Installation Guide
IGBT Module Replacement for D1h–D8h Drives
VLT® FC Series FC 102, FC 103, FC 202, and FC 302
1 Overview
1.1 Description
D1h–D8h drives have 3 IGBT modules. If the brake option is present, the drive also includes a brake IGBT module. This IGBT module
replacement kit contains all components required to install 1 replacement IGBT module or 1 brake IGBT module.
SPARE PARTS COMPATIBILITY
recommends replacement of all IGBT modules or all brake IGBT modules, when 1 or more modules fail.
-
For best results, replace modules with parts from the same lot number.
1.2 Kit Numbers
Use these instructions with the following kits.
Table 1: Numbers for IGBT Module Replacement Kits
Kit number
176F3362
176F3363
176F3364
176F3365
176F3366
176F3367
176F3422
176F3423
176F3424
176F3425
176F4242
1.3 Items Supplied
The following parts are contained in the kit.
•
1 IGBT module
•
Syringe of thermal grease
•
Hardware for busbar mounting
•
Fasteners
Danfoss A/S © 2023.10
N O T I C E
Kit description
IGBT dual module 300 A 1200 V T4/T5 drive
IGBT dual module 450 A 1200 V T2/T4/T5 drive
IGBT dual module 600 A 1200 V T2/T4/T5 drive
IGBT dual module 900 A 1200 V T2/T4/T5 drive
IGBT brake module 450 A 1700 V
IGBT brake module 650 A 1700 V
IGBT dual module 300 A 1700 V T7 drive
IGBT dual module 450 A 1700 V T7 drive
IGBT dual module 450 A 1700 V T7 drive PP2
IGBT dual module 650 A 1700 V T7 drive PP2
IGBT dual module 450 A 1200 V T4/T5 drive
AN341428219214en-000201 / 130R0383 | 1
