Instructions for use
GB
English,1
XWDA 75128
This symbol reminds you to read this
!
instruction manual.
Contents
Installation, 2-3-4-5
Cutting off the water or electricity supply
Cleaning the Washer-dryerCleaning the detergent dispen-
ser drawer
Wash cycles, 10
Push&Wash+Dry
Personalisation, 11
Detergent dispenser drawer
Troubleshooting, 13-14
tion, 15
Washer-dryer
GB
1
Advertisement
Table of Contents
Related Manuals for Indesit XWDA 75128
Summary of Contents for Indesit XWDA 75128
-
Page 1: Table Of Contents
Cleaning the Washer-dryerCleaning the detergent dispen- ser drawer Caring for the door and drum of your appliance Cleaning the pump Checking the water inlet hose XWDA 75128 Precautions and tips, 7 General safety Load balancing system Disposal Description of the Washer-dryer and... -
Page 2: Installation
Installation ! This instruction manual should be kept in a Levelling the machine correctly will provide safe place for future reference. If the Washer- it with stability, help to avoid vibrations and dryer is sold, transferred or moved, make sure excessive noise and prevent it from shifting that the instruction manual remains with the while it is operating. - Page 3 Connecting the drain hose • the supply voltage is included within the values indicated on the Technical Data Plate fixed on Connect the drain the machine. hose, without bending it, to a draining duct or • the socket is compatible with the washing a wall drain situated machine’s plug.
-
Page 4: The First Wash Cycle
As the colours of the wires in the lead may not ! The power supply cable must only be repla- correspond with the coloured markings iden- ced by an authorised serviceman. tifying the terminals in your plug, proceed as follows: Warning! The company denies all liability if and Connect Green &... -
Page 5: Technical Data
Technical data Model XWDA 75128 width 59.5 cm Dimensions height 85 cm depth 54 cm from 1 to 7 kg for wash programme Capacity from 1 to 5 kg for the drying programme Electrical please refer to the technical connections... -
Page 6: Care And Maintenance
Care and maintenance Cutting off the water and electricity Caring for the door and drum of your supplies appliance • Turn off the water tap after every wash cycle. • Always leave the porthole door ajar in order This will limit wear on the hydraulic system to prevent unpleasant odours from forming. -
Page 7: Precautions And Tips
Precautions and tips • Do not use the appliance to dry foam rubber ! This washer-dryer was designed and constructed in or similar elastomers. accordance with international safety regulations. The fol- • Make sure that the water tap is turned on during the drying lowing information is provided for safety reasons and must cycles. -
Page 8: Description Of The Washer-Dryer And Starting A Wash Cycle
Description of the Washer-dryer and starting a wash cycle Control panel WASH CYCLE PROGRESS OPTION indicator lights buttons with indicator lights DOOR START/PAUSE ON/OFF LOCKED button with indicator button light indicator light LEVEL-BASED WASH CYCLE DRYING TEMPERATURE Detergent dispenser drawer knob button button... -
Page 9: Indicator Lights
Indicator lights Door locked indicator light When the indicator light is on, the porthole door is locked The indicator lights provide important information. to prevent it from being opened; make sure the indicator This is what they can tell you: light is off before opening the door (wait approximately 3 minutes). -
Page 10: Wash Cycles
Wash cycles Push&Wash+Dry This function makes it possible to start an automatic wash and drying cycle either when the machine is off without having to press the ON/OFF button in advance, or after switching on the machine without having activated any button and/or selector (otherwise the Push&Wash+Dry function will be deactivated). -
Page 11: Personalisation
Personalisation Setting the temperature Press the TEMPERATURE button to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash . The Washer-dryer will automatically prevent you from selec- ting a temperature which is higher than the maximum value set for each wash cycle. Setting the drying cycle Two different types of drying are possible: time-based and Table of drying times (guideline values) -
Page 12: Detergents And Laundry
Detergents and laundry Detergent dispenser drawer Anti-odour: use programme 3 for washing garments with bad odours (e.g. smoke, sweat, fried food). The program- Successful washing results also depend on the correct me is designed to remove bad odours while preserving the dose of detergent: adding too much detergent will not fabric fibres. -
Page 13: Troubleshooting
Troubleshooting Your Washer-dryer could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. • The appliance is not plugged into the socket fully, or not enough to make contact. •... - Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
-
Page 15: Product Guarantee And Repair Information
Product Guarantee and Repair Information Guarantee Recycling and Disposal Information As part of Indesit’s continued commitment to 12 Months Parts and Labour Guarantee helping the environment, Indesit reserves the right Your appliance has the benefit of our manufacturer’s to use quality, recycled components to keep down guarantee, which covers the cost of breakdown customer costs and minimise material wastage. - Page 16 195132354.00 04/2015 - Xerox Fabriano Indesit Company Spa Viale Aristide Merloni, 47 60044 Fabriano (AN) Italy www.indesit.co.uk...
