with snow chains, or when starting off in tem becomes active.

  • Page 123: Auxiliary Driving Systems

    SAFETY Towing With HSA Traction Control System (TCS) AUXILIARY DRIVING SYSTEMS HSA will also provide assistance to mitigate roll back The TCS monitors the amount of wheel spin of each of while towing a trailer. the driven wheels. If wheel spin is detected, the TCS BLIND SPOT MONITORING (BSM) —...
  • Page 124 SAFETY The BSM detection zone covers approximately one lane The BSM system can become blocked if snow, ice, mud, width on both sides of the vehicle 12 ft (3.7 m). The or other road contaminants accumulate on the rear zone length starts at the outside rearview mirror and fascia/bumper where the radar sensors are located.
  • Page 125 SAFETY Entering From The Rear The BSM system will not alert you of objects that are traveling in the opposite direction of the vehicle in adja- Vehicles that come up from behind your vehicle on cent lanes page 231. either side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
  • Page 126 SAFETY Rear Cross Path (RCP) NOTE: Blind Spot Alert Lights/Chime In a parking lot situation, oncoming vehicles can be When operating in Blind Spot Alert Lights/Chime mode, RCP is intended to aid the driver when backing out of blocked by vehicles parked on either side. If the sen- the BSM system will provide a visual alert in the appro- parking spaces where their vision of oncoming vehicles sors are blocked by other structures or vehicles, the...

  • Page 127: Forward Collision Warning (Fcw) With Mitigation - If Equipped

    SAFETY FORWARD COLLISION WARNING WARNING! (FCW) WITH MITIGATION — Forward Collision Warning (FCW) is not intended to IF EQUIPPED avoid a collision on its own, nor can FCW detect every type of potential collision. The driver has the respon- FCW with Mitigation provides the driver with audible sibility to avoid a collision by controlling the vehicle warnings, visual warnings (within the instrument cluster via braking and steering.
  • Page 128 SAFETY Pedestrian Emergency Braking (PEB) — • Changing the FCW status to the “Far” setting allows the The system will retain the last setting selected by system to warn the driver of a possible collision with the the driver after ignition shut down. If Equipped vehicle in front using audible/visual warning when the •...

  • Page 129: Tire Pressure Monitoring System (Tpms)

    SAFETY The PEB button is located in the Uconnect display in the The tire pressure will vary with temperature by approxi- decrease the tire pressure to approximately 24 psi Controls settings page 100. mately 1 psi (7 kPa) for every 12°F (6.5°C). This (165 kPa).
  • Page 130 SAFETY NOTE: Vehicles With Compact Spare — If Equipped CAUTION! It is particularly important for you to check the tire pres- 1. The compact spare tire does not have a Tire Pressure • After inspecting or adjusting the tire pressure sure in all of the tires on your vehicle monthly and to Monitoring System sensor.

  • Page 131: Occupant Restraint Systems

    SAFETY TIRE PRESSURE MONITORING SYSTEM LOW TPMS DEACTIVATION — IF EQUIPPED OCCUPANT RESTRAINT SYSTEMS PRESSURE WARNINGS The Tire Pressure Monitoring System (TPMS) can be Some of the most important safety features in your deactivated if replacing all four wheel and tire assem- The TPMS Warning Light will illuminate in the vehicle are the restraint systems: blies (road tires) with wheel and tire assemblies that do...

  • Page 132: Seat Belt Systems

    SAFETY BeltAlert Warning Sequence 4. Never allow children to slide the shoulder belt SEAT BELT SYSTEMS behind them or under their arm. The BeltAlert warning sequence is activated when the Buckle up even though you are an excellent driver, even vehicle is moving above a specified vehicle speed range 5.
  • Page 133 SAFETY NOTE: WARNING! WARNING! If BeltAlert has been deactivated and the driver or out- • • board front seat passenger (if equipped with outboard Do not allow people to ride in any area of your vehicle A seat belt that is buckled into the wrong buckle front passenger seat BeltAlert) is unbuckled the Seat that is not equipped with seats and seat belts.
  • Page 134 SAFETY Lap/Shoulder Belt Operating 3. When the seat belt is long enough to fit, insert the 5. Position the shoulder belt across the shoulder and Instructions latch plate into the buckle until you hear a “click.” chest with minimal, if any slack so that it is comfort- able and not resting on your neck.
  • Page 135 SAFETY Adjustable Upper Shoulder Belt 1. Remove the mini-latch plate and regular latch plate WARNING! Anchorage from its stowed position in the headliner slightly behind the second or third row seat. • Wearing your seat belt incorrectly could make your In the front and second row outboard seats the shoul- injuries in a collision much worse.
  • Page 136 SAFETY 3. Route the shoulder belt to the inside of the left head 5. Sit back in seat. Slide the regular latch plate up the 7. Position the lap belt so that it is snug and lies low restraint. webbing as far as necessary to allow the seat belt to across your hips, below your abdomen.
  • Page 137 SAFETY Seat Belt Pretensioner WARNING! WARNING! The front outboard seat belt system is equipped with • Using a Seat Belt Extender when not needed can • If the mini-latch plate and mini-buckle are not pretensioning devices that are designed to remove increase the risk of serious injury or death in a properly connected when the seat belt is used by slack from the seat belt in the event of a collision.
  • Page 138 SAFETY WARNING! • Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.

  • Page 139: Supplemental Restraint Systems (Srs)

    SAFETY Third Row Stow Clip — If Equipped SUPPLEMENTAL RESTRAINT WARNING! SYSTEMS (SRS) Your vehicle may be equipped with a stow clip on the • Failure to replace the seat belt assembly could lower trim behind the third row. This clip is used to hold increase the risk of injury in collisions.
  • Page 140 SAFETY Air Bag Warning Light Front Air Bags NOTE: If the speedometer, tachometer, or any engine related The Occupant Restraint Controller (ORC) This vehicle has front air bags and lap/shoulder belts gauges are not working, the Occupant Restraint Control- monitors the readiness of the electronic for both the driver and front passenger.
  • Page 141 SAFETY Front Air Bag Operation This vehicle may be equipped with a driver and/or front WARNING! passenger seat belt buckle switch that detects whether Front Air Bags are designed to provide additional pro- the driver or front passenger seat belt is buckled. The •...
  • Page 142 SAFETY Occupant Classification System (OCS) — Occupant Classification Module (OCM) And Sensor The OCS will NOT prevent deployment of the Passenger Front Passenger Seat Advanced Front Air Bag. The OCS may reduce the infla- The Occupant Classification Module (OCM) is located tion rate of the Passenger Advanced Front Air Bag if the underneath the front passenger seat.
  • Page 143 SAFETY Lighter Weight Passengers (Including Small Adults) • The OCS determines the front passenger’s most prob- Objects are lodged under the front passenger seat. able classification. The OCS estimates the seated • When a lighter weight passenger, including a small Objects are lodged between the front passenger weight on the front passenger seat and where that adult, occupies the front passenger seat, the OCS may...
  • Page 144 SAFETY WARNING! • Placing an object on the floor under the front pas- senger seat may prevent the OCS from working properly, which may result in serious injury or death in a collision. Do not place any objects on the floor under the front passenger seat. The Air Bag Warning Light in the instrument panel will turn on whenever the OCS is unable to classify the...
  • Page 145 SAFETY Supplemental Driver And Front • Do not add a secondary seat cover or mat. Passenger Knee Air Bags • At no time should any Supplemental Restraint Sys- tem (SRS) component or SRS related component or This vehicle is equipped with a Supplemental Driver fastener be modified or replaced with any part Knee Air Bag mounted in the instrument panel below except those which are approved by FCA US LLC.
  • Page 146 SAFETY Supplemental Side Air Bag Inflatable Curtains The SABICs may help reduce the risk of partial or com- The Side Air Bags will not deploy in all side collisions, (SABICs) plete ejection of vehicle occupants through side win- including some collisions at certain angles, or some dows in certain side impact events.
  • Page 147 SAFETY The SABICs may help reduce the risk of partial or com- If you do have a collision which deploys the air bags, WARNING! plete ejection of vehicle occupants through side win- any or all of the following may occur: dows in certain rollover or side impact events.
  • Page 148 SAFETY Maintaining Your Air Bag System NOTE: NOTE: After an accident, place the ignition in the STOP (OFF) • Air bag covers may not be obvious in the interior position to avoid draining the battery. Carefully check WARNING! trim, but they will open during air bag deployment. the vehicle for fuel leaks in the engine compartment •...

  • Page 149: Child Restraints

    SAFETY Event Data Recorder (EDR) NOTE: CHILD RESTRAINTS This vehicle is equipped with an event data recorder • Everyone in your vehicle needs to be buckled up at all For additional information, refer to (EDR). The main purpose of an EDR is to record, in cer- http://www.nhtsa.gov/parents-and-caregivers or times, including babies and children.
  • Page 150 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who have not reached Either an Infant Carrier or a Convertible Child Restraint, facing rear- Infants and Toddlers the height or weight limits of their child restraint ward in a rear seat of the vehicle...
  • Page 151 SAFETY Children Too Large For Booster Seats their rear-facing convertible child seat. Children should WARNING! remain in a forward-facing child seat with a harness for Children who are large enough to wear the shoulder as long as possible, up to the highest weight or height belt comfortably, and whose legs are long enough to Do not install a rear-facing car seat using a rear sup- allowed by the child seat.
  • Page 152 SAFETY Recommendations For Attaching Child Restraints Restraint Type Combined Weight of the Use Any Attachment Method Shown With An “X” Below Child + Child Restraint LATCH – Lower Anchors Seat Belt Only LATCH – Lower Anchors Seat Belt + Top Tether Only + Top Tether Anchor Anchor...
  • Page 153 SAFETY Seven Passenger Stow ‘n Go Seating LATCH Positions Eight Passenger LATCH Positions Lower Anchorage Symbol (Two Anchorages Per Lower Anchorage Symbol (Two Anchorages Per Seating Position) Seating Position) Top Tether Anchorage Symbol Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined weight of the What is the weight limit (child’s weight + weight of the child restraint) child and the child restraint is 65 lb (29.5 kg).
  • Page 154 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front passenger seat if the Can the rear-facing child restraint touch the back of the front pas- child restraint manufacturer also allows contact. See your child senger seat? restraint owner’s manual for more information.
  • Page 155 SAFETY Locating The LATCH Anchorages the center of the 60% seat for either the center or left outboard seating position. All tether anchorages are The lower anchorages are round bars that located on the back of the seat, near the floor. are found at the rear of the seat cushion where it meets the seatback, below the anchorage symbols on the seatback.
  • Page 156 SAFETY equipped with a tether strap. The tether strap will have WARNING! a hook at the end to attach to the top tether anchorage and a way to tighten the strap after it is attached to the • Use anchorages C and D to install a LATCH- anchorage.
  • Page 157 SAFETY the vehicle, you may wish to move it to its rear-most bing retract back into the retractor. If it is locked, the WARNING! position to make room for the child seat. You may ALR will make a clicking noise while the webbing is also move the front seat forward to allow more room pulled back into the retractor.
  • Page 158 SAFETY Seven Passenger Stow ‘n Go Seating Automatic Locking Eight Passenger Automatic Locking Retractor (ALR) Retractor (ALR) Locations Locations ALR — Switchable Automatic Locking Retractor ALR — Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Top Tether Anchorage Symbol Frequently Asked Questions What is the weight limit (child’s weight + weight of the child restraint) Always use the tether anchor when using the seat belt to install a for using the Tether Anchor with the seat belt to attach a forward-...
  • Page 159 SAFETY Installing A Child Restraint With A NOTE: bing to retract back into the retractor. As the web- Switchable Automatic Locking Retractor bing retracts, you will hear a clicking sound. This If the folding, non-adjustable head restraint interferes means the seat belt is now in the Automatic Locking with the installation of the child restraint, the head (ALR): mode.
  • Page 160 SAFETY Installing Child Restraints Using the Top Tether Anchorage WARNING! Do not attach a tether strap for a rear-facing car seat to any location in front of the car seat, including the seat frame or a tether anchorage. Only attach the tether strap of a rear-facing car seat to the tether anchorage that is approved for that seating position, located behind the top of the vehicle seat.
  • Page 161 SAFETY To connect the tether strap hook to the tether anchor- age for either seating position on the 60% third row seat: 1. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.

  • Page 162: Safety Tips

    SAFETY SAFETY CHECKS YOU SHOULD WARNING! MAKE INSIDE THE VEHICLE • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat Seat Belts belts. • Inspect the seat belt system periodically, checking for Be sure everyone in your vehicle is in a seat and cuts, frays, and loose parts.

  • Page 163: Periodic Safety Checks You Should Make Outside The Vehicle

    SAFETY Floor Mat Safety Information PERIODIC SAFETY CHECKS YOU WARNING! SHOULD MAKE OUTSIDE THE Always use floor mats designed to fit your vehicle. Only • ONLY use the driver’s side floor mat on the driver’s use a floor mat that does not interfere with the opera- VEHICLE side floor area.

  • Page 164: Exhaust Gas

    SAFETY EXHAUST GAS CARBON MONOXIDE WARNINGS WARNING! WARNING! Exhaust gases can injure or kill. They contain carbon Carbon monoxide (CO) in exhaust gases is deadly. monoxide (CO), which is colorless and odorless. Follow the precautions provided to prevent carbon Breathing it can make you unconscious and can monoxide poisoning: •...

  • Page 165: In Case Of Emergency

    IN CASE OF EMERGENCY NOTE: HAZARD WARNING FLASHERS SOS AND ASSIST MIRROR — IF EQUIPPED • Your vehicle may be transmitting data as authorized The Hazard Warning Flashers button is located in the If equipped, the rearview mirror contains an SOS and by the subscriber page 231.
  • Page 166 IN CASE OF EMERGENCY SOS Call System Limitations 4. You should be able to speak with the SOS operator WARNING! through the vehicle audio system to determine if Vehicles sold in Mexico DO NOT have SOS Call system additional assistance is needed. •...

  • Page 167: Jacking And Tire Changing - If Equipped

    IN CASE OF EMERGENCY • Even if the SOS Call system is fully functional, factors Never place anything on or near the vehicle’s LTE CAUTION! beyond FCA US LLC’s control may prevent or stop the (voice/data) or 4G (data) and GPS antennas. You SOS Call system operation.

  • Page 168: Preparations For Jacking

    IN CASE OF EMERGENCY EQUIPMENT REMOVAL WARNING! • 1. Remove the access panel to the jacking equipment. The jack is designed to be used as a tool for changing tires only. The jack should not be used to 2. Unlatch the Portable Air Compressor or Tire Service lift the vehicle for service purposes.

  • Page 169: Jacking Instructions

    IN CASE OF EMERGENCY 3. Remove Jack by turning the jack screw counterclock- WARNING! wise to collapse from storage area that is located behind the tire. • Do not let any passenger sit in the vehicle when it is on a jack. •...
  • Page 170 IN CASE OF EMERGENCY Extending The Wrench Jack Locations Front Jack Location 1. Loosen (but do not remove) the wheel lug nuts by WARNING! turning them to the left, one turn while the wheel is still on the ground. Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you.
  • Page 171 IN CASE OF EMERGENCY NOTE: 5. Remove the wheel lug nuts, for vehicles with wheel covers, remove the cover from the wheel by hand. Do not install the wheel cover on the inflatable Do not pry the wheel cover off. Then pull the wheel spare tire.

  • Page 172: Road Tire Installation

    IN CASE OF EMERGENCY 12. Place the deflated (flat) tire and foam tray cover ROAD TIRE INSTALLATION 4. Install the remaining lug nuts with the cone shaped assembly in the rear cargo area. Do not stow the end of the nut toward the wheel. Lightly tighten all deflated tire in the inflatable spare tire location.

  • Page 173: Portable Air Compressor - If Equipped

    IN CASE OF EMERGENCY Portable Air Compressor Usage With Inflatable Spare NOTE: PORTABLE AIR COMPRESSOR — Tire If the tire is overinflated, use the deflation button to IF EQUIPPED reduce the tire air pressure. 1. Remove the Portable Air Compressor from the stor- Your vehicle may be equipped with a Portable Air Com- age location.

  • Page 174: Return Inflatable Spare Tire

    IN CASE OF EMERGENCY Tire Service Kit Storage RETURN INFLATABLE SPARE TIRE Depending on the vehicle trim level, the Tire Service Kit To return Inflatable Spare Tire to its storage location. storage may vary. 1. Return the Jack. The Tire Service Kit is secured with a strap and is stored in the storage bin located behind the rear cargo 2.
  • Page 175 IN CASE OF EMERGENCY Tire Service Kit And Components And Operation Selecting Sealant Mode • • The Tire Service Kit Sealant is only intended to seal punctures less than 1/4 inch (6 mm) diameter in Push in the Mode Select Knob and turn the tread/contact surface of your vehicle’s tires.
  • Page 176 IN CASE OF EMERGENCY NOTE: 3. Place the transmission in PARK (P) and cycle the WARNING! ignition in the OFF position. Sealant may leak out through the puncture in the tire. • A loose Tire Service Kit thrown forward in a colli- 4.
  • Page 177 IN CASE OF EMERGENCY If the tire does not inflate to at least 26 psi (1.8 Bar) 3. Remove the cap from the valve stem, and then WARNING! pressure within 15 minutes: screw the fitting at the end of the Sealant Hose onto the valve stem.
  • Page 178 IN CASE OF EMERGENCY 2. Disconnect the Tire Service Kit from the valve stem, 3. Remove the bottle cover. reinstall the cap on the valve stem and unplug from 12 Volt outlet. 3. Place the Tire Service Kit in its proper storage area in the vehicle.

  • Page 179: Jump Starting

    IN CASE OF EMERGENCY WARNING! Do not attempt jump starting if the battery is frozen. It could rupture or explode and cause personal injury. CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur.

  • Page 180: Jump Starting Procedure

    IN CASE OF EMERGENCY WARNING! WARNING! CAUTION! Do not connect the jumper cable to the negative (-) Do not allow vehicles to touch each other as this Accessories plugged into the vehicle power outlets could establish a ground connection and personal post of the discharged battery.

  • Page 181: If Your Engine Overheats

    IN CASE OF EMERGENCY NOTE: WARNING! In certain cold conditions, ice may prevent the fuel door from opening. If this occurs, lightly push on the fuel You or others can be badly burned by hot engine cool- door to break the ice buildup. Then push on the rear ant (antifreeze) or steam from your radiator.

  • Page 182: Manual Park Release

    IN CASE OF EMERGENCY Follow These Steps To Activate The Manual Park To Reset The Manual Park Release: MANUAL PARK RELEASE Release: 1. Apply firm pressure to the brake pedal while seated 1. Apply firm pressure to the brake pedal while seated in the driver’s seat.

  • Page 183: Towing A Disabled Vehicle

    IN CASE OF EMERGENCY NOTE: CAUTION! Push the ESC OFF button to place the Electronic Stabil- ity Control (ESC) system in “Partial Off” mode, before • Racing the engine or spinning the wheels may lead rocking the vehicle page 119. Once the vehicle has to transmission overheating and failure.
  • Page 184 IN CASE OF EMERGENCY NOTE: Vehicle Recovery Tow Points CAUTION! Your vehicle is equipped with Vehicle Recovery Points • You must ensure that the Auto Park Brake feature is that can be used to recover a disabled vehicle, located Recovery feature: disabled before towing this vehicle (if rear wheels on the underbody of the vehicle.

  • Page 185: Enhanced Accident Response System (Ears)

    IN CASE OF EMERGENCY CAUTION! • Do not use sling-type equipment when towing. Vehicle damage may occur. • When securing the vehicle to a flatbed truck, do not attach to front or rear suspension components. Damage to your vehicle may result from improper towing.

  • Page 186: Servicing And Maintenance

    SERVICING AND MAINTENANCE Once A Month Or Before A Long Trip: SCHEDULED SERVICING An authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If • Check engine oil level. a scheduled oil change is performed by someone other Your vehicle is equipped with an automatic oil change •...
  • Page 187 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, boot seals, tie rod ends, and replace if necessary. Inspect the brake linings, parking brake function. Inspect front accessory drive tensioner, idler pulley, and replace if necessary. Additional Maintenance Replace engine air cleaner filter.

  • Page 188: Engine Compartment

    SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L ENGINE 1 — Engine Coolant Pressure Cap 5 — Windshield Washer Reservoir Cap 2 — Brake Fluid Reservoir Cap 6 — Engine Oil Fill 3 — Engine Air Cleaner Filter 7 — Engine Oil Dipstick 4 —...

  • Page 189: Checking Oil Level

    SERVICING AND MAINTENANCE CHECKING OIL LEVEL ADDING WASHER FLUID WARNING! To ensure proper engine lubrication, the engine oil must The fluid reservoir is located in the front of the engine • Battery fluid is a corrosive acid solution and can be maintained at the correct level.

  • Page 190: Pressure Washing

    SERVICING AND MAINTENANCE Materials Added To Engine Oil PRESSURE WASHING ENGINE OIL The manufacturer strongly recommends against the Cleaning the engine compartment with a high pressure Engine Oil Selection addition of any additives (other than leak detection washer is not recommended. dyes) to the engine oil.

  • Page 191: Accessory Drive Belt Inspection

    SERVICING AND MAINTENANCE When inspecting accessory drive belts, small cracks that Some conditions can be caused by a faulty component WARNING! run across the ribbed surface of a belt from rib to rib, are such as a belt pulley. Belt pulleys should be carefully considered normal.
  • Page 192 SERVICING AND MAINTENANCE The cabin air filter is located in the fresh air inlet behind 4. Open the glove compartment door as far as possible CAUTION! the glove compartment. Perform the following proce- to gain access to the cabin air filter compartment dure to replace the filter: cover.

  • Page 193: Body Lubrication

    SERVICING AND MAINTENANCE 10. Close the cabin air filter compartment cover, and WINDSHIELD WIPER BLADES reinsert the snaps into their slots. Push the snap Clean the rubber edges of the wiper blades and the lids until fully attached. windshield periodically with a sponge or soft cloth and 11.
  • Page 194 SERVICING AND MAINTENANCE Front Wiper Blade Removal/Installation 2. To disengage the wiper blade from the wiper arm, flip up the release tab on the wiper blade and while holding the wiper arm with one hand, slide the wiper CAUTION! blade down towards the base of the wiper arm. Do not allow the wiper arm to spring back against the glass without the wiper blade in place or the glass may be damaged.
  • Page 195 SERVICING AND MAINTENANCE Rear Wiper Blade Removal/Installation 1. Lift the rear wiper arm pivot cap away from the glass to allow the rear wiper blade to be raised off of the glass. NOTE: The rear wiper arm cannot be fully raised off the glass unless the wiper arm pivot cap is unsnapped first.

  • Page 196: Exhaust System

    SERVICING AND MAINTENANCE 3. Insert the wiper blade pivot pin into the opening on To minimize the possibility of catalytic converter CAUTION! the end of the wiper arm. Grab the bottom end of damage: the wiper arm with one hand, and press the wiper •...
  • Page 197 SERVICING AND MAINTENANCE Engine Coolant Checks Selection Of Coolant Adding Coolant Check the engine coolant (antifreeze) protection every For further information page 226. Your vehicle has been built with an improved engine 12 months (before the onset of freezing weather, where coolant (OAT coolant conforming to MS.90032) that NOTE: applicable).
  • Page 198 SERVICING AND MAINTENANCE Disposal Of Used Coolant • Some vehicles require special tools to add coolant If an examination of your engine compartment shows properly. Failure to fill these systems properly could no evidence of radiator or hose leaks, the vehicle may Used ethylene glycol-based coolant (antifreeze) is a lead to severe internal engine damage.

  • Page 199: Brake System

    SERVICING AND MAINTENANCE BRAKE SYSTEM AUTOMATIC TRANSMISSION WARNING! In order to ensure brake system performance, all brake Special Additives • Use only manufacturer recommended brake fluid system components should be inspected periodically. page 227. Using the wrong type of brake fluid For the proper maintenance intervals page 184.

  • Page 200: Fuses

    SERVICING AND MAINTENANCE FUSES CAUTION! General Information If a transmission fluid leak occurs, visit an authorized dealer immediately. Severe transmission damage may occur. An authorized dealer has the proper tools WARNING! to adjust the fluid level accurately. • When replacing a blown fuse, always use an appro- priate replacement fuse with the same amp rating Fluid And Filter Changes as the original fuse.
  • Page 201 SERVICING AND MAINTENANCE NOTE: CAUTION! The function and amperage of the following fuses are different, depending on vehicle trim level and content. When installing the Power Distribution Center cover, it is important to ensure the cover is properly posi- tioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center and possibly result in an electrical system failure.
  • Page 202 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Blade Fuse Description * If Equipped – – Not Used – 25 Amp Clear Ignition Coil/Fuel Injector – – Not Used – 25 Amp Clear Amplifier/Active Noise Control * – – Not Used – –...
  • Page 203 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Blade Fuse Description * If Equipped – – Not Used – 15 Amp Blue Media HUB / PWR Lumbar * – – Not Used 20 Amp Blue – 30 Amp Pink – Power Liftgate * 25 Amp Clear –...
  • Page 204 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Blade Fuse Description * If Equipped 40 Amp Green – ESP-ECU & Valves – 15 Amp Blue RF HUB/ KIN / ESL / DVD Front & Rear HVAC Control / OCM / ESL / –...
  • Page 205 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Blade Fuse Description * If Equipped RR Entertainment / Media Hub / USB (S) / Rain Sensor / Sunroof / RR View Mirror – 10 Amp Red / Overhead DVD Player / Int Monitoring Camera / Wireless Charging Pad –...

  • Page 206: Bulb Replacement

    SERVICING AND MAINTENANCE Cavity Cartridge Fuse Blade Fuse Description * If Equipped – 10 Amp Red Airbag – 15 Amp Blue Left HID Headlamp * 30 Amp Pink – Trailer Tow Electric Brake Mod * Headlamp Level / RR Camera / Blindspot F100 –...
  • Page 207 SERVICING AND MAINTENANCE Interior Bulbs Lamps Bulb Number Instrument Cluster Lamps Liftgate Lamp(s) Overhead Console Reading Lamps Removable Console Lamp – If Equipped Visor Vanity Lamps 6501966 Exterior Bulbs Lamps Bulb Number Reflector Low Beam — H11LL Halogen Head Lamp Reflector High Beam —...
  • Page 208 SERVICING AND MAINTENANCE Replacing Exterior Bulbs FRONT AND REAR SIDE MARKER LAMPS 3. Remove bulb from the front side marker lamp socket and replace with a new bulb. FRONT TURN SIGNAL LAMP See the following steps to replace: 4. Install front side marker lamp socket in lamp assem- 1.

  • Page 209: Tires

    SERVICING AND MAINTENANCE NOTE: TIRES • P (Passenger) — Metric tire sizing is based on US TIRE SAFETY INFORMATION design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- Tire safety information will cover aspects of the follow- tion.
  • Page 210 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
  • Page 211 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
  • Page 212 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: 1. Number of people that can be carried in the vehicle. NOTE: 2. Total weight your vehicle can carry. The proper cold tire inflation pressure is listed on the driver’s side B-pillar or the rear edge of the driver's side 3.
  • Page 213 SERVICING AND MAINTENANCE Steps For Determining Correct Load (6) If your vehicle will be towing a Limit— trailer, load from your trailer will be transferred to your vehicle. Consult (1) Locate the statement “The com- this manual to determine how this bined weight of occupants and cargo reduces the available cargo and lug- should never exceed XXX kg or...
  • Page 214 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.

  • Page 215: Tires - General Information

    SERVICING AND MAINTENANCE TIRES — GENERAL INFORMATION Both underinflation and overinflation affect the stability CAUTION! of the vehicle and can produce a feeling of sluggish Tire Pressure response or over responsiveness in the steering. After inspecting or adjusting the tire pressure, always reinstall the valve stem cap.
  • Page 216 SERVICING AND MAINTENANCE Tire Pressures For High Speed Operation Tire Spinning Tire Repair If your tire becomes damaged, it may be repaired if it The manufacturer advocates driving at safe speeds and When stuck in mud, sand, snow, or ice conditions, do meets the following criteria: within posted speed limits.
  • Page 217 SERVICING AND MAINTENANCE These indicators are molded into the bottom of the Keep dismounted tires in a cool, dry place with as little WARNING! tread grooves. They will appear as bands when the exposure to light as possible. Protect tires from contact tread depth becomes 1/16 of an inch (1.6 mm).

  • Page 218: Tire Types

    SERVICING AND MAINTENANCE Snow Tires Spare Tire Matching Original Equipped TIRE TYPES Tire And Wheel — If Equipped Some areas of the country require the use of All Season Tires — If Equipped snow tires during the Winter. Snow tires can Your vehicle may be equipped with a spare tire and be identified by a mountain/snowflake sym- All season tires provide traction for all seasons (Spring,...

  • Page 219: Wheel And Wheel Trim Care

    SERVICING AND MAINTENANCE WARNING! WARNING! WARNING! Compact and collapsible spares are for temporary Compact and collapsible spares are for temporary Limited use spares are for emergency use only. Instal- emergency use only. With these spares, do not drive emergency use only. With these spares, do not drive lation of this limited use spare tire affects vehicle more than 50 mph (80 km/h).

  • Page 220: Snow Traction Devices

    SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or Low Gloss CAUTION! CAUTION! Clear Coat Wheels Avoid products or automatic car washes that use Do not use scouring pads, steel wool, a bristle brush, CAUTION! acidic solutions or strong alkaline additives or harsh metal polishes or oven cleaner.

  • Page 221: Tire Rotation Recommendations

    SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION TIRE ROTATION WARNING! RECOMMENDATIONS UNIFORM TIRE QUALITY GRADES Using tires of different size and type (M+S, Snow) The tires on the front and rear of your vehicle operate between front and rear axles can cause unpredictable at different loads and perform different steering, driv- handling.

  • Page 222: Traction Grades

    SERVICING AND MAINTENANCE cantly from the norm due to variations TEMPERATURE GRADES WARNING! in driving habits, service practices, and The Temperature grades are A (the The temperature grade for this tire is differences in road characteristics and highest), B, and C, representing the established for a tire that is properly climate.

  • Page 223: Bodywork

    SERVICING AND MAINTENANCE BODYWORK BODY AND UNDERBODY CAUTION! MAINTENANCE • Do not use abrasive or strong cleaning materials PROTECTION FROM ATMOSPHERIC such as steel wool or scouring powder that will Cleaning Headlights AGENTS scratch metal and painted surfaces. Your vehicle is equipped with plastic headlights and fog •...

  • Page 224: Interiors

    SERVICING AND MAINTENANCE INTERIORS PLASTIC AND COATED PARTS liquid. Please do not use polishes, oils, cleaning fluids, solvents, detergents, or ammonia-based cleaners to Use Mopar® Total Clean to clean vinyl upholstery. clean your leather upholstery. SEATS AND FABRIC PARTS NOTE: CAUTION! Use Mopar®...

  • Page 225: Technical Specifications

    TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) In the event power assist is lost for any reason (i.e., repeated brake applications with the engine off) the brakes will still function. However, the effort required to The VIN is on the left front corner of the instrument brake the vehicle will be much greater.

  • Page 226: Fuel Requirements

    TECHNICAL SPECIFICATIONS After 25 miles (40 km) check the lug nut/bolt torque to 2 method. The use of higher octane premium gasoline DO NOT USE E-85 IN NON-FLEX be sure that all the lug nuts/bolts are properly is not required, as it will not provide any benefit over FUEL VEHICLES tightened.

  • Page 227: Methylcyclopentadienyl Manganese Tricarbonyl (Mmt) In Gasoline

    TECHNICAL SPECIFICATIONS NOTE: METHYLCYCLOPENTADIENYL usage of Top Tier Detergent gasoline is recommended. Visit www.toptiergas.com, at the link below, for a list of Intentional tampering with the emissions control system MANGANESE TRICARBONYL (MMT) TOP TIER Detergent Gasoline retailers. can result in civil penalties being assessed against you. IN GASOLINE Indiscriminate use of fuel system cleaning agents should be avoided.

  • Page 228: Fluid Capacities

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 3.6L Engine 19 gal 71 L Engine Oil With Filter 3.6L Engine 5 qt 4.7 L Cooling System* 3.6L Engine 15 qt 14.2 L * Includes heater and coolant reservoir filled to MAX level. ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part...

  • Page 229: Chassis Fluids And Lubricants

    TECHNICAL SPECIFICATIONS CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease cor- rosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (anti- freeze) or any “globally compatible”...

  • Page 230: Customer Assistance

    Available 24 hours, 7 days a week. FOR YOUR VEHICLE FCA US LLC and its authorized dealers are vitally inter- Call 1-800-521-2779 or visit chrysler.rsahelp.com(USA) ested in your satisfaction. We want you to be happy with Call 1-800-363-4869 or visit fca.roadsideaid.com our products and services.

  • Page 231: Fca Us Llc Customer Center

    P.O. Box 9145 Phone: (800) 247-9753 closest authorized Chrysler, Dodge, Jeep®, or Ram Medford, MA 02155 dealer. If you choose to go to another dealer, you will be CUSTOMER ASSISTANCE FOR THE Attention Claims Department responsible for the cost of the extra distance.

  • Page 232: Service Contract

    CUSTOMER ASSISTANCE SERVICE CONTRACT We appreciate that you have made a major investment MOPAR® PARTS when you purchased the vehicle. An authorized dealer You may have purchased a service contract for a has also made a major investment in facilities, tools, Mopar®...

  • Page 233: In Canada

    CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Change Of Ownership Or Address To contact NHTSA, you may call the Vehicle Safety Hotline toll free at To order the following manuals, you may use either the *If you have purchased this vehicle used or have 1-888-327-4236 (TTY: website or the phone numbers listed below.
  • Page 234 CUSTOMER ASSISTANCE Le présent appareil est conforme aux CNR d`Innova- tion, Science and Economic Development applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: 1. l'appareil ne doit pas produire de brouillage, et 2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est sus- ceptible d'en compromettre le fonctionnement.
  • Page 235 INDEX Air Pressure Tires .....213 About Your Brakes....223 Back Up Camera .
  • Page 236 INDEX Oil (Engine) ....186 Cooling System ....194 Radiator (Coolant Pressure) .
  • Page 237 INDEX Exhaust Gas Cautions ....162 Gasoline ....224 Heated Seats....33 Exhaust System .
  • Page 238 INDEX Key Fob Programming (Remote Keyless Entry) ..12 Passing ....37, 39 Automatic Dimming ....36 Keyless Enter 'n Go™...
  • Page 239 INDEX Oil Filter, Selection ....188 Oil Life Reset ....61 Radial Ply Tires .
  • Page 240 INDEX Reclining ....24 Steering Wheel Audio Controls ...116 Safety ....207, 213 Seatback Release .
  • Page 241 INDEX Transporting Pets ....160 Wind Buffeting ....53 Tread Wear Indicators .
  • Page 243 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Chrysler brand vehicle and to provide a convenient reference source for common questions.
  • Page 244 First Edition ©2023 FCA US LLC. All Rights Reserved. Tous droits réservés. Chrysler is a registered trademark of FCA US LLC or FCA Canada Inc., used under license. Chrysler est une marque déposée de FCA US LLC ou FCA Canada Inc., utilisée sous le permis. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Table of Contents
