iPro SERIES
(v.3.5)

Advertisement

loading

Related Manuals for Emerson iPro Series

Summary of Contents for Emerson iPro Series

  • Page 1 SERIES (v.3.5)
  • Page 2 IPRO 4 DIN (IPG100D – IPG200D – IPC100E RANGES) 4.5.1 Description of the connections ............................38 4.5.2 Description of the inputs and outputs ..........................38 4.5.3 Technical specifications ..............................39 4.5.3.1 Analogue inputs ............................... 39 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 2/96...
  • Page 3 Digital inputs ................................70 4.11.3.3 Analogue outputs ..............................70 4.11.3.4 Digital outputs ................................71 4.11.3.5 Wiring diagrams ............................... 71 4.11.3.6 Mechanical specifications ............................72 4.11.3.7 Electrical specifications ............................72 4.11.3.8 Plastic container ..............................72 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 3/96...
  • Page 4 Analogue output for relays (coil power supply 12Vdc) ....................... 91 CONNECTION OF THE DIGITAL OUTPUTS ELECTRONIC EXPANSION VALVE DRIVER IPG800 SERIES 7.7.1 GENERAL RULES ................................91 7.7.2 ELECTRICAL CONNECTIONS ............................92 CANBUS CONNECTION RS485 SLAVE CONNECTIONS 7.10 RS485 MASTER CONNECTION 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 4/96...
  • Page 5 Under no circumstances is the device to be opened - the user does not require the internal components. Please contact qualified service personnel for any assistance. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 5/96...
  • Page 6 13 August 2005 and must be disposed of as separated waste.  Should the product be disposed of incorrectly, sanctions may be applied as stipulated in applicable local regulations regarding waste disposal. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 6/96...
  • Page 7 Internal web server with the Dixell website as default with the option of downloading a customised website for reading and writing variables with synoptic creation (via HTML). • Ethernet port. • USB port. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 7/96...
  • Page 8 The LED display (only for the 4 DIN versions) has the following features: • Configurable digits and icons • 6 fully programmable keys RELEVANT DATA Operating temperature: -10 to +60°C (14 to 140°F) Relative humidity: 20 to 85% 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 8/96...
  • Page 9 • IPRO.LINK IPL500D (connectivity module) • EXPANSION IPX106D (6 relay, disconnectable connectors + molex connectors) IPX206D (6 relay, spring connectors + screw connectors) IPX306D (6 relay, disconnectable connectors + screw connectors) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 9/96...
  • Page 10 IPRO.GENIUS AND IPRO.CHILL (IPG100D – IPC100D RANGES) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 10/96...
  • Page 11 Yellow status LEDs (LED1) and red LED (ALARM) See relative paragraph Connector for NC contact to reset an external modem RS232 connector for an external GSM modem connection (SIEMENS TC35) Connector for the internal analogue modem 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 11/96...
  • Page 12 Opto-insulated digital input 16 (potential free contact) DI17 Opto-insulated digital input 17 (potential free contact) DI18 Opto-insulated digital input 18 (potential free contact) DI19 Opto-insulated digital input 19 (potential free contact) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 12/96...
  • Page 13 Relay 11 normally open contact RL11 Common relays 11 RL12 Relay 12 normally open contact RL12 Common relays 12 RL13 Common relays 13 RL14 Relay 14 normally open contact RL14 Common relays 14 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 13/96...
  • Page 14 The electrical devices controlled by these analogue outputs must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the outputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 14/96...
  • Page 15 Do not use different voltages for the various groups of relays nor within each group. 4.1.3.6 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 15/96...
  • Page 16 Plastic container Mount: On a DIN rail (EN 50022, DIN 43880) Fastened with screws via the removable plastic flaps. Material: PC-ABS Thermoplastic Self-extinguishing: V0 (UL94) Comparative Tracking Index (CTI): 300V Colour: Black 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 16/96...
  • Page 17 Control to classify with the definitions 2.5.1 e 2.5.2 mentioned in the section 2.5 of the general requirements EN60730-1 (2.5.1 = integrated control, 2.5.2 = incorporated control). Electrical safety: • EN60730-1 Electromagnetic compatibility: • EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 17/96...
  • Page 18 RS485 Master connector Rx and Tx LED to indicate that communication is active Line terminal (Term) Digital relay outputs (for digital outputs with potential free contacts) 3 NO relays, 1 common 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 18/96...
  • Page 19 Opto-insulated analogue output 1 0 - 10V Out2 Opto-insulated analogue output 2 0 - 10V Out3 Opto-insulated analogue output 3 0 - 10V Out4 Opto-insulated analogue output 4 0 - 10V GND(-) Common opto-insulated analogue output 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 19/96...
  • Page 20 Relay 12 normally open contact RL13 Relay 13 normally open contact Common relays 11, 12, 13, 14 and 15 (MAX 6A) RL14 Relay 14 normally open contact RL15 Relay 15 normally open contact 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 20/96...
  • Page 21 2 configurable outputs 0-10Vdc, 4-20mA (Out5 and Out6) Maximum load: 40mA (Out1 - Out4) 20mA (Out5 and Out6) max with configured outputs 0-10Vdc 400Ω max with configured outputs 4-20Ma 22Ω per live analogue output 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 21/96...
  • Page 22 Do not use different voltages for the various groups of relays nor within each group. 4.2.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 22/96...
  • Page 23 Control to classify with the definitions 2.5.1 e 2.5.2 mentioned in the section 2.5 of the general requirements EN60730-1 (2.5.1 = integrated control, 2.5.2 = incorporated control). Electrical safety: • EN60730-1 Electromagnetic compatibility: • EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 23/96...
  • Page 24 IPRO.GENIUS AND IPRO.CHILL (IPG300D – IPC300D RANGES) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 24/96...
  • Page 25 Yellow status LEDs (LED1) and red LED (ALARM) See relative paragraph Optoinsulated analogue outputs 24Vac/dc power supply Connector for NC contact to reset an external modem RS232 connector for an external GSM modem connection (SIEMENS TC35) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 25/96...
  • Page 26 Opto-insulated digital input 12 DI13 Opto-insulated digital input 13 DI14 Opto-insulated digital input 14 DI15 Opto-insulated digital input 15 DI16 Opto-insulated digital input 16 DI17 Opto-insulated digital input 17 DI18 Opto-insulated digital input 18 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 26/96...
  • Page 27 NC relay output to reset an external modem (24Vac/dc) Supply Power supply for opto-insulated analogue outputs at 24Vac or 24Vdc(+) Supply Power supply for opto-insulated analogue outputs at 24Vac or 24Vdc(-) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 27/96...
  • Page 28 The electrical devices controlled by these analogue outputs must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the outputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 28/96...
  • Page 29 Do not use different voltages for the various groups of relays nor within each group. 4.3.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 29/96...
  • Page 30 Control to classify with the definitions 2.5.1 e 2.5.2 mentioned in the section 2.5 of the general requirements EN60730-1 (2.5.1 = integrated control, 2.5.2 = incorporated control). Electrical safety: • EN60730-1 Electromagnetic compatibility: • EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 30/96...
  • Page 31 - RS485 MASTER (ModBus RTU) RS485 connector to connect the device with a monitoring system - RS485 SLAVE (ModBus RTU) Ground connection for RS485 and Serial Port LED1= yellow status led 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 31/96...
  • Page 32 Not Opto-insulated digital input 3 potential free contact DI 2 Not Opto-insulated digital input 2 potential free contact DI 1 Not Opto-insulated digital input 1 potential free contact Common not opto-insulated digital inputs 1 to 3 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 32/96...
  • Page 33 (+12V or +5V) must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the inputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 33/96...
  • Page 34 Verify the capacity of the output used. There is double insulation between the digital outputs and the low voltage of the rest of the circuit. Do not use different voltages for the various groups of relays or within each group. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 34/96...
  • Page 35 Molex connectors with low voltage wiring SELECOM/CIVILUX connectors for digital outputs (250Vac, 6A max) Microprocessor: AT91RM9200 32-bit 200Mhz Permanent FLASH memory: 128MB, in 8-bit RAM: 32MB or 64MB, in 16-bit Internal clock: standard 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 35/96...
  • Page 36 Control to classify with the definitions 2.5.1 e 2.5.2 mentioned in the section 2.5 of the general requirements EN60730-1 (2.5.1 = integrated control, 2.5.2 = incorporated control). Electrical safety: • EN60730-1 Electromagnetic compatibility: • EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 36/96...
  • Page 37 IPRO 4 DIN (IPG100D – IPG200D – IPC100E RANGES) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 37/96...
  • Page 38 Digital input 3 24Vac/dc Digital input 4 24Vac/dc Digital input 5 24Vac/dc Digital input 6 24Vac/dc Digital input 7 24Vac/dc Digital input 8 24Vac/dc Digital input 9 24Vac/dc DI10 Digital input 10 24Vac/dc 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 38/96...
  • Page 39 Use another transformer (do not use the same secondary of the controller's power) in order to prevent the inputs from malfunctioning or being damaged. Note: the digital inputs as dry contacts are available on request. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 39/96...
  • Page 40 Do not use different voltages for the various groups of relays nor within each group. 4.5.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 40/96...
  • Page 41 This adapter must be used in the processing environment for the application download in the ipro. This adapter is not set up for fixed or continuous connection. If the adapter should be kept connected continuously, the room temperature must not exceed 50°C. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 41/96...
  • Page 42 USB port for downloads (BIOS, ISaGRAF® application, maps of parameters, remote display applications, network configuration, website) and uploads (log files) Ethernet port for TCP/IP connections SIM CARD slot (only for version with GPRS modem) Connection for GPRS modem antenna 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 42/96...
  • Page 43 LAN or RS485 MASTER Connection (-) – depend on the model Serial Port LAN or RS485 MASTER Connection (+) – depend on the model CANBUS connection (-) CANBUS connection (+) 4.6.3 Technical specifications 4.6.3.1 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 43/96...
  • Page 44 On a DIN rail (EN 50022, DIN 43880) Fastened with screws via the removable plastic flaps. Material: PC-ABS Thermoplastic Self-extinguishing: V0 (UL94) Comparative Tracking Index (CTI): 300V Colour: Black or White, depending on the model 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 44/96...
  • Page 45 Rx and Tx LED to indicate that communication is active Line terminal (Term) LAN serial port connector Dip-switch to set the address of the device. Green LED to indicate the presence of power Red status LED (ALARM) See relative paragraph 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 45/96...
  • Page 46 Common relays 5, 6 and 3 (MAX 6A) Common relays 1, 2 and 4 (MAX 6A) Relay 1 normally open contact Relay 2 normally open contact Relay 3 normally open contact 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 46/96...
  • Page 47 Verify the capacity of the output used. There is double insulation between the digital outputs and the low voltage of the rest of the circuit. The common relays of the outputs are separate and split into groups. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 47/96...
  • Page 48 SELECOM/CIVILUX connectors for digital outputs (250Vac, 6A max) or with a different order code: Phoenix quick coupling connectors for low voltage STELVIO 90° screw connectors for digital outputs (250Vac, 6A max) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 48/96...
  • Page 49 The address of the device is set via a dip-switch and numbering is binary as shown in the table below: Not used If the address is changed while the device is switched on, to confirm the new address remember to switch off and switch on again the device. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 49/96...
  • Page 50 LAN serial port connector Dip-switch to set the address of the device (for CANBUS and LAN communication). Green LED to indicate the presence of the power supply Red status LED (ALARM) See relative paragraph 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 50/96...
  • Page 51 Relay 5 normally open contact (please check the electrical characteristics of the relay used ) Not used Relay 6 normally closed contact Relay 6 normally open contact Common relay 6 (MAX 8A) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 51/96...
  • Page 52 SSR relays with normally open contact 1A(12 - 250Vac): - only in AC load - minimum current is 50mA (equivalent to 12W - 250Vac) - internal impedance 300KΩ (current 0.2mA at 250Vac with an open contact) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 52/96...
  • Page 53 The common relays of the outputs are separate and split into groups. 4.8.3.5 Wiring diagrams 4.8.3.6 Mechanical specifications 4 DIN module 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 53/96...
  • Page 54 The address of the device is set via a dip-switch and numbering is binary as shown in the table below: Not used If the address is changed while the device is switched on, to confirm the new address remember to switch off and switch on again the device. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 54/96...
  • Page 55 Digital relay outputs 3 NO relays + 1 changeover relay, 1 common Digital relay outputs 6 NO relays, 2 common Digital relay outputs 3 NO relays + 2 changeover relays, 3 common 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 55/96...
  • Page 56 Opto-insulated digital input 1 Opto-insulated digital input 2 Opto-insulated digital input 3 Opto-insulated digital input 4 Opto-insulated digital input 5 Opto-insulated digital input 6 Opto-insulated digital input 7 Opto-insulated digital input 8 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 56/96...
  • Page 57 SSR relay 18 normally open contact RL17 SSR relay 17 normally open contact Common relays 16, 17, 18 and 19 RL19 SSR relay 19 normally open contact RL20 Relay 20 normally open contact 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 57/96...
  • Page 58 The electrical devices controlled by these analogue outputs must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the outputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 58/96...
  • Page 59 Do not use different voltages for the various groups of relays nor within each group. 4.9.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 59/96...
  • Page 60 The address of the device is set via a dip-switch and numbering is binary as shown in the table below: Not used If the address is changed while the device is switched on, to confirm the new address remember to switch off and switch on again the device. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 60/96...
  • Page 61 5 NO relays, 1 common and 1 potential free (Neutral) The position 93 is not connected Digital outputs with SSR relays 4 NO relays, 1 common The position 109 is not connected 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 61/96...
  • Page 62 Opto-insulated digital input 2 Opto-insulated digital input 3 Opto-insulated digital input 4 Opto-insulated digital input 5 Opto-insulated digital input 6 Opto-insulated digital input 7 Opto-insulated digital input 8 Opto-insulated digital input 9 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 62/96...
  • Page 63 Relay 21 normally open contact RL22 Relay 22 normally open contact RL23 Relay 23 normally open contact RL16 SSR relay 16 normally open contact RL17 SSR relay 17 normally open contact 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 63/96...
  • Page 64 The electrical devices controlled by these analogue outputs must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the outputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 64/96...
  • Page 65 Do not use different voltages for the various groups of relays nor within each group. 4.10.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 65/96...
  • Page 66 The address of the device is set via a dip-switch and numbering is binary as shown in the table below: Not used If the address is changed while the device is switched on, to confirm the new address remember to switch off and switch on again the device. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 66/96...
  • Page 67 4 NO relays, 2 common Digital relay outputs 3 NO relays, 1 common + 3 NO relays, 1 common Digital relay outputs 3 NO relays, 2 common + 2 NO relays, 3 common 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 67/96...
  • Page 68 Reference “-“ for opto-insulated digital inputs 1 to 20 (if inputs 24Vac or 24Vdc) DI11 Opto-insulated digital input 11 DI12 Opto-insulated digital input 12 DI13 Opto-insulated digital input 13 DI14 Opto-insulated digital input 14 DI15 Opto-insulated digital input 15 DI16 Opto-insulated digital input 16 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 68/96...
  • Page 69 CAN Bus CAN Bus connection (+), not open CAN Bus CAN Bus connection (-), not open CAN Bus CAN Bus connection (insulated gnd), not open LAN Connection (+) LAN Connection (-) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 69/96...
  • Page 70 The electrical devices controlled by these analogue outputs must be powered separately with another transformer (do not use the same secondary of the controller's power) in order to prevent the outputs from malfunctioning or being damaged. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 70/96...
  • Page 71 Do not use different voltages for the various groups of relays nor within each group. 4.11.3.5 Wiring diagrams 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 71/96...
  • Page 72 The address of the device is set via a dip-switch and numbering is binary as shown in the table below: Not used If the address is changed while the device is switched on, to confirm the new address remember to switch off and switch on again the device. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 72/96...
  • Page 73  Up to 5 different languages for each application  Panel or wall mounted (depending on the model)  Dedicated power supply and communication via a 3-way cable from the programmable controller 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 73/96...
  • Page 74 Now download the application from Visoprog Note: This procedure it is possible only if the version of the BIOS of the Visograph is the version 1.6 (23/02/2011), 8.1 (04/03/2011) or superior. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 74/96...
  • Page 75 5.1.4 Dimensions 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 75/96...
  • Page 76 - if on, the system is malfunctioning. Therefore, verify the CANBus or LAN connection or the configuration/connection of the analogue inputs. - if it flashes, the device is transferring data. - if it flashes, the device is receiving data. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 76/96...
  • Page 77  Always separate the power of the controller from that of all the other electrical devices present in the system.  The secondary of the supply transformer of the devices must never be connected to the earth. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 77/96...
  • Page 78 - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. - if used as a digital input (potential free - not live), use the same connection configuration of the sensors. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 78/96...
  • Page 79 Two sensors must be connected through one of the inputs (from Pb6 to Pb7) and the power supply (+12V) as shown in the diagram below. Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 79/96...
  • Page 80 Two sensors must be connected through one of the inputs (from Pb6 to Pb7) and the power supply (+5V/GND) as shown in the diagram below. Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 80/96...
  • Page 81 Two sensors must be connected through one of the inputs (from Pb6 to Pb7) and the power supply (+12V/GND) as shown in the diagram below. Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 81/96...
  • Page 82 - the power supply of the sensor must be separate from that of the programmable controller - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 82/96...
  • Page 83 - the power supply of the sensor must be separate from that of the programmable controller - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 83/96...
  • Page 84 IPG200, IPX125D, IPX115D, IPX215D, IPX215D VERSIONS IPG108D, IPG208D VERSION (special version not standard version) Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 84/96...
  • Page 85 IPG200D, IPX115D, IPX125D, IPX215D, IPX225D VERSIONS IPG108D, IPG208D, IPG108E, IPG208E VERSION (standard version) Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 85/96...
  • Page 86 On request (different Part Number) it is possible to have the Opto-Insulated digital input but with power supply 24Vac (in this case no potential free contacts). Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 86/96...
  • Page 87 0 - 10V, 4 - 20mA Analogue output for condensation control IPG-IPC VERSION IPG108, IPG208 VERSION Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 87/96...
  • Page 88 PWM analogue output for condensation control IPG100 VERSIONS (not available for IPG200 and 4 DIN) Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 88/96...
  • Page 89 0 - 10V, 4 - 20mA Proportional analogue output for servomotors/actuators IPG-IPC IPG 4 DIN Recommendations: - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 89/96...
  • Page 90 - the power supply of the device must be separate from that of the programmable controller - follow the diagram of the device used, for the numbering. - the configuration is determined by the application. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 90/96...
  • Page 91 Before using the actuator, please, read the technical manual of the valve supplied by the manufacturer and check the maximum current used to drive the valve in order to verify that they are lower than that indicated here above. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 91/96...
  • Page 92 EX3 Emerson Emerson V4 VALVE ORANGE ORANGE WHITE WHITE V2 VALVE BROWN ORANGE V3 VALVE YELLOW YELLOW BLACK YELLOW V1 VALVE BLACK BLACK BLUE BLUE +12V VALVE GRAY GRAY GRAY BROWN (Common) 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 92/96...
  • Page 93 CANBUS CONNECTION Recommendations: - follow the diagram of the device used, for the numbering. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 93/96...
  • Page 94 RS485 SLAVE CONNECTIONS Recommendations: - follow the diagram of the device used, for the numbering. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 94/96...
  • Page 95 7.10 RS485 MASTER CONNECTION Recommendations: - follow the diagram of the device used, for the numbering. 1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 95/96...

This manual is also suitable for:

Ipg108dIpg108e
