Model:
TA2R-2S
STANDARD FEATURES
DESIGN
• True's solid door reach-in's are designed with
enduring quality that protects your long term
investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly (CFC
free) 134A refrigerant.
• Extra large evaporator coil balanced with higher
horsepower compressor and large condenser
maintains 33°F to 38°F (.5°C to 3.3°C) cabinet
temperature for the best in food preservation.
• Sealed, cast iron, self-lubricating evaporator fan
motor(s) and larger fan blades give True reach-
in's a more effi cient low velocity, high volume
airfl ow design. This unique design ensures faster
temperature recovery and shorter run times in
the busiest of foodservice environments.
• Top mounted refrigeration system with
evaporator positioned out of food zone to
maximize capacity.
• Hot gas condensate for energy effi ciency.
• Glass condensate pan to prevent electrolysis.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors, front,
sides, back and bottom.
• Interior - NSF approved, white aluminum side
walls and back liner. 300 series stainless fl oor
with coved corners.
• Insulation - entire cabinet structure and solid
doors are foamed-in-place using high density,
CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail dipped
in rust inhibiting enamel paint for corrosion
protection inside and out.
• Frame rail fi tted with 4" (102 mm) diameter stem
castors - locks provided on front set.
PLAN VIEW
77"
(1956 mm)
3
1
/
"
16
(31 mm)
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
TA Series:
Reach-In Solid Door
Refrigerator
DOORS
• 300 series stainless steel exterior and liners.
Doors open within cabinet dimensions.
• Door locks standard.
• Lifetime guaranteed recessed door handles.
Each door fi tted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Positive seal self-closing doors with 120° stay
open feature. Lifetime guaranteed door hinges.
• Magnetic door gaskets of one piece construction,
removable without tools for ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated wire
shelves 23
Four (4) shelf supports included per shelf (fi eld
installed). Shelves adjustable on 6" (153 mm)
increments.
• Four (4) different interior kits available (see Kit
Options). Pilasters and tray slides require fi eld
installation.
LIGHTING
• Incandescent interior lighting - lights activated
by rocker switch mounted above doors, safety
shielded.
MODEL FEATURES
• Exterior digital temperature display, available
with either °F or °C.
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and ready
for fi nal connection to a 115/60/1 phase - 15 amp
dedicated outlet. Cord and plug set included.
78
(1986 mm)
4"
ELEVATION
(102 mm)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
TRUE FOOD SERVICE EQUIPMENT
1
3
/
" x 27
/
" (597 mm x 705 mm).
2
4
115/60/1
NEMA-5-15R
1"
(26 mm)
3
/
"
16
3
84
/
"
16
(2139 mm)
5"
(127 mm)
Model
KCL
TA2R-2S
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230-240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ 6" (153 mm) stainless steel legs.
❒ Stainless steel rail skirt for use with legs (fi eld
installed).
❒ Metal door handles (factory installed).
❒ Additional shelves.
❒ Electronic temperature control (factory
installed).
❒ Correctional facilities options.
❒ Curb mountable units.
❒ Remote cabinets (condensing unit supplied
by others; system comes standard with 404A
expansion valve and requires 404A refrigerant).
Consult factory technical service department for
BTU information.
KIT OPTIONS
Upcharge and lead times may apply.
❒ Kit #1: Nine (9) sets of #1 type tray slides and
pilasters (fi eld installed), bottom support of one
(1) 18"L x 26"D (458 mm x 661 mm) pan or two
(2) 14"L x 18"D (356 mm x 458 mm) pans.
❒ Kit #2: One (1) set half-section #2 steel rod tray
slides and pilasters (fi eld installed), rim support
of one (1) 18"L x 26"D (458 mm x 661 mm) pan.
❒ Kit #3: Six (6) sets of universal type tray slides
and pilasters (fi eld installed), bottom support
of one (1) 18"L x 26"D (458 mm x 661 mm) pan,
two (2) 14"L x 18"D (356 mm x 458 mm) pans or
two (2) 12"L x 20"D (305 mm x 508 mm) pans.
❒ Kit #4: Three (3) chrome shelves
23
1
/
"L x 27
3
/
"D (597 mm x 705 mm). Four
2
4
(4) shelf supports included per shelf. Shelves
adjustable on 6" (153 mm) increments.
❒ Additional kit option components available
individually.
3
51
/
"
8
(1305 mm)
34
5
/
"
8
(880 mm)
17
23
/
32
(598 mm)
PLAN VIEW
Elevation
Right
Plan
TFQY54E
TFQY54S
TFQY54P
5
58
/
"
32
(1478 mm)
"
3D
TFQY543
